Demag System 500/900-3300 (2006)

Demag System 500/900-3300

Condition: excellent (used), Year of construction: 2008, clamping force: 5,000 kN, Demag System 500/900-3300 (2008) Fpjdpfx Ajwv Uykea Nep Clamping unit Clamping force: 500 tons Platten dimension: 1300 x 1200 mm Distance between tie bars: 900 x 800 mm Mold height min. : 440 mm Mold height max. 880 mm Injection unit Screw diameter: 80 mm Injection pressure: 1855 bar Injection volume: 1779 cm3 Shot weight: 1620 g Transport dimensions Dimensions: 8,7 m x 2.3 m x 2,5 m Weight (clamping unit/injection unit): 16.500/5.400 kg 4x Core pullers Cascade control 2-way hydraulic EUROMAP 67 interface Additional connections for 2 core pulls on the fixed tool clamping plate 10-way cooling water flow regulator with temperature display Additional nozzle controller; 1 circuit; PID controller

Condition: like new (used), Year of construction: 2003, For sale complet MC 4 control for Krauss-Maffei machines, tested and full in function ! Fodpoikfmhofx Aa Nepp

Condition: good (used), Year of construction: 1997, Krauss Maffei KM 650 - 3500 C2 injection molding machine Year of production - 1997 Fully hydraulic closing system. MC 3 control system Fsdpfxsvlpcgs Aa Nopp SP 3500 plasticizing system complete plasticizing system for thermoplastics in the version with abrasion protection, with a screw diameter of 90 mm, with a non-return lock and an open nozzle. Closing system: complete plasticizing system for thermoplastics with a screw diameter of 90 mm, with a non-return lock and an open nozzle. TECHNICAL DATA: Closing unit: - Mold closing force: kN 6500 - Mold opening force: kN 346 - Mould mounting plate movement force -- opening kN 169 -- closing kN 144 - Mounting plate dimensions (h x v): mm 1490 x 1440 - Clearance between columns (h x v): mm 1000 x 930 - Mold opening stroke: mm 1150 - Minimum mold height: mm 600 - Opening width: mm 1750 - Ejector stroke: mm 250 - Ejector force: kN 226/285 Injection unit: - Screw diameter: mm 90 - Injection pressure: bar 1742 - Injection volume: cm3 1953 - Injection weight for PS: g 1777 - Injection capacity cm3/s 649 - Increased injection capacity - Electric-hydraulic equipment: - Nominal power of the pump motor: kW 90 - Power of installed heaters: kW 44 - Number of cylinder heating zones: 7 - Oil tank capacity: l 1240 Dimensions and weight: - Net weight with control cabinet: t 39.5 - Machine dimensions (length x width x height): m 9.36 x 2.65 x 2.44

Condition: reconditioned (used), Year of construction: 2006, operating hours: 60,000 h, functionality: fully functional, clamping force: 8,000 kN, screw diameter: 85 mm, Horizontal injection moulding machine from Krauss-Maffei. 800 tons clamping force. Year of manufacture 2006. Screw diameter 85mm. MC5 control. Approximately 60,000 working hours. The machine is delivered REFURBISHED by our team of technical experts and in optimal working condition. We can offer commissioning services at our customer's premises, ensuring full functionality upon installation completion. Technical Details Fsdpfx Aasw Avafe Nepp Screw diameter: 85mm Injection pressure: 2242 Bar Injection volume: 2695 cm3 Injection weight: 2452g (PS) Year of manufacture: 2006 Working hours: 60,000 Minimum mould thickness: 550/1100mm (Min/Max) Maximum platen distance: 2100mm Opening stroke: 1600mm Tie bar distance: 1120x1000mm Platen dimensions: 1600x1530mm Clamping force: 8000 kN

Condition: excellent (used), Year of construction: 2005, KM 500/2700C2 Fpedev Uzq Ujpfx Aa Nep Technical Specifications Clamping Side: Clamping Force: 5000 kN Tie Bar Dimensions (H x V): 900 x 800 mm Minimum Installation Height: 480 mm Maximum Platen Distance: 1650 mm Centering: 200 mm Mold Weight: 7900 kg Injection Side: Screw Diameter: 80 mm Displacement: 1433 cc Injection Pressure: 1829 bar Equipment: MC 4 Control System Core Pulls: 2+2 Machine is sold without robots and peripherals!

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, KM 500-3500 C2 Year of manufacture: 2007 Operating hours in automatic mode: 60,000 h Clamping unit Clamping force: 5,000 kN Mounting plate dimensions: 1270 x 1310 mm Distance between tie bars: 900 x 800 mm Min./max. mold height: min. 480 mm Maximum opening stroke: 1,650 mm Injection unit Screw diameter: 80 mm Injection volume: 1,543 cm³ Shot weight: 1,404 g Injection pressure: 2,205 bar Electrical and hydraulic equipment Nominal pump motor power: 90 kW Fsdpfow Rflrjx Aa Nspp Heating capacity: 44 kW Dimensions and weight Net weight with control cabinet: 27,090 kg Dimensions (L x W x H): 7.65 m x 2.55 m x 2.55 m

Condition: used, Year of construction: 1999, Technical details: screw size: 45 mm injection shot weight in Polysterol: 149 g/PS Fsdpfxowvkgme Aa Njpp closing pressure: 1250 kN
