Used Straightening Press - Horizontal for sale (19,094)

Condition: like new (used), Year of construction: 2022, machine/vehicle number: DF0147, Pressure: 150 t Total power requirement: 20 kW Machine weight approx.: 11.5 t space requirement approx.: 8800 x 1800 x 2200 mm pressure setting infinitely variable via rotary control : 15-150 t cylinder diameter : 100 mm pressing speed (infinitely variable via joystick) : 0-9,9 mm/s servo motor : 2 kW cooling unit : 1 kW Giodpfx Aasfxygwogou Oil tank (under press table): 350 l Oil cooling (electric): 1 kW (max) Profile straightening press 150 T with two pressure cylinders. The straightening machine is prepared for the particular type of material by interchangeable rounded spacer elements. The replacement of the 10 inserts is done manually by simply pushing them into the holding grooves. The scope of delivery includes basic equipment for one profile. The program for the respective profile is then called up on the monitor. The monitor shows the ideal line and, in addition, an ascending and descending millimeter scale with 0.5 mm lines. The profile to be straightened is now placed on the left side of the table, pushed against a holder and clamped with a quick-clamping device. Both the holder and the quick-clamping device are mounted on a clamping plate for quick adjustment. This clamping plate moves on a linear guide from left to right and vice versa. Transport is by a chain drive and a servo motor. The movement is triggered by a joystick on the control panel. After the profile has been clamped, the operator moves the clamping platen into the press using the joystick. The travel speed is up to 100 mm per second, but can be continuously adjusted down to 10 mm per second. To do this, it is sufficient to pull the lever of the control system slightly less. A high-resolution camera now shows the profile in the press. The operator sees exactly the deviation from the ideal line. Depending on the need, he now pushes or pulls the profile to the desired accuracy. He then continues to move slowly through the press, seeing in detail on the monitor whether the profile is now straight. Depending on the need, he can now move the profile forwards or backwards and readjust it. After the profile has been straightened, it moves out of the press on the right and can be removed. If desired, the clamping platen now moves back to the loading position on the left or it is now loaded from the right to save time. The press may only be operated under the following conditions: Perm. ambient temperature: 5-60 °C Permissible relative humidity: at 20°C - 90%, at 40°C - 50% Height of the installation site NN: + 1000 m Perm. fluctuations E-mains: +/- 10%.

Condition: used, Technical details: Giedpfx Aasu Nfrpogou pressure: 200 t stroke: ca. 200mm mm table surface area: L:1200xH:450 mm jaw width: 1000x200 mm total power requirement: 18 kW weight of the machine ca.: 15 t dimension machine xH: 4,5x1,5x2,2 m Beam - Straight Bending Machine - electric box (LxWxH:0,85x0,8x2,7m) - chuck intake: LxW 1200x220mm - chuck adjustment 200mm moveable - opening width of chucks 300mm - manual control accessories: - div. limit stops, tools, try square and marking gauges i.D. *

Condition: used, Year of construction: 2008, Technical details: Gjdpsw Ng D Tjfx Aagjiu pressure: 6 t stroke: 1020 mm total power requirement: 3,5 kW Can only adjust between tips *

Condition: used, Hydraulic Horizontal Straightening Press, Horizontal Press STENHOJ Type 40 Horizontal hydraulic press for straightening work on steel beams or welded structures Serial no. 42615 Year of manufacture: 1984 Refurbished in 2025 Pressing force: 40 tons Ram stroke: 300 mm Piston rod diameter: 80 mm Working height: 780 mm (floor to center of piston rod) Table size without pressure pads: approx. 1000 x 290 mm Gisdpfx Aasydqd Hsgju Installation dimension, ram + press block to counter bearing: 260 mm (with pressure pads on ram and counter bearing) Installation dimension, ram without press block to counter bearing: 440 mm (without pressure pads on counter bearing) Height of the two adjustable pressure pads: 130 mm Pressure pad width: 220 mm Advance speed: 10 mm/s Return speed: 20 mm/s Hydraulic tank capacity: approx. 60 liters Motor power: 3 kW Power supply: 400 Volt, 50 Hz - Cylinder stroke operated manually via an actuation lever, sensitive control via mechanical control valve - Pressing force readable via pressure gauge - Ram stroke position with actual value display, digitally readable, ideal for precise repeatability of pressure points during straightening - 2 adjustable counter bearings via threaded spindle (centric parallel adjustment from 290 to 890 mm) - Straightening tools with rounded pressure faces - Infeed rollers for material support, centrally height-adjustable via handwheel (roller width = 250 mm) Required space (L x W x H): 170 x 140 x 100 cm Weight: 1250 kg In excellent condition

