Used Axa Vcc 50 for sale (44)

Condition: used, Year of construction: 2008, machine/vehicle number: 8504, Make: AXA Type VHC 50 / 2000-XTS Year of manufacture: 2008 Control: CNC CNC moving column machining center AXA - VHC 50 2000-XTS - 5 axes - NC rotary table WITHOUT chuck shown - Infinitely variable positioning of the swivel milling head - Pick-up station Technical details / accessories / add: x-way vert. 2.000 /hor. 1.400/2 mm y-path vert. / hor. 900 mm z-path vert. 1,200 / hor. 940 mm Control iTNC 530C Heidenhain Distance between spindle nose and table vert. 0 - 740 mm Distance between spindle nose and table hor. 250 - 1,050 mm Main spindle: Speed range - main spindle 30 - 7,500 min/-1 Drive power - main spindle 25 kW Max. Torque 540 Nm Tool holder SK 50 DIN 69871A Tiltable +/- 115 ° Resolution 0.001 ° NC rotary table: Face plates diameter 1,500 mm Table speed 20 min/-1 Max. table load approx. 1,500 kg Tool changer: Pelhceqy E Apocqnogk Number of tool positions 60 pos. SK 50 tool holder max. tool diameter 110 mm max. tool diameter with free neighboring box 180 mm Max. tool length 400 mm max. tool weight max. 15.0 kg Changing time approx. 8.0 sec Feed rates: rapid traverse ( X / Y / Z ) 30 / 30 / 25 m/min Total power requirement 75 kVA Machine weight approx. 33.0 t Space requirement approx. 10.0 x 7.0 x 4.0 m Chip conveyor Coolant system High pressure cooling Internal coolant supply Oil mist extraction Paper belt filter B-axis Swivel milling head Hydraulic unit various tool holders approx. 10 pcs. Tool changer 60-fold measuring probe electr. handwheel Operating mode 4 Errors in technical data excepted. machine has been freshly repainted inside and out.

Condition: ready for operation (used), Year of construction: 2008, Functionality: fully functional, travel distance X-axis: 2,000 mm, travel distance Y-axis: 900 mm, travel distance Z-axis: 1,200 mm, controller model: Heidenhain iTNC 530C, spindle speed (max.): 7,500 rpm, number of slots in tool magazine: 60, Equipment: chip conveyor, The machine was recently repainted (inside and out) TECHNICAL DETAILS X-axis: 2,000 mm Y-axis: 900 mm Z-axis: 1,200 mm Rapid traverse speed (X/Y/Z): 30 / 30 / 25 m/min Pgslhov D N Imsccqnek Main spindle Speed range: 30 - 7,500 rpm Drive power: 25 kW Max. torque: 540 Nm Tool holder: SK 50 DIN 69871A Swivel range: ±115° Resolution: 0.001° Distance spindle nose - table Vertical: 0 - 740 mm Horizontal: 250 - 1,050 mm NC rotary table Faceplate diameter: 1,500 mm Table speed: 20 rpm Max. table load: approx. 1,500 kg Tool changer Capacity: 60 tools Tool holder: SK 50 Max. tool diameter: 110 mm Max. tool diameter with free adjacent tool box: 180 mm Max. tool length: 400 mm Max. tool weight: 15.0 kg Changeover time: approx. 8.0 s MACHINE DETAILS Dimensions: approx. 10.0 x 7.0 x 4.0 m Weight: approx. 33.0 t Connected load: 75 kVA Operating hours: The last service visit was in December 2019. At that time, the operating hour meter showed 42,554 hours, which was confirmed in writing by the manufacturer, AXA. The machine was dismantled in February 2020. EQUIPMENT - Swivel milling head, continuously adjustable positioning - Pick-up station - Coolant system with high-pressure cooling - Internal coolant supply - Oil mist extraction - Paper belt filter - Hydraulic unit - Measuring probe - Electric handwheel - Various tool holders (approx. 10 pieces) Rotary table is sold without the chuck shown. Any vises, tool holders, and jaw chucks shown are not included!

