Press brake

Trumpf TrumaBend V130

Condition: excellent (used), functionality: fully functional, Year of construction: 2001, Including basic set of tools. Lisovací síla 130 t Fedpfexuqfkjx Aa Nogi Délka ohranění 3060 mm Vzdálenost mezi stojany 2690 mm Zdvih 365 mm Rozměry stroje dxšxv 3640x2060x2885 mm Hmotnost stroje 12950 kg

Condition: ready for operation (used), Year of construction: 2000, operating hours: 39,700 h, Control Unit Brand DELEM Model DA 65 Additional Equipment CNC electro-hydraulic press brake / CNC Control Model: DELEM CNC control model DA 65 / Swivel control panel, front left / 2D graphic programming & product display / Tool & program library / CNC Controlled Axes: Y1 + Y2 / X / R / Z1 + Z2 / I axis / CNC Controlled Backgauge (X axis) / CNC-Controlled Height Adjustment of the Backgauge (R axis) / CNC-Controlled Adjustment of the Fence Fingers (Z axis) / CNC-Controlled, Pneumatic Die Adjustment (I axis) / WILA Manual Table Crowning, incl. Analog Value Display / TRUMPF Hydraulic Upper Tool Clamping / TRUMPF Manual Lower Die Clamping / 1x Free-Moving 2-Hand / Foot Control / Rear Safety Device (Sliding Door) This 4-axis TRUMPF TrumaBend V130 press brake was manufactured in 2000. It features a CNC electro-hydraulic system with DELEM CNC control, offering precise bending with a pressure of 130 tons and a folding length of 3060 mm. The machine includes multiple CNC-controlled axes for enhanced flexibility and accuracy in operation. Consider the opportunity to buy this TRUMPF TrumaBend V130 press brake. Contact us for more information about this machine. Fgsdpfoxnd Ufsx Aa Noi Application Types Bending

Condition: used, functionality: fully functional, Year of construction: 2002, operating hours: 319 h, machine/vehicle number: B0104S0007, control type: NC control, degree of automation: manual, actuation type: electric, controller manufacturer: Pilz siehe Foto, working width: 3,000 mm, stroke length: 365 mm, throat depth: 850 mm, number of axes: 6, type of crowning: CNC-controlled, back gauge adjustment: CNC-controlled, input voltage: 400 V, input current: 47 A, Equipment: CE marking, documentation/manual, emergency stop, foot remote control, Used but well-maintained hydraulic press brake with low operating hours Manufacturer: TRUMPF Model: TrumaBend V130 Fgodpfx Asxl Scxja Noi Year of manufacture: 2002 Technical Data Manufacturer: Trumpf Model: TrumaBend V130 Year: 2002 Operating hours: 319 h (read) Press force: max. 1300 kN Stroke: max. 365 mm Operating pressure: max. 340 bar Connected load: 18.8 kVA Compressed air connection: 6 bar Weight: 12,950 kg

Condition: used, Year of construction: 1997, pressure 130 t chamfer lenght 3060 mm distance between columns 2690 mm column arm 410 mm stroke 365 mm dayligth 535 mm ajustment speed 200 mm/sec working feed 1.0 - 10.0 mm/sec return speed 135 mm/sec table width 120 mm table height 1050 mm tiltable up to +/- 10.0 mm Number of working hours ca. 31.800 h compressed air 5.0 - 7.0 bar oil volume 250 l operating pressure 340 bar voltage 400 V total power requirement 23.0 KVA weight of the machine ca. 12950 kg range L-W-H 3660 x 2310 x 2900 mm Machine in a well-maintained condition (!!) with only approx. 31.800 operating hours - in checked condition - machine video - ?v=PBV-MDtZnlE Equipment: - CNC electro-hydraulic press brake - DELEM CNC control model DA 65 * swiveling control panel, front left Fjdpfsxacfmsx Aa Nogi * 2D graphic programming & product display * Tool & program library * USB keyboard and mouse interface - CNC controlled axes: Y1 + Y2 / X1 + X2 / R1 + R2 / Z1 + Z2 / I axis - CNC controlled back stop (X1 + X2 axis) - CNC controlled height adjustment of the back stop (R1 + R2 axis) - CNC controlled adjustment of the stop fingers (Z1 + Z2 axis) - CNC controlled, pneumatic die displacement (I axis) - CNC WILA electro-motoric table crowning - TRUMPF hydraulic upper tool clamping - TRUMPF manuel Lower tool clamp - 1x freely movable 2-hand / foot control - Safety device at the rear (sliding door) - Safety device at the side (swinging door) - Original operating instructions + spare parts list

Condition: excellent (used), Year of construction: 1999, Technical Data: Working length: 3050 mm Fgjdpfx Ajw Tcncsa Nji Distance between uprights: 2690 mm Pressing force: 130 t CNC control: DELEM Adjustable backgauge Controlled axes: Z1 / Z2; X; R CNC-controlled crowning Installation height: 535 mm Stroke: 365 mm Throat depth: 410 mm Hydraulic tool clamping top and bottom Ram position measuring system with spring-back compensation via glass scales Program-controlled lower tool shifting (I-axis) for 2 positions Motor power: 12.5 kW Number of backgauge fingers: 2 CE mark Dimensions (L x W x H): approx. 3800 x 2350 x 3150 mm Weight: approx. 14 tonnes Condition: Good condition The seller is not liable for typing or data transmission errors. The machine's appearance, technical condition and wear correspond to its age; used machines are sold without any warranty.