Condition: good (used), WF HHP 625 – Horizontal Press Year: 2006 Manufacturer: WF Maschinenbau u. Blechformtechnik GmbH & Co KG Germany Machine Model: WF HHP 625 Machine Type: Horizontal Hydraulic Press Technical Specifications: Maximum workpiece diameter: 625 mm Godpfxjzb Il Ns Aageiu Minimum workpiece diameter: 350 mm Maximum workpiece length: 325 mm Maximum press stroke: 750 mm Maximum press force: 2000 kN Siemens 840D control system Parker hydraulic components Hydraulic oil tank capacity: approx. 800 liters Required cooling water for hydraulic system: approx. 1000 l/h Cooling water inlet temperature: max. 25°C Air supply connection: 6 bar / ½” Ambient operating temperature: 10°C – 40°C Hydraulic Equipment: Main Hydraulic Motor: Manufacturer: Blumenbecker Type: 14BG 207-4AA 200L Power: 30 kW Voltage: 400V / 50Hz Speed: 1465 rpm Secondary Hydraulic Motor: Manufacturer: Blumenbecker Type: 7AA 132 S-4 Power: 5.5 kW Voltage: 400V / 50Hz Speed: 1450 rpm Hydraulic Pump: Manufacturer: Parker Type: PV080R1K1T1NSLD Internal Gear Pump: Manufacturer: Denison / Parker Type: T6CMYR20-1-R_00C1 Flow rate: 93 l/min at 1450 rpm Central Lubrication Unit: Manufacturer: Vogel Type: MFE5-BW7+299 Oil Spray Unit: Manufacturer: Vogel Type: MFE5-BW7+299 Machine Dimensions (Transport Position): Width: approx. 2600 mm Length: approx. 5800 mm Height: approx. 2400 mm Weight: approx. 20,000 kg Additional Information: Hydraulic horizontal press with automated loading/unloading preparation Robot loading interface prepared (robot not included) Transport and lifting drawings available Original manuals and technical documentation included

Condition: new, The scope of delivery includes: 1x Top tool, new Tool system: UKB system Trumpf / Wila / LVD with Simple Clamp Type: 15320-500 (15320X) Angle: 28° Radius: R 1.0 mm Length: 500 mm Width: 24 mm Height: 120 mm Load capacity: 800 kN/m max. Gedezcuqbjpfx Aageiu Material: 42 CrMo4 Weight: ≈ 10 kg Internal reference: DE-KW23-26-03 Explanation: The tool is used in bending presses (also known as die-bending presses) for industrial sheet metal processing. The standardized tool holder, "Simple Clamp safety button," allows the operator to install and remove the segment vertically at any desired point of the press clamping mechanism. Note: This tool is being sold as part of a customer return (purchase date: April 2026) and is therefore offered at a reduced price. Your contacts at our company: Mr. Andre Evering Mr. Mario Klöver Mr. Falk Deutsch General information about the item: This item is offered for pickup only. Any additional transport or shipping of this item will incur additional costs, which can be requested separately depending on the delivery location and scope of delivery.

