Eccentric press

SMERAL LEN 40CA

Year of construction: 2002, condition: used, pressure 63 t throat 315 mm stroke 8-100 mm Cjdpolp U D Tofx Afpsgr no. of strokes 140 Hub/min ram - range of adjustment 63 mm table surface area 1200x630 mm ram surface 800x315 mm hole in the table Ø 110 mm table height 820 mm tool hole in ram Ø 50 mm dayligth 335 mm total power requirement 7,5 kW weight of the machine ca. 5 t

Condition: used, Year of construction: 1970, pressure:63 t throat:250 mm Codpfx Ajcxxx Hefpogr stroke:8-100 mm table depth:710 mm table width:500 mm ram head dimension:450x280 mm ram adjustment:63 mm no. of strokes:140 Hub/min total power requirement:7 kW weight of the machine ca.:3,5 t

Condition: excellent (used), pressure 50 t throat 245 mm stroke 14 / 90 mm ram adjustment 75 mm table height adjustment 150 mm strokes per minute 42/85 table surface area 700 x 490 mm ram surface 400 x 230 mm tool hole in ram 40 mm hole in the table 240 x 140 mm daylight, max. stroke above - ram adjustment above 360 mm total power requirement 4 kW Cgsdpfx Astrhf Asfpor weight of the machine ca. 3,41 t dimensions of the machine ca. 0,8 x 1,75 x 2,1 m Machine was partially overhauled in our house as follows: - disassembly, cleaning and inspection - table milled over - new paintwork of the machine - shaft crack test carried out - disassemble Ortlinghaus clutch and additional brake, clean, check, replaceseals - additional air storage tanks - new control cabinet with safety control and touchscreen display - new wiring of the machine - new Vogel central lubrication system with piping - new Herion press safety valve + maintenance unit - new Balluff cam swith - new 2-hand control panel - new footswitch - Current UVV test with braking time measurement - Machine safe for hand inlay work

Condition: used, Single-Column Eccentric Press WEINGARTEN Type EV 63 Machine No. 738 / 61 Year of manufacture: 1962 Pressing force: 63 tons Throat depth: 260 mm Table size: 630 x 530 mm Table opening: Ø 210 mm Ram area: 315 x 260 mm Adjustable ram stroke: 8–100 mm Ram adjustment: 63 mm Ram shank bore: Ø 40 mm, with clamping piece Installation height: max. 450 mm Strokes per minute: 115 spm Air requirement: min. 4.5 bar Motor power: 4 kW Electrical connection: 380 Volt, 50 Hz Table height above floor: approx. 750 to 900 mm - Electric stroke release via foot switch or two-hand control - Overload protection by shear plate - Clutch-brake combination via WEINGARTEN friction-threaded clutch with TDC safety - Front crankshaft support bearing Cjdsk S Htxspfx Afpsgr - Press table height adjustable via 2 threaded spindles - Manual central lubrication system - Free-standing electrical cabinet - UVV (accident prevention regulations) for manual loading operations Space requirements (L x W x H): 1750 x 1600 x 2430 mm Weight: 4.5 tons In good condition

Condition: used, Year of construction: 2007, pressure 63 t stroke 8 - 120 mm no. of strokes 40 - 120 /min throat 280 mm passage to the back 325 mm dayligth 440 mm table surface area 820 x 580 mm hole in the table 200 mm Csdewc U Inopfx Afpogr table height over floor 830 mm ram surface 470 x 340 mm ram adjustment 100 mm power requirement 4,0 kW Weight 5,2 t dimensions (WxDxH) 1,3 x 1,8 x 2,8 m permitted for manual loading according to the CE-norm with infinitely variable drive, pneumatic clutch/brake combination, light guard (make Sick), hydraulic overload protection in ram, pneumatic counterbalance on ram, manual stroke adjustment, manual ram adjustment, central lubrication, two-hand and foot operation

Condition: used, Year of construction: 1985, Pressure 080 t throat 345 mm stroke 20 - 160 mm no. of strokes 65 /min Cgodpjvuug Nofx Afpsr distance table/ram, max. stroke up, adjustment up 495 mm table surface area 920 x 610 mm table height over floor 800 mm Hole in the table 280 mm passage to the back 670 mm ram surface 650 x 400 mm ram adjustment 50 mm power capacity 10,0 kW weight 7,7 t Dimensions (WxDxH) 1,5 x 2,2 x 3,15 m permitted for manual put-in according to the German Safety Regulations (UVV) with motor, pneumatic clutch, hydraulic overload protection in ram, manual stroke adjustment, motoric ram adjustment, motoric centralized lubrication, two-hand operation Press is at the moment being overhauled electrically and mechanically - video is from before starting the overhaul WITH mechanical partly overhaul, WITH new electrical control Pilz

Condition: good (used), pressing force: 50 t, stroke length: 320 mm, Capacity 50 Ton Throat 225 mm Adjustable stroke 8 - 100 mm Number of strokes 320 p/min Cjdpfx Afstt A T Topegr Ram size 300 x 280 mm Table size 500 x 800 mm Machine LxWxH: 160 x 120 x 260 cm Machine weight: 6 Ton

Year of construction: 1970, condition: used, pressure 63 t throat 440 mm stroke 8-100 mm no. of strokes 65 Hub/min ram - range of adjustment 63 mm table surface area 720x750 mm Codpfx Ajlp U Eqjfpegr ram surface 440x280 mm hole in the table Ø 240 mm table height 830 mm tool hole in ram Ø 40 mm weight of the machine ca. ca. 5,0 t

Condition: used, Year of construction: 1989, Pressure 080 t throat 300 mm Csdpfx Aovuuavofpogr stroke 8 - 140 mm no. of strokes 60 / 90 /min distance table/ram, max. stroke up, adjustment up 420 mm table surface area 800 x 600 mm hole in the table 330 x 230 mm table adjustable 230 mm table height over floor 750 - 980 mm ram surface 600 x 240 mm ram adjustment 100 mm power capacity 4,5 / 6,9 kW Weight 5,5 t Dimensions (WxDxH) 1,4 x 2,5 x 2,6 m permitted for manual put-in according to the German Safety Regulations (UVV) with motor with 2 speeds, hydraulic clutch/brake combination, hydraulic overload protection in ram, manual stroke adjustment, manual ram adjustment, adjustable table, manual central lubrication, two-hand and foot operation press can be inspected in running condition in our warehouse

Condition: good (used), Year of construction: 1984, functionality: fully functional, pressing force: 63 t, Band saw LEN63C Cedpfeu Nkfuox Afpsgr
