Used Gildemeister Ctx 500 for sale (231)

Condition: good (used), Year of construction: 2015, operating hours: 28,735 h, Functionality: fully functional, spindle speed (max.): 5,000 rpm, DMG Gildemeister CTX Beta 500 The DMG Gildemeister CTX Beta 500 is a high-precision and versatile CNC lathe that is ideal for demanding production tasks. This machine combines state-of-the-art technology with reliability and precision and is ideal for machining workpieces with complex geometries. Technical data: - Model: CTX Beta 500 - Manufacturer: Gildemeister Drehmaschinen GmbH - Year of manufacture: 2015 - Control: Siemens 840D - Spindle hours: 11,344 hours - Tool holder VDI40 12 Pos. - Heat exchanger for spindle - Direct position measuring system - IKZ 600 l - Chip conveyor - Oil mist extraction - Including approx. 60 tools - Rotation diameter over bed: 700 mm - Rotation diameter over slide: 380 mm - x -axis: 300 - y -axis: 120 (+/- 60) mm - z -axis: 550 mm Cplf0A9Psi

Condition: excellent (used), Year of construction: 2010, Heidenhain Turn Plus IT control Turning diameter 410 mm turning length 500 mm Main spindle speed 5,000 min-1 Cz29Cpksaq Counter spindle speed 6,000 min-1 16-position turret with driven tool Chip conveyor Bar loading magazine IRCO SIMAG

Condition: ready for operation (used), Year of construction: 1999, Functionality: fully functional, turning diameter over cross slide: 680 mm, turning length: 1,097 mm, turning diameter: 680 mm, spindle bore: 107 mm, spindle speed (max.): 3,600 rpm, spindle speed (min.): 18 rpm, travel distance X-axis: 320 mm, travel distance Z-axis: 1,097 mm, spindle motor power: 23,000 W, quill stroke: 120 mm, overall weight: 8,700 kg, CTX 500 V1 with Heidenhain 3190 Machine is fully operational Viewing under power is possible Hx3J7Ud Very nice machine

Condition: excellent (used), Year of construction: 2014, Functionality: fully functional, turning length: 460 mm, turning diameter: 240 mm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 145 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 520 mm, tool mount: 30 mm, bar passage: 52 mm, Turning and milling center Gildemeister CTX 500 Alpha V6 with Y-axis and short bar loader. Year of construction: 2014 Control: Heidenhain CNC Pilot 640 Technical data: Main spindle speed: 30 - 6,000 min-1 Spindle type: ISM 52 Drive power: 22 KW Chuck diameter: 165mm, 3 jaws Counter spindle speed: 30 - 6,000 min-1 Spindle type: ISM 36 Chuck diameter: 170mm Turret: 12 stations Number of rubbed: 12 stations Tool holder: VDI 30 Speed: 10 - 5,000min-1 Uj9Rh372Rl Travels: X-axis: 135mm Y-axis: +/- 40mm Z1-axis: 520mm Center distance: 780mm Accessories: - Short bar loader LNS Quickload - Coolant system with 12bar - Counter spindle flushing - Small tool package - Chip conveyor

Condition: used, Year of construction: 1997, turning length 1.000 mm swing diameter max. over bed cover 600 mm swing diameter above cross guideway 420 mm control Eltropilot Heidenhain travel -x axis 275 mm travel -z axis 1.065 mm Main spindle: turning speed range - main spindle 16 - 3.200 min/-1 power capacity - main spindel 27 kW max. Torque 800 Nm spindle diameter in front bearing 120 mm spindle bore 85 mm chucking diameter 260 mm spindle head 220H5 turret: number of toolpositions 12 pos. Shank diameter 40 mm turret change time 0,8 sec. Tailstock: diameter of quill 100 mm quill stroke 120 mm taper of center MK 5 pressure center sleeve max. 950 daN feeds: rapid traverse X: 10 / Z: 15 m/min Feed force X: 500 / Z: 1.000 daN total power requirement 52 kVA Plghia30 weight of the machine ca. 7,5 t dimensions of the machine ca. 5,5 x 2,5 x 2,1 m CNC-Lathe GILDEMEISTER - CTX 500

Condition: ready for operation (used), Year of construction: 1999, Functionality: fully functional, turning diameter over cross slide: 455 mm, turning length: 1,097 mm, turning diameter: 680 mm, spindle bore: 107 mm, spindle speed (max.): 3,600 rpm, spindle speed (min.): 18 rpm, travel distance X-axis: 320 mm, travel distance Z-axis: 1,097 mm, spindle motor power: 23,000 W, rapid traverse X-axis: 24 m/min, rapid traverse Z-axis: 30 m/min, total height: 2,130 mm, total length: 5,560 mm, total width: 2,400 mm, spindle nose: 220h5, CTX 500 with Heidenhain 3190 control unit Fully functional. Available immediately Many tool holders Machine has extraction system Bsdnwljz8Fw

