Used Emmegi Phantomatic X4 for sale (64)

Condition: ready for operation (used), Year of construction: 2011, A CNC aluminum profile processing center Emmegi including a corner joining machine Pressta 1800 is available. Axes: 4, travel X/Y/Z: 4300mm/270mm/300mm, speed: 20000rpm, tool positions: 4, angle machining heads: 2, max. magazine saw blade diameter: 180mm, tapping capacity: M8, machine dimensions X/Y: approx. 5000mm/1300mm, weight: approx. 2200kg, spindle hours: 14422h. Documentation available. On-site inspection is possible. Expected to be available from January 2025. Pelhcdwjvcpz Dj Dsgk

Year of construction: 2003, Condition: used, Functionality: fully functional, Emmegi Phantomatic isola t4 cnc aluminum profile machining center Manufacturer: Emmegi. Model: Phantomatic. Model year: 2003. Voltage: 3-phase. Dimensions and weight: Length: 5000 mm. Width: 1700 mm. Polhcdwev Rrvao Dogk Height: 2400 mm. Weight: 1550 kg. In working condition. The machine is located in Poland and connected to power - 33350 Piwniczna Zdrój

Condition: excellent (used), Year of construction: 2016, travel distance X-axis: 7,700 mm, travel distance Y-axis: 420 mm, Emmegi Phantomatic X6 HP 4 axis Machining Centre Year: 2016 Pgslhjwbqmqscdw Dsk 'X' axis travel: 7700mm

Condition: like new (used), Year of construction: 2021, CNC work center with 3 controlled axes with automatic rotation of the tool on three fixed positions that allows to perform machining on 3 sides of the piece. It is dedicated to the machining of bars or pieces in aluminum, PVC, light alloys in general and steel up to 2 mm thick. It has a manual 9-place tool magazine to which one or two automatic magazines with 4 places each can be added, which can be installed on both sides of the cabin. The profile is positioned using a pneumatic stop positioned on the left, the locking is done using 4 sturdy clamps that are positioned automatically via the X axis. The optional installation of a second pneumatic stop on the right side allows to perform oversized machining of bars of double length compared to the working field. All CN axes are absolute and do not require zeroing when restarting the machine. It also has a mobile work surface that facilitates the piece loading/unloading operation and significantly increases the workable section. ELECTROSPINDLE - M - The 4 kW electrospindle in S1 can reach a speed of 20,000 rpm. The electrospindle can perform an automatic rotation by electronically locking itself in 3 fixed positions (-90°, 0° and +90°), allowing the profile to be machined on 3 faces, without having to reposition it. It can be used on aluminum, PVC and light alloy profiles, and can also machine steel extrusions with thicknesses of up to 2 mm. Pslhcdewd Tdwjw Djgk VICES The machine software, depending on the length of the piece and the machining operations to be performed, is able to determine, in complete safety, the positioning height of each clamp group. The automatic positioner allows each clamp group to be hooked and moved by moving the carriage. This operation takes place with maximum speed and precision, avoiding long times and risks of collision and making the machine easy to use even by less experienced operators. The mobile work table facilitates the loading/unloading operation of the piece and significantly increases the workable section.

Condition: excellent (used), Emmegi Phantomatic 2400 CNC window milling machine Polov Tb Iqehcdw Djgk x axis travel: 2400 mm y axis travel: 240 mm with axis travel: 230 mm

Condition: excellent (used), Functionality: fully functional, Working range X : mm. 3100 Electrospindles 1 HSD ISO 30 connection – – max 18000 rpm Tool change positions 3+1 Work table no. 4 clamps Weight: Kg 1950 • Dimensions: mm. 5.472 X 1.900 X 2.200 Pgslhcdev S I D Asw Dok

Year of construction: 2006, Condition: good (used), 3-axis / 5-sided machining with ISOLA soundproof cabin for aluminum, PVC and steel profile bars The machine has two processing zones and 2 tool magazines, which can be used individually in pendulum mode or both together for loading over the entire processing length (multi-part operation). The clamps can be positioned on the left and right independently of the processing head. Travel paths: X - axis: 7000mm Y - axis: 300mm (+ 113mm of the movable work table) Z - axis: 350mm P - axis: 3500mm (for left-hand clamp positioning) H - axis: 3500mm (for right-hand clamp positioning) 8 clamping elements (4 clamps per machining zone) Pgslhcdwotp Ucmj Dok 12 tool holders (6 holders per changer magazine/machining zone) incl. Camplus software 2 angle heads

