Sorting machine Scheider Sorter

Steinert ISS 100

Condition: used, Year of construction: 2007, System: Mobile sludge dewatering system, mobile decanter/centrifuge Manufacturer: Hiller Model: Solid bowl screw centrifuge Type: DP51 Mach. no.: H3991 Year of manufacture: 2007 Maximum drum speed: 3400 l/min Drum inner diameter: approx. 505 mm Drum material: ST52.0 Drum wall thickness: 13.0 mm Other: Steel exchange case with reinforced base, Accessories: Pump for sludge inlet, flocculant suction pump, flocculant solution pump Flocculant station: 2 chamber system for liquid polymers with agitator, adjustable Kdjdpfevz Dnpex Anwsn Double shaft paddle mixer: galvanized steel Total weight: approx. 4200 kg Purchase and rental possible.

Condition: used, Plant: Mobile sludge dewatering plant, decanter / centrifuge mobile Manufacturer: Hiller Model: Solid bowl screw centrifuge Type: DP45-422 Kdjdpfxsppddyo Anwjn Machine No.: H3480 Year of construction: 2006 Maximum permissible: Drum speed 3800 I/min Inner diameter: Drum 450 mm Drum material: H2/St52 Electric motor: yes Other: steel exchange case with reinforced bottom, accessories: pump for sludge inlet, flocculant suction pump, flocculant release pump Flocculant station 2 chamber system for liquid polymers with agitator , adjustable Double shaft paddle mixer galvanized steel Total mass : approx. 3200 kg Purchase and rent : possible.

Condition: used, Year of construction: 1991, Flottweg three-phase decanter, Z4D-3/441, last used in a fruit juice plant. Inner drum diameter: 420 mm Inner drum length: 1245 mm Drum wall thickness: 10 mm The medium to be separated is fed into the hollow center axis of the decanter. Centrifugal force causes the solids to collect on the drum shell. A cylindrical-conical screw conveyor transports the ring of solids to the discharge openings, where it is ejected into the solids housing. The two liquid components separate according to their specific density and form two hollow liquid cylinders. The diameter of the liquid rings can be adjusted using a peeling disc and overflow weir. One of the two phases is discharged without pressure and one is discharged under pressure via the paring disc. The moisture content of the solids and the purity of the liquids can be controlled by: - Varying the phase separation discs and paring diameter - Decanter speed - Screw speed Additional title: 3-phase decanter Max. bowl speed: 4000 r/min Max. sediment-density: 1 g/cm³ Kodpfxeyr Iccs Anwodn Max. ambient temperature: 100 °C Mass moment of inertia: 15.5 kgm2 with an empty drum Weight: 2250 kg Material: housing from stainless steel 1.4301 (AISI 304); drum made of high-strength cast stainless steel 1.4463 Position: free standing Base construction: Horizontal decanter drum in steel frame, on square tube frame with dome feet Features: Base with rubber mountings, electric motor (Loher 180 M, 22 kW)

Condition: good (used), Year of construction: 1995, shredding by 3 HARDOX-coils (spirals) diameter x length: approx. 500 x 1.700 mm opening: approx. 1.100 x 1.700 mm new base frame with steel construction Kdjdpfxel I Dx No Anwen new feed-hopper 8 m³ new control cabinet incl. 7 unused spare coils

Year of construction: 2003, condition: reconditioned (used), Overhauled machine Disassembled ready for transport in container (2) Anti-wear linings Kodpfoizkxwex Anwedn New bearings Passing capacity 160 Tm hour Motor from 50 kw to 150 Kw depending on needs. Current motor installed 75 kw

Year of construction: 2022, operating hours: 975 h, condition: used, functionality: fully functional, overall weight: 9,600 kg, total length: 6,050 mm, total width: 2,450 mm, total height: 2,700 mm, machine/vehicle number: B0501, The MAGNETIC DRUM consists of a two-stage drum magnetic separation system designed to remove all magnetic particles from a material stream. Because the intensity of both magnetic drums can be selected and each drum can be activated or deactivated as needed, this module is highly flexible and can always be adapted to the specific properties of the feed material. The dual magnetic separation enables higher purity levels while maintaining constant throughput. This module is part of our rental fleet. Ksdpfxoxt Dqqj Anwodn