Year of construction: 1992, Condition: ready for operation (used), Travel X/Y/Z: 250mm/150mm/1600mm, speed: 6000rpm, turning diameter: 500mm, turning length: 500mm, turning diameter over bed/slide: 500mm/290mm, center distance: 780mm, spindle diameter: 102mm, tool turret holder: VDI40, tool positions: 12, chuck: KNC S. Including filter system IFN CTX 400, year of construction: 1993, gripper Felsomat line gantry PE03, year of construction: 1992 and chip conveyor Bürener SP225, year of construction: 1992. Dimensions X/Y/Z: approx. 5600mm/2400mm/2100mm, weight: approx. 7500kg, operating hours: 48720h. R88Itvkkj7

Condition: excellent (used), Year of construction: 1998, Functionality: fully functional, Hello I have for sale a reputable brand of DMG GILDEMEISTER CTX 500 V3 CNC lathe machine With C axis and driven tools. The machine is in very good technical and visual condition. _ Type: CNC lathe Manufacturer: DMG GILDEMEISTER Model: CTX 500 V3 Control: HEIDENHAIN 3190 + TURN PLUS overlay for program generation Country of manufacture: Germany Year of manufacture: 1998 _ Machine parameters: - head: 12 - tools for VDI 40 toolholders ( every second socket driven ) - max rpm 3500/min. - C axis B23Z8Jit - driven tools - max length of turning in Z axis: 1150 mm - max diameter of turning in X axis: 500mm - chuck on the spindle BERG Fi-315mm - max roller diameter Fi-91mm - cooling system - hydraulic tailstock - controlled from the program - chip conveyor - spindle drive power: 31 KW - DTR - machine weight: 9 tons _ WHY IS IT WORTH BUYING MACHINES at PPM ? - we have our own service _ stationary and mobile - we have already sold more than 700 DMG machines - possibility to start up the machine at the customer's - operator training and delivery of the machine to the customer included in the price - all our machines are after professional technical inspection - ready to work - purchase of the machine is possible through the installment system and leasing. _ www_ppmsc_en _

Condition: ready for operation (used), Year of construction: 2002, Functionality: fully functional, machine/vehicle number: 02260001501, turning length: 600 mm, turning diameter over cross slide: 324 mm, spindle speed (max.): 5,000 rpm, travel distance X-axis: 185 mm, travel distance Z-axis: 635 mm, indexing of C-axis: 0.025 °, TECHNICAL DETAILS Control system: SIEMENS Max. circulation diameter: 680 mm Circulation diameter via X-guide: 565 mm Max. turning diameter: 324 mm Max. turning length: 600 mm Main spindle Spindle head diameter (flat flange): 170h5 mm Max. bar diameter: 65 mm Spindle diameter (front bearing): 120 mm Spindle bore: 79 mm Drive power S1, 100% ED: 25 kW Speed range: up to max. 5,000 rpm Torque S1, 100% ED: 270 Nm Buckling speed: 900 rpm C-axis (main spindle) Speed: 250 rpm Holding torque: 200 Nm Pitch accuracy: 0.025° Counter spindle Spindle head diameter (flat flange): 140h5 mm Max. bar diameter: 42 mm Spindle diameter (front bearing): 90 mm Spindle bore: 57 mm Drive power S1, 100% ED: 25 kW Speed range: up to max. 7,000 rpm Torque S1, 100% ED: 160 Nm Buckling speed: 1,500 rpm C-axis (counter spindle) Chqdjmsl0K Speed: 250 rpm Holding torque: 120 Nm Pitch accuracy: 0.025° Cross slide (X/Y/Z) Face travel (X): 185 mm Longitudinal travel (Z): 635 mm Vertical travel (Y): +40 mm Rapid traverse speed (X/Y/Z): 60/15/45 m/min Feed force (X/Y/Z): 3.5/7/7 kN Ball screw (Y): 40x5 mm Ball screw (Z): 40x15 mm Counter spindle (Z2) Longitudinal travel: 666 mm Input speed: 45 m/min Ball screw: 40x15 mm Tool carrier Driven tools: 12 Shank diameter (VDI 69880): 40 mm Max. power: 9.4 kW Torque: 20 Nm Speed range: up to max. 4,500 rpm MACHINE DETAILS hydraulic system Capacity: 10 l Pump output: 2.2 kW Max. pressure: 80 bar Clamping device and tailstock pressure: 10-60 bar Coolant device Capacity: 210 l Pump capacity: 1.7 kW Delivery rate (at 6 bar): 20 l/min Electrical power requirement Connected load: 50 kVA Operating voltage: 400 V Frequency: 50 Hz Fuse protection: 80 A Voltage fluctuation: +6%/-10% Bar loader Manufacturer: Breuning Notes - The tools shown in the turret are not part of the auction. - The collets for the collet chuck are included.