Condition: ready for operation (used), Technical characteristics AXIS TRAVEL X AXIS (longitudinal) (mm) 4300 Y AXIS (cross) (mm) 270 Z AXIS (vertical) (mm) 300 ELECTRO-SPINDLE Max. power rating (S1) (kW) 5,5 Max. power rating Max. speed (rpm) 20000 Tool taper HSK 63F AUTOMATIC TOOL MAGAZINE Max. number of tools in the tool magazine 4 standard Max. number of angle machining heads loadable in the tool magazine 2 Max. blade diameter loadable in the tool magazine (mm) Ø 180 FUNCTIONS Multi-piece operation MACHINABLE FACES With straight tool (top face) 1 With angle machining head (side faces and ends) 2 + 2 With blade tool (side faces and ends) 2 + 2 TAPPING CAPACITY (with tap on aluminium and through hole) With compensating chuck M8 Rigid Polhcoundg Uodw Degk WORKPIECE CLAMPING Standard number of vices 4 Max. number of vices 6 Power and Motors Pluging: Three-phased Overall dimensions Lenght: 5000 mm Width: 1300 mm Weight: 2000 Kg

Year of construction: 2011, Condition: excellent (used), X-axis travel (longitudinal axis) 4300 mm Y-axis travel (transverse axis) 270 mm Z-axis travel (vertical axis) 300 mm Electrospindle 1 HSD - max 18000 rpm - power 5.5 kW Tool magazine capacity 8 Bevel gearbox for lateral machining Number of vices 4 Pslhcevi N H Tjdw Dogk Vices positioning: automatic Weight 1950 kg

Year of construction: 2020, Condition: ready for operation (used), Saw blade diameter: 2x400mm, max. cutting length: 4000mm, cutting angle: +/-45°. Documentation available. On-site inspection is possible. Pgolhcdswfg Hbew Dsk

Year of construction: 2011, Condition: good (used), Roller belt left: 400 cm, roller belt right: 600 cm. Pelhcdewdui Iew Degk

Condition: good (used), Year of construction: 2008, Functionality: fully functional, Machine in excellent condition with suction Pgslovbvkvehcdw Dsk Visible in operation in our premises. Price machine loaded on truck. Possibility of assembly and start-up in your workshops at an additional cost

Year of construction: 2004, Condition: excellent (used), 4-axis machining center Pelhcdewfw N Tjw Dsgk work range in X: 7000 mm automatic clamp movement

Condition: used, NUMERIC CONTROL WORK CENTER FOR ALUMINUM/PVC Working Area: X = 6500 mm Y = 250 mm Z = 250 mm Main Features: - Nr. 1 HSD 3-axis electrospindle with ISO 30 attachment - Angular head with 2 outputs for horizontal milling - Automatic tool change magazine - Nr. 8 Vices - Right + Left stops - ISAC SAB 9500 Numeric Control - Scrap and chip collection drawers - Installed power: 11 kW - Machine weight: 2700 kg Pgslhcdowd Tvyow Djk - Machine overall length: 8600 mm

Year of construction: 1999, Condition: used, Max. sawing length: 5,000 mm Pjlhswb Eq Recdw Djgk Max. saw blade diameter: 500 mm Automatic positioning of the length as well as motorized angle adjustment inwards and outwards Moving roller conveyor Material support Minimum quantity spray device Weight: 1800 kg

Condition: like new (used), Year of construction: 2021, operating hours: 1,000 h, Functionality: fully functional, machine/vehicle number: C125349, travel distance X-axis: 7,800 mm, travel distance Y-axis: 1,100 mm, travel distance Z-axis: 655 mm, rapid traverse X-axis: 75 m/min, rapid traverse Y-axis: 60 m/min, rapid traverse Z-axis: 40 m/min, nominal power (apparent): 15 kVA, torque: 12 Nm, controller model: Emmegi, workpiece width (max.): 580 mm, workpiece height (max.): 400 mm, total height: 2,820 mm, total length: 12,820 mm, total width: 4,800 mm, overall weight: 13,870 kg, spindle speed (max.): 24,000 rpm, coolant supply: 6 bar, number of spindles: 1, number of slots in tool magazine: 24, Equipment: chip conveyor, rotational speed infinitely variable, A 5-axis profile machining center from Emmegi, built in 2021 due to insufficient utilization, is for sale. The machine is in mint condition and can be tested on-site. The axis travels are: X-axis: 7800 mm Y-axis: 1100 mm Z-axis: 655 mm Profiles made of aluminum 3.3535, steel 1.0038, steel 1.0553, and stainless steel 1.4301 were machined on this machine. Cutting with the 500 mm circular saw blade is only possible in aluminum. The machine was equipped with a second lubrication circuit in 2022 to allow the use of separate lubricants for aluminum and steel materials. The following machining operations can be performed: - (Thread) milling - Drilling - Thread cutting - Flow drilling in stainless steel up to 3 mm with pre-drilling, steel up to 3 mm with pre-drilling, and aluminum up to 4 mm without pre-drilling Pjlhcdwewczg Dj Dsgk - Miter cutting (only possible in aluminum) Included are Emmegi's CAM software "CAMplus 6.1" as well as the additional software "job" and "shape" CAMplus - enables graphical programming in the office or at the machine job - enables the merging and waste optimization of individual jobs shape - enables the milling and drilling of free contours If you have any further questions, please contact me.

