Vertical turning lathe

Pietro Carnaghi AC 20

Condition: good (used), Year of construction: 2009, functionality: fully functional, Technical details faceplate diameter 1800 mm swing diameter 2000 mm turning height 1270 / 1120 mm Control SIEMENS 840 D workpiece weight max. 5000 kg ram head dimension 250 x 250 mm table turning speeds 1 - 320 U/min cross rail - adjustment 400 mm ram head - cross travel (X) -2770 / +2275 mm ram head - vertical travel (Z) 1250 mm c-axis 360° (0,001°) deg milling drive 37 kW turning speed range - milling 10 - 3000 U/min power capacity - table 100 kW Torque 31784 Nm feed range (X/Z) 0,1 - 15000 mm/min weight of the machine ca. 55 t Additional information Used CNC vertical lathe for turning, drilling and milling Kjdpfxsx Uwtqe Ahusdg First machine installation in the year 2011. Max. workpiece diameter: 2040 mm Max. workpiece height: 1270 mm Ram stroke: 1250 mm Max. workpiece weight: 5000 kg (per pallet/chuck) Table speed range: 1.0 - 320 rpm Table drive motor: 100 kW Drilling and milling spindle: 37 kW Crossbar travel: 2 steps of 200 mm each Total electrical connection value: 218 kVA CNC control: Siemens 840 D Number of NC axes: 4 (X, Z, C, crossbar adjustment) Travels: X-axis: -1650 to + 2165 mm Z-axis: 1250 mm Rapid traverse X- Z-axis: 15 m/min Number of tool magazine spaces: 80 spaces in the chain magazine, of which 60 x HSK 100 and 20 x Capto C6 Disc magazine 12-pos. for rotary holders and attachment heads Coolant system with filter and circulation unit Chip conveyor Oil-mist-extractor 1 pallet with jaws, diameter 1800 mm 1 hydraulic chuck with base jaws, diameter 1800 mm Various drilling and milling heads 2 measuring probes Several turning tool holders Special feature: Pallet changer with two stations, equipped with a face plate Ø1800 mm and a six-jaw lever compensation chuck with mechanical centrifugal force compensation Ø1800 mm. Note: The machine is in a pit. Condition description: The cross roller bearing on the Carnaghi was replaced about half a year ago. The Siemens components in the control cabinet were also completely replaced at the end of 2023. The machine also has a measuring probe for tool measurement and an external Renishaw measuring probe for workpiece measurement. As a special feature, the machine also has a measuring probe installed on the Z-axis (Z1-axis). This brings an advantage in terms of accuracy and time, as the tool does not have to be put down for measuring. However, it is currently shut down and should be overhauled when it is put back into operation. The machine also has a Rotomors six-jaw lever compensating chuck with centrifugal force compensation, which was completely overhauled in 2020/21.

Condition: ready for operation (used), Broadbent Heavy Duty Lathe 1041mm x 10,000mm Year approx. 1973. Swing over bed 1041mm (41”) Swing bin gap1575mm (62”) Distance between centres 9300mm (30’ 6”) Spindle bore 115m (4 ½”) Spindle speeds (18) 3.3 – 360 rpm Spindle motor 30 HP or 40 HP (To be confirmed) Tailstock 6 MT Imperial Metric screw-cutting with change gears. 36” Faceplate with 4 adjustable jaws, 54” Faceplate, Taper turning attachment, Power feed to top slide, Ksdpfsv I T Ewjx Ahuodg 2 x 18” 3 point steadies, 24”/28” Steady.

Condition: used, Year of construction: 2009, faceplate diameter 1800 mm swing diameter 2000 mm turning height 1500 mm Control SIEMENS 840 D workpiece weight max. 5000 kg ram head dimension 250 x 250 mm table turning speeds 1 - 320 U/min power capacity - table 100 kW Torque 31784 Nm total connected load 218 kW weight of the machine ca. 55 t Turning- and Boring heads: - 4 x Turning heads + steelholders - 3 x Turning heads for Capto - 1 x Boring head (driven) Kdedpevylilofx Ahuog - 2 x angular boring heads (Manufacturer Benz) Dimensions: - Turning diameter on the faceplate 2000 mm - Faceplate diameter 1800 mm - Turning height with turning head L100 1500 mm Power on the ram: - Clamping force of tool holder or accessories 120,000 N - Max. Feed force Z and X axis 30,000 N - Drive power of the milling, drilling and grinding spindle 37 kW - Speeds for turning 10 - 3000 rpm Travels: - Axis X, horizontal support on the crossbeam -2270/+2275 mm - Axis Z, vertical support on crossbeam 1250 mm - Axis C, table rotation 360° Feed speeds: - Axis X 15,000 mm/min - Axis Z 15,000 mm/min - Axis C 3.25 rpm Coolant system: - Coolant system filter system 1500 l Chain tool magazine with 80 places: - max. tool weight 30 kg - Max. tool diameter with free auxiliary slots 250 mm Disk magazine with 12 slots: - max. weight of tool holders/accessory units 150 kg - max. length of tool holders 500 mm - max. magazine load 1000 kg Pallet changer with 2 pallets: - Pallet diameter 1800 mm - Pallet load capacity (centered) 5000 kg - Pallet load capacity (on center) 4000 kg Equipment / accessories: - 1x pallet with claw boxes, diameter 1800 mm - 1x hydraulic chuck with base jaws, diameter 1800 mm - Various drilling and milling heads - Various turning tool holders - 2x measuring probes

