Mesh welder

Schnell Italy 2500-6-12

Condition: refurbished (used), SCHLATTER Welded wire mesh production line MG24 Full revamped WORKING RANGE Panel width: max. 2500 mm Weft wire length: min. 900 mm Weft wire length with QF5 dispenser: min. 300 - 1600 mm Spacing between extreme warp wires: max. 2400 mm Mesh length (warp wire length): max. 2500 - 6000 mm Spacing between warp wires: min. 100 mm Spacing between weft wires: 25-250 mm Adjustable by cutting device (0-1) Warp wire diameter: 4.0 - 12.0 mm Weft wire diameter: 4.0 - 12.0 mm Number of warp wires: max. 24 WELDING MESH MACHINE MG 24.1/8C, Basic equipment including: - 1 Machine frame - 1 Upper support for press reception, continuously adjustable by hand crank - 1 Magnet supports with retaining magnets and weft wire monitoring. - 1 Row of pneumatic solenoid valves for press actuation. - 1 Installation for air and water. - 2 Pneumatic rotary drives with oil damping - Static motor torque with 5 bar compressed air: 480 Nm - Front continuously adjustable from: 25 - 250 mm adjustable by cutting device (0-1) - 1 Advance carriage with panel lifting device - 1 Set of tools for machine adjustment WELDING SECTION 8 Type C Transformers Rated power of each transformer: 100 kVA No-load secondary voltage: 7.1 V Rjdowu Tu Dspfx Afcsp Rated secondary current: 14 kA 8 Thyristor contactors ES 130 12 Welding presses: 5.0 kN 12 Chain current bridge for spacing of warp wires: 50-100 mm 12 Chain current bridge for spacing of warp wires (for offset warp wires): 100 mm 10 Chain current bridge for spacing of warp wires: 100-150 mm 8 Chain current bridge for spacing of warp wires (for offset warp wires): 150 mm 6 Chain current bridge for spacing of warp wires: 150 - 200 mm 6 Chain current bridge for spacing of warp wires (for offset warp wires): 200 mm 24 Lower electrode holders Cu with standard angled electrodes and each with a water-cooled current cable, width: 58 mm 24 Wire clamping pliers Panel width: max. 2500 mm Weft wire length: min. 900 mm Weft wire length with QF5 dispenser: min. 300 - 1600 mm Spacing between extreme warp wires: max. 2400 mm Mesh length (warp wire length): max. 2500 - 6000 mm Spacing between warp wires: min. 100 mm Spacing between weft wires: 25-250 mm Warp wire diameter: 4.0 - 12.0 mm Weft wire diameter: 4.0 - 12.0 mm Number of warp wires: max. 24

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 2-1, 2006, Eurobend CNC 16x4 rebar from coil straightening and cutting machine in used but working condition. 4 x 5 Ton decoilers with pneumatic brakes. 4 x rotor for diameter 8-10-12-16 mm rebar wire straightening and automatic cutting with hydraulic moving cutters. 1 line or even up to 4 lines together cutting. Rodpfx Afordvq Ajcsp PC with barcode scanner option. Cutting length up to 14 meters and more. Pockets for storage. Chain conveyor for transport of bundles.

Year of construction: 1985, condition: reconditioned (used), Technical Details : Wire Dimeter range- 4-12mm Gscxckebw Rsdpfx Afsh In Thscop Run out table - 4m Speed -80' m/min. Reconstruction- 2022

Condition: used, functionality: fully functional, machine/vehicle number: D20E/7694, Offer Number: D20E/7694 Machinetype: multiple wire drawing machine - dry Make: SKET / MILL Type: 8 BLOCK Constr. year: inlet wire diameter: 6,5 mm finished wire diamter: 1,6 mm number of drafts: 8 diameter of capstan: 550 mm and 650 mm Redpfx Aswi S Ixefcep speed -meters/sek: 8-12 Location: Europe

Condition: good (used), Year of construction: 1991, Mesh welding line EVG model G95/102 Min / max wire diam - 4,00 - 12,00 mm Max width of mesh panels - 2.750 mm Rodpfxsvxq Eij Afcep FULLY AUTOMATIC - Lines wires and CROSS wires feeding from coils / spools. Please see attached document !

