Used Fanuc Wire Edm Machine for sale (945)

Year of construction: 2016, condition: used, overall weight: 4,200 kg, total length: 2,900 mm, total width: 3,260 mm, total height: 2,200 mm, workpiece weight (max.): 3,000 kg, FANUC ROBOCUT α-C800iB Wire EDM Machine Technical Specifications: Max. Workpiece Dimensions: 1,250 × 975 × 300 mm Max. Workpiece Weight: 3,000 kg Wire Diameter: 0.10–0.30 mm Max. Taper Angle: ±30° / 150 mm Max. Wire Spool Weight: 16 kg Travel X-axis: 800 - mm Travel U-axis: 200 - mm Dimensions (LxWxH) approx.: 2900 x 3260 x 2200 mm Component weight max.: 3,000 kg Control: FANUC Series 31i-W Model B Travel Y-axis: 600 - mm Travel V-axis: 200 - mm Guodpfxjz N Nuxs Af Usi Weight approx.: 4,200 kg Travel Z-axis: 310 - mm Year of construction: 2,016 Terms of payment: 100% prepayment before pick-up Terms of delivery: From foundation under power: Yes

Condition: excellent (used), Year of construction: 2021, FANUC ROBOCUT C400iC wire EDM machine + FANUC CRX-10iA robot, manufactured in 2021. FANUC 31i-WB CNC control. X, Y, Z LINEAR SCALES. AUTOMATIC DOOR. FANUC ROTARY TABLE. CHILLER UNIT. Travel: X 400, Y 300, Z 255, U +60, V +60 mm. Maximum taper 30°/80 mm. Maximum dimensions of the part to be machined: 730 x 585 x 250 mm. Maximum weight of the part to be machined: 500 kg. Godpjz Hw Hcsfx Af Usui Wire spools up to 16 kg. Wire diameters: 0.10-0.30 mm. FANUC CRX-10iA ROBOT. VISION SYSTEM. 6 controlled axes. R-30iB Plus controller. Maximum load: 10 kg. Maximum arm length: 1,249 mm.

Condition: ready for operation (used), Year of construction: 1988, Control: FANUC Travel: X= 500, Y= 350, Z= 300 mm Max. table load: 350 kg Guodpfx Afsxx Uats Uei Dimensions: 3500 x 2400 x 2400 mm Weight: 3,000 kg

Condition: used, FANUC Robocut C 600 iA is a wire cutting EDM designed for precision, high accuracy and reliability. Working table 600×400 mm; max workpiece 1050×820×300 mm; table load 1000 kg; travels X600 Y400 Z310 U200 V200; wire from 0.1 mm. Power supply 50 Hz 3x 400 V; total power 11 kVA; machine weight ~1500 kg; overall 1800×1600×2000 mm. Accessories: lamp, automatic wire threading, Daikin cooling unit, automatic sliding door, glass rulers X,Y, rotating spindle Hirschmann F. Enables tight tolerances; typical applications: automotive, watchmaking, machine tools, aerospace, medical. Gjdpfxjyxprto Af Uoui

Condition: used, Year of construction: 1988, functionality: fully functional, workpiece weight (max.): 350 kg, travel distance X-axis: 350 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 270 mm, wire diameter (max.): 0.3 mm, table width: 450 mm, overall weight: 2,300 kg, table length: 600 mm, table height: 300 mm, empty load weight: 2,300 kg, Fully functional machine in good condition for its age, equipped with a guiding system (sliding guides). Gusdpfx Afezcww Ro Uei The Matra Fanuc Tape Cut W2 is a classic and highly reliable CNC wire EDM machine manufactured in 1988. This machine combines the advanced technology of the Japanese Fanuc control system with the precision of the German Matra machine tool manufacturer.