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2000, machine/vehicle number: 885669, bending force (max.): 130 t, working width: 3,050 mm, stroke length: 365 mm, throat depth: 410 mm, clearance between the columns: 2,800 mm, TECHNICAL DETAILS Pressing force: 130.0 t Working area Working width: max. 3,050 mm Max. stroke: 365 mm Throat depth: 410 mm Distance between columns: 2,800 mm Number of axes: 6 Control Control: CNC Control type: Delem DA65 Controlled axes: Y1-Y2 + X-R-Z1-Z2 + I + crowning Fgjdpfow Dqckex Aa Nsi MACHINE DETAILS Dimensions and Weight Overall length: 3,500 mm Overall width: 2,200 mm Overall height: 2,400 mm Weight: 11,000 kg EQUIPMENT WILA hydraulic clamping Angle measurement system Documentation CE marking

Condition: ready for operation (used), Year of construction: 1998, operating hours: 34,327 h, This 5-axis TRUMPF TrumaBend V130 press brake was manufactured in 1998. It features a 3-meter bending length and a 130-ton capacity, with a stroke of 215mm. If you are looking to get high-quality bending capabilities, consider the TRUMPF TrumaBend V130 machine we have for sale. Contact us for more information about this machine. Fsdpoxnd Tbjfx Aa Negi Application Types Bending

Condition: used, Year of construction: 1996, pressure 130 t Fsdpfxoxabqbe Aa Nogi chamfer lenght 3060 mm distance between columns 2690 mm column arm 410 mm stroke 215 mm dayligth 385 mm ajustment speed 200 mm/sec working feed 1-10 mm/sec return speed 135 mm/sec table width 120 mm table height 1050 mm tiltable up to +/- 10 mm Number of working hours 53.820 h compressed air 5.0 - 7.0 bar oil volume 250 l operating pressure 340 bar voltage 400 V total power requirement 16.0 KVA weight of the machine ca. 11250 kg range L-W-H 3640 x 2210 x 2375 mm - in checked condition - machine video - ?v=23IbxRaZ2KA Equipment: - CNC electro-hydraulic press brake - including DELEM CNC control model DA 65 * swiveling control panel, front left * 2D graphic programming & product display * tool & program library * including new TFT-LCD industrial monitor - CNC controlled axes: Y1 + Y2 / X / R - CNC electro-motor / controlled back stop (X axis) - CNC electro-motor / controlled height adjustment (R axis) - manual adjustment of the 2x stop fingers, from the front (Z axes) - manual adjustment of the die displacement, from the front (I axis) - WILA manual table crowning, including analog value display - TRUMPF hydraulic upper tool clamp - TRUMPF manual lower tool clamp - 1x freely movable 2 hand / foot control - Safety device at the rear (sliding door) - Safety device at the side (swinging door) - Original operating instructions + CE declaration + circuit diagram

Condition: excellent (used), Year of construction: 2000, Technical specifications: Working length: 3050 mm Distance between columns: 2690 mm Press force: 130 t CNC control: DELEM DA65 2 D graphic Adjustable backgauge Controlled axes: Y1 / Y2; X; R; I CNC table bending compensation: Wila Moducrown Hydr. Tool clamping at the top and bottom Pneumatic tool shifting Number of bending aids: 2 Installation height: 535 mm Stroke: 220 mm Thrust: 410 mm Motor power: 12.5 kW CE mark Dimensions (length x width x height): approx. 3800 x 2350 x 3150 mm Fgodpfx Aaswimvwo Noi Weight: approx. 14 tons Accessories: 1 set of standard tools Condition: Good condition, tools in mint condition The seller is not liable for typographical or data transmission errors. The machine's appearance, technology, and wear are consistent with its age; used machines are sold without any warranty.

Year of construction: 2004, condition: ready for operation (used), Additional Equipment Standard Equipment: Sturdy machine frame with welded, all-steel construction / Pressure beam with high bending strength / Electro-hydraulic top drive via proportional valves / Modern block hydraulics / Modufix upper tool holder system, manual and hardened / Lower tool holder for EV dies, manual clamping, programmable displacement / Safety device / CNC crowning / Prepared for BendMaster / Machine Equipment Upgrades: Increase in installation height and stroke by 150 mm each / Backgauge system with 6 axes and control cabinet air conditioning / Hydraulic and hardened upper tool clamping / Hydraulic lower tool clamping / Further Options: Prepared for ACB® / 3D control system with color display / Network / 6-axis sensor system / BendMaster (Standard Equipment): Sturdy base body with welded, steel construction / Lightweight handling arm in cast aluminum construction / Low floor travel, running to the right (travel 2750 mm) / Sheet metal sensor integrated in the C-axis arm / Rotary feedthrough for cable harnesses in the D-axis / Prepared for automatic gripper change / Sensor system for 4 axes backgauge / Vacuum generation / Safety fence with safety device and 3 sliding doors / Control system: Operator terminal with additional external I-PC / BendMaster Extension: Extended floor travel (travel 2000 mm) Fjdpsxd H Utjfx Aa Nsgi This TRUMPF Trumabend V130 press brake was manufactured in 2004. It features a sturdy all-steel frame, electro-hydraulic top drive, and a 6-axis backgauge system. Equipped with a CNC crowning and a 3D control system with a color display, it ensures precision and ease of use. Consider the opportunity to buy this TRUMPF Trumabend V130 press brake. Contact us for more information about this machine. Application Types Bending