Condition: good (used), Year of construction: 2012, AXA DBZ 2/50 double station machining center, Year of construction 2012, Siemens 840 control system, Travel X/Y/Z 2x800/600/600 mm, 16-position tool changer, SK 50 tool holder, Spindle speed up to 4,000 rpm, Pgslhoridf Uoccqnok Milling spindle - water-cooled hollow shaft motor, dir. Measuring systems, chip conveyor, heat exchanger, switch cabinet, oil mist lubrication, Rittal cooling system,

Year of construction: 2003, Condition: excellent (used), Working travels 6000x1000x1200mm B-Axis milling head +/-90° Table size 6400x1000mm Spindle taper HSK-100 Pgjlhcjd Rz Uvecqnek Spindle speeds -9000 rpm Tool changer 80 pos. Control SIEMENS 840D Coolant through spindle Tool measuring device Zero point clamping system 3R MARCELS MASCHINEN CH

Condition: ready for operation (used), Year of construction: 2000, Functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 400 mm, spindle speed (max.): 8,000 rpm, overall weight: 12,000 kg, AXA KBM 1500/3000 4-axes X1500 Y3000 Z400 A360º rotation table 600mm tool changer 20x machine is in good condition, currently still in use Pgjlhccsv Nppbeqnjk

Condition: new, Year of construction: 2024, The P50MR motorized hydraulic press guarantees high performance and maximum execution precision thanks to the robust structure entirely cut by laser without welding in the points of greatest stress. They are equipped with a 400 [V] 50-60 [Hz] submersible motor control unit, a fast approach and return pump calibrated to 20 [bar] plus an adjustable pressure pump with handwheel to obtain the required power. They are also equipped with a pressure relief valve with mechanical block to prevent overpressure and the pressure gauge (standard) allows to calibrate with extreme precision the power delivered. Power Ton 50 Inside light shoulders mm 800 Approach speed mm/min 1800 Working speed mm/min 350 Rapid flow rate l/min 26 Flow rate in slow l/min 5 Cylinder stroke mm 300 Cylinder bore mm 135 Stem diameter mm 70 Shank diameter mm M30 Tank capacity 50 litres Max. pressure bar 350 Voltage V400 Frequency Hz 50-60 Engine power kW 3 Max. current consumption A 5.5 Weight kg 500 Dimensions 1550 x 800 x 1965 (h) Pgelsfvhqgohccqnok

Condition: ready for operation (used), Year of construction: 2015, length in total 6580 mm band width 450 / Nennweite 500 mm conveying height 1200 38,1 Pgslhccqsv Htlbjnok total power requirement 0,55 kW weight of the machine ca. 0,75 t dimensions of the machine ca. 6,6*1,2*1,5 m EXW TIROL / Austria

Condition: used, Quills, processing unit, automatic drilling machine, drilling machine, standing drill, Multi-spindle drilling machine -System without control -1x quill processing units Pelhsb A I Dxoccqnjgk -2x sledges -Max. Feed stroke: 110 mm -Speed: 1400 rpm -Built-in collet: 6 mm -Weight: 350 kg

Year of construction: 2023, Condition: new, AXA MOVING CYLINDER ELECTRO-HYDRAULIC PRESS. 150-ton power. Automatic double speed with rapid. Moving cylinder stroke 816 mm transverse. Internal clearance from shoulder to shoulder mm 1500 Rod stroke mm 300 GALTECH distributors. - 2MP block. - No. 2 VIVOIL external gear unidirectional pumps. One for rapid approach and return (calibrated at 20 bar) and one with adjustable pressure with handwheel to set the required power. - Pressure relief valve with mechanical lock to prevent overpressure. Polhcslruhdecqnsgk - Standard pressure gauge to display power output. - INTECH electrical panel certified according to current regulations and with independent CE marking.

