Center lathe

TNM CS6266C

Condition: used, TECHNICAL DETAILS - maxi bar diameter : 12.7 [mm] - main headstock strokes (fixed/rotary sleeve) : 130/80 [mm] - spindle power : 4 [kW] - rotation speed : 12 000 [rpm] - upper turret : 6 positions - lower turret : 6 positions - number of rotary positions on turret : 6 - sub-spindle maxi diameter : 12.7 [mm] - sub-spindle rotation speed : 12 000 [rpm] Gedpfouhav Djx Aa Isbg - dimensions : 2850 x 110 x 1480 [mm] - hours in production : 12408 [H] - spindle hours : 9400 [H] EQUIPMENT - CNC TRAUB TX 8i control - bar feeder LNS Alpha ST 320 - C axis on main spindle and sub-spindle - brake on main spindle and sub-spindle - parts catcher with conveying strip - anti fire device - lubricating tank with pump with cooling unit - chip conveyor - various fixed and driven tool holders

Condition: excellent (used), Year of construction: 2013, functionality: fully functional, collet bore: 32 mm, turning length: 320 mm, turning diameter: 32 mm, total length: 2,640 mm, total height: 1,840 mm, total width: 1,400 mm, spindle speed (max.): 8,000 rpm, overall weight: 3,500 kg, rotational speed (max.): 8,000 rpm, coolant tank capacity: 16 l, power: 75 kW (101.97 HP), Equipment: rotational speed infinitely variable, Doosan Puma ST32G Sliding Head CNC Lathe Machine Type: Sliding Head CNC Lathe Year: 2013 - Installed in late 2014 Control: Fanuc Series 31i - Model B Condition: Excellent Includes LNS Express 332 S2 Bar Feed LNS Swarf Conveyor Losma Mist Extractor LNS Mist Extractor(Spare) Parts Conveyor Manuals Technical Specifications Max Machining Diameter: 32mm Max Main Spindle Stroke: 320mm Max Drilling Capacity: 13mm Max Tapping Capacity: M12 x 1.75mm Max Milling Capacity: 8mm Main & Sub Spindle Speeds: 8000rpm Main Spindle Power: 7.5kW Sub Spindle Power: 3.7kW X1 Axis Travel: 114mm Z1 Axis Travel: 320mm Y Axis Travel: 404mm C1 Axis Travel: 360 deg X2 Axis Travel: 393mm Z2 Axis Travel: 343mm C2 Axis Travel: 360 deg Rapid Traverse all Axes: 32m/min Front Tool Stations: 20 Back Tool Stations: 4 Driven Tool Speeds: 8000rpm Coolant Tank Capacity: 160L HP Coolant: No Coolant Flow Rate: 200L/min Power Supply: 22Kva Gsdpjtwy N Esfx Aa Iobg Machine Dimensions: 2640 x 1400 x 1840mm Machine Weight: 3500kg

Condition: used, Year of construction: 2000, functionality: limited functionality, overall weight: 8,000 kg, type of input current: AC, Equipment: documentation/manual, Curd pre-pressing vat with a capacity of 12,000 litres and filling station cheese moulds from Tetra Pak Tebel. Year of manufacture 1999. In good condition, but with obsolete automation/PCL. We can provide PLC replacement and refurbishment on request. Available to visit. Documentation available. Gbjdjulnrvopfx Aa Ieg

Condition: ready for operation (used), Year of construction: 2001, operating hours: 41,000 h, functionality: fully functional, turning diameter over cross slide: 400 mm, spindle bore: 66 mm, spindle speed (max.): 4,000 rpm, travel distance X-axis: 200 mm, travel distance Z-axis: 600 mm, Equipment: documentation/manual, rotational speed infinitely variable, 2-axis CNC lathe in perfect working order Year 2001 and maintained. Very reliable machine (in 20 years, spindle and clamping pot have been rebuilt once and hydraulic accumulator) HEIDENHAIN Turn Plus IT CNC (conversational and ISO) 12-station VDI 30 turrets Very precise and rigid, suitable for quality 5 (Heidenhain scale on the X axis) Chip conveyor Part catcher arm, diameter 66, length 100 Gbodpswb Eqdsfx Aa Ijg Hydraulic counterspindle (pedal) 400/400V isolation transformer 210mm hydraulic Autoblock chuck with pressure compensator (for clamping thin parts) 66mm spindle bore Pre-equipped bar feeder 41,000 operating hours (see hour meter) All original documentation and invoices (few).

Year of construction: 1999, condition: used, functionality: fully functional, machine/vehicle number: 99031, DD Motor 27.9KW; 2655 RPM Automatic feeding system MAAG gear Pump; Type: EXTREX EX 28 - 4STE with control system MAAG; Type: MAAX 5 Input and Output pressure sensors (up to 350 Bar) on the gear pump Possibility to add Inox tank 2m length * 0.45m width with possibility to apply calibration system: Godpfx Aswqrprea Ijbg - Equipped with vacuum pump, 8 exits vacuum collector and cooling collector with 8 exits. - Manual adjustments: right/left, up/down, forward/backwards

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, travel distance X-axis: 750 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 430 mm, rapid traverse X-axis: 20 m/min, rapid traverse Y-axis: 20 m/min, rapid traverse Z-axis: 20 m/min, controller manufacturer: GSK, controller model: GSK218MC-V, spindle speed (max.): 8,000 rpm, number of slots in tool magazine: 21, CINCINNATI ARROW 750 GARANTIA: 2 ANOS Servomotores de eixo com encoder absoluto de 25 bits (sem pilhas). X e Y - 6N/m Z - 12 N/m Spindle de 7.5KW com 8000 Rpm máximo. Cursos de: X 750 mm Y 500 mm Z 430 mm Armazém de ferramentas do tipo umbrela com 21 ferramentas Cone BT40 Rápidos de 20m/min Controlador 218MC-V da GSK Ecrã policromático Comunicação por rede, rs232 ou USB Controlador preparado para maquinação de alta velocidade Comando MPG portátil incluído Quadro elétrico completamente refeito com material de alta qualidade (Disjuntores de nível industrial 10KA Schneider, disjuntores motores de periféricos da Schneider, fonte de alimentação Weidmuller, contactores da Schneider, relés da Weidmuller) Transformador trifásico para alimentação do sistema CNC novo incluído Sensores da máquina novos, Bomba de água nova, cablagem nova. Lubrificação da Spindle e rolamentos através de central de lubrificação com acionamento pneumático, testada e funcional. Forras telescópicas em inox originais nos eixos X e Y, lona no Z. ----- CINCINNATI ARROW 750 2 YEAR WARRANTY Axis servo motors with 25-bit absolute encoder (without batteries). X and Y - 6N/m Z - 12 N/m 7.5KW spindle with 8000 Rpm maximum. Strokes of: X 750 mm Y 500 mm Z 430 mm Gbedpsv U Dncsfx Aa Iog Umbrella-type tool magazine with 21 tools Taper BT40 Rapid 20 m/min GSK 218MC-V controller Colour screen Network communication, RS232 or USB Controller prepared for high-speed machining Portable MPG control included Electrical panel completely redone with high quality material (Schneider industrial grade 10KA circuit breakers, Schneider peripheral motor circuit breakers, Weidmuller power supply, Schneider contactors, Weidmuller relays) New three-phase transformer for powering the CNC system included. New machine sensors, new water pump, new wiring. Spindle and bearing lubrication through a pneumatically driven lubrication center, tested and functional. Original stainless steel telescopic linings on the X and Y axes.
