Sorting machine Scheider Sorter

Steinert ISS 100

Year of construction: 1979, condition: ready for operation (used), A Gebr. Pfeiffer ball mill is available. Drive power: 330kW, diameter: 2400mm, length: 5000mm, number of motors: 2, motor weight: 180kg, flywheel width: 3.2mm. On-site inspection is possible. Itsdpfxov Dwire Ahusb

Condition: excellent (used), functionality: fully functional, machine/vehicle number: 92 880 13, opening: approx. 1.030 x 720 mm rotor-Ø x –width: 1.000 x 1.000 mm Iedpfx Ajlhrufohustb weight: approx. 13 t.

Condition: good (used), Double-toggle jaw crusher Manufacturer: O&K Jaw width: approx. 1,000 x 850 mm In stock Iedpfx Ahev Rp N Rjuotb

Condition: used, Manufacturer: SatrindTech Srl Type: F 810 Mach.No.: 65489 Shredding Chamber size : 850 x 590mm. Ijdpfx Ahewvk A Ueuetb Distance between shaft centres: 215mm. With 15 kW Electrical motor. Crushers will be overhauled, sandblasted and painted.

Condition: excellent (used), Year of construction: 2014, IFE eddy current separators are used for separating non-ferrous metals (aluminium, copper, brass, etc.) from all types of bulk material. IFE eddy current separator, central system INP including discharge hood, feeder tray, support frame, and control unit. Working width: 2000 mm Rotational speed: 2500 rpm Main drive: 11 kW Iedpfxowxfqro Ahuetb Conveyor drive: 2.2 kW Weight approx. 3200 kg Dimensions incl. discharge hood: L = 4300 mm W = 2900 mm incl. main drive H = 1250 mm incl. discharge hood IFE feeder tray, type: UE-1900x2000 F-2LM865T Working length = 2000 mm Working width = 1900 mm 2x vibration motors Dimensions LxWxH 2230 x 2200 x 1900 mm Weight approx. 1300 kg Support frame made of steel girders, platforms, stairs, discharge plate. Very well-maintained control cabinet with control system available. Machine available immediately.

Condition: good (used), Year of construction: 1995, shredding by 3 HARDOX-coils (spirals) diameter x length: approx. 500 x 1.700 mm opening: approx. 1.100 x 1.700 mm Itodpsl I Dx Nsfx Ahusb new base frame with steel construction new feed-hopper 8 m³ new control cabinet incl. 7 unused spare coils

Condition: used, Technical data IFE cascade screens (vibrating waste screens): Itsdpfx Aju Tg Rrehueb Manufacturer IFE Aufbereitungstechnik GmbH, Austria Type SM 2400 x 5000 F - UW30 Year of construction 2009 Drive motor 22 kW Rated current 43 A Screen dimensions overall 5,000 x 2,400 mm (l x w) Dimensions of individual sieve segment 950 x 800 x 130 mm (l x w x d) Screen hole grid 150 x 125 mm Length of screen fingers (steel tubes in front of the screen segments) 400 mm Swing width max. 18.5 mm Weight approx. 6,600 kg Possible applications: The waste screen is suitable for use in plants for sorting household waste, commercial and industrial waste, paper and cardboard, scrap metal and electrical waste. Blockage-free screening with the most difficult feed materials, with high throughput capacity, no pigtail formation with oversize particles, loosened oversize particle discharge over the entire screen width and no downtimes for screen cleaning are the greatest advantages of this plant technology. Remark: The screen plates / screen segments have been covered with steel plates without a screening function over the course of time for use in the paper sorting system. The steel plates are only attached and can be removed again. Remarks on the overall layout: Technical documentation for the machine is only available in German. An inspection of the machine is possible by arrangement. We do not accept any liability for the technical data or any errors.

Condition: ready for operation (used), Steinert Electro Magnetic Drum Brand: Steinert Dimension drum : Lenght 1300 mm , Ø 500 mm. Driving: 4 kW Gearbox. Power drum = 3 kW. Itedpfou Tlr Ijx Ahusb Including new rectifier.

Year of construction: 2003, condition: reconditioned (used), Overhauled machine Disassembled ready for transport in container (2) Anti-wear linings New bearings Passing capacity 160 Tm hour Iodpoizkxwjfx Ahujtb Motor from 50 kw to 150 Kw depending on needs. Current motor installed 75 kw

Year of construction: 2025, condition: new, The Zig-Zag Air Separator by Koltex Plastic Recycling Systems enables efficient separation of bulk materials into fractions with different densities. The material to be separated is fed into the device via a rotary valve, ensuring even distribution across the entire cross-section of the separation channel. Itjdpfjvmxvfox Ahujb Sorting is carried out using an upward airflow generated by a high-performance blower. The air flows through the separator channel, lifting lighter particles while heavier fractions fall downward due to gravity. The specially designed Zig-Zag channel forces the material to pass through the airflow multiple times at each turn. Lighter fractions are effectively lifted and discharged through the top airflow, while heavier particles remain and fall, ensuring precise and efficient separation. The separator is equipped with advanced dust extraction cyclones with filters that eliminate dust emissions throughout the process. This ensures not only high separation efficiency but also environmental safety and workplace cleanliness. Koltex Plastic Recycling Systems also offers high-quality shredders, which can be integrated at the start of the process to create a complete grinding line with the separator. This solution enables comprehensive material processing, from shredding to precise separation, providing full control over the recycling process.