Condition: good (used), Year of construction: 2002, Functionality: fully functional, Technical details x-travel 2940 mm y-travel 900 mm Pgslhccjwgatdoqnok z-travel 950 mm Control Heidenhain iTNC 530 Additional information 5-axes Universal Machining Center Travels: X-axis: 2940 / 2 x 1220 mm Y-axis: 900 mm Z-axis: 950 mm CNC swivelling milling head with infinitely variable positioning, directly programmable from -90 to +90 deg. Speed range: 35 to 8000 rpm. Drive power: 20 kW Tool holder: SK 40 Tool positions: 2 x 22 (44) Table size: 3890 x 800 mm Built-in NC rotary table RTA4S800 Equipment: CNC control HEIDENHAIN iTNC 530 Chip conveyor Measuring probe, RENISHAW OMP 60 Coolant system Paper band filter SA 25/600, 20 bar Electronic handwheel Heidenhain HR 410 Operating instructions Machine parameters on storage medium

Condition: ready for operation (used), Year of construction: 1990, Control Unit Brand SIEMENS Main Drive Number of axis 4 Movement X-Axis Movement 2360 Y-Axis Movement 420 Polhcjv Nb Euecqnegk Z-Axis Movement 600 This 4-axis AXA VSC 2 M vertical machining center was manufactured in 1990. Consider the opportunity to buy this AXA VSC 2 M vertical machining center. Contact us for more information. Application Types Milling

Condition: good (used), Manufacturer: AXA Type: HFB 600 Control system: Siemens 840D Solutione Line Year of construction: 2015 Specifications: Metric Metric US Standard There are no specifications for this machine (yet). Dimensions (estimate) length Pgolhccqot Tdp Tenjk 7800 mm width 2300 mm height 2250 mm weight 15000 kg Please note: The information on this page is given in good faith and to the best of our knowledge, and where possible, has been obtained from the manufacturer, but accuracy cannot be guaranteed. Accordingly, it does not constitute a representation or contract and we recommend that you check all relevant details. Finishing of sealing surfaces The finishing of the sealing surfaces of the approx. 17m long tubes is done by an NC-controlled feed unit and an NC-controlled facing slide with 2 ABS tool holders for either lathe tools, measuring sensors or measuring probes. The work piece is first measured via the measuring sensors in the slide heads and aligned by the adjustable roller supports. The tube is hydraulically tightened into position by the swimming jaw once it lies at a right angle and centric to the facing slide head. The interchangeable measuring sensors calculate how to process the surface whic

Condition: new, Year of construction: 2024, Electro hydraulic press 110 Ton Made in Italy The P110 MR is equipped with: 400 V 50-60 Hz immersed motor control unit. Pump for fast approach and return in 20 bar calibration. Adjustable pressure pump with handwheel to obtain the required power. Pressure relief valve with mechanical block to prevent overpressure. Pressure gauge (standard) that allows to calibrate with extreme precision the delivered power. The P110 MR is the only hydraulic press consisting of 2 laser-cut FE 510 monolithic structure uprights. without welding in the places of greatest stress This feature gives it extraordinary robustness. It is non-deformable and guarantees tight working tolerances. The P110 MR is equipped with a 30-litre tank and has a rapid descent speed of 1,400 mm/min. Weight : kg 1,100 Max pressure : bar 350 Max. flow rate : t. 110 Rapid flow rate :l/min 34 Slow flow rate : l/min 5 Pjlhjfh R N Doccqnegk Inside shoulders : mm 1004 Rapid rod feed : mm/min 1.400 Slow rod feed : mm/min : 130 Voltage : V 400 Frequency :Hz 50-60 Power : kW 3 Max. absorbed current : A 7,3 Cylinder stroke : mm 300 Cylinder diameter : mm 200 Stem diameter : mm 110 Piston descent speed : mm/sec 23 Tank capacity : litres 30

Condition: used, Year of construction: 2000, x-travel 1760 mm y-travel 500 mm z-travel 600 mm control TNC 410 table-size 2000 x 500 mm feeds 1 - 10000 mm/min rapid traverse 25/25/20 m/min spindle turning speed - stepless 60- 6000 U/min spindle taper ISO 40 tool change unit 22 Pos. total power requirement 69 kW weight of the machine ca. 10 t Pelov Uccrjhccqnjgk dimensions of the machine ca. 4,2 x 2,3 x 2,7 m This machine does have a long table for long parts or with a partition to work by shuttle machining. Control: Heidenhain TNC 410. We supply 3 pieces additional tables along with the machine.