Condition: used, Year of construction: 1991, functionality: not functional, workpiece weight (max.): 350 kg, travel distance X-axis: 350 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 270 mm, wire diameter (max.): 0.3 mm, table width: 450 mm, overall weight: 2,300 kg, table length: 600 mm, table height: 300 mm, empty load weight: 2,300 kg, With a small investment, it can be made operational again, but the new owner could also use it for spare parts (all its electrical boards are intact, but the pump system and wiring system require repair). Gujdpfx Afe Aifnqs Uji The Matra Fanuc Tape Cut W2 is a classic and extremely reliable CNC wire EDM machine manufactured in 1988. This machine combines the cutting-edge technology of the Japanese Fanuc control system with the precision of the German Matra machine tool engineering.

Condition: good (used), Year of construction: 1999, functionality: fully functional, FOR SALE: FANUC ROBOCUT α-1iA Wire EDM Machine Specifications and technical capabilities (Manufacturer’s plate): • Model: ROBOCUT α-1iA (Type A04B-0312-B002/E5) • Year of manufacture: October 1999 (Serial number: P99X11330) Gjdpfxe Af Auve Af Ueui • Numerical Control: FANUC Series 18i-W • Axis travels (Stroke): X = 520 mm | Y = 370 mm | Z = 410 mm • Taper axes: U = 120 mm | V = 120 mm • Maximum workpiece weight: 1,000 kg (1 tonne) • Power supply: 200/220V (Three-phase, 50/60 Hz) – Required power: 13 kVA • Machine weight: 2,700 kg (2.7 tonnes) Included equipment: • Original control panel with remote screen and keyboard • Work tank with full protective enclosure • Automatic wire threading system (roller guide system) • Remote manual control unit Condition: • Used machine, fully operational, sold as is.

Condition: repair required (used), Manufacturer: FANUC Type: A04B-0221-B201 The condition of the machine is unknown; it is not functioning. It is being sold in its current condition. !! Guedeik Hb Tspfx Af Uji We do not know what the problem is!

Condition: like new (used), Year of construction: 2022, operating hours: 931 h, functionality: fully functional, load capacity: 8 kg, arm reach: 2,032 mm, controller manufacturer: fanuc, controller model: R30ib mate plus, teach pendant manufacturer: ipendant fanuc, ROBOT ARM MANUFACTURER: FANUC MACHINE TYPE: ARC Mate 100iD/8L TECHNICAL SPECIFICATIONS PAYLOAD: 8 kg REACH: 2032 mm YEAR OF MANUFACTURE: 2022 Guodpfe Akci Isx Af Uji CONTROLLER: R-30iB Mate Plus OPERATING HOURS: 931 hours

Year of construction: 1993, condition: ready for operation (used), A Fanuc CNC wire EDM machine is available. Travel X/Y: 350mm/500mm, max. workpiece dimensions X/Y/Z: 450mm/650mm/300mm, max. workpiece weight: 500kg, machine dimensions X/Y/Z: approx. 2600mm/2550mm/2200mm, weight: approx. 2300kg, operating system: Fanuc Series 16-WA. Documentation available. An on-site inspection is possible. Gedpfxozqu E Tj Af Ujui

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, Fanuc Series 180iS-WB control system Travel ranges: X 320 mm, Y 220 mm, U 120 mm, V 120 mm, Z 180 mm Max. workpiece weight: 500 kg Machine weight: 1,700 kg Power supply: 13 kVA The machine can be inspected while powered on. Guodpfx Aezvd Sajf Uji

