WEINIG UNIPLAN

Condition: used, Year of construction: 2005, Unimat 23 E: Working width (with cutter circle 140 mm): 20 – 230 mm. Working height (with cutter circle 163 mm): 8 - 120 mm. 1st spindle lower horizontal spindle: 7.5 kW, 2nd spindle right vertical spindle: 11 kW (shared with left vertical spindle), 3rd spindle left vertical spindle, 4th spindle upper horizontal spindle: 7.5 kW. Each spindle diameter: 50 mm. Each spindle speed: 8,000 rpm. Feed system: 4 kW. Mechanical feed, steplessly adjustable: 5-24 m/min. Working table: 2.5 m long (incl. joining fence). Lsdpfsvvkciox Ac Heak Uniplan 23: Max. working width: 230 mm. Working height min.: 15 mm / max.: 120 mm. Feed: 3 kW. Horizontal spindles each 5.5 kW. Feed speed, steplessly adjustable: 6 – 36 m/min. Spindle speed: 6000 rpm. Spindle diameter: 50 mm. Tool clamping length: 240 mm. Max. tool diameter: 163 mm. Fixed lower chip removal: 0.5 mm. Short piece package for min. workpiece length: 280 mm. Mechanical spindle brakes up to 7.5 kW. Feed braking system up to 5.5 kW. 1st feed roller synchronized with photocell. Spindle speed 7200 rpm, incl. motor power 7.5 kW. Improved noise insulation of the full safety enclosure. Location: Customer

Condition: used, Available: No. 1 and No. 2 Used control cabinet of a Weinig type Uniplan as a spare parts carrier or for the new construction of a control cabinet with control panel. Lodpjt Snzwsfx Ac Heak

Condition: good (used), Year of construction: 2004, Weinig Unimat 23 EL Year of manufacture: 2004 Working width: 230 mm, Working height: 120 mm 1. Bottom spindle with 7.5 kW motor and spindle brake 2. Right spindle with separate motor, 7.5 kW and spindle brake Speed: 8,000 rpm with high-performance ball bearings, NC-axis with frequency inverter, axial stops milled to 35 mm height 3. Left spindle with separate motor, 7.5 kW, speed 8,000 rpm with high-performance ball bearings, NC-axis with frequency inverter, radial pneumatic pressure guide left for varying workpiece widths up to 200 mm 4. Top spindle with 7.5 kW motor and spindle brake, speed 8,000 rpm with high-performance ball bearings, NC-axis radial Pneumatic axial control, adjustment range 40 mm, glazing bead ejection, pneumatically cycled. - Infeed system with 4 kW motor and infeed brake - Short piece package - UC-Matic package consisting of: PLC control, central motor start, parts monitoring, operator terminal, free-standing control cabinet, free-standing operating panel, magnetic interlock for safety cover - Enhanced sound insulation - Automatic planing and feeding system for different workpiece lengths and widths Workpiece dimensions Length: 400 – 3,500 mm (4,000 mm) Width: 40 – 200 mm Thickness: 20 – 100 mm Ledjwyuluspfx Ac Hoak Powered conveyor belt Belt width 250 mm, conveying length 4,500 mm, additional photoelectric sensor for signal transmitter Weinig Hydro Finish Planing Machine Uniplan 23 Year of manufacture: 2004 Working width: 230 mm, Working height: 120 mm 1. Bottom spindle with 7.5 kW motor and spindle brake, speed 7,200 rpm 2. Top spindle with 7.5 kW motor and spindle brake, speed 7,200 rpm, NC-axis radial - First feed roller cycled with photocells - NC-axis for separate feed height adjustment - Improved sound insulation - UC-Matic package - 2 hydro straight cutter blocks 501 with HSS strip planer knives 30 mm x 3 mm, max. 9,000 rpm, dimensions 163 mm x 230 mm x 50 mm, Z=4

Year of construction: 1995, condition: good (used), planing width 220 mm planing height 140 mm tool diameter max 160 mm 2 x 5.5 kW main engines 3 kW feed motor feed speed 6 - 36 m / min - on the inverter feed on cardan shafts Lodpfx Acog E Uqcs Hsak heads supported on both sides electric height adjustment

