Cnc turning and milling center

MAZAK INTEGREX 200 IV S

Condition: used, Year of construction: 1998, machine/vehicle number: 98BE510071, turning length: 90 mm, spindle speed (min.): 4,000 rpm, spindle motor power: 11 W, overall weight: 6,300 kg, bar passage: 51 mm, 12 position upper turret (6 are driven) -10 position lower turret (5 are driven) - sub spindle - 2 x C axis - equipped with Lns Sprint S2 bar loader with front magazine, fixed and driven tool holders, manuals - Fanuc 18T Control Bcedpfswidp Iox Afcsw

Condition: used, Year of construction: 2011, Mazak HC Nexus 5000-II Mazatrol Matrix Nexus Year: July 2011 Pallet Size: 500 x 500 mm Movement: - X: 730 mm - Y: 730 mm - Z: 740 mm Spindle Speed: 12,000 rpm Tool Changer: 40 positions Bcedpfev Tvh Ssx Afcjw Chip Conveyor: Chrome

Condition: like new (used), MACHINE DATA TORNI TACCHI FTC model 51 OVERALL DIMENSIONS Center distance 4000 m/m Height 1550 m/m Width 1400 m/m Length 6200 m/m Weight 10.000 Kg Swing over bed 1120 m/m Swing over carriage 810 m/m Swing over gap 1350 m/m Hole through spindle 123 m/m Number of speeds 18 Bedpfsd Tm D Esx Afcocw Range of speeds 7-550 / 1’ Horsepower of motor 25HP Morse taper № 6 Metric threads – inch – module – pitch 3 jaw chuck 450 m/m Face plate 850 m/m Extra face plate 1420 m/m Good condition

Year of construction: 2001, condition: excellent (used), Multispindle lathe Schütte AG20 Bjdpfxjhrihye Afcocw

Condition: excellent (used), Year of construction: 2007, machine/vehicle number: 22049, functionality: fully functional, CNC horizontal machining center MAZAK HC NEXUS 5000-II + PALLETECH (6 Paletten) Mfg. year 2007 Mazatrol Matrix control movements: X-axis: 730 mm Y-axis: 730 mm Bjdpfx Afjpm Igzjcocw Z-axis: 740 mm Distance spindle nose to spindle center 70-810 mm Distance spindle center to pallet surface 100-830 mm Pallet size 500 x 500 mm Max. workpiece dimensions Ø800 x 1000 mm Max. pallet load 700 kg Main spindle 30 kW Max. spindle speed 18.000 rpm BT-40 Tool magazine for 120 tools NC indexing table, 1° indexing Tool length measuring – Laser Renishaw NC4 Swarf conveyor, Tecnoforme Coolant through spindle Coolant tank 300 microns rotofilter 18 bar high pressure pump Pulse generator Palletech system with pallets and loading station CE-mark

Condition: as good as new (ex-display), Year of construction: 2024, functionality: fully functional, turning diameter over cross slide: 600 mm, spindle bore: 90 mm, turning diameter: 570 mm, turning length: 3,000 mm, quill stroke: 220 mm, quill diameter: 80 mm, total length: 4,900 mm, total width: 1,300 mm, spindle speed (max.): 1,600 rpm, spindle speed (min.): 28 rpm, bed width: 380 mm, Turning diameter in gap: 720 mm, overall weight: 4,500 kg, . Height of centers mm 300 . Distance between centers mm 3000 . Width of the bench mm 380 . Rotating diameter on the bench mm 600 . Rotating diameter on the natural recess mm 720 . Turning diameter on the transverse carriage mm 570 . Length of the natural recess mm 360 . Maximum spindle speed G/1’ 28/1600 . Spindle nose type D1 8” . Spindle hole diameter mm 90 . Tailstock quill stroke mm 220 . Tailstock quill diameter mm 80 . Tailstock quill length mm 370 . Tailstock morse taper N 6 . Transverse carriage stroke mm 360 . Tool carriage stroke mm 180 . Mobile steady rest (Max. turning diam.) mm 220 . Fixed steady rest (Max. turning diam.) mm 270 . Main motor power Kw 11 . N. standard threads N 254 . Standard threads min/max (metric) fil x 1” 1/56 . Standard threads min/max (witworth) mm 0.5/28 Bcedpovi Ez Tofx Afcsw . Standard threads min/max (module) Mod. 0.5/28 . Threads min/max (diametric pitch) d.p 1/56 . Longitudinal feeds min/max mm 0.08/3 . Transversal feeds min/max mm 0.04/1.5 . Length of carriage support on the bench mm 600 . Length of transversal carriage mm 600 . Net weight kg 4500 . Dimensions mm 4900 x 1300

Condition: used, Year of construction: 2005, functionality: fully functional, turning length: 1,500 mm, spindle speed (max.): 4,000 rpm, rotational speed (max.): 4,000 rpm, overall weight: 14,400 kg, Mazak Integrex 300 3 ST Control -Mazatrol 640 mt pro 2 Spindles 1500mm No CE Bcjdpjx Rkvqefx Afcjw 2005/05 in very good condition Turret lathe.....10 tool ATC.....40 tool Maximum Swing 33.5″ 850.9 mm Maximum Swing (Y-axis use) 26″ – 33.5″ 660.4 mm – 850.9 mm Maximum Swing over Cross Slide 33.5″ 850.9 mm Maximum Swing over Lower Turret 16.5″ 419.1 mm Located in Israel under power and ready for inspect . This CNC made in Japan and definitely needs a permit of MATI