Condition: excellent (used), Year of construction: 2010, operating hours: 72,059 h, turning length: 1,050 mm, turning diameter: 465 mm, spindle speed (max.): 3,250 rpm, travel distance X-axis: 300 mm, travel distance Z-axis: 1,050 mm, spindle motor power: 32,000 W, total height: 2,010 mm, total length: 5,300 mm, total width: 2,230 mm, swing diameter over cross slide: 465 mm, torque: 420 Nm, overall weight: 8,100 kg, bar passage: 90 mm, bar diameter: 90 mm, collet bore: 102 mm, CNC controller: SINUMERIK 810D with ShopTurn Capacity X-axis travel mm: 300 Z-axis travel mm: 1.050 Brxsmnukim3 Turning length mm: 1.050 Max. turning diameter mm: ø 465 Swing over bed mm: ø 680 Swing over cross-slide mm: 465 Bar work capacity mm: ø90 Upper turret Number of tool slots St .: 12 (6x driven) Speed ​​driven tools RPM: 4.000 Main spindle Speed ​​spindle rpm: 3.250 Drive power spindle kW: 33/22 (40%/100% DC) Spindle bore mm: 102,5 Spindle nose: Flat flange (220h5) Maximun torque Nm: 420 (100% DC) Tailstock Tailstock travel mm: 850 Holder: MK5 Equipment part catcher Workarea light Foot switch for chuck or collet system Driven tools included Working time hours Spindle 1: 72.059 Rated power kVA: 50 Basic machine dimensions / weight Length mm: 5.300 Width mm: 2.230 Height mm: 2.010 Weight kg: 8.100

Condition: defective spare-parts repository (used), Year of construction: 1995, CNC Lathe Fabr.GILDEMEISTER Type: CTX 600 Year 1995 turning diameter 600 mm turning length 2000 mm chuck Forkardt 315 mm,tool turret Tailstock, chip conveyor. Machine technically in good condition electrically missing parts Machine is good for retofit or spare parts carrier Complete machines Documentation available. Only complete sale. C9Xlpkq

Condition: good (used), Year of construction: 2009, Machine is in good working condition. Parts from pictures will come. With machine will come 3 + 3 live tool holder, and equipement from boxes. Cutting tools not come. Technical details shown on picture. Dqmpzx

Year of construction: 2003, Condition: ready for operation (used), Main Drive Number of axis 3 Additional Equipment Tool support system: Rev. 20/20 It is equipped with a bar feeder and driven tools. Longitudinal slide travel: 635 mm Spindle nose (DIN flat flange): 170h5 Internal spindle taper: 79 mm Spindle diameter: 120 mm Chuck diameter: 250 mm Max. torque: 270 N Number of bed units: 1 This 3-axis Gildemeister CTX 420 linear was manufactured in 2003. It features a max turning diameter over bed of 680 mm and a chuck diameter of 250 mm, suitable for diverse turning tasks. Equipped with a bar feeder and driven tools, it enhances productivity and precision. If you are looking to get high-quality turning capabilities, consider the Gildemeister CTX 420 linear machine we have for sale. Contact us for more information about this machine. Cqvsyapijs Application Types Turning

Condition: excellent (used), Year of construction: 1995, Functionality: fully functional, turning length: 1,500 mm, turning diameter: 500 mm, Control: Cycle control with 14" color screen Grundig Manual Plus TECHNICAL DATA circulation diameter - over bed 500 mm - over cross slide 290 mm Face travel 260 mm Center distance 1500 mm Drive power (100% ED) 11 kW Speed range 8 - 2800 rpm Spindle bore 70 mm Tailstock -Quill diameter 80 mm -Quill stroke 180 mm -Quill holder MK 5 Tool holder Multifix quick-change holder size C EQUIPMENT/ACCESSORIES  Manual turning with handwheels  Turning with work cycles  Automatic turning  Tailstock with various centers  Multifix quick-change holder size 6 incl. various cassettes (approx. 8 pieces) Bn7Sifb2X3S  Three-jaw chuck ø 315 incl. clamping jaws  Four-jaw chuck ø 250 incl. clamping jaws  Closed steady rest  Open steady rest  Splash and chip protection thanks to sliding doors  Protective cover for chuck  Coolant device  Chip tray  Work area lighting  Set-up elements  Documentation