Condition: used, Working width 230 mm Working height 15-120 mm Number of spindles 2 St. Weinig Hydro Planer Type Uniplan 23 ----- Machine was factory overhauled by Weinig in 2024. Description: For two-sided horizontal woodworking with two working spindles. Spindle arrangement: horizontal, bottom and top. The two horizontal spindles are equipped with hydraulically tensioned counterbearings without axial adjustment. Built-in straight jointers on both spindles with automatic stone feed, remotely controlled with the hood closed. Lsdjxpn Tzopfx Ac Hoak Machine with continuous, chainless feed, equipped with rubber rollers. Electric up/down adjustment of the spindles according to a mechanical digital display (SIKO). On/off switch for limiting the up/down adjustment. Feed roller pressure pneumatic. Stops and table tops are not adjustable. Machine with steel table tops. Machine with full enclosure and integrated sound and dust protection including interior lighting. Electrical design according to DIN VDE 0113, electrical equipment of industrial machines EN 60204, IEC - 204 - 1. Other electrical regulations are not taken into account. Machine includes operating tools, but does not include machining tools. The Weinig Uniplan spindles operate at a speed of 7200 revolutions per minute. Before using existing tools, please check that they are suitable for the speed. Please also consider this when ordering new tools. Technical specifications Max. working width: 230 mm Min. working height: 15 mm, max.: 120 mm Feed: 3 kW (4 HP) Horizontal spindles each: 7.5 kW (7.5 HP) Infinitely variable feed speed: 6 - 36 m/min. Spindle speed: 7,200 rpm Spindle diameter: 50 mm Tool clamping length: 240 mm Maximum tool radius: 163 mm Fixed clamping clearance at bottom: 0.5 mm (Technical data according to the manufacturer - no guarantee!)

Condition: excellent (used), Weinig Uniplan double-sided planer Planing width 220mm Planing height 15-120mm Power of horizontal spindles 2x 5.5kw Ljdpfxorxuvqo Ac Hjak Spindles speed 6000r.p.m Diameter of spindles 50mm Spindles supported on both sides Feed speed 6-32m/min Feed motor 3kw

Condition: used, Weinig Unimat 23 E + Uniplan 23 planing line, including a return conveyor. An NC-controlled line for planing and profiling window scantlings, including glazing bead removal or other planing tasks, with automatic workpiece return to the operator. spindles: 4 + 2 working width: 230 mm working height: 120 mm spindle 1: 7.5 kW / 50 mm / 8,000 rpm spindle 2: 11 kW / 50 mm / 8,000 rpm spindle 3: Common motor with spindle 2 / 50 mm / 8,000 rpm spindle 4: 7.5 kW / 50 mm / 8,000 rpm Spindle 1 Uniplan: 5.5 kW / 50 mm / 7,200 rpm Spindle 2 Uniplan: 5.5 kW / 50 mm / 7,200 rpm feed: 5-24 m/min service: PC Control Nexus Ljdpfxsx An R Tj Ac Hoak NC axes: Unimat 2 & 3, Uniplan 1

Condition: used, Number of spindles 8 St. Working width 230 mm Working height 120 mm Weinig Planing and moulding line ----- Consisting of the following individual machines: Item 1: Weinig Profimat 23 E, four-side planer, stock number: 2803 5 spindles + glazing bead saw Lajdpfxoxpn Tuo Ac Hjk Item 2: Weinig Uniplan 23, stock number: 2804 Fine and hydroplaner with 2 horizontal spindles Item 3: Weinig RF 15, stock number: 2805 Longitudinal-cross-longitudinal conveyor with workpiece return to the operator Detailed descriptions of the machines can be found under the mentioned stock numbers. (Technical specifications according to the manufacturer, without guarantee!)

Condition: used, Hydro-fine planing machine Weinig Uniplan 23 for two-sided surface finishing, as an alternative to sanding (e.g. in window construction) with high-performance spindles. * Very good original condition spindles: 2 Lasdpfx Ajt Rmbmoc Hjk Spindle arrangement: Bottom (7.5 kW) – Top (7.5 kW) spindle arrangement: Bottom (7.5 kW) – Top (7.5 kW) working width: 230 mm working height: 120 mm Spindle ø: 50 mm feed: 3 kW // max. 36 m/min Spindle speed: 7,200 rpm Jointers: Yes jointer: Yes Counter bearing: Yes Short parts package: Yes