Condition: ready for operation (used), Year of construction: 1991, machine/vehicle number: MS 25E19111, Number of spindles: 6 Spindle bore: 27 mm Turning length: 59 mm Hexagonal material: 24 mm Square material: 18 mm Cross slide travel: 36 mm Longitudinal slide travel: 85 mm Spindle speeds: 366 - 5020 rpm Torque: 95 Nm Bcsdsv Raatjpfx Afcjw Control: INDEX Total power requirement: 20 kW - 6 cross slides - 6 longitudinal slides - Multi-edge device - Thread cutting device - Hydraulic pick-up device - Workpiece conveyor belt - Bar loading magazine, IEMCA, type PRA 40/35/P

Condition: good (used), Year of construction: 1997, Also available CONQUEST T51 model The used HARDINGE CONQUEST T42L 3-axis motorized CNC lathe is a robust and precise medium-sized inclined bed numerical control lathe, turning length approximately 700mm, bar passage 42m, automatic turret with 12 positions with motorized tools, FANUC 18-T CNC with color LCD and RS232 serial interface for data transfer 5″ ASA spindle maximum revolutions: 4,200 rpm continuous C-axis Bedpfxovtrc So Afcscw 20HP spindle power X-axis travel: 172mm Z-axis travel: 575mm machine weight 4,000 Kg. Complete with 210mm AUTOBLOCK hydraulic chuck, tool presetting, programmable tailstock, 2 motorized tool holders (1 axial and 1 radial), chip evacuator, set of fixed and manual tool holders and backup disk; Year of construction 1997; machine compliant with “CE” standards, in excellent condition.

Condition: new, Year of construction: 2024, machine/vehicle number: OR-220701306, Description: OREE PH-3015: ( 3 Kw) New from stock in Europe. 40 sold in 10 month. We can deliver this type Laser cap. from (1 till max 20 Kw) A Compact Design with Complete Protection (CE) table length 3050 mm table width 1530 mm laser head ( SWISS RAYTOOLS ) autofocus laser capacity Kw 6 overall dimensions 8265 x 2280 x 2150 mm weight of the machine ca. 5.400 kg Furnishing: - Max-photonics Laser source 3 Kw - CYPCUT (full option, no extra control option cost) - High integrated, simple operation, leading technology - Ray-tools autofocus cutting head - CYPCUT - CAD / CAM software include: - Nestling, With leapfrog, Edge seeking, Fly cutting, ETC - 23" touchscreen, keyboard, control panel - additional loading unit - central Lubrication system Cutting capacities: ( for 3 Kw ) - normal steel 20 mm - stainless steel 10 mm - aluminium 10 mm - brass 9 mm - copper 7 mm Axes: - Machine axes: 3 axes (X, Y, Z,) - X-axis travel 3000 mm - Y-axis travel 1500 mm - Z-axis travel 315 mm - Axis speed X / Y: 100 m / min - Positioning accuracy: +/- 0.03 m - Reputability accuracy +/- 0.02 mm - Acceleration max. 1,5 G Automatic table change: - Number of table 2 (15 second max for changing) - automatic change, max load on tables 1440 kg. - 2 x CCTV camera on pallet arear on screen assisting gases: - mild steel - oxygen (0.5 - 25 bar) - stainless steel - nitrogen (0.5 - 25 bar) - Aluminium - compressed air or nitrogen (0.5 - 25 bar) including: - Compatible suction system, cap 3 Kw - Spare part basic supply package - cutting from reflective sheet metal materials - 3 part trolly under work table Bcodpfx Afjlkgd Iecsw Why CNC Top Ten bv - Cnc Top Ten company have over 50 year experience in CNC machines. - And we have more service and sales locations in west and east Europe - they know from beginning what to respect service, installation and training. - for this machine the installation and training is 1,5 week. Not included. - we can offer cost also depend on end-user place and country. - Machines for cutting thin sheets - axes equipped with Japanese servo motors YASKAWA - Servo motors reach up to 100 m/min. - Accelerations up to 1.5 G - Fiber laser is the green laser technology for the future - (Saving of at least 50% energy costs) - Components / therefore very low-maintenance - Save up to 50% per part through more efficient production - In addition, precise cuts and smooth surface quality - Heavy-duty constructed frame, - equipped with world-famous, durable, high-quality components We use the most high quality parts Like: -- Yaskawa servo drives -- Hiwin linear rails -- Tongfei water chiller dual use for source and laser head -- 2 CCTV camera’s on screen -- Auto central lubrication -- Touch screen 23 inch -- For providing quickly service, we add WIFI function for our technician operates troubleshooting and adjust parameters remotely -- YYC/APEX rack and pinion -- standard delivery is with power transformer and stabilizer total power requirement 50 kW -- TBI high precision ball screw for Z axis -- saw tooth blade table -- air and gas pressure real time monitoring on screen -- CE declaration -- warranty 2 year, max 3600 hours Official Dealer CNC Top Ten b.v. Coevorden Holland
