CNC-Lathes

MIYANO BNA 42 MSY

Condition: excellent (used), Year of construction: 1994, Manual Plus control unit Turning diameter 260 mm Swing diameter 475 mm Center distance 1000 mm Turning length 880 mm Spindle speed 3,000 min-1 4-fold parat holder Tailstock Crsdpfx Afjt T T Urj Hok

Condition: used, Year of construction: 1998, turning diameter 570 mm Crodpfx Asugawfsf Hok turning length 2000 mm control total power requirement 15 kW weight of the machine ca. 3,5 t dimensions of the machine ca. m

Condition: used, Year of construction: 2023, In the market for a Top of the Range Miyano? Then have a look at this one! 18 months old and just over 1000 hours on the clock…it is as new! Still on site where it can be seen under power. The following is from Miyano’s Spec sheet: The Miyano ABX-64SYY – is a Top of the range, twin spindle, twin turrets with Y-axis on each turret. The ability to machine simultaneously at the left and right spindles using the upper and lower turrets, both featuring a Y-axis function, means that complete front and back machining of products with complex shapes can be accomplished simply and in a short time. High rigidity and high torque with 40 Nm driven tools. The use of rigid 40 Nm driven tool drives capable of heavy cutting ensures stable milling. Two turrets with a total of 24 tool positions, all driven, handle complex machining just like a machining centre. This machine also features the optional parts conveyor, Hainbuch collet chucks on both spindles, high pressure coolant, probing and a steady rest that’s mounted on the lower turret. Machining Capacity and Chuck System Maximum Machining Diameter of Bar Work SP1/SP2 ø64/51mm Collet Chuck SP1/SP2 Stationary Power Chuck SP1/SP2 6″/6″ hydraulic drive Standard Turning Length 125mm Spindle Spindle Nose SP1/SP2 A2-8/A2-6 Spindle motor(30min./Cont.) SP1 15/11kW SP2 7.5/5.5kW Spindle Speed Range SP1 50 – 5,000min-1 40 – 4,000min-1 SP2 50 – 5,000min-1 Turrets(Upper L/R Turrets & Lower Turret) Type of Turret 2 x 12 Station Turret Shank Height of Square Turning Tool □20mm Diameter of Drill Shank ø40mm ø20mm ø25mm Slide Stroke X1, X2 axis 190mm Z1/Z2 axis 550mm/721mm Y1, Y2 axis ±40mm Zs axis 756mm Rapid Traverse Rate X1, X2 axis 16m/min Z1/Z2 axis 30/20m/min Y1, Y2 axis 12m/min Zs axis 30m/min Driven Tools Maximum Number of Revolving Tools 24 Rotation speed of Driven Tools 60 – 6,000min-1 Driven Tool Motor AC Servo 4.5kW Machine Dimensions Machine Height 2,222mm Floor Space 3,290×2,204mm Machine Weight 10,900kg Name of the machine: Miyano ABX-64SYY Crjdpjw I D Duefx Af Hsk

Condition: excellent (used), Year of construction: 2022, operating hours: 2,963 h, functionality: fully functional, TECHNICAL DATA - Number of spindles: 2 MAIN SPINDLE - Max. bar diameter: 42 mm - Travel: 100 mm - Spindle speed: 6,000 rpm - Spindle drive power: 7.5/5.5 kW - Minimum C-axis resolution: 0.001° SUB SPINDLE - Max. bar diameter: 34 mm - Spindle speed: 5,000 rpm - Spindle drive power: 5.5/3.7 kW - Minimum C-axis resolution: 0.001° - Number of turret heads: 2 UPPER TURRET HEAD - Number of positions: 8 - Travel X: 140 mm - Travel Z: 235 mm - Travel Y: 70 mm (+/-35 mm) - Driven tool speed: 5,000 rpm - Driven tool power: 1.0 kW LOWER TURRET HEAD - Number of positions: 6 - Travel X/Z: 140 / 310 mm ELECTRICAL SUPPLY - Total connected load: 30 kVA WEIGHT AND DIMENSIONS - Required floor space: 2,220 x 1,460 mm - Machine height: 1,700 mm - Machine weight: 3,100 kg Crsdpfxew Igyrs Af Hsk

