Circular sawing machines

Altendorf F 45 ProDrive

Condition: excellent (used), Altendorf F45 prodrive panel saw 300 cm sliding table, Ljdpfx Aox Npvtsc Hsta Blade tilt and height are motorized and adjustable, Right-side rip fence motorized adjustable up to 1340 mm, 2-axis scoring unit, electrically adjustable, 5.5 kW vario motor, speed controlled by frequency inverter, Max. blade diameter 450 mm, Used machine in very good condition.

Condition: new, engine output 5 kW Lsdpswli Nrefx Ac Hjta saw-blade dia. 300-350 mm Working speed 0-40 m/min weight ca. 1.300 – 1.800 kg kg

Condition: excellent (used), Year of construction: 2024, Sawblade tiltable 46 ° Length of the rolling table 3000 mm cutting width 13000 mm Ljdpex Ak Hwjfx Ac Hsta Motor output 7,5 kW Cutting height 204 mm Saw blade diameter 550 mm Speed 3000/4000/5000 U/min. weight of the machine ca. 1250 kg

Condition: new, Year of construction: 2025, functionality: fully functional, cutting length (max.): 3,105 mm, cutting width (max.): 1,300 mm, cutting width at rip fence: 1,300 mm, cutting height with scoring (max.): 150 mm, saw blade diameter: 450 mm, height adjustment type: electric, table height: 910 mm, rotational speed (min.): 3,000 rpm, rotational speed (max.): 5,000 rpm, type of input current: three-phase, input voltage: 400 V, warranty duration: 12 months, power: 7.5 kW (10.20 HP), Altendorf F45 Pro Drive The machine is new and configured as follows: Working height: 910 mm Sliding table length: 3200 mm Control panel at eye level for comfortable operation Cutting height: 150 mm with a 450 mm saw blade Ledpfx Acexaudhs Heta Main motor: 7.5 kW with three rotation speeds; features the AKE saw blade changing system 2-axis scoring unit with a safety LED light in the scoring area, enhancing operator awareness when the scoring unit is active Main motor and scoring unit ON/OFF buttons on the sliding table for convenient machine startup Mitre crosscut fence, extendable to 3500 mm, with angle correction Cutting width: 1300 mm with CNC, programmable via the screen Gobjxaudhskr A Tq Djkc Motorized rise, fall, and tilt adjustment (0–46°) for the main saw blade, with automatic cutting height correction when the blade is tilted The Altendorf F45 has long been recognized as the flagship of sliding table saws, consistently setting the highest quality standards for this type of machine.

Condition: used, Year of construction: 2000, With electric height and tilt adjustment Used, excellent condition, little used Make Altendorf Type F45 Year of manufacture 2000 Ledpfxevxlq Hs Ac Hota Machine number GS-tested Motor 4 kW Steel guides Carriage length approx. 3000 mm Cutting width approx. 1050 mm Pivoting up to 45° Prepared for scoring unit Parallelogram guard Tabletop extension Anodized aluminum parts Electric height adjustment Electric tilt adjustment Digital display: - Cutting angle - Speed Extraction connection D 120/80 mm Space required approx. 3010 mm x 1800 mm x 1500 mm Weight approx. 1000 kg Storage location 97447 Gerolzhofen, free on load, unpacked Sold in the current condition as seen, without warranty or guarantee

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, machine/vehicle number: 18-03-12-070, cutting length (max.): 3,000 mm, cutting width at rip fence: 1,300 mm, saw blade diameter: 450 mm, Equipment: rotational speed infinitely variable, Manufacturer-refurbished Altendorf F45 ProDrive with angle miter fence and Digit L display! TECHNICAL DETAILS Maximum cutting length: 3,000 mm Cutting width at rip fence: 1,300 mm Table length: 840 mm Main saw blade diameter: 450 mm Saw blade projection 90° with single-sided tilt: 154 mm 90° with double-sided tilt: 154 mm +45° with single-sided tilt: 105 mm +45° with double-sided tilt: 105 mm -45° with double-sided tilt: 78 mm MACHINE DETAILS Ltodpoxc Ufqofx Ac Hja Power: 7.5 kW (10.20 HP) Dust extraction connection Upper extraction: Ø = 80 mm Lower extraction: Ø = 120 mm Negative pressure: 1,200 Pa at total extraction connection, Ø = 140 mm Air consumption: v_min = 1,110 m³/h at 20 m/s Air cushion table Compressed air consumption: 200 l/min at 1 bar (max. 400 l/min at max. 3 bar) EQUIPMENT Continuously variable speed Template holder Front support roller Air cushion table WGA Digit-L PA 1300 mm CNC

Condition: excellent (used), Year of construction: 2017, Used machine F45 Pro Drive Ltsdex Nru Ejpfx Ac Hoa Year of manufacture: 2017 Template holder Max. saw blade diameter: 450 mm Motor: 5.5 kW Double roller carriage: 3200 mm Table extension: 840 mm Digit-L angle/miter fence 1100 mm CNC rip fence 2-axis scoring unit Rapido scoring system LED lighting Duplex double-sided miter fence Location: ex customer site - immediately available -