Condition: used, Year of construction: 2007, operating hours: 33,156 h, machine/vehicle number: 88746, AXA Portale VPC-55 in good condition Heidenhain iTNC-530 Vertical 3-axis gantry center Year of construction 2007 X-axis 2360mm Y-axis 1400mm Pgolhccovg Hd Dsqnjk Z-axis 900mm Table clamping surface approx. 2700 x 1100mm, load up to approx. 3000kg Pendulum operation possible 7 T-slots 14H9 Mass approx. 25t. Oil drip tray Heidenhain handwheel HR 410 Heidenhain direct measuring system M&H 3D probe Machine protection system from Brankamp Spindle version SK50 DIN 69871A 56kW drive with up to 6000 1/min IKZ 20bar + belt filter system in tank Spindle hours approx. 28700 Tool changer 30x Hinged belt chip conveyor right side Chip flushing gun

Condition: used, Year of construction: 2011, Technical details: x-travel: 2600 mm y-travel: 900 mm z-travel: 900 mm spindle turning speed range: 6000 U/min table surface area: 3450 mm tool taper: SK 40 numbers of tools: 36 weight of the machine ca.: 21 t space requirements approx. LxWxH: 8 x 4,5 x 3,2 m connected load: 69 kW New spindle 2024 Infrared probe Polhccqswdv Ncensgk A-axis stepless Internal cooling Air through spindle *

Condition: ready for operation (used), Year of construction: 2006, operating hours: 12,965 h, Control Unit Brand HEIDENHAIN Model iTNC 530 Main Drive Spindle speed range 6000 (-15000) Tool taper SK 40 (HSK-A63) Number of axis 5 Movement X-Axis Movement 2940 mm X-Axis Rapid Traverse 40 m/min Y-Axis Movement 900 mm Y-Axis Rapid Traverse 30 m/min Z-Axis Movement 950 mm Z-Axis Rapid Traverse 30 m/min C-Axis Movement +/-100º Table Table load 1200 kg Tools Slots in storage 36 Max tool diameter 85 (with adjacent free slots 135 mm) Max tool length 400 mm Additional Equipment Machines comes with C-axis and a +/-100º b-axis head. This 5-axis AXA VHC 3-3000 S was manufactured in 2006. A universal machining centre, it offers robust capabilities for diverse machining tasks. Ideal for those seeking reliable performance in a used machine. Contact us for more information. Application Types Milling Pjlhccjvxl Rajqnjgk

Condition: good (used), Year of construction: 2017, travel distance X-axis: 4,000 mm, travel distance Y-axis: 900 mm, travel distance Z-axis: 950 mm, Manufacturer: AXA Type: VHC 3XT Control: SIEMENS 840D Year of construction: 2017 Double rotary table left and right 4e axis Gantry mode for clamping long bed workpieces Tilting spindle head for machining all sides in 1 setting Distance spindle - table vertical 0 - 970 mm Distance spindle - table horizontal 250 - 1100 mm Large tooling package included (holders and vices and clamping) Clamping assembly beam off 4000 mm for fast & flexible change overs Direct measuring in all 3 axis with resolution 0.001 Power on 21,000 running around 8000 Hours Specifications Metric US standard X - axis 4000mm Y - axis 900mm Z - axis 950mm B - axis 270° table length 4000 mm Table width 900 mm Table load 1500 Peljv Ta Suohccqnegk X-axis feed 40,000 mm/min. Y-axis feed 40,000 mm/min. Z-axis feed 30,000 mm/min. Tool holder Sk50 ISO/Bt/Mk Spindle power 56 kW Speed 6000 rpm Tool changer 22 Internal coolant supply Yes Number of controlled axes 3 + 2 Chip conveyor Yes Cooling system Yes Dimensions (estimate) Length 9950 mm Width 4300 mm Height 3600 mm Weight 36000 kg Please note: The information on this page has been obtained to the best of our knowledge and belief, and where possible, from the manufacturer. The information is provided in good faith, but its accuracy cannot be guaranteed. Accordingly, it does not constitute a representation or contractual terms. We recommend that you check all important details.

