Die-sinking EDM machine

Fanuc Robocut alpha C600

Condition: good (used), Year of construction: 2007, travel distance X-axis: 750 mm, travel distance Y-axis: 750 mm, travel distance Z-axis: 725 mm, CNC control Sinumerik 840D NC-rotary table B-axis automatic tool changer for 320 tools pallet changing device, 2 pallets 500 mm x 500mm coolant through spindle device IKZ (80 bar) chip conveyor coolant device Technische Daten / technical details: X-Weg längs / X-travel longitudinal 750 mm Y-Weg senkrecht / Y-travel vertical 750 mm Kdsdpjq Ui Hqofx Anwjn Z-Weg quer / Z-travel cross 725 mm B-Achse / B-axis 360 ° Spindelaufnahme / spindle taper HSK 63A Drehzahlbereich Spindel / spindle speed 50-10000 Upm /rpm Werkzeugplätze / tool places in changer 320 Vorschub / infeed 60000 mm/min Eilgang / rapid feed 60 m/min Antriebsleistung Spindel 40/100% ED / drive capacity spindle 40/100%ED 37/24 kW Gewicht der Maschine ca. / weight ca. 15000 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: used, TECHNICAL DETAILS - Number of axes : 4 MILLING SPINDLE - Tool holder type : BT30 - Spindle power : 4,9 [kW] - Spindle speeds : 16.000 [rpm] LINEAR AXES - Travels on X/Y/Z axes : 700 x 400 x 300 [mm] - Rapid traverses rates (X/Y/Z) : 50 / 50 /56 [m/min] - Cutting feed rates (X/Y/Z) : 1 - 30.000 [mm/min] - Distance table / spindle nose (min./max.) : 330 - 630 [mm] TOOL CHANGER - Auto. Tool Changer type : Parapluie - Tool magazine capacity : 21 - Tool exchange time : 0,8 [sec] TABLE - Table dimensions : 800 x 400 [mm] - Maximum weight upon table : 250 [kg] POWER SUPPLY - Supply voltage : 220 [V] - Total installed power : 9,5 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2.050 x 2.220 [mm] - Machine height : 2.497 [mm] - Machine weight : 2.400 [kg] MACHINE HOURS - Number of hours under power : 23.456 [h] - Number of working hours : 16.703 [h] Kedpfx Ansxzu T Sswjdn EQUIPMENT - CNC : Brother CNC-C00 - Interface : Ethernet / USB - Electronic handwheel - CNC option : extanded Memory 500 Mo - CNC option : High accuracy mode BⅡ - Type of divisor : 4e axe CNC intégré * manufacturer : YUKIWA * model : DRC170-EU * travel 4th axis : 360 [°] * indexing precision 4th axis : 0,001 [°] * clamping diameter : 140 [mm] * center height : 135 [mm] * with counter bearing * Coolant tank : 150 [l] * with high-pressure pump : 15 [bars] * With cabin washing - Coolant through spindle - Tool probe - Electric transformer

Condition: good (used), CHARACTERISTICS Plate diameter ⌀; 3200 mm Maximum turning/turning diameter ⌀; 3300 mm - With upright forward; 3300 mm - With upright set back; 5600 mm Min. turning/turning diameter ⌀ - With advanced upright; 800 mm Kdodpfxer I Ayko Anwsn - With upright set back; 3100 mm Max turning height; 750 mm Control; FAGOR 8025 Spindle RPM (2 ranges); - 0,5 - 10 rpm - 10 - 40 rpm Motor Power; 80 hp Maximum table load; 30.000 kg

Condition: used, Year of construction: 2011, turning diameter 160 mm turning length 550 mm control Siemens Kdjdpfoyuzfpjx Anwen weight of the machine ca. 9000 kg

Condition: excellent (used), Year of construction: 2009, operating hours: 28,742 h, functionality: fully functional, bar passage: 65 mm, FANUC Series 31i-Model A 3 turrets Kodpfx Anjydmbuowsdn Parts conveyor Magazine Further details on request

