Used Tornos Swiss Dt 13 for sale (120)

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, machine/vehicle number: 2560460122, Tornos Swiss GT13/6 - Sliding Headstock Automatic Lathe CNC Control: FANUC 31i-B, 6 axes, 13 mm capacity Basic Machine Equipment: - 6 linear axes - Independent main and counter spindle - Synchronously rotating guide bush - Adaptation for operation without guide bush - C axis for main and counter spindle - Adjustable pneumatic ejector incl. counter spindle coolant flushing - 3-color signal lamp (yellow, red, green) Redpeyzigcefx Ad Aot - Centralized lubrication - Electrical interface for Tornos bar feeder - Oil mist extraction interface - Interface for fire protection system - Interface for customer M-function (6 inputs and 6 outputs) - Compliance with CE and EMC standards Main Spindle: - Max. speed: 15,000 rpm - Adapted for F16 collets (76-1076) - Max. bar diameter without preparation: 10 mm - Max. bar diameter with preparation: 13 mm - C1 axis function Guide Bush: - Max. speed: 15,000 rpm - Max. diameter of synchronously rotating guide bush: 13 mm (with integrated motor), guide bush type: B (853) - Max. workpiece length in one clamping: 180 mm - Adaptation kit for operation without guide bush (max. travel: 30 mm) Tool System for Main Operations: - Tool holder for 5 turning tools 12x12 mm on the front of the carrier - Tool holder for 4 turning tools 12x12 mm on the rear of the carrier - S11 tool drive (10,000 rpm) for rotating tools mounted on the front of the carrier X1/Y1 - 1 drive module for cross machining with 3 spindles for ESX 16 collets (2 x 10,000 rpm and 1 x 6,250 rpm) - S21 tool drive (6,000 rpm) for up to 2 driven units mounted on the rear of the carrier X1/Y1 (driven units not included) - Tool carrier with 4 bores Ø 22 mm for stationary finishing tools Counter Spindle: - Max. speed: 15,000 rpm - Adapted for F16 collets (76-1076), max. Ø capacity: 13 mm - C4 axis function Tool System for Secondary Operations: - Base carrier for 8 back-working tools; on the 4 upper positions, rotating and/or stationary tools can be mounted (rotating tools not included) - 4 lower positions with 4 fixed holders for ESX 16 collets - 2 stationary holders with Ø 22 mm bores (for upper positions) - S51 tool drive (6,000 rpm) for driving back-working tools (max. 4 rotating tools) ----- Attractive Offer – Flexible & Worry-Free We not only offer you a high-quality product, but also tailor-made financing options to suit your requirements. Whether down payment, installment plan, or individual financing solutions – together we will find the right option for you. Upon request, we will also handle the complete transport organization. From planning to reliable delivery, we ensure a smooth and punctual process so you do not have to worry about a thing.

Condition: ready for operation (used), Year of construction: 2004, spindle speed (max.): 12,000 rpm, bar diameter (max.): 13 mm, number of axes: 6, This 6-axis TORNOS Deco 13 b was manufactured in 2004. It features a maximum bar diameter of 13 mm and a spindle speed range of 100 – 12,000 rpm. The machine includes a linear tool system with 6 tool positions and full machining capabilities for turning, drilling, tapping, and threading. If you are looking to get high-quality turning capabilities, consider the TORNOS Deco 13 b Swiss Type Lathe we have for sale. Contact us for further details. • Capacity: • Max bar diameter: 13 mm • Axes: • Number of axes: 6 (X1, Y1, Z1, X2, Y2, Z2) • Main spindle (S1): • Max bar capacity: 16 mm • Recommended min bar diameter: 3 mm • Max workpiece length: 160 mm • Collet type: Schaublin F20 • Subspindle (S2): • Max part diameter: 16 mm • Max part length (counter-operation): 160 mm • Spindle speed: 100–12,000 rpm • Clamping force: 730 daN • Axes travels: • X1: 35 mm, Y1: 158 mm, Z1: 187 mm • X2: 118 mm, Y2: 160 mm, Z2: 174 mm • Feed rates: • Max axis speed: 20 m/min • Guide bushing: • Max bar passage: 16 mm • Tooling system: • Linear tool system (front + rear) • Number of tool positions: 6 (3 axial + 3 transversal) • Tool spacing: 38 mm • Max rotating tools: up to 3 • Driven tools (S3): • Max speed: 8,000 rpm • Power: up to 1.1 kW • Drilling capacity: up to 8–10 mm • Tapping capacity: M6–M8 • Counter operations: • 3 working positions • Full machining capability (turning, drilling, tapping, threading) • Cooling system: • Oil capacity: 200 L • Chip tank: approx. 100 L Additional equipment • Bar feeder (integrated): • Max bar length: 3.3 / 3.85 / 4.2 m • Min bar length: 1.2 m • Bar diameter range: 3–16 mm • Parts unloader • Oil bath system Rsdjywlhbopfx Ad Aot • RS232 interface • Work area lighting Technical Specification Counter Spindle Yes Driven Tools Yes