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, Equipment: cooling unit, documentation/manual, FANUC Robocut α-C400iB 31i WB HMI Complete with RENISHAW part probe Hammer for removing swarf Spatula for collecting swarf Robot interface for unattended machining Door with automatic (opening) descent • CNC Fanuc 31i-WB • Z-axis controlled by CNC • Wire driving unit with automatic threading AWF2 • 15” ‘touch screen’ display and portable keyboard • Automatic water level adjustment • Dielectric fluid filtration system • Fanuc cooling unit • Three-phase 380/220V 15 kVA transformer MANUALS TECHNICAL SPECIFICATIONS: Maximum workpiece size (mm)……………..……………730 x 630 x 250 Gsdps Ah T Rwsfx Af Ueui Maximum workpiece weight (kg) ……………..………….500 Travel of X and Y axes (mm) ……………..……400x 300 Travel of Z axis (mm) ……………...…255 Travel of U and V axes (mm)…………….. ………..120 x 120 Maximum taper angle (°/mm)……………. 30°/80 Minimum incremental step of drives (mm)……………..……………..…0.0001 Wire diameter (mm)…………….……0.10/0.30 Maximum wire weight (kg)…………….……………..……………..……..16 Footprint (W/D) (mm)…………….……………..1930 x 2330 Machine weight (approx.) (kg)…………….…………….1800 Control…………….……………..FANUC 31i-WB Program memory size (MB)…………….……………...4 Generator AC ……………..standard Pulse generator ……………fully transistorized Maximum cutting speed …………….330 mm2/min (brass wire Ø 0.3 mm) Minimum surface roughness …………….Standard 0.3 Ra (OPTIONAL 0.1 RA for superfine finishing) Dielectric system ……………..……………Deionized water Tank capacity (liters)…………….……………..……………520 Filters ……………2 paper filters Machine weight …………….1800 kg FANUC Robocut α-CiB Series 31i WB Machine features High precision: New high-rigidity structure with thermal insulation. Symmetrical pyramid structure with a wide base to eliminate load overhang Lower guide support with thermally isolated arm Tank with hermetic pre-closure device (patented) Servo control of the water level in the working tank (follows the position of the Z-axis) Transparent sealing plate in two partitions for easy inspection and maintenance Economic efficiency: Long service life of wear parts Low operating costs Minimum footprint for installation Energy consumption monitoring User friendly: Numerical control of the latest generation FANUC 31i WB 15” ‘touch sensor’ LCD screen with Teach pendant USB I/O for data and programs System features to increase machining speed and precision New concept Skim Cutting Power Supply SF2 generator for finishing with Ra 0.3µm on tool steels with a thickness of up to 60 mm Patented AIP2 (artificial intelligence) discharge pulse control High-speed servo control (direct and not through the CNC) Machining of variable thickness shapes optimized thanks to AIP2 pulse control

Condition: excellent (used), High-quality FANUC wire EDM machine in excellent condition. The machine is well-maintained, ready for operation, and suitable for precise wire EDM applications in tool, mold, and precision machine manufacturing. Manufacturer: FANUC Model: ROBOCUT α-1iD Type: A04B-0320-B001 #E5 Machine No.: P089D1671 Year of Manufacture: 09/2008 Control: FANUC Series 310iS-WA Machine Type: CNC Wire EDM Machine X-axis: 600 mm Y-axis: 400 mm Z-axis: 310 mm U-axis: 200 mm V-axis: 200 mm Rapid traverse X: 900 mm/min Rapid traverse Y: 900 mm/min Rapid traverse Z: 900 mm/min Rapid traverse U: 450 mm/min Rapid traverse V: 450 mm/min Max. workpiece weight: 1,000 kg Machine weight: 3,000 kg Guedpfezrzzdjx Af Uoi Power supply: 200 V AC, 3-phase, 50/60 Hz Connected load: 13 kVA Automatic wire threading Full immersion machining Suitable wire diameter: 0.10–0.30 mm Upon request, we will gladly send you a video.

Condition: excellent (used), Year of construction: 2003, functionality: fully functional, Fanuc Series 180iS-WB control system Guodpo Aiu Rwsfx Af Uoi Travel ranges: X 320 mm, Y 220 mm, U 120 mm, V 120 mm, Z 180 mm Max. workpiece weight: 500 kg Machine weight: 1,700 kg Power supply: 13 kVA The machine can be inspected while powered on.

Condition: good (used), Year of construction: 2016, The machine is in good technical condition, testing can be arranged by prior agreement. Gedpfx Afs Aibu Ts Ujui

Condition: used, Year of construction: 2011, Wire erosion / EDM Travel distance X: 370 mm Travel distance Y :270 mm Gujdpfx Afez Eqk Se Uei Travel distance Z: 255 mm max. workpiece size X: 700 mm max. workpiece size Y: 600 mm max. workpiece size Z: 250 mm max. workpiece weight: 500 kg with AWF ( Automatic Wire Feeding ) U / V axis: 60 generator: 13 Ampere submerged cooling unit FANUC Series 31i-WA control Automatic wire threading Cutting in water bath Cooling unit Filtration system