Condition: used, Year of construction: 1965, pressure 400 t throat 1140 mm stroke 600 mm table surface area 2000x1000 mm Plate 4000x1000x300 mm ram head dimension 2000x1040 mm Cylinder 300 mm Giedpfjyt R Dlex Aagju Daylight 650 dimensions of the machine ca. 3,9x4x4,2 m Machine has been overhauled. Maximum distance from ram to clamping plate: 1250 mm The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: good (used), Year of construction: 2011, pressing force: 160 t, Press force: 160 t Minimum counter bearing distance: 550 Maximum counter bearing distance: 1550 Maximum workpiece width: 400 Cylinder stroke: 450 mm Clearance – horizontal: 400 mm Total power requirement: 18.5 kW Machine weight approx.: 13.5 t Space requirement approx.: 3.65 x 1.7 x 1.62 m Additional information: Hydraulic, horizontally acting straightening and bending machine Type DZ 160 Press force: 1600 kN Adjustable from 0-1600 kN Power consumption: 18.5 kW Hydraulic pressure: 245 bar Godpfxjzcc T De Aagsiu Minimum counter bearing distance: 550 mm Maximum counter bearing distance: 1,550 mm 2 movable straightening beams for applying pressure and counter pressure Maximum workpiece width: 400 mm Mains connection: 400/230 V, 50 Hz N/PE Dimensions (L x W x H): 3,650 x 1,700 x 1,620 mm Machine weight: 13,500 kg Hydraulic unit (L x W x H): 1,700 x 800 x 1,400 mm Control cabinet: 800 x 500 x 1,800 mm Kunkel hydraulic straightening and cambering presses are used in heavy steel construction to pre-tension or straighten beams and profiles. Especially in modern steel high-rise construction, it is essential, for aesthetic reasons, to give structural elements a camber – a slight curvature – so that, under load, the impression of straight, horizontal contour lines is maintained. Kunkel machines offer the highest precision and economic efficiency. With this straightening press, the workpiece can be machined in both directions in a straightening position. All straightening blocks are adjustable. In addition, the machine has a mobile control panel.

Condition: good (used), Clamping plate, plate field, welding table, welding table, clamping plate, scribing and measuring plate, measuring table, straightening plate, short-stroke heavy-duty cylinder, hydraulic cylinder, support cylinder, hydraulic ram, pressure ram, hydraulic press, bending machine, straightening machine, profile straightening system, strip straightening machine, strip straightening device, shaft straightening system, combined bending machine-straightening press, profile bending machine, bending machine bending/straightening press -Mounting plate: Mounting plate with straightening press -Length: 3260 mm -Width: 1380 mm -Piston diameter: Ø 63 mm -Stroke: 200 mm -Pressure force: t -Overall dimensions: 3260/1380/H1940 mm Giedpezbhqxjfx Aagou -Weight: 2820 kg

Condition: good (used), functionality: fully functional, pressing force: 160 t, stroke length: 500 mm, operating speed: 30 mm/s, reverse speed: 40 mm/s, table width: 850 mm, table height: 780 mm, throat depth: 400 mm, oil tank capacity: 210 l, total length: 3,370 mm, total width: 1,730 mm, total height: 1,480 mm, overall weight: 6,500 kg, installation height: 400 mm, pressing speed: 3 mm/s, Equipment: documentation/manual, Hydraulic horizontal box press PYXWM-160. Manufactured by WMW VEB Dessau - 1978. The machine has been overhauled. Ready to work. Max. pressing force 160 tons. Piston stroke 500 mm. Piston speed: Forward 30 mm/sec Pressing 2.5 mm/sec Backward 40 mm/sec Height from base to center of piston 260 mm. Machine frame height 780 mm. Gisdpfjwndnujx Aagju Base length from support tool 600 mm. Support tool length 520 mm. Max. clamping width 1730 mm. Working clamping width 400 mm. Support tool height 400 mm. Support tool spacing min-max 240-1100 mm. Dimensions: Length 3370 mm. Width 1730 mm. Height 1480 mm. Frame width 700 mm. Engine power 11 kW. Oil tank capacity 210 liters.

Condition: as good as new (ex-display), Year of construction: 2024, tool height: 130 mm, pressing force: 12 t, bending force (max.): 12 t, Stierli bender 120HE horizontal press Horizontal bending machine, manual control with angle fine adjustment. Very universal, for bending flat steel, sheet, round steel, profiles, tubes angular or round, forming tools and easy fixing of own tools or special tools, + straightening as straightening press. Bending pressure 12 tons tool height 130 mm Stroke 0-170 mm stepless Bending capacity 130x12 mm S235 Gjdpfx Aajflc R Degeiu Straightening performance light straightening work Pipe bending 3/8"-11/2" Demonstration machine year 2024 incl. hand and foot pedal Machine as good as new

