CNC Turning & milling machine

GILDEMEISTER Twin 42-II

Condition: good (used), Year of construction: 2000, gear diameter: 449 mm, Equipped with: Fanuc 150MB CNC Control Dry Cutting Cutter Shroud Chip Evacuation System Auto Doors Hydraulic System Lubrication System Work light Stack Light Specifications: Largest Speed Ratio: 10:01 Work Area (Continuous): Largest Depth of Teeth: 15.24 mm Largest Width of Tooth Face: 50.8 mm Work Area Axis: Horizontal Movement X Axis: -114 - 178 mm Vertical Movement Y Axis: -178 - 190 mm Movement of the Carriage Baseplate Z-Axis: -10.16 - 500 mm Workpiece Headstock Swiveling Range B-Axis: -3 - 90 Degree Maximum Distance Machine Center to Spindle Side: 165 mm Number of Teeth: 5-200 Inclusive Max. Gear Pitch Dia. of Typical 35 Deg. Spiral Angle Gear Using Max. Cutter Dia. 12" Cutter at the Following Ratios: Face Milling 1 x 1 - 13.5" - 342.9mm 2 x 1 - 16.0" - 406.4mm 5 x 1 - 17.7" - 450.0mm Face Hobbing (210mm Dia. Cutter) 1 x 1 - 10.560" - 268.22mm 2 x 1 - 10.286" - 275.00mm 5 x 1 - 11.810" - 300.00mm Milling Head Diameter: Helixact: 100,125,169,200,250,320mm Continuous Gumption Procedure, Teichloroethylene: 102 - 210 mm Workpiece Spindle: Drilling of Large Diameters: 5 3/64" Cone Upward Gradient on 304.8 mm (1 Foot): 21/32" Deep One of the Cone: 5.29" Diameter of the Whole Spindle Perforating: 3.35" Speeds: B-Axle Workpiece Headstock Drag Axis: 30 Degrees A-Axle Workpiece Spindle Number of Revolutions: 0 83 min-1 X-Axis Horizontal: 80 mm/sec Y-Axis Vertically: 80 mm/sec Z-Axis Carriage Baseplate: 80 mm/sec Space Requirement L x W x H (Approximate): 4.75 x 3.40 x 2.54m / 188" x 134" x 100" Hsdpfx Aneruakgopop Machine Weight (Approximate): 10980 kg / 24,156#

Condition: new, distance between shaft and table: 470total power requirements: 2,2 kwweight approx.: 1,2messurements (LxWxH): Länge2400 mm Breite/Tiefe2160 mm Höhe2300 mm Gewicht 1200 kgspindle rotation speed: 60 4200 min¯¹ Hodpfxsd H Hhzo Anpjp

Condition: ready for operation (used), Rotation diameter over bed/slide: 560mm/300mm, max. workpiece weight between centers: 2500kg, max. workpiece weight in chuck: 800kg, center width: 1000mm, machining length: 980mm, feed: 8m/min, bed width: 433mm, tool positions: 8, tool holder: VDI40. Machine dimensions X/Y/Z: approx. 3000mm/2300mm/1800mm, weight: approx. 3700kg, control: Siemens 810D Manual Turn. Documentation available. On-site inspection is possible. Hjdpfowynvtsx Anpop

Condition: good (used), Year of construction: 2005, Machine type: Cylindrical grinding machine Manufacturer: Junker Model: Jumat 5340/s Serial number: 2328 Hedskyrqiopfx Anpop Year of manufacture: 2005 Available immediately Ex works, for self-disassembly We can optionally offer disassembly and loading services.

Condition: reconditioned (used), Year of construction: 2007, Teach-in lathe 230x1000; reconditioned machine with general inspection and overhaul, replacement of seals and Z-axis bearings bar capacity 58 mm CNC FAGOR 8055 year of manufacture 2007 complete with: self-centering chuck chip conveyor manual turret with CAPTO C4 interface set of tool holders set of jaws manuals and CE certificate Hjdpev Nquljfx Anpjp