Condition: excellent (used), Year of construction: 2024, operating hours: 1,822 h, functionality: fully functional, machine/vehicle number: P2414C718, workpiece weight (max.): 500 kg, travel distance X-axis: 400 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 250 mm, total height: 1,970 mm, total length: 2,120 mm, total width: 1,970 mm, wire diameter (max.): 0.253 mm, workpiece height (max.): 250 mm, workpiece width (max.): 630 mm, workpiece length (max.): 730 mm, type of input current: AC, table width: 440 mm, overall weight: 2,200 kg, table length: 626 mm, input voltage: 400 V, tank capacity: 520 l, travel speed (max.): 2,000 mm/min, input frequency: 50 Hz, input current: 32 A, positioning accuracy: 0 mm, Equipment: cooling unit, documentation/manual, The machine has undergone a general overhaul, and the water system has been cleaned. The machine is equipped with new, original precision diamond guides (0.253), new feeders, all bearings, cutting contacts, encoder batteries, parameter backups, filters and a detection unit. The system has been updated to the latest version. The machine comes with a complete set of standard accessories: flushing nozzles, wire alignment jig, clamps, etc. Guodpfxo Ahhn Io Af Usi

Condition: like new (used), Year of construction: 2019, clamping force: 2,200 kN, Equipment: documentation/manual, Fanuc FANUC ROBOSHOT Alpha S220iA (2019) _FANUC Roboshot α-S220iA – Equipment List_ _Basic Technical Specifications_ 1. Clamping force: 2200 kN 2. Injection speed: 200 mm/s 3. Max. injection pressure: 1900 bar 4. Min./Max. mold height: 250–750 mm (extended) 5. Clamping stroke: 550 mm 6. Tie bar spacing (H×V): 650 × 650 mm 7. Locating ring: Ø 160 mm 8. Ejector stroke: 150 mm 9. Screw diameter: 48 mm (318 cm³) 10. Screw/barrel: W/C (hardened, high wear & corrosion resistance, up to 350 °C, 30% GF) 11. Nozzle: Standard open R19D4 _Control & Software (FANUC 31i-B CNC)_ 1. 15" LCD touchscreen 2. SI unit (kN, MPa...) 3. Password-protected screen lock 4. AI pressure profile trace function 5. AI metering control function 6. AI mold protection function 7. AI ejector protection function 8. Backflow monitor function 9. Precise metering 2, 3 10. Auto purge function 11. Extruder delay timer function 12. High precision V-P switch function 13. Injection unit temperature control and display 14. Automatic mold height adjustment 15. 2-stage ejection 16. Ejector delay function 17. Pre-ejection function Guedpfx Aozkttcef Usi 18. Optimal energy consumption function _Standard Machine Equipment_ 1. Extended mold height 2. 4-circuit rotameter 3. Automatic mold height adjustment 4. Hopper slider 5. 3-color LED signal lamp 6. Automatic purge and material cleaning function 7. Plasticizing speed control 8. Decompression control additional function 9. Backflow monitoring function 10. AI mold and ejector protection 11. Mold protection output on moving platen 12. Energy consumption measurement function 13. Robot interface (Euromap 67) 14. Auto stop/shutdown mode 15. 3 independent air valves 16. 8 digital outputs, 11 digital inputs 17. Pre-injection / injection compression function 18. Cascade injection valve control (up to 8 valves) 19. USB and memory card output 20. Tool kit (standard tools + grease gun) 21. User manual (Hungarian) 22. Warning labels (Hungarian) _Clamping Unit Specifications_ 1. Mechanism: Double toggle 2. Clamping force: 2200 kN / 220 tonf 3. Die height (single platen): 250–650 mm _(opt. 250–750 mm)_ 4. Clamping stroke: 550 mm 5. Locating ring: Ø 160 mm 6. Tie bar spacing (H×V): 650 × 650 mm 7. Platen size (H×V): 900 × 900 mm 8. Min. mould size (H×V): 375 × 375 mm 9. Ejector stroke: 150 mm 10. Max. ejector force: 35 kN / 3.5 tonf