Condition: as good as new (ex-display), Year of construction: 2024, functionality: fully functional, tool height: 200 mm, operating speed: 10 mm/s, working height: 200 mm, bending angle (max.): 180 °, sheet thickness steel (max.): 20 mm, sheet thickness copper (max.): 20 mm, lifting speed: 10 mm/s, bending force (max.): 42 t, Stierli bender 420HE Horizontal bending machine, with manual control and angle fine adjustment system Very universal, for bending flat steel, sheet, round steel, profiles, tubes angular or round, forming tools and easy fixing of own tools or special tools, + straightening as straightening press. Bending pressure 42 tons Tool height 200 mm Stroke 0-300 mm stepless Bending capacity 200x24 mm S235 Straightening power for HEA180 Giedpfx Ajflc Spoagju Bending and straightening program via selector switch Demonstration machine year 2024 incl. hand and foot pedal Machine as good as new

Condition: as good as new (ex-display), Year of construction: 2024, tool height: 300 mm, stroke length: 350 mm, bending angle (max.): 180 °, pressing force: 82 t, sheet thickness steel (max.): 30 mm, sheet thickness copper (max.): 30 mm, lifting speed: 10 mm/s, bending force (max.): 82 t, Stierli bender 820HE Horizontal bending and straightening machine, with manual control and stroke fine adjustment system STRAIGHTENING with this horizontal press: Fast and precise straightening for welding parts, profiles, beams, sheets, pipes, flat steel, etc.... BENDING with this horizontalpress: Very universal, for bending flat steel, sheet, round steel, profiles, tubes angular or round, forming tools and easy fixing of own tools or special tools, + straightening as straightening press. Bending pressure 82 tons Tool height 300 mm Stroke 0-300 mm stepless Bending capacity 300x20mm (up to 300x30 with large V-block) S235 Godjgqfmnopfx Aageiu Straightening power for HEA260 Bending and straightening program via selector switch Demonstration machine year 2024 incl. hand and foot pedal Machine as good as new

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, Equipment: documentation/manual, HSM HL 7009 Re / Li horizontal baler. The machine is in very good condition and regularly serviced by an authorized service center. This baler is designed for larger waste disposal projects in retail outlets and small and medium-sized central warehouses. Bales from the HL 7009 model have a cross-section of 1100 x 1100 mm and, with a bale length of 1200 mm, can weigh up to 600 kg, ensuring optimal utilization of the truck's payload. Pressing force: 700 kN Specific pressing force: 58 N/cm² Drive power: 10.5 kW Gijdpozck Uiofx Aagsu Voltage / frequency: 400 V / 50 Hz Idle capacity (theor.): 42.97 m³/h Loading opening width x length: 890 x 1020 mm Bale width x height x length: 1100 x 1100 x 1200 mm Total length x width x height: 5366 x 2525 x 2559 mm Bale weight: 600 kg

Condition: used, functionality: fully functional, Hydraulic straightening press Manufacturer: G + K Year of manufacture: 1992 Max. pressing force: 130 t Table size (bottom): 800 x 500 mm with T-slots Table size (top): 800 x 500 mm with T-slots Installation dimension: 1000 mm Gisdpeza S Daefx Aagju System pressure: 250 bar Electric motor: 15 kW Weight: 3400 kg Operating voltage: 380 AC, 24 DC Bsbmm Av Esxr Rnaeuodc Control system renewed 5 years ago The machine is equipped with 2 tables, one at the bottom and one at the top, each measuring 800 x 500 mm. A throttle valve is installed on the hydraulic unit for pressure adjustment.

Condition: used, functionality: fully functional, Equipment: documentation/manual, Hydraulic straightening press Manufacturer: G + K Year of manufacture: 1992 Max. pressing force 130 t Table size (bottom) 800 x 500 mm with T-slots Table size (top) 800 x 500 mm with T-slots Installation dimension 1000 mm System pressure 250 bar Bjbmm Av Eoxr Rnaeujdc Electric motor 15 kW Gedpfx Aaoza Szrsgeiu Weight 3400 kg Operating voltage 380 AC, 24 DC Control system renewed 5 years ago 2 tables (bottom) 800 x 500 mm The hydraulic unit allows for pressure adjustment via a throttle valve, which can be monitored on the pressure gauge. The electrical system was overhauled by Schäger Steuerungsbau.