Condition: used, TECHNICAL DETAILS - max. power : 40 [t] - max. workpiece diameter : 40 [mm] - spindle diameter : 80 [mm] - spindle length : 120 [mm] - max. tool diameter : 250 [mm] - dimensions : 2400 x 2100 x 2200 [mm] - weight : 7100 [kg] EQUIPMENT - control CNC (base Siemens) - tail stock device Ksdpfxouhb Uhj Anwodn - coolant tank with pump - 2 boring wheel 80, diameter : 260 [mm]

Condition: used, Year of construction: 2001, functionality: fully functional, Press force 85 t, Bending length 2050 mm, Distance between uprights 1750 mm, Control DELEM, Stroke 215 mm, Throat depth 410 mm, Total power 13 kW, Weight 8,750 kg, Machine dimensions 3190 x 2100 x 2375 mm Ksdpfx Asw Imq Rjnwjdn

Condition: used, TECHNICAL DETAILS - Number of axes : 4 - Number of spindles : 1 - Number of turrets : 1 MAIN SPINDLE - Spindle nose : A2-8 - Spindle power : 18,5 [kW] - Spindle speeds : 4.000 [rpm] - Max. bar diameter : 80 [mm] - Max. machining length : 728 [mm] - Max. turning diameter : 460 [mm] - C axis indexing precision : 0,001 [°] TURRET - Number of positions : 12 - Number of motorized positions : 12 - X/Z stroke : 260/795 [mm] - Y stroke : +/- 50 [mm] - Tool type : BMT - Live tools speed : 10000 [rpm] TAILSTOCK - Tailstock type : Numérique - Type of cone : CM5 - Tailstock stroke : 650 [mm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 39 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 3.110 x 1.922 [mm] - Machine height : 2.120 [mm] - Machine weight : 6.100 [kg] MACHINE HOURS - Number of hours under power : 26654 [h] - Number of working hours : 15488 [h] EQUIPMENT - CNC : CELOS - Interactive programming : MAPPS 4 - Interface : USB, PCMCIA, RJ45, RS232 - Tool probe : Renishaw - Coolant tank * with high-pressure pump : 15 [bars] - Chips conveyor - Tool probe Kdsdpfx Aex Tvklonwon - Parts catcher - Parts conveying strip - Bar loader : LNS QUICK LOAD SERVO 80 S2 - Number of fixed tool holders : 9 - Number of turning tool holders : 3 - Electric transformer - Collet chuck

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, Equipment: documentation/manual, Machine model: ALC400G Max. workpiece dimensions (W×D×H): 600 × 470 × 240 mm (Flushing) Max. workpiece dimensions (W×D×H): 600 × 470 × 230 mm (Submerged) Max. workpiece weight: 500 kg (Flushing) Max. workpiece weight: 350 kg (Submerged) Work tank dimensions (W×D): 850 × 610 mm Kdedpfx Asyu Nqmsnwsn X axis travel: 400 mm Y axis travel: 300 mm Z axis travel: 250 mm U axis travel: 150 mm V axis travel: 150 mm Taper angle (at workpiece thickness 130 mm): ±25° Wire diameter: Ø0.1 – Ø0.3 mm Wire feed speed (max): 420 mm/sec Wire tension: 3 – 23 N Machining method: Flushing / Submerged Distance from floor to table top: 995 mm Wire bobbin weight: 8 kg Machine dimensions (W×D×H): 2,115 × 2,500 × 2,230 mm Machine installation space (W×D): 3,350 × 3,850 mm Machine weight (including power supply): 3,400 kg Air pressure: 0.5 MPa Air consumption: 30 NL/min Total power input: 3-phase, 50/60 Hz, 13 kVA Dielectric tank external dimensions (W×D): 700 × 2,155 mm Dielectric tank weight (empty): 450 kg Dielectric tank capacity: 675 liters Dielectric fluid filtration method: 3 replaceable paper filters (internal pressure type) Deionizer: Ion-exchange resin (18 L type)

Condition: excellent (used), Year of construction: 2005, X 450 Y 300 Z 300mm, BT 30, 10.000Rpm, cooling trough spindle, paper filter, Mitsubishi Kedpfxetiyl Eo Anwjdn