Condition: like new (used), Year of construction: 2019, clamping force: 1,000 kN, Equipment: documentation/manual, Clamping force: 100 t Gsdpfjzktkzox Af Ujui Screw diameter: 32 mm Shot volume: 103 cm3 Type: Horizontal Drive: Electric FANUC Roboshot α-S100iA : Basic Technical Specifications Mechanism: Double toggle Clamping force: 1000 kN / 100 tonf _(opt. 1250 kN / 125 tonf)_ Die height double platen: 150–450 mm _(opt. 150–550 mm)_ Die height single platen: 220–520 mm _(opt. 220–620 mm)_ Clamping stroke: 350 mm Locating ring: Ø 125 mm Tie bar spacing (H×V): 460 × 410 mm Platen size (H×V): 660 × 610 mm Min. mould size (H×V): 265 × 240 mm Ejector stroke: 100 mm Max. ejector force: 25 kN / 2.5 tonf _(opt. 60 kN / 6.0 tonf)_ 1. Clamping force: 1000 kN 2. Injection speed: 200 mm/s 3. Max. injection pressure: 2200 bar 4. Min./Max. mold height: 150 mm / 620 mm (extended) 5. Clamping stroke: 350 mm 6. Tie bar spacing: 460 × 410 mm 7. Ejector stroke: 100 mm 8. Screw diameter: 32 mm (103 cm³) 9. Screw/barrel: W/C (hardened, high wear and corrosion resistance, up to 350 °C, 30% GF) 10. Nozzle: Standard open R19D4 Control & Software (FANUC 31i-B CNC) 1. 15" LCD touchscreen 2. SI unit (kN, MPa...) 3. Password-protected screen lock 4. AI pressure profile trace function 5. AI metering control function 6. AI mold protection function 7. AI ejector protection function 8. Backflow monitor function 9. Precise metering 2, 3 10. Auto purge function 11. Extruder delay timer function 12. High precision V-P switch function 13. Injection unit temperature control and display 14. Automatic mold height adjustment 15. 2-stage ejection 16. Ejector delay function 17. Pre-ejection function 18. Optimal energy consumption function Standard Machine Equipment 1. Extended mold height 2. 4-circuit rotameter 3. Automatic mold height adjustment 4. Hopper slider 5. 3-color LED signal lamp 6. Automatic purge and material cleaning function 7. Plasticizing speed control 8. Decompression control additional function 9. Backflow monitoring function 10. AI mold and ejector protection 11. Mold protection output on moving platen 12. Energy consumption measurement function 13. Robot interface (Euromap 67) 14. Auto stop/shutdown mode 15. 3 independent air valves 16. 8 digital outputs, 11 digital inputs 17. Pre-injection / injection compression function 18. Cascade injection valve control (up to 8 valves) 19. USB and memory card output 20. Tool kit (standard tools + grease gun)

Condition: ready for operation (used), Two identical machines are available. Connected load: 32kW, length: 3500mm, width: 2400mm, height: 2400mm, weight: 3t. On-site inspection is possible. Godpfxouyk Rle Af Usui

Condition: good (used), Year of construction: 2004, functionality: fully functional, The used FANUC ALFA 1-iC wire EDM is a medium-sized, 5-axis CNC-controlled electrical discharge machine with submerged machining; X/Y/Z travel: 550/370/410 mm; year of manufacture: 2004, CE-compliant, complete with automatic wire threading, chiller, and openable roof. Technical specifications of the FANUC ROBOCUT ALPHA 1iC wire EDM: - Maximum workpiece dimensions (L x W x H): 820 x 730 x 300 mm - Maximum workpiece weight: 1000 kg - CNC control: Fanuc Series 180is-WB - 5 axes (X, Y, Z, U, V) - Stroke on axes X/Y/Z/U/V: 550/370/410/120/120 mm Godjxd R Hmjpfx Af Usui - Rapid traverse on X, Y, Z axes: 900 mm/min - Rapid traverse on U, V axes: 450 mm/min - Worktable size (L x W): 780 x 600 mm - Maximum cutting angle: 30 degrees - Automatic wire threading - Wire diameter: 0.1–0.3 mm - Electrical supply: 400 V; 50/60 Hz - Total power requirement: 13 kW - Total machine weight: 3100 kg