Condition: new, AUTOMATIC DOUBLE SPEED MOTORIZED HYDRAULIC PRESS WITH RAPID POWER 20 TON Max capacity TON 20 Approach speed (in rapid) mm/min 1700 Working speed (in slow) mm/min 440 Godpfervz A Ssx Aagoiu Cylinder rod stroke mm 300 Cylinder rod diameter mm 45 Shank diameter mm M14 Tank capacity liters 30 Max pressure bar 350 Voltage V 400 Frequency Hz 50-60 Motor Power kW 1.5 Max absorbed current A 3.8 Weight Kg 200

Condition: new, Year of construction: 2024, Electro hydraulic press 110 Ton Made in Italy The P110 MR is equipped with: 400 V 50-60 Hz immersed motor control unit. Pump for fast approach and return in 20 bar calibration. Adjustable pressure pump with handwheel to obtain the required power. Pressure relief valve with mechanical block to prevent overpressure. Pressure gauge (standard) that allows to calibrate with extreme precision the delivered power. The P110 MR is the only hydraulic press consisting of 2 laser-cut FE 510 monolithic structure uprights. without welding in the places of greatest stress This feature gives it extraordinary robustness. It is non-deformable and guarantees tight working tolerances. The P110 MR is equipped with a 30-litre tank and has a rapid descent speed of 1,400 mm/min. Weight : kg 1,100 Max pressure : bar 350 Max. flow rate : t. 110 Rapid flow rate :l/min 34 Slow flow rate : l/min 5 Inside shoulders : mm 1004 Rapid rod feed : mm/min 1.400 Slow rod feed : mm/min : 130 Voltage : V 400 Frequency :Hz 50-60 Power : kW 3 Godpfxjfh R N Ds Aagjiu Max. absorbed current : A 7,3 Cylinder stroke : mm 300 Cylinder diameter : mm 200 Stem diameter : mm 110 Piston descent speed : mm/sec 23 Tank capacity : litres 30

Condition: new, Year of construction: 2026, functionality: fully functional, input voltage: 400 V, input current: 7 A, pressing force: 150 t, stroke length: 300 mm, Equipment: CE marking, documentation/manual, MOTORIZED HYDRAULIC PRESS WITH AUTOMATIC DOUBLE SPEED AND RAPID ADVANCE CAPACITY: 150 TONS The monolithic frame is entirely laser-cut and securely bolted in package form. This characteristic makes all our presses deformation-resistant, even in areas subject to the highest stress. All components are manufactured in Italy. Hydraulic power unit with ICME submerged motor 400 V, 50/60 Hz; cylinders and frames made in Italy. Gsdjy E Rr Ispfx Aageiu GALTECH monobloc distributor. No. 2 single-direction external gear pumps in aluminium by VIVOIL: one dedicated to fast approach and return (set at 20 bar), and one with pressure adjustable via handwheel to set the required force. Maximum pressure valve with mechanical lock to prevent overpressure. 2 MP CETOP high-range modular block. Standard pressure gauge for displaying delivered power. INTECH electrical control panel, certified to current standards and independently CE marked. Maximum capacity: 150 tons Rapid approach speed: 1,450 mm/min Working speed (slow): 105 mm/min Cylinder rod stroke: 300 mm Cylinder rod diameter: 110 mm Shaft diameter: M30 Tank capacity: 50 L Maximum pressure: 350 bar Voltage: 400 V Motor power: 3 kW Weight: 1,300 kg

Condition: good (used), Clamping plate, plate field, welding table, welding table, clamping plate, scribing and measuring plate, measuring table, straightening plate, short-stroke heavy-duty cylinder, hydraulic cylinder, support cylinder, hydraulic ram, pressure ram, hydraulic press, bending machine, straightening machine, profile straightening system, strip straightening machine, strip straightening device, shaft straightening system, combined bending machine-straightening press, profile bending machine, bending machine bending/straightening press Gisdpfx Aezakf Njagju -Mounting plate: Mounting plate with straightening press -Length: 4025 mm -Width: 1990 mm -Piston diameter: Ø 63 mm -Stroke: 110 mm -Pressure force: 20 t -Overall dimensions: 1990/4025/H1920 mm -Weight: 5060 kg

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, pressing force: 15 t, bale width: 700 mm, bale height: 700 mm, bale weight: 220 kg, input voltage: 400 V, power: 4 kW (5.44 HP), empty load weight: 2,700 kg, Manufacturer: Borg Baling Company Type: S-15KK Year of production: 2002 3x400V, 4kW, 14.5A Gijdpfx Ash Dy Rfeagou Compression force: 15t Net weight: 2.7 t Bale max. sizes 700x700x1000 mm weight of a bale: ca 120 – 220kg Wide Range of Used Machinery, Industrial Equipment