Condition: used, CNC 3+2 axis vertical machining center DECKEL MAHO type DMU 35 M CNC control SIEMENS 810D with ShopMill Manufacturer no. 11065353554 Year of manufacture 2001 Travel paths: X: 350 mm, Y: 240 mm, Z: 340 mm Table movements: C-axis: 360° Swivel range: +105° / -15° Universal swivel - rotary table: 400 x 290 mm, center hole 30H6 Table load: max. 100 kg Distance spindle nose - table: min. 145 mm to max. 485 mm Feed rate: 5,000 mm/min Rapid traverse (X / Y / Z): 5 m/min Input resolution: 0.01 mm Total power requirement: 15 kVA Speed range - main spindle: 20 - 6,300 min/-1 Drive power - main spindle: 6.3 / 10 kW (100% / 40% ED) Torque: max. 55 / 80 Nm Crsdpovt D D Uofx Af Hok Tool holder: SK 40 DIN 69871 Pull bolt: DIN 69872 or ISO 7388/2 Type B Interface: Serial RS232C, LAN (RJ45) Power connection: 400 volts, 50 Hz, 15 kVA Compressed air connection: 6 bar - CNC control Siemens Sinumerik 810D with ShopMill V05.03.22, NCU 03.03.34-CCU1E, MMC103 - 3-axis controlled (X, Y and Z axis) - Manual swivel rotary table, C axis = table rotation 360°, B-axis = swivel range +105°/ -15° - direct path measuring system for all 5 axes - electronic handwheel - spindle drive via servo motor with toothed belt and 2 gear stages - fully protected cabin with sliding door - swiveling control panel - coolant nozzles on the vertical head - chip tray with coolant container and cooling lubricant pump - work area lighting - documentation available space requirement L x W x H 2000 x 2000 x 2100 mm weight 1750 kg good condition

Condition: used, Year of construction: 2001, turning diameter 500 mm turning length 1000 mm control MONFORTS CONTROL control SYSTEM MTC-K turning diameter over bed slide 290 mm spindle bore 70 mm spindle turning speed range 3 - 2800 U/min spindle power 15 kW max. torque on the spindle 1530 Nm Crsdpevh I Hvofx Af Hjk spindle head DIN 55027 Gr. 8 feed power X/Z axis 11300 N rapid travel - longitudinal/face 10 / 5 m/min bed width 360 mm travel of cross-slide 265 mm upper slide travel 140 mm turning tool - shaft cross cut 32 x 25 mm tailstock quill diameter 80 mm tailstock quill stroke 160 mm tailstock taper MT 5 weight of the machine ca. 3,1 t dimensions of machine L x W x H 2,88 x 1,68 x 2,18 m Accessories: 3-jaw chuck ROTA-S plus 250 mmø, 4 pos. toolholder PARAT, coolant

Condition: used, TECHNICAL DETAILS - Number of axes : 9 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 20 [mm] - Spindle speeds : 12000 [rpm] - Spindle power : 3,7/5,5 [kW] - C axis indexing precision : 0,001 [°] COUNTER-SPINDLE - Max. bar diameter : 20 [mm] - Spindle speeds : 12000 [rpm] - Spindle power : 3,7 / 5,5 [kW] - C axis indexing precision : 0,001 [°] - Number of turrets : 1 LOWER TURRET - Number of positions : 12 - X/Z stroke : 90x65 [mm] - Y stroke : 50 [mm] - Number of guide bush holders : 2 GUIDE BUSH HOLDER 1 - Number of positions : 10 - Number of motorized positions : 4 - X/Y stroke : 90 / 319 [mm] END ATTACHMENT - Number of positions : 12 - X/Z stroke : 215x305 [mm] POWER SUPPLY Crodpfx Afouhbdij Hek - Supply voltage : 400 [V] WEIGHT & DIMENSIONS - Machine floor space : 2000x1280 [mm] - Machine height : 1720 [mm] - Machine weight : 3600 [kg] MACHINE HOURS - Number of hours under power : 23167 [h] EQUIPMENT - CNC : Fanuc 31i-B - Interface : Ethernet / RS232 / USB / PCMCIA - 3 colors status lamp - Rotating guide bush - Parts catcher - Ejection of workpiece - Coolant tank - Bar loader : Iemca Elite 220 (2010) - Fire extinguisher * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer.

Condition: used, Year of construction: 2008, turning diameter 560 mm turning length 2000 mm control FANUC Series oi-TC CNC Credpfx Afeviyh Uo Hjk spindle turning speed range 2200 U/min spindle bore 82 mm tailstock quill taper MT 5 quill stroke 150 mm total power requirement 7,5 kW weight of the machine ca. 3800 kg dimensions of the machine ca. 3800 x 1750 x 1600 mm

Condition: used, Year of construction: 1977, turning diameter x mm turning length x mm swing diameter over bed slide x mm turning diameter over bed x mm Codperpa Nysfx Af Hork 550mm weight of the machine ca. 1,5 t