Condition: good (used), Year of construction: 1999, For sale is a horizontal machining center from Axa of the Vario type with 2 milling tables. The machine is in good condition and has done little "heavy machining" (was mainly used for drilling and thread cutting). Technical data: Year of manufacture 1999 Control: Heidenhain TNC 410 M digital Table dimensions 2030 mm *500 mm Maximum table load (evenly distributed) 800 kg Min. speed 30 1/min Max. speed 10.000 1/min Drill length on X-axis (mechanical feed) 1760 mm Drill length on Y-axis (mechanical feed) 500 mm Drill length Z-axis (mechanical feed) 620 mm Machine dimensions: Height: 3900 mm Length: 2900 mm Width: 3000 mm Weight: 9 tons SCOPE OF DELIVERY/EQUIPMENT 1 spindle version SK 40 DIN 69 871 A 1 switch cabinet (integrated in the rear of the machine) Ball screws: Made by Deutsche Star Central lubrication unit: Bielomatik Hydraulic unit: Hydac RTA 2-300 MK-3 tailstock manually operated Electric handwheel HR 410 Pjlhett Abmsccqnsgk Scraper belt conveyor discharge side right Measuring probe TS 630 WORKPIECE HOLDERS NOT INCLUDED IN THE OFFER Prices plus value added tax Viewing possible by appointment. Contact us, our team will be happy to help you. Trade-in or exchange possible! Machines purchase / sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MUCH MORE. Do you need a high-quality but inexpensive metalworking machine for your production? Or do you want to sell yours? For further information or contact options, please visit our website

Condition: ready for operation (used), Year of construction: 2001, Functionality: fully functional, machine/vehicle number: 86084, travel distance X-axis: 1,760 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 600 mm, table width: 2,030 mm, table length: 500 mm, spindle speed (max.): 8,000 rpm, number of slots in tool magazine: 22, Equipment: chip conveyor, documentation/manual, No reserve price - guaranteed sale to the highest bidder! Page layout: Left/right editing possible with a divider. TECHNICAL DETAILS X-axis stroke: 1,760 mm (2 x 700 mm) Y-axis stroke: 500 mm Z-axis stroke: 600 mm Table clamping area: 2,030 x 500 mm T-slots: 3 x (14H9 / guide slot H7) Spindle & Tool Change Spindle mount: SK 40 DIN 69 871 A Tool changer: 22-station, side-mounted Speed range: 80 - 8,000 rpm Spindle disk: Ø 144 B 26035/2/2 Control & Axes Control: Heidenhain TNC 410 M Control panel: CNC contouring control, movable on the right side of the machine Control cabinet: Integrated into the rear of the machine Ball screws (Deutsche Star) X-axis: 1510 - 5 - 3471 Ø 50 x 20 x 2,450 mm Y-axis: 1510 - 4 - 5103 Ø 40 x 20 x 1,300 mm Z-axis: 1510 - 4 - 4811 Ø 40 x 10 x 1,190 mm Pgjlhsv Sbkpeccqnsk Measuring system Manufacturer: Heidenhain Type: LS 186 C 1840 ML (X), LS 186 C 640 ML (Y), LS 186 C 740 ML (Z) Central supply systems Central lubrication system: Bielomatik Hydraulic unit: Hydac MACHINE DETAILS Machine weight: 9.5 t Dimensions: 3.8 x 2.9 x 3.1 m Machine length with chip conveyor: 5.4 m EQUIPMENT - External belt filter system (300 liters, 20 bar) - Hinged-belt chip conveyor type FSB 300 - Electric handwheel HR 410 (Heidenhain) - Coolant line with 6 nozzles - Splash guard cover - 2 hand guns - 2 work area lights - Includes 6 vices