Condition: excellent (used), Year of construction: 2012, Functionality: fully functional, machine/vehicle number: C109289, cutting length (max.): 4,000 mm, saw blade diameter: 500 mm, Double saw for cutting aluminum, 500 mm blade, radial cut for increased cutting capacity. Automatically set angles of 90, 45, 30 degrees. Roller feeder supporting the profile on the movable head, USB socket, list import, intermediate support. Pgslhcdwowcb D Ne Djk

Year of construction: 2011, Condition: ready for operation (used), Functionality: fully functional, saw blade diameter: 550 mm, conveyor belt length: 300 mm, conveyor belt width: 6,000 mm, machine/vehicle number: 0112613,, Machine recovered from the insolvency of an automotive supplier - machines are currently still in operation! TECHNICAL DETAILS Sawblade diameter: 550 mm Roller conveyor: 300 x 6,000 mm Material feed Feed: automatic Material clamping: present EQUIPMENT - Automatic feed - Material clamping - Control system - Chip extraction system - Two light barriers Further information according to the manufacturer - without guarantee Machine length: approx. 17.2 m Sawblade speed: approx. 2,800 rpm U-axis travel: approx. 7.4 m Sawblade swivel range: -45° to +45° Pgelhcswbvbtodw Dok Maximum loading length: 7,200 mm

Condition: ready for operation (used), Functionality: fully functional, 4-axis machining center Pgelhcdowfw Ntew Dsk

Year of construction: 2011, Condition: excellent (used), Functionality: fully functional, 4-axis milling machine 8 pneumatic clamps with automatic positioning Pjlhcdswaa Uusw Dogk automatic toolchange 8 tools Dynamic pendular usefull lenght 7700 mm

Condition: excellent (used), Year of construction: 2014, Functionality: fully functional, cutting length (max.): 6,000 mm, saw blade diameter: 550 mm, Used Emmegi PrecisionTS2 Emmegi Precision TS2 Double Miter Saw Year of 2014 Cutting length 6000mm Double miter saw with 3 controllable axes with automatically movable saw unit and electronic control of all miters from 45° (inside) to 15° (outside) with an accuracy of 280 intermediate positions per degree. Including profile support roller conveyor on the movable unit Additional clamping device on the roller conveyor Label printer with dispenser Pjlowaz Agehcdw Degk PRO software (overlength cutting, underlength cutting, cross-cutting, wedge cutting) SLICE software (butt cuts with variable corners and lengths up to a usable cut of 500mm) Driver for connecting external calculation programs

Condition: good (used), Year of construction: 1996, Functionality: fully functional, machine/vehicle number: 238067, saw blade diameter: 450 mm, type of input current: three-phase, Saw for cutting aluminum profiles at a 90 degree angle, fully automatic cutting. Pelhswcbh Uocdw Djgk

Condition: refurbished (used), Functionality: fully functional, Blade diameter 450 mm Blade shaft diameter 32 mm Blade cutting speed 60 m/sec Blade feed speed 0÷60 mm/sec Pgslhcdowctnysw Dek Motor power 4 Kw Blade motor revolutions 2800 rpm CE machine Dimensions 1220 x 1000 x h 1550 mm Weight 500 Kg Notes Complete with user manual and CE Including roller conveyor with positioning stop via handwheel and mechanical counter

Condition: excellent (used), Year of construction: 2011, Functionality: fully functional, Compact work center with 5 controlled axes, the last of which controls the movement of the piece reference stop to the right and left for total control of the work cycle. The rotating vice table (CN axis) allows you to work up to 4 sides of the piece without unlocking the vices. Variable speed electrospindle up to 11,500 rpm, quick tool change with collet attachments, ISO 30 cone. Pgelhcdswb R Rpjw Dsk

Year of construction: 2011, Condition: excellent (used), Functionality: fully functional, AXIS TRAVELS X AXIS (longitudinal) (mm) 4,000 Y AXIS (transversal) (mm) 470 Z AXIS (vertical) (mm) 420 A AXIS (spindle rotation) 0°  180° ELECTROSPINDLE Maximum power in S1 (kW) 8 Maximum speed (rpm) 24,000 Polhcdowbwnhsw Dsgk Tool attachment cone HSK - 63F AUTOMATIC TOOL MAGAZINE ON BOARD CARRIAGE Maximum number of tools in magazine 8 Maximum blade diameter that can be inserted into magazine (mm) Ø = 180