Condition: new, pressing force: 300 t, For sale is a hydraulic portal straightening press (H-frame) from manufacturer Durendus with a maximum pressing force of 300 t. The machine features a table size of 1,500 × 2,000 mm, a maximum installation height of 1,000 mm, and a stroke of up to 600 mm, making it particularly suitable for straightening, alignment, and heavy forming applications in industrial environments. The machine shown here was built and delivered to a customer’s specification; we can manufacture this machine as a new unit on short notice. Available Options (upon request): The options listed below are based on completed customer projects and allow targeted adaptation of the machine to specific applications. The base machine is delivered in a functional basic configuration—in practice, it is most often expanded with additional features and configured to meet project requirements. Examples include: * Siemens S7-1200 PLC + 7” display for operator interface * Wireless remote control * Safety edge at the base of the portal columns (600 mm) * Table with T-slots * Motorized bridge positioning * Travel path extension * Larger open height * Light curtain under the bridge * Laser distance measurement * Lifting cylinder in the table ##### Technical Data & Information: Hydraulic Portal Straightening Press – H-frame – 300 t ==== General Specification - Designation: Hydraulic portal straightening press - Type: H-frame / portal press - Manufacturer: DURENDUS - Pressing force: 300 t (adjustable) - Distance between uprights: 1,580 mm - Table size: 1,500 × 2,000 mm - Bridge travel: 1,500 mm - Lateral travel (center): ±500 mm - Max installation height: 1,000 mm - Table height from floor: 950 mm - Ram extension: 200–400 mm - Total weight: approx. 9,500 kg ==== Hydraulic Cylinder - Piston stroke: 0–600 mm - Max working pressure: 250 bar - Return speed: 16 mm/s - Ram speed: 10 mm/s ==== Hydraulics & Drive - Hydraulic pump: ASC - Pump capacity: 60 l/min - Tank volume: 250 l - Motor rating: 11 kW - Pressure accuracy: ±5 bar - Hydraulic unit: top-mounted - Valve technology: DUBLOMATIC - Filter: FILTREC - Oil level monitoring: electronic - Cooling: air cooling ==== Movement System - Bridge drive: 2 × 2.2 kW - Lateral cylinder movement: 0.75 kW - Movable bridge: yes - Laterally movable cylinder: yes ==== Control System - PLC: SIEMENS S7-1200 - Operation: pendant panel / wired remote control - Control: manual valve + electric control - Optional: 7" touchscreen - Optional: wireless remote control - Optional: up to 99 programs storable ==== Safety - Hydraulic overload protection - Electronic overload protection - End travel safety switches (top/bottom) - Safety PLC - CE-compliant design - Optional: safety edge on portal columns ==== Electrical Connection - Main supply: 400 V AC - Control voltage: 24 V DC - Frequency: 50 Hz - Main motor: 11 kW - Total connected load: approx. 18 kW Fields of application: Straightening, tool and mold making, steel construction, heavy forming, maintenance, try-out, alignment work (Hydraulic press, hydraulic straightening press, portal press, portal straightening press, 300-ton press, 300 t press, H-frame press, heavy-duty press, industrial press, forming press, straightening system) ##### The images shown serve as samples and may deviate from the actual configuration. Gjdsyzfkqepfx Aagoiu