Condition: good (used), turning length: 6,000 mm, spindle bore: 260 mm, Swing over bed Ø: 850mm Swing over cross slide Ø:500mm DBC Turning Length: 6000mm Spindle bore: 260mm Spindle power: 28kW Kdsdpfx Ahewvtg Aeusg Bed width: 650mm Stroke pinole: 300mm Spindle taper: 6Mk Workpiece weight: 5000 Length: 10000mm Width: 2100mm Height: 2600mm Weight: 12800kg

Condition: ready for operation (used), Year of construction: 1978, functionality: fully functional, turning diameter over cross slide: 960 mm, turning length: 10,000 mm, turning diameter: 1,300 mm, spindle bore: 160 mm, Lathe Wohlenberg model M 1000 BSN in excelent condition. Machine were retrofited with Siemens 802. Ksdexprrbjpfx Ahujdg Machine is under power and it can be tested.Two steady rest

Condition: used, Year of construction: 1996, functionality: fully functional, Equipment: documentation/manual, rotational speed infinitely variable, Geminis Lathe Type: CNC5/PLUS/1000/4000 CNC control: Fagor Year: 1996 With 2 steadies + Tooling Kdodpfjxvr E Ijx Ahujg With 2 chucks Can be inspected under power Video available

Condition: ready for operation (used), Year of construction: 2006, Mori Seiki NL3000Y/1250 Turning Centre (2006) Mori Seiki MSX-850II Control Manufactured & Installed in 2006 Various Live Tool Holders & Various Static Tooling Supplied Tool Setting Arm C & Y Axis Tailstock 12” Chuck Swarf Conveyor Machine Capacity: Max’ Swing over Bed 995mm Max’ Swing over Cross Slide 825mm Max’ Recommended Turning Dia’ 420mm Standard Turning Dia’ 310mm Max’ Turning Length 1260mm Kdjdpow Rry Nofx Ahuog Max’ Bar Work Dia’ 90mm X Axis Travel 210 + 70mm Y Axis Travel 120mm (+- 60) Z Axis Travel 1370 C Axis 0.001 Spindle: Main Spindle Speeds 3000rpm 2 Spinde Ranges Spindle Nose A2-8 12” Chuck Turret: Number Of Tool Stations 10 Height of Angle Tool Shank Section 25mm Dia’ of Borig Bar 50mm Live Tooling Speeds 6000rpm General Dims: Machine Dims - 4522 x 2291mm Weight 8100Kgs For sale with Jet Machinery Ltd Jet Machinery Stock No: #78830 Machine Serial Number: NL301FJ0675 Cost: £55,000.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: used, functionality: fully functional, spindle bore: 82 mm, turning diameter: 820 mm, turning length: 6,000 mm, GURUTZPE lathe model Super A, 6,000 mm between centers, swing on bed 820 mm, on carriage 550 mm, in the neckline 1150 mm, diameter of the shank 82 mm, motorized carriage, 16 speeds of 9-500 rpm, has 3 steadys . Ksdpsv Rm Iwefx Ahuodg

Condition: used, functionality: fully functional, turning diameter over cross slide: 1,400 mm, turning length: 7,000 mm, turning diameter: 1,780 mm, spindle bore: 120 mm, bar passage: 120 mm, CNC PARALLEL LATHE (HEAVY-DUTY) MEUSER Technical Specifications Brand: Meuser Kedpexxa N Tsfx Ahusdg Model: D1400 Distance between centers: 7000 mm Swing over bed: 1780 mm Swing over carriage: 1400 mm Spindle bore: 120 mm CNC: Fagor 8055 (Year 2015) PRICE AND FURTHER INFORMATION ON REQUEST (CNC, SIEMENS, HASS, LAGUN, FAGOR, CINCINNATI, HEIDENHAIN, MACHINING, PINACHO, MORISEIKI, MILLING MACHINE, LATHE, GRINDER, BORING MACHINE, PRESS, LASER, SHEAR, PRESS BRAKE)

Condition: ready for operation (used), functionality: fully functional, turning diameter over cross slide: 550 mm, spindle bore: 77 mm, turning diameter over bed slide: 800 mm, GURUTZPE lathe model Super AT 400/6000, 6,000 mm between points, turning on bed 820 mm, on carriage 550 mm, shaft diameter 76,5 mm, 16 speeds from 9-500rpm, has fixed rear Steady , , has 4 independent claws chuck diameter 800mm, , very good condition in general Kedpfx Ahewd D Iteujdg