Condition: excellent (used), Year of construction: 2006, Fanuc control ... Fanuc 32i Turning diameter ... 290mm turning length ... 339mm inclined bed spindle bore ... 56mm tool turret ... 6 Axis X ... 160mm Axis Z ... 339mm Axis C ... 360° Spindle speed ... 10-6000/min. Machine weight ... 4200kg L x W x H ... 2885/3865x1720x1670mm Dqlfkb The machine is in good condition, possible to test under power.

Condition: used, Year of construction: 2001, Technical data: Flat travel: 220 mm Cfsgl2Jbru Longitudinal travel: 635 mm Turning diameter over bed: 570 mm Turning diameter over support: 420 mm Main spindle: Speed range: 25 - 5000 rpm Drive power 100% ED: 21 kW Max. Torque: 240 Nm Spindle bearing diameter: 120 mm Spindle bore: 79 mm Counter spindle: Speed range: 25 - 5000 1/min Drive power 100% ED: 9 kW Max. Torque: 72 Nm Rapid traverse: 24 m/min Tailstock: Tailstock diameter in the front area: 80 mm Tailstock travel: 550 mm Tailstock mount: MK 4 Tailstock force min/max: 1.5 / 8 KN Universal disk-type turret with driven tools: Number of driven tool stations: 12 max. clamping diameter of the attached tools: 13 mm Drive power 100% ED: 5 KW Total power requirement: 44 kVA Dimensions without chip conveyor/chip tray, approx.: 3210 x 1750 x 1750 mm

Condition: used, Year of construction: 2006, turning diameter 0260 mm turning length 580 mm control 840 D Siemens centre height 190 mm turning diameter over bed 500 mm turning dia. over face-slide 365 mm Main spindle: turning speed range - main spindle max. 6.000 min/-1 power capacity - main spindel 10 / 7,5 kW max. Torque 115 / 86 Nm spindle diameter in front bearing 100 mm spindle bore 68,5 mm usable bar diameter 52 mm chucking diameter 210 mm axis stroke: travel -x axis 185 mm travel -z axis 580 mm turret: number of toolpositions 12 pos. tool taper VDI 30 Shank diameter 20 x 20 mm feeds: rapid traverse X: 24 / Z: 30 m/min Feed force 4,5 kN total power requirement 30 kVA Bskzusxsi2E weight of the machine ca. 4,25 t dimensions of the machine ca. 5,0 x 2,2 x 1,8 m CNC - Lathe with sub spindle. Control Siemens 840 D. Machine has Y- axe and live tooling. We supply an IEMCA Kid 70 bar loader along with the machine.

Condition: good (used), Year of construction: 2006, Machine is in good working condition Cm8Sskfb2Y

Condition: excellent (used), Year of construction: 2005, technical data in pictures, machine still under power. Bsivucwvpq0

Condition: ready for operation (used), Year of construction: 2001, CNC lathe Gildemeister Graziano GT CTX 400 Control: FANUC 21 Type of machine: CTX 400 Year of manufacture: 2001 Weight of the machine: 5500 kg Speed range: 25-5000 rpm Rotation diameter over bed: 570 mm Rapid traverse: 20/24 m/min Dimensions L x W x H: 5.5 x 2.5 x 1.7 m Bsjw7Qsdgwk Turning length: 600 mm Revolver 12 pos. not driven VDI 40 Tailstock Tailstock taper: MK4 Chuck size: 250 mm Machine works. Spindle ok. Video available.