Condition: used, Year of construction: 2021, machine/vehicle number: HB 2022-A-073, pressing force: 300 t, Portal straightening press with 300 T capacity a) idle and pressing speed up to 17 mm/sec. b) opening speed up to 55 mm/sec c) table size 2500x1600mm d) open height 700 mm Giedoh Agnuopfx Aagou e) total size approx. LBH 4500 x 2300 x 3700 mm f) Oil temperature indicator on the tank g) Lubrication via grease nipple h) table in grid construction,with T grooves according to customer's request, otherwise 22mm i) operation on swivel arm, mounted on the bridge j) pressure adjustment from 50 T to 300 T via MONITOR k) bridge moves by two gear motors, via racks l) Cylinder moves to the left and to the right via toothed racks m) Machine body double painted n) Cylinder induction hardened Type of construction Press design PORTAL PRESS Thermally neutral 80 - 120 °C Number of operating sides 3 side Forces Pressing force max. 3,000 kN Free ripping force max. 500 kN Pressure build-up time Closed die Steel to steel Max. 3 sec. Dimensions Max. Opening width 700 mm Stroke and min. opening 700 mm/ 0 mm Table height above floor approx. 9ß0 mm Height above floor (headroom) approx. 3700 mm Hall height min. 5.000 mm Deflection Determined at max. clamping force with 70% occupancy < = 0.8 mm/m Weight Total weight of press without operating materials and table plate approx. 22 T Speeds Fast closing with 17 mm sec. Pressing speed 8 mm sec. Opening 55 mm sec. Sound pressure Sound pressure level, measured at 1.5m height at the control panel after max. 78 db(A) DIN 45635-T16-KL3 Hydraulics Number of pressing cylinders 1 pc. Operating pressure max. 350 bar Pressing pressure build-up time 02. mz sec. Pressure accuracy during pressing stroke +/- 5 bar Main pump BOSCHREXROTH approx. 93 L/min Oil volume approx. HLPD 46 MW 900 liters Ambient temperature max. 45 °C Oil temperature max. 55 °C Electrical system Main supply 400 V AC Control voltage 24 V DC Frequency 50 Hz Hydraulic connection Main motor IE3 22 kW Total connection Approx. 30 kW

Condition: new, Year of construction: 2019, pressing force: 275 t, pressure:275 t distance between columns:3000 mm Gijdpfx Aofxyigoagju total power requirement:30 kW weight of the machine ca.:40 t draw back pressure:27 t pump capacity:Axialpumpe mit Proportionalventil :6000 mm :max. 3000 mm Table dimensions:6000 x 3000 mm table height over floor:700 mm distance between table / ram:1100 mm :450 l traversing speed:auf X und Y, 30-33 mm/sec. down speed:2-10 mm/sec :2-50 mm/sec. Cylinder hub:900 mm Cylinder diameter:440 mm Stestle extension:200 / 200 mm / Ø :40 mm Siemens Control System:S7 1200 Monitor Siemens 9":Touch Panel Tax desk:tragbar

Condition: as good as new (ex-display), Year of construction: 2021, pressing force: 400 t, Gantry straightening press with 400 T capacity a) idle and pressing speed up to 17 mm/sec. b) opening speed up to 60 mm/sec c) table size 6000x3000mm d) open height 1500 mm e) total size approx. LBH 6000 x 5000 x 4500 mm f) Oil temperature indicator on the tank g) Lubrication via grease nipple h) Table in grid construction, i) operation on swivel arm, mounted on the bridge j) pressure adjustment from 60 T to 400 T via MONITOR k) Bridge moves by two gear motors, via toothed racks l) Cylinder moves to the left and right via toothed racks m) Machine body powder coated, or double painted n) T-slots according to customer requirements o) cylinder induction hardened PORTAL PRESS Thermally neutral 80 - 120 °C Number of operating sides 3 side Forces Pressing force max. 4000 kN Free ripping force max. 600 kN Pressure build-up time Closed die Steel to steel Max. 3 sec. Dimensions Max. Opening width 1500 mm Stroke and min. opening 1500 mm/ 0 mm Table height above floor approx. 900 mm Height above floor (headroom) approx. 4500 mm Hall height min. 5500 mm Deflection Determined at max. clamping force with 70% occupancy < = 0.8 mm/m Weight Total weight of press without operating materials and table plate approx. 52 T Speeds Fast closing with 17 mm sec. Sound pressure Sound pressure level, measured at 1.5 m height at the control panel according to DIN 45635-T16-KL3 max. 78 db(A) Hydraulics Number of pressing cylinders 1 pc. Operating pressure max. 280 bar Pressing pressure build-up time 2-3 sec. Pressure accuracy during pressing stroke +/- 5 bar Main pump BOSCHREXROTH approx. 150 L/min Gijdpfxehyc Nwe Aageu Oil volume approx. HLPD 46 MW 900 liters Ambient temperature max. 45 °C Oil temperature max. 55 °C Electrical system Main supply 400 V AC Control voltage 24V DC Frequency 50 Hz Connection hydraulics Main motor IE3 30 kW Total connection Approx. 35 kW