Year of construction: 2025, condition: new, The Zig-Zag Air Separator by Koltex Plastic Recycling Systems enables efficient separation of bulk materials into fractions with different densities. The material to be separated is fed into the device via a rotary valve, ensuring even distribution across the entire cross-section of the separation channel. Sorting is carried out using an upward airflow generated by a high-performance blower. The air flows through the separator channel, lifting lighter particles while heavier fractions fall downward due to gravity. The specially designed Zig-Zag channel forces the material to pass through the airflow multiple times at each turn. Lighter fractions are effectively lifted and discharged through the top airflow, while heavier particles remain and fall, ensuring precise and efficient separation. Kjdpfxovmxvfo Anwedn The separator is equipped with advanced dust extraction cyclones with filters that eliminate dust emissions throughout the process. This ensures not only high separation efficiency but also environmental safety and workplace cleanliness. Koltex Plastic Recycling Systems also offers high-quality shredders, which can be integrated at the start of the process to create a complete grinding line with the separator. This solution enables comprehensive material processing, from shredding to precise separation, providing full control over the recycling process.

Condition: used, Year of construction: 1991, Allis Chalmer 60 109 M-II Primary Gyratory Crusher 2 complete units, intake size: 1,500 mm (60 inches), cone diameter: 2,725 mm (109 inches), output size: 175 to 250 mm (7 to 10 inches), throughput: approx. 4,700 to 6,400 t/h, without electric motor (required drive power: 750 kW), including one hydraulic hammer each, total weight: approx. 570 t per unit Ksdpfx Anovg A Rajwsdn

Condition: ready for operation (used), Year of construction: 2003, A self-cleaning disc stack centrifuge (disc separator) GEA is available. Drum speed range: 4000-4800rpm, drum diameter: 682mm, max. feed density liquid/solids: 1.1kg/dm³/1.3kg/dm³, drum volume: 125l. An on-site inspection is possible. Kjdpfxjydpz Do Anwsdn

Condition: excellent (used), functionality: fully functional, Westfalia Separator AG CIP System Westfalia Separator AG CIP System | Tank, Pump, Heat Exchanger System type: CIP (Cleaning In Place) Manufacturer: Westfalia Separatoren AG / GEA Group A complete CIP (Cleaning In Place) installation from the renowned manufacturer Westfalia Separator AG, designed for automatic cleaning and disinfection of process lines in the food and dairy industries. The system is equipped with stainless steel tanks with heating jackets, recirculation pumps, a GEA Ecoflex plate heat exchanger, and a control cabinet. Main components of the system: 1. Stainless steel CIP tanks Brand: Westfalia Separator AG Type: CIP-TANK 3000 L (2 pcs) Serial numbers: 96/00408-1 and 96/00408-2 Year of manufacture: 1996 Capacity: (2×) 3300 liters Operating pressure: 0 bar Operating temperature: 80 °C Dimensions: (2×) 3000 × 1900 × 2300 mm 2. Stainless steel platform with stairs Dimensions: 2950 × 2200 × 2400 mm 3. Stairs Dimensions: 600 × 600 × 500 mm 4. Centrifugal pump Brand: Hilge Type: EURO-HYGIA-B-SUPER-II/60 B Number: 23/96/11349 Capacity: 30 m³/h Power: 11.0 kW Dimensions: 750 × 350 × 450 mm 5. Flow meter Brand: Endress + Hauser Model: Promag 53 Dimensions: 350 × 200 × 200 mm Accurate flow measurement for CIP media. 6. Anema centrifugal pump Dimensions: 530 × 300 × 300 mm 7. Plate heat exchanger Brand: GEA Ecoflex GmbH Type: VT20 CDS Serial number: 170/13832 Dimensions: 900 × 550 × 1500 mm High efficiency heat transfer for CIP solution preparation. 8. Control cabinet Dimensions: 670 × 220 × 800 mm Kjdpfoxtvb Usx Anwedn Responsible for controlling and monitoring CIP system operation. 9. Stainless steel buffer tank (CIP tank) Tank dimensions: Ø 800 × 800 mm Overall dimensions: 1150 × 900 × 1770 mm 10. Anema centrifugal pump, number: 32078 Operating pressure: 12 bar Dimensions: 650 × 400 × 450 mm The Westfalia Separator AG CIP system is a comprehensive solution for cleaning process installations, providing: - high process hygiene, - monitoring of cleaning parameters (temperature, flow, time), - integration capability with dairy, food, or beverage production lines. The use of components from GEA, Hilge, Endress + Hauser, and Anema ensures reliability and long service life of the system.