Condition: used, Year of construction: 1980, functionality: fully functional, machine/vehicle number: D08L/7600, Offer Number: D08L/7600 Machinetype: straightening and cutting machine Make: WAFIOS Type: RS40S Constr. year: 1980 diameter range: 4-10 mm Rsdpfx Afowi S N Nscjp cutting length: 3000 mm speed - meters/min: 130 Location: In our warehouse

Condition: used, Year of construction: 2016, functionality: fully functional, working width: 2,000 mm, wire diameter (max.): 6 mm, type of input current: three-phase, operating speed: 142 mm/s, mesh size: 9,999 mm, continuous power (apparent): 833 kVA, We offer a used Schlatter MG600/MG24.4/10Sp-AC mesh welding machine, model year 2016. Type: MG600/MG24.4/10Sp-AC Serial number: 4885.31609 Year of manufacture: 2016 Rated primary voltage U1N: 400 V Rated secondary voltage Ua: 230 V Primary phases: 3 ~ Secondary phases: 1 ~ Frequency: 50 Hz Rjdpfxjyaqzqj Afcop Rated apparent power Sp: 833 kVA Rated primary current I1,p: 1202 A Primary short-circuit current I1cp: 50 kA Secondary short-circuit current I’acp: 10 kA If you have any questions or require further information, please feel free to send us a message or call us.

Condition: excellent (used), Year of construction: 1992, Manufacturer EVG Rsdpjwp Ilysfx Afcep Type TSD 7-25 Machine No. 958 Year of manufacture 1993 Working direction L > R Beam types KT 8… Beam height (mm) 90-250 Carrier length min. (mm) max. (mm) 14,000 Fixed lengths: Yes Cutting pitch (mm) 100/200 Spool unwinder (pcs.) 5 LAR: Yes Wire diameter - 5-12 mm smooth/ribbed Diagonal - 4-7 mm smooth / ribbed Stack height max. (mm) - 500

Condition: refurbished (used), Year of construction: 2025, JAGER welded mesh line U-Gsa-st Full revamped "as new" Technical data 24 pay off for longitudinal wire spools, longitudinal wire straightening equipment Line wire pull off system Longitudinal wire loop Longitudinal wire straightening equipment Cross wire magazine Number of installer line wires : 24 up to 10 mm Diameter of lines wires : 4 to 10mm Diameter of cross wires : 4 to 10mm Rsdpewu Dcxefx Afcjp Separation between line wires : 100, 150, 200, and 300 mm Separation between cross wires : min 30 mm , steplessly programmable Max. length of cross wire (mesh width) 2500 mm , max welding width : 2400 mm Mesh length : min 3000 mm and max . 6000 mm Trafos : 8 x 160 Kva Number of installer line wires: Number of installer line wires : 24 up to 10 mm Diameter of lines wires: 4 to 10mm Diameter of cross wires: 4 to 10mm Separation between line wires: 100, 150, 200, and 300 mm Separation between cross wires: min 30 mm , steplessly programmable Max. length of cross wire (mesh width): 2500 mm Max welding width: 2400 mm Mesh length: 3000 - 6000 mm Trafos: 8 x 160 Kva

Condition: used, Year of construction: 2011, functionality: fully functional, machine/vehicle number: D12E/8151, Offer Number: D12E/8151 Machinetype: wire nail press Rodpowi Tl Eefx Afcjp Make: ENKOTEC Type: NA05 SH Constr. year: 2011 diameter range: 1,8-2,5 mm nail length: 32-57 mm output - pieces/min: 2000 Location: Europe