Condition: excellent (used), Year of construction: 2015, With a focus on optimized and energy-efficient drives in the automotive industry, significantly higher demands are placed on the components of the drive system. Higher power transmission, higher torques, and a smaller overall size are the challenges. This development has led to an increased need for cold-formed splines. With the vertical spline press (VSP), Sack & Kiesselbach provides customers with a solution that offers technological and logistical advantages compared to conventional technologies (such as rolling or broaching). The relatively small and very user-friendly press can be configured for both manual and automated operation. Hedpfxsgtty Tj Anpop In addition to the spline press, the customer can also obtain the appropriate tooling system and the corresponding process technology from a single source. 1 used vertical spline press Manufacturer: Sack & Kiesselbach Type: VSP 50/30 Year of manufacture: 2015 Technical data: Press force: 500 kN Ram stroke: 450 mm Closing speed: 200 mm/s Pressing speed: 5.5 mm/s Opening speed: 120 mm/s Table dimensions: 500 x 400 mm Installation height: 1000 mm Distance between columns: 530 mm Spline cylinder speed: 3-9.5 mm/s Dimensions: Height: 2900 mm Width: 3100 mm Depth: 1400 mm Drive power: 8 kW Special equipment: Digital position measuring system Spline tool for internal gearing

Condition: used, Year of construction: 2006, Technical details: grinding diameter: 5-55 mm grinding length: 500 mm total power requirement: 44 kW -- Intended use and general information -- Fully automated external and surface grinding of synchronous rings Centre height: 200 mm Grinding length: 500 mm Grinding wheel arrangement: right, 30° angled Grinding wheel dimensions: 600 x 30 x 203.2 mm Drive power: 7 kW X/Z axis drive: ball screw Travel speed: 0.01 - 10,000 mm/min. Resolution: 1 µm Concentricity of workpiece spindle: < 1 µm Workpiece changing system: Fanuc robot Control: Siemens Sinumerik 840-D Hsdpfx Ajvg Thijnpjp Machine weight: 7,000 kg Centre height: 200 mm Grinding length: 500 mm *

Condition: good (used), functionality: fully functional, Machine weight: 1725 kg Total machine power: 3 kW Table clamping surface: 800x400 mm Hodpsvzkzcjfx Anpop Longitudinal table movement - x-axis: 600 mm Transverse table movement - z-axis: 400 mm Vertical table movement - y-axis: 400 mm Spindle taper: ISO 40 Spindle speed: 40-2000 rpm Working longitudinal feed - x-axis: 8-400 mm/min Working transverse feed - z-axis: 8-400 mm/min Working vertical feed - y-axis: 8-400 mm/min Rapid feed x/z/y: 2000/2000/1000 mm/min Max. workpiece weight: 400 kg

Condition: excellent (used), Mikron Gear Hobbing Machine A33/0 – for Module 0.5 to 2.5 – rarely used Manufacturer: Mikron Model: A33/0 – Gear Hobbing Machine (vertical) Version: Base machine with standard milling head Condition: used, very good condition, machine has been rarely operated Color: green Hsdpfxsx A D Izs Anpep Technical Data Max. workpiece diameter: approx. 80 mm Max. hobbing length: approx. 150 mm Module range: approx. 0.5 – 2.5 Ideal for small gears in the module range 0.5 – 1.0 Main drive: 3 kW Electrical connection: 3 x 380 V AC, 50 Hz Total power consumption: approx. 9.5 kVA Dimensions & Weight L x W x H: approx. 1,450 x 1,380 x 2,080 mm Weight: approx. 2,200 kg Special Features Very well-suited for manufacturing small gears (module 0.5 – 1.0) Machine was rarely used in production, therefore minimal wear Availability / Service Detailed photos and operating video available upon request Quotation including price, delivery terms, and lead time possible Subject to prior sale and errors.

Condition: excellent (used), Year of construction: 2018, CNC control: Fanuc Series Oi-MF New machine, only 150 spindle hours Hsdpfxowa Ip He Anpjp - Flat guideways - Gearbox - Internal cooling - Various tool holders and 1 vise Travel paths X-travel 850 mm Y-travel 530 mm Z-travel 530 mm Spindle nose (to table surface) 100-630 mm Spindle axis to column surface 590 mm Table Table size 530 x 950 mm Maximum table load 800 kg T-slots (W x NO. x P) 18 x (5) x 100 mm Spindle Spindle speed 8000 rpm Spindle mount BT-40 Spindle power 7.5/11 kW Feed rate Rapid positioning speed 20 / 20 / 20 m/min. Cutting feed rate: 1 – 10,000 m/min. Automatic tool changer Number of tools: 24 Tool taper: BT-40 MAS Tool holder bolt: P-40T (45°) Max. tool diameter: Ø 80 mm Max. tool diameter (no adjacent tool): Ø 150 mm Max. tool length: 250 mm Max. tool weight: 7 kg Tool change time (tool to tool): 2.5 sec Tool change time (chip to chip): 6 sec Machine dimensions: Floor area: 2450 x 2700 mm Machine weight: 6000 kg Max. machine height: 2900 mm Air supply connection: 7 kg/cm2
