Condition: used, Year of construction: 1984, workpiece diameter 470 mm workpiece length 1650 mm max. dia. of teeth cutting 120 mm max. length of teeth cutting 1100 mm no. of teeth (continued procedure) 12-96 number of teeth (interrupted procedure) 10-30 Fjdpfx Aow Hg Uhefpogh rapid traverse 10 m/min feeds 40-240 mm/min control Siemens total power requirement 18,5 kW weight of the machine ca. 8,5 t Weitere technische Details entnehmen Sie bitte unserem d Rolling Machine | GROB - ZRM e9 extended Version with Soundproof Enclosure The machine has been retrofitted with a SIEMENS S7 control system. The machine is in very good condition. For further technical details, please refer to our offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: ZRM-e9 | ZRMe9

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, machine/vehicle number: 109 956, workpiece diameter (max.): 38 mm, workpiece length (max.): 500 mm, TECHNICAL DETAILS Workpiece Rack Length: max. 610 mm Workpiece Diameter: 38 mm Module Range: 0.3 – 1.3 Max. Slide Stroke: 1130 mm Max. Rolling Bar Length: 915 mm Max. Profile Outer Diameter (Standard): 50 mm Max. Profile Width (Standard): 125 mm Gear Cutting (Rollability): 0.3–1.25 Machine Cycle Times Tailstock forward (approx. 300 mm stroke): 1.0 s Rolling bars forward: 4.2 s Tailstock return (approx. 300 mm stroke): 1.5 s Rolling bars return: 4.8 s Loading/Unloading (manual): 5 s MACHINE DETAILS Weight & Dimensions Total Weight (without automation): 12,200 kg Fgjdpewx H R Tsfx Afpjh Overall Width: 5,014 mm Machine Width: 3,104 mm Depth without cantilever: 2,564 mm Depth with cantilever: 4,166 mm Hydraulic System Hydraulic Tank: 1,000 l Hydraulic Operating Pressure: 80 bar Electrical Equipment Operating Voltage: 400 V / 3 phases Frequency: 50 ±1 Hz Coolant System Tank Capacity: 260 l Pump Pressure: 3 bar Pump Flow Rate: 24 l/min Cooling Water Supply for Hydraulic Tank (Quantity): 10 l/min Cooling Water Connection for Hydraulic Tank (Temperature): 20 °C EQUIPMENT Full enclosure included Tailstock included Hydraulic system included Oil system included

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, machine/vehicle number: 109987 - 2800015, workpiece diameter (max.): 38 mm, workpiece length (max.): 500 mm, stroke length: 1,950 mm, Suitable for chipless cold forming of profiles such as splines (straight or helical), spiral gears, oil grooves, CV joints, threads and knurls TECHNICAL DETAILS Workpiece diameter: 38 mm Workpiece length: 500 mm Rack length – max.: 610 mm Max. slide stroke: 1,950 mm Fodpewm Hqvefx Afpegh Max. rolling bar length: 1,400 + 330 mm Max. profile external diameter (standard): 60 mm Max. profile width (standard): 175 mm Rollable profiles for involute gears (module range): 0.3–2.0 MACHINE DETAILS Machine weight: 10 t Total power requirement: 52 kW Current type: 3 Ph Frequency: 50 Hz Operating voltage: 400 V Rated current: 99 A Overall width: 5,014 mm Machine width: 4,560 mm Depth without boom: 2,541 mm Depth with boom: 4,165 mm Height: 2,100 mm Total weight (without automation): 14,500 kg Drive power: 45 kW Hydraulic tank capacity: 1,000 l EQUIPMENT - Machine in horizontal design - Complete enclosure - Tailstock - Hydraulic system - Oil system

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, machine/vehicle number: 109853 - 280028, workpiece diameter (max.): 38 mm, workpiece length (max.): 500 mm, TECHNICAL DETAILS EX-CELL-O Cold Rolling Machine with Felsomat (1999) Design: Horizontal Area of application: Chipless cold forming of profiles such as splines (straight or helical), spiral gears, oil grooves, CV joints, threads, and knurls Workpiece data Workpiece diameter: 38 mm Workpiece length: 500 mm Profile width: 92 mm Profile outer diameter (standard): 50 mm Profile width (standard): 125 mm Rollable profiles for involute gears: 0.3 - 1.25 m Rolling bar length: 610 mm Travel movements Slide stroke: 760 mm Cycle times Tailstock forward (at approx. 300 mm stroke): 1.0 s Rolling bars forward: 3.0 s Tailstock retraction (at approx. 300 mm) Stroke): 1.5 s Rolling bars return: 3.5 s Loading/unloading (manual): 5.0 s Fgsdpfx Ajwmb Trofpeh Cycle time: 14.0 s Gear cuts/hour at 100% Ne: 260 MACHINE DETAILS Overall width: 5,014 mm Machine width: 2,360 mm Depth without boom: 2,541 mm Depth with boom: 4,165 mm Height: 2,100 mm Machine weight: 10 t Electrical design – Voltage/Frequency: 380/50 V/Hz Total power requirement: 24 kW Drive power: 22 kW EQUIPMENT - Complete enclosure - Tailstock - Hydraulic system - Oil system

