THERMO FORMING MACHINE

TFT IMC 5030 (MIT WERKZEUGEN)

THERMO FORMING MACHINE TFT IMC 5030 (WITH TOOLS)

Equipment / Additional information:
unwinding:
Roll recording: easy
Max roll diameter: mm 1000
Settlement: automatically
Thermoforming machine:
Maximum tool dimensions: mm 520x330
Pos. Molding height max .: 15 mm
Neg. Molding height max .: 120 mm
Sheet width: mm 150/760
Movement Step: mm 50/330
Max HIPS film thickness: 1.8 mm
Hub of the sub-table: 150 mm
Clamping force: 7500 Kg
Inst power top heater: 18.8 Kw
Inst power under heater: 14.1 Kw
Idle clock speed: per minute 40th
power main drive motor: 2.2 Kw
Engine power. Film feed: 0.75 Kw
Air operating pressure: Kg / cm2 7
Water consumption at 12 °: 1t / 1` approx.30
Air consump. at 7 kg / cm2: 1t / cycle 125
Installed power: Kw 50

9xTool:

Article no. // Tool no. // Cavities // Description / Product:

3599 // 457 // 10 // Vending machine cup capacity/capacity/contenance=223ml

593 // 460 // 8 // Coffee-to-go / thermo mug / thermo cup
Filling capacity / Capacity / Contenance=300ml / 12 oz

509 // 452 // 6 // Ice cream cup: filled to the brim=140ml /
Filling capacity with headspace 6mm: 120 ml

591 // 459 // 10 // Thermo mug ⌀ 81/180ml

740 // - // - // Standard cup with sealing edge ⌀ 75-120ml

3589 // 458 // 12 // Coffee-to-go / thermo mug / thermo cup:
Filling capacity / Capacity / Contenance=80ml

Hfjdpfx Ajn D Ew Isfpon
595 // 456 // 10 // Vending cup / Gobelet pour automate:
Filling capacity / Capacity / Contenance=150ml

210 // - // - // Baking case / technical part / plate or tray

8000 // 455 // - // Granule cup 180 ml / technical part with flat sealing edge