Condition: excellent (used), Year of construction: 2002, AXA Vario 2 Year 2002 Pjlhceumhumocqnjgk Travel X : 1700 mm Travel y : 600 mm Travel z: 600 mm 1,760 mm or 2 x 700 mm IKZ Tool changer : 22 times / SK 40 8000 1/min

Condition: good (used), Year of construction: 2008, Universal machining center: Moving column Machine type: AXA VHC 2 - 1760 XTS Control: Siemens 840 D ShopMill Year of construction: 2008 TECHNICAL DATA: Travels: X-axis: 1,760 (2 x 630) mm Y-axis: 600 mm Z-axis: 800 horizontal or 770 vertical mm A-axis B-axis: +/- 100°, hydraulically clamped, infinitely variable interpolation Rapid traverse: (X/Y/Z): 40 / 40 / 30 m/min. Number of controlled axes: 5 Speed range: 30 - 6,000 1/min. Drive power: 30 kW Torque: 143 Nm Tool holder: SK 40 Tool changer Tool positions: 36 NC rotary table: AXA RTA 4L-520 Faceplate: Ø 520, for vertical & horizontal setup mm Tailstock: manual, center height 280 mm Polhev Nhwdjccqnegk Machine weight: 12,000 kg Space requirement (LxWxH): 5.2 x 3.4 x 3.3 m Equipment features: Internal cooling (IKZ): 30 bar Chip conveyor: Discharging to the left, integrated 200 l coolant tank Coolant system Coolant tank: 400 l Measuring probe: 3 D, Renishaw RMP 60 with RMI receiver (wireless version) Optional use of external cooling with compressed air or emulsion Direct path measuring system: Heidenhain Operating mode: 4 Separating plate for work table for pendulum machining Hardened flat guides Counter guides coated with sliding surface (Turcite) Renewal of the sliding surface of the basic slide X/Y in 2022.

Condition: used, Year of construction: 2005, travel distance X-axis: 8,000 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 850 mm, controller manufacturer: HEIDENHAIN, controller model: ITNC 530, total height: 3,300 mm, table width: 600 mm, table length: 8,930 mm, overall weight: 28,000 kg, spindle speed (max.): 15,000 rpm, space requirement length: 11,200 mm, space requirement width: 3,300 mm, CONTROLS .. CNC controls HEIDENHAIN ITNC 530 BASIC DESIGN .. basic design: moving column WORKING RANGE -CUBIC- .. number of processing axes (excl parallel axes): 5 .. X-axis travel: 8000 mm .. Y-axis travel: 700 mm .. Z-axis travel: 850 mm .. rotating range B-axis from: 90 ° .. rotating range B-axis up to: -90 ° .. distance of axis of horizontal spindle - clamping surface (max.): 1030 mm TABLE .. table surface (left-right): 8930 mm .. table surface (front-back): 600 mm SPINDLE / HEAD .. tool fixture: HSK A63 .. spindle revolutions (min): 30 /min .. spindle revolutions (max): 15000 /min .. tool fixture: HSK A63 Pelhcsvtp Aiecqnegk .. drive power S6 40%: 30 kW .. spindle torque S6 40%: 143 Nm AXIS DRIVES .. traverse velocity X (max): 10000 mm/min .. traverse velocity Y (max): 10000 mm/min .. traverse velocity Z (max): 10000 mm/min .. rapid traverse X: 40000 mm/min .. rapid traverse Y: 40000 mm/min .. rapid traverse Z: 30000 mm/min TOOL MAGAZINE .. number of positions: 36 .. tool diameter max.: 85 mm .. - with free neighbour positions: 135 mm .. tool length max.: 400 mm .. tool weight max.: 10 kg .. tool changing time: 5 s ELECTRICAL SPECIFICATIONS .. mains power supply: 55 kVA .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. space requirements -left/right-: 11200 mm .. space requirements -front/back-: 3300 mm .. total height: 3300 mm .. total weight approx.: 28000 kg ATTACHMENTS .. guideway covers: yes .. chip conveyor: yes .. coolant unit: yes .. band filtration unit: yes .. through spindle coolant attachment: yes .. closed cabin: yes .. European CE standards: yes X = 8000mm or 2x 3750mm pendulum stroke (vertical) - Internal cooling 40 bar - Coolant tank 800 liters - Belt filter - 3 D radio measuring probe - Raising the machine table by 70mm - Table load 1200kg/m² - Machines currently in storage and no longer powered - 2 round tables with clamping cubes

