Used Haas St-40 for sale (1)

Condition: good (used), Year of construction: 2016, functionality: fully functional, HAAS ST-40L CNC lathe, year of manufacture 2016, C-axis, driven tools, tailstock, steady rest, extended bed The machine is equipped with a C-axis, driven tools, programmable tailstock, Kitagawa hydraulic steady rest, chip conveyor, and accessories. The machine is powered on and available for testing by appointment. Machine basic specifications: Manufacturer: HAAS Automation, Inc. Model: ST-40L Year of manufacture: 01/2016 Serial number: 3104909 Control system: HAAS CNC Power supply: 3 × 400 V / 50 Hz Machine weight: approx. 14,062 kg Design: extended bed ST-40L Technical parameters: Max. swing diameter over bed: 876 mm Max. turning diameter: 648 mm Max. turning length: 2,032 mm X-axis travel: 432 mm Z-axis travel: 2,032 mm Work travel X/Z: 18 / 8.1 m/min Rapid traverse X/Z: 18 / 8.1 m/min Positioning accuracy: 0.005 mm Repeatability: 0.003 mm Spindle Spindle: A2-8 Spindle bore: 102 mm Spindle bore diameter: 117 mm Max. spindle speed: 2,400 rpm Spindle power: 30 kW / 40 HP Torque: 1,898 Nm at 150 rpm Chuck: hydraulic 3-jaw Kitagawa B15, diameter 381 mm Turret and driven tools Turret: 12-position combined turret Tool clamping: 6× VDI 40 / 6× BOT Driven positions: every other position in the turret Tool drive: yes C-axis in the spindle: yes Max. speed of driven tools: 0–6,000 rpm Power of driven tools: 9.3 kW C-axis positioning: 0.001° Continuously controlled C-axis in the spindle: yes Tailstock and steady rest Programmable tailstock: yes, servo-controlled Tailstock taper: MK5 Tailstock clamping force: 1,334–6,672 N Hydraulic steady rest: Kitagawa 1131 Steady rest range: 110–310 mm Separate oil lubrication for the steady rest: yes Max. steady rest speed: 650 rpm Max. clamping force of the steady rest roller: 20 kN Machine equipment The machine is equipped with: HAAS CNC control system, C-axis, driven tools, 12-position turret with 6× VDI / 6× BOT, programmable tailstock, Kitagawa 1131 hydraulic steady rest, Kitagawa B15 hydraulic chuck, chip conveyor, cooling unit, automatic central lubrication, Gedpfx Ajy Tnwwohvjiu manual spray gun for coolant, manual air blow gun, remote jog handle, USB port, work area lighting, set of tool holders and accessories. Accessories The machine comes with accessories as shown in the photos, including: ER32 driven tool holders, VDI/BOT tool holders, set of hard jaws for Kitagawa B15 chuck, additional jaws, sleeves and clamping elements. Operating hours According to the display on the control system: Cycle start time: approx. 7,208 h Cutting time with feed: approx. 5,989 h Machine condition The machine is currently in operation and powered on. Inspection and testing are possible by appointment. The technical condition corresponds to the normal operation of a used machine.