Condition: ready for operation (used), Year of construction: 2005, machine/vehicle number: 80439431220, CNC lathe Gildemeister CTX 510, Bpzmk7Vz Ser. no. 80439431220, year 2005 with chip conveyor DMG, Ser. no. 11570-00110 and Heidenhain Plus IT control for auction in our online auction with expiry date 26.11.2024 Go via Click-out

Condition: excellent (used), Year of construction: 2004, operating hours: 34,530 h, Functionality: fully functional, turning length: 305 mm, turning diameter: 290 mm, travel distance X-axis: 160 mm, travel distance Z-axis: 305 mm, tool mount: 30 mm, For sale is a CNC turning-milling center of the brand Gildemeister and the type CTX 210 The machine is in very good condition, with 8,400 spindle hours. Individual orders were processed on the machine. Technical data: Year of manufacture: 2004 Control system: Sinumerik 840 D Shopturn Operating hours: 34,530 h Spindle hours: 8,395 h Working range: Circulation Ø over bed path cover: 380 mm Rotation Ø over face guide cover: 290 mm Face travel (X-axis): 160 mm Longitudinal travel (Z-axis): 305 mm Main spindle: Spindle head Ø: 120 h5 Spindle head Ø in front bearing: 90 mm Spindle bore: 56 mm Chuck Ø: 140/165 mm Drive power 100/ED: 7.5 kW Max. torque: 72 Nm Speed range: 20-6,000 1/min Cross slide feed drive: X feed force: 5 kN Z feed force: 5 kN Rapid traverse speed X: 15 m/min Rapid traverse speed Z: 30 m/min Tool turret with AGW stations from Duplomatic: Number of tool stations: 12 of which driven tools: 12 Drive power 40% ED: 3 kW Tool holder: VDI 30 Tailstock: Ponol diameter: 80 mm Tailstock stroke: 345 mm Center point: MK3 Tailstock force min./max.: 400 daN Dimensions and weight: Dimensions L*W*H: 2,885 * 1,690 * 1,670 mm Weight: 3,500 kg Accessories included in the offer: Chip conveyor, training documents, machine description, live center, 3 jaw chucks, clamping key for chuck, various jaws for chuck Offered separately: 1 AGW direct, 1 AGW angle, 14 tool holders right & left, 15 boring bar holders, 1 tool holder lengthwise, 4 drill chuck holders, collet chuck incl. 11 collets, 1* 2-jaw chuck Transportation and loading can be arranged on request, at an extra charge. organized throughout Europe. Prices plus VAT Viewing possible by appointment. Please contact us, our team will be happy to help you. Trade-in or exchange possible! Ccnn2W8B Machines purchase / sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MUCH MORE. Do you need a high-quality but inexpensive metalworking machine for your production? Or do you want to sell yours? For further information or contact options, please visit our website

Condition: excellent (used), Year of construction: 2007, - Control: FANUC 32i - max. bar Ø: 65 mm - max. speed: 5.000 1/min - turret with 12 stations (not driven) - tailstock - chip conveyor Bjya7Hgjax7 - without air filter - Bar loader TOP-Automazioni XF 475 max. bar length 4,200 mm WITHOUT BAR FEEDER € 15.000,-

Condition: used, Year of construction: 2010, turning diameter max. 410 mm turning length 1.235 mm control IT / Turn Plus Heidenhain greates pass round over bed 700 mm Main spindle: turning speed range - main spindle max. 4.000 min/-1 power capacity - main spindel 35 / 45 kW max. Torque 770 Nm spindle head 220 h5 spindle diameter in front bearing 160 mm max. usable bar diameter 95 / 104 mm C-Axis 0,001 ° chucking diameter - mm turret: number of toolpositions 12 pos. Number of driven toolspositions 12 pos. Spindle speed - driven tool stations max. 4.000 min -1 power capacity driven tool-stations 12 kW max. Torque 36 Nm tool taper VDI 40 DIN 69880 turret change time 30°: 0,4 sec. Y - Axis 120 (+/- 60) mm axis stroke: x-axis 300 mm z-axis 1.300 mm y-axis +/- 60 mm Tailstock: tailstock 1.200 mm taper of center MK 5 clamping capacity 1.400 daN feeds: rapid traverse ( X / Y / Z ) 30 / 22,5 / 30 m/min total power requirement 60 kVA weight of the machine ca. 7,7 t dimensions of the machine ca. 6,0 x 3,5 x 2,5 m CNC - Turning- and Millingcenter C2Sc9Zux GILDEMEISTER - CTX beta 1250 V4 - Tailstock - Y-axis - Tool drive - Direct measuring system - Bar machining package - Connection for bar feed / bar loading magazine

Condition: excellent (used), Year of construction: 2005, Control Siemens ... Sinumerik 840 D Cejbgqhv Turning diameter ... 365mm turning length ... 450mm Inclined bed Spindle bore ... 52mm Tool turret ... 12/6 Spindle speed ... 0-6000/min. Main motor power ... 12/16kW Axis C ... 360° Max. Rod diameter ... 60mm L x W x H ... 4000 x 1640 x 1730mm Machine weight ... 3500kg The machine is in good condition, possible to test under power.