Condition: ready for operation (used), Year of construction: 2007, operating hours: 33,157 h, Functionality: fully functional, machine/vehicle number: 86746, travel distance X-axis: 2,360 mm, travel distance Y-axis: 1,400 mm, travel distance Z-axis: 900 mm, controller model: Heidenhain iTNC-530 B, table load: 3,000 kg, rotational speed (max.): 6,000 rpm, Pendulum operation possible TECHNICAL DETAILS X-axis: 2360 mm Y-axis: 1400 mm Z-axis: 900 mm Table clamping area: approx. 2700 x 1100 mm Max. table load: approx. 3000 kg Clamping system: 7 T-slots 14H9 Control: Heidenhain iTNC-530 Spindle system Spindle design: SK50, DIN 69871A Drive power: 56 kW Max. spindle speed: 6000 rpm Number of slots in the tool magazine: 30 MACHINE DETAILS Machine switch-on time: 99,990 h Program run: 33,157 Poljv D Nw Uehccqnegk Spindle hours: approx. 28,700 Machine weight: approx. 25 t EQUIPMENT - IKZ with belt filter system (20 bar) - Machine protection system (Brankamp) - Hinged belt chip conveyor - Measuring system (Heidenhain direct) - 3D probe (M&H) - Oil drip tray - Chip flushing gun Any visible vices, tool holders and jaw chucks are not part of the scope of delivery!

Condition: good (used), Year of construction: 2008, travel distance X-axis: 750 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 600 mm, controller manufacturer: HEIDENHAIN, controller model: ITNC 530C, total height: 2,800 mm, table width: 500 mm, table length: 1,000 mm, overall weight: 8,000 kg, spindle speed (max.): 10,000 rpm, space requirement length: 6,000 mm, space requirement width: 4,500 mm, CONTROLS .. CNC controls HEIDENHAIN ITNC 530C BASIC DESIGN .. basic design: moving column WORKING RANGE -CUBIC- .. number of processing axes (excl parallel axes): 3 .. .. among of them simultaneous CNC axes: 3 Pelju Nkcashccqnjgk .. X-axis travel: 750 mm .. Y-axis travel: 500 mm .. Z-axis travel: 600 mm TABLE .. table surface (left-right): 1000 mm .. table surface (front-back): 500 mm .. workpiece load (max): 800 kg SPINDLE / HEAD .. spindle revolutions (max): 10000 /min .. tool fixture: ISO SK 40 TOOL MAGAZINE .. number of positions: 22 DIMENSIONS / WEIGHTS .. space requirements -left/right-: 6000 mm .. space requirements -front/back-: 4500 mm .. total height: 2800 mm .. total weight approx.: 8000 kg Machine for shuttle operation 2xX750mm, Machine in good and well-maintained condition Has only processed aluminum or plastic Equipment: - various tool holders - each side with 3R clamping system (see photo) - Workspace light