Condition: like new (used), Year of construction: 2023, Robodrill D21MIB5P/10K/2-W FANUC ROBODRILL D21MIB Plus Version with 2 option slots 24,000 rpm high-speed spindle X-axis travel: 500 mm Extended column +100 mm FANUC CNC control Series 31i-B High-speed CPU CE-compliant version Control panel with touchscreen including touch pen Enabling switch Machine interior with LED lighting Automatic oil lubrication Standard air blow function Telescopic cover for X-axis Z-axis protective cover Spindle head cover Machine enclosure for X500 version 32 A CEE connector Transformer for European version Air distribution system English machine and safety labeling Documentation / operating and spare parts manuals, English CE basic package CE basic package PE connection kit 32-A CEE plug FANUC DDRIB rotary table Integration of a FANUC DDRIB rotary table Additional controlled axis Additional axis amplifier 80 A Gusdpj Adu Ilofx Af Uei DDRIB connection / plug connection FANUC DDRIB rotary table, 1 unit Cable holder for X500/X700 Integration of the DDRIB including rotary feedthrough FANUC coolant system BASIC, left-hand side, without chip conveyor External cooling (AK) with 5.5 bar Flushing of the work area / chip flushing with 200 l/min Left-hand version Without chip conveyor 3-year-old machine that is completely new but has not been accepted by the end customer from Fanuc in the last 3 years.

Condition: used, TECHNICAL DETAILS TRAVELS - Travels on X/Y/Z axes : 600x400x310 [mm] - Travels on U/V axes : [mm] - Max. taper : [°/mm] PART - Max. part dimensions : 1050x820x300 [mm] - Max. part weight : 1000 [kg] WIRE GUIDE - Wire diameter : 0.1-0.3 [mm] - Coil weight : 16 [kg] POWER SUPPLY - Supply voltage : 380 [V] - Total installed power : 13 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2650x3050 [mm] - Machine height : 2070 [mm] - Machine weight : 3600 [kg] MACHINE HOURS - Number of working hours : 3236 [h] Gsdey Tzc Topfx Af Usui EQUIPMENT - CNC : Fanuc 31iw-model B - Cooling unit - Filtration unit

Condition: like new (used), Year of construction: 2022, operating hours: 2,900 h, functionality: fully functional, load capacity: 8 kg, arm reach: 2,032 mm, controller manufacturer: fanuc, controller model: r30ib mate plus, teach pendant manufacturer: ipendant fanuc, input voltage: 380 V, ROBOT ARM & WELDING SYSTEM MANUFACTURER: FANUC MACHINE TYPE: ARC Mate 100iD/8L TECHNICAL SPECIFICATIONS PAYLOAD: 8 kg REACH: 2032 mm YEAR OF MANUFACTURE: 2022 CONTROLS: R-30iB Mate Plus Gjdpfj Akchfsx Af Ueui RUNNING TIME: 2900 hours FRONIUS TPS 400i: 400 Amp. WATER-COOLED ABICOR BINZEL Torch Cleaning Station TCS Compact 200-220V * 3 TRANSFORMER SYSTEM DEVICENET COMMUNICATION

Condition: used, Year of construction: 2006, FANUC ROBOCUT ALPHA- OiC WIRE ERODING MACHINE YEAR: 2006 Gsdpezv En Ajfx Af Usui X STROKE: 320.0mm RAPID: 900mm/min Y STROKE: 220.0mm RAPID: 900mm/min Z STROKE: 255.0mm RAPID: 900mm/min U STROKE: 120.0mm RAPID: 450mm/min V STROKE: 120.0mm RAPID: 450mm/min MAX. TABLE WEIGHT: 500.0 kgs COMPLETE WITH.... CHILLER SYSTEM COOLANT FILTRATION SYSTEM TRANSFORMER RENISHAW MACHINE MANUALS