Condition: as good as new (ex-display), Year of construction: 2024, functionality: fully functional, Exhibition machine – as new – including the following options: - Laser cutline indicator - Saw motor with 7.5 kW (10 HP) - Mitre fence swivels +/- 50° with length compensation - Programmable saw blade height adjustment Saw unit swivels up to 46° Pressure beam, including: LED lighting with 3 different action colors: - WHITE: Machine at standstill - RED: Pressure beam lowering or emergency stop function - BLUE: Saw unit in motion Up to 3,400 mm extendable telescopic stop with 2 digital displays 4 parallel, motorized positioning width stops on a 2,000 mm wide support table, size adjustment up to 1,300 mm Automatic stop retraction Versatile support table 800 x 200 mm Scoring system using the main saw blade in synchronised rotation Automatic workpiece length detection for minimum travel distances Mobile, height-adjustable control panel, including: - Touchscreen control panel with cut plan creation - Saw blade stand - Template holder - Emergency stop button, start button, selector switch for grooving/groove sawing/cutting, rotary switch for feed speed - Switch for laser (option) - USB socket Attention: Machine is supplied without saw blade! Technical data: Cutting length: 3,200 mm Max. saw blade projection: 100 mm at 90°, 72 mm at 45° Lodpfx Ajw Uf Nljc Hjta Saw blade: Diameter 300 – 350 mm, bore 30 mm Saw blade speed: 4,000 rpm Motor: 5 kW (= 7.5 HP) Feed speed: 0 – 40 m/min Overall length: approx. 4,270 mm Weight: from approx. 1,150 to 1,550 kg (depending on equipment) Required air pressure: 7 bar Extraction ports: 1 x 100 mm, 1 x 120 mm

Condition: new, F 45 ProDrive:The new F 45 is a masterpiece of technology and design. The machine stand, which has been redesigned from the ground up, exceeds all previous values in terms of torsional rigidity and low eye-level control, with which you can call up the height and tiltof the saw blade plus, depending on the control package selected, the speed andother functions.3.5" color screen with separate keyboardAutom. Automatic dimensional correction at the parallel and angle stop when swivelling the saw unitSimple calibration of the axesMachine diagnostics, operating hours counter, USB interfaceCalling up the last dimension entry (back function)99 storable cutting programsGrooving: with automatic step-by-step positioning of therip fence400V / 50Hz - Europe , scale: scale in mmM44249machine height 910 mmM64099eye-level operationbasic equipmentThe control panel of the F 45 is mounted at eye level. This means that all axes can be conveniently controlled and all settings are in -hand operation of the swing-away deviceM64096max. blade diameter 450 mmBasic equipmentThe F 45 is equipped with a parallelogram guardwith two hoods for 90° and angle cuts.{They are infinitely adjustable in large pressure roller in the infeed automatically adjusts theguard to the workpiece maximum saw blade diameter is 450 mm. This achieves a saw blade projection of max. 154 mm.M511005.5 kW (7.5 hp)optionalone-sided swivel saw unit with 5.5 kW (7.5 hp) motor,manuallyadjustable to 3/4/5000 rpm. Swivel range: 0 - 46°AKE quick-change system for the main saw bladeThe motors have 20% more torque than standard electric motors with the samepower consumption.M24038Preparation for 2-axis scoring unitOptionScoring unit preparationfor retrofitting a scoring unitM41010Table top extension 840 mmBasic equipmentTable top extension 840 mmconsisting of a CDF panel with HPL coating on both sides. Itis particularly scratch and impact resistant.M34204Double castor trolley with trolley length 3200 mmOptionDouble castor trolley, trolley length 3200 mmThe Altendorf double castor trolley can be locked in any position. Thedouble castors, made of hardened steel, holdthe upper carriage in conjunction with the lower carriage absolutely precisely in thehard chrome-plated guide rods. The carriage construction is designed as an extremely torsion-resistant and dimensionally stable multi-hollow chamber system. The table surface is anodized.A hard chrome-plated round bar serves as a mount for the cross slide and as an interface for various accessories.M44404Angle mitre fenceOptionAngle mitre fence, cutting to length up to 3500 mmThis Altendorf-patented fence with integratedlength compensation facilitates the precise cutting of 90° angles andmitres in one function. In the front and rearstop position, the swivel angle is infinitely adjustable by 49° andis indicated by a measuring scale. Simply move the fence ruler to theselected angle dimension according to the scale and then set the desired lengthon the fence cut-to-length dimensions from approx. 1700 mm, theroller-supported and stable telescopic extension takes over the outer fence entire cross slide is supported by a precision-manufactured,prismatic support of the round bar of thedouble roller carriageIncluding: two single tilt stopsM44441CNC parallel fence 1000 mmOptionCNC parallel fence, cutting width 1000 mmThe CNC-controlled parallel fence can be controlled at a traversing speedo... Ltodpfx Asvzhdzsc Hsa