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, workpiece diameter (max.): 160 mm, rotational speed (max.): 300 rpm, workpiece length (max.): 25 mm, TECHNICAL DETAILS Description: Hydraulic internal rolling machine for tapered or cylindrical back rolling of profiles on sliding sleeves, sliding gears, or similar parts. Workpiece Data Workpiece diameter: 160 mm Workpiece length: 25 mm Workpiece internal gearing, adjusted approx.: 85 mm Workpiece external: 75 - 140 mm Workpiece width approx.: 16 - 36 mm Workpiece external pressure ring, adjusted: 160 mm Travel and setting data Maximum travel of the rolling carriage: 60 mm Center distance between workpiece and rolling wheel: 22 mm Rolling wheel speeds, continuously adjustable: 30 - 300 rpm Rolling pressure, continuously adjustable (at 100 bar): 6.1 t Control system: SIEMENS PLC Monitoring control: LAUER PCS 900 / BRANKAMP C 90 with screen display MACHINE DETAILS Machine weight approx.: 4,500 kg Space required approx.: 2.5 x 2.5 x 2.1 m Spindle drive approx.: 6 kW Total drive: 14 kW Total power requirement: 14 kW Operating voltage: 400 V Frequency: 50 Hz EQUIPMENT - Workpiece carousel loading device for 18 workpieces with workpiece inspection station - Workpiece transport device Fjdpswmb Rkofx Afpjgh - Changeover time to a different workpiece size: 30 min / Machining time per workpiece approx.: 25 s - Workpiece storage for intermediate storage - Separate hydraulic system - Separate control cabinet - Coolant system Note: Working areas are approximate and depend on the workpiece and tool conditions.

Condition: used, Year of construction: 2016, Technical details: Fgedeudf Evepfx Afpjh weight: 22 t

Condition: used, Year of construction: 1987, rolling capacity max. NA t workpiece diameter 38 mm workpiece length 500 mm total power requirement 24 kW weight of the machine ca. 10 t dimensions of the machine ca. m Max.Ø tool slide stroke 760 mm Max.Ø rack length 610 mm Length of workpiece between centres, approx. 500 mm Max. tooth width / profile width 92 mm Max. workpiece Ø 38 mm Tailstock stroke on outboard support, hydraulic, approx. 500 mm Module range 0.3 - 1.3 Total electrical load, approx. 24 kW - 380 V - 50 Hz Weight, approx. 10,000 kg Accessories / Special Features * KBH Workpiece Feed Device, standing parallel to the machine, at present set-up for feed-in and feed-out of shaft-formed workpieces, approx. Ø 16 x 200 mm long, with prism conveyor belt and lifting station for 2 shafts (blank and finished part), as well as workpiece positioning control. * Originally, external gears were formed on the machine using pinion cages (no. of teeth = 25), Ø approx. 32 mm x 14 mm long, workpiece Ø approx. 80 x 80 mm long. * Various accessories: * Separate switch cabinet. * Separate hydraulic unit, 900 l. * Coolant device in the machine. * Control panel with malfunction message in plaintext, etc. Roto Flo machines are ideal for mass production of smaller gears/profiles. The coldforming process is a lot faster and more economical than other chip removing methods. Workpieces are clamped between 2 live centres and 2 synchronous opposed directional coldforming racks simultaneously engage the workpart and start rotation. During rotation, the profile is formed successively within one stroke. In the calibrating zone, the profiling and surfacing performance of the tool are optimised. Profiles do not require a run-out. The coldforming process requires a rigid and heavy duty construction of the machine, which ensures the required precision over the years. Between 25,000 and 100,000 working cycles can be performed with one set of racks, also for serrations. Condition : Very good. Machine can be inspected under power. Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract. Thank you for your interest. We always have a good selection of gear machines available. Please let us know what you need. Fgedpfjt Hw D Dox Afpjh

Condition: reconditioned (used), machine/vehicle number: 550-235-ELD, GENERAL CHARACTERISTICS workpiece Ø max. 41 mm Range Module máx/min. 1,5 / 0.39 Rack face width 92 mm Manufacturing No. 550-235-ELD Máx/min. pitch form 20/40-32/64 Maximum stroke of tools trolley 760 mm Rack length máx. 610 mm ELECTRICAL CHARACTERISTICS Fgsdpfx Afod Nw Ttjpeh Main motor power 15 Cv