Condition: used, TECHNICAL DETAILS - Number of axes : 8 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 13 [mm] - Max. machining length : 190 [mm] - Spindle speeds : 15000 [rpm] - Spindle power : 4 [kW] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Max. bar diameter : 13 [mm] - Spindle speeds : 15000 [rpm] - Spindle power : 4 [kW] - C axis indexing precision : 0.001 [°] GUIDE BUSH HOLDER 1 - Number of positions : 8 - Number of motorized positions : 3 - Live tools speed : 6000 [rpm] - Live tools power : 1 [kW] GUIDE BUSH HOLDER 2 - Number of positions : 8 - Number of motorized positions : 2 - Live tools speed : 6000 [rpm] - Live tools power : 1 [kW] END ATTACHMENT - Number of positions : 4 SECONDARY OPERATION - Number of positions : 8 - Number of motorized positions : 4 - Live tools speed : 6000 [rpm] - Live tools power : 0.75 [kW] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 26 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2170 X 1140 [mm] - Machine height : 1890 [mm] - Machine weight : 2800 [kg] MACHINE HOURS - Number of hours under power : 30788 [h] EQUIPMENT - CNC : Fanuc 31i-B - 3 colors status lamp - Rotating tool motor on : S11,S21,S51 - Rotating guide bush - Parts catcher - Ejection of workpiece - Parts conveying strip - Chips conveyor - Coolant tank : KNOLL * with high-pressure pump * with paper filtering unit - Bar loader : TORNOS SBF326-3.2M - Fire extinguisher * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer. Redpfx Aoyacvted Aet - Electric transformer

Condition: used, TECHNICAL DETAILS - Number of axes : 8 - Number of spindles : 2 MAIN SPINDLE Redpfx Asyacvmod Ast - Max. bar diameter : 13 [mm] - Max. machining length : 190 [mm] - Spindle speeds : 15000 [rpm] - Spindle power : 4 [kW] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Max. bar diameter : 13 [mm] - Spindle speeds : 15000 [rpm] - Spindle power : 4 [kW] - C axis indexing precision : 0.001 [°] GUIDE BUSH HOLDER 1 - Number of positions : 8 - Number of motorized positions : 3 - Live tools speed : 6000 [rpm] - Live tools power : 1 [kW] GUIDE BUSH HOLDER 2 - Number of positions : 8 - Number of motorized positions : 2 - Live tools speed : 6000 [rpm] - Live tools power : 1 [kW] END ATTACHMENT - Number of positions : 4 SECONDARY OPERATION - Number of positions : 8 - Number of motorized positions : 4 - Live tools speed : 6000 [rpm] - Live tools power : 0.75 [kW] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 26 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2170 X 1140 [mm] - Machine height : 1890 [mm] - Machine weight : 2800 [kg] MACHINE HOURS - Number of hours under power : 32783 [h] EQUIPMENT - CNC : Fanuc 31i-B - 3 colors status lamp - Rotating tool motor on : S11,S21,S51 - Rotating guide bush - Parts catcher - Ejection of workpiece - Parts conveying strip - Chips conveyor - Coolant tank : KNOLL * with high-pressure pump * with paper filtering unit - Bar loader : TORNOS SBF326-3.2M - Fire extinguisher * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer. - Electric transformer

Condition: used, TECHNICAL DETAILS - Number of axes : 8 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 13 [mm] - Max. machining length : 190 [mm] - Spindle speeds : 15000 [rpm] - Spindle power : 4 [kW] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Max. bar diameter : 13 [mm] - Spindle speeds : 15000 [rpm] - Spindle power : 4 [kW] - C axis indexing precision : 0.001 [°] GUIDE BUSH HOLDER 1 - Number of positions : 8 - Number of motorized positions : 3 - Live tools speed : 6000 [rpm] - Live tools power : 1 [kW] GUIDE BUSH HOLDER 2 - Number of positions : 8 - Number of motorized positions : 2 - Live tools speed : 6000 [rpm] - Live tools power : 1 [kW] END ATTACHMENT - Number of positions : 4 SECONDARY OPERATION - Number of positions : 8 - Number of motorized positions : 4 - Live tools speed : 6000 [rpm] - Live tools power : 0.75 [kW] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 26 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2170 X 1140 [mm] - Machine height : 1890 [mm] Redpoyacvgefx Ad Ajt - Machine weight : 2800 [kg] MACHINE HOURS - Number of hours under power : 31941 [h] EQUIPMENT - CNC : Fanuc 31i-B - 3 colors status lamp - Rotating tool motor on : S11,S21,S51 - Rotating guide bush - Parts catcher - Ejection of workpiece - Parts conveying strip - Chips conveyor - Coolant tank : KNOLL * with high-pressure pump * with paper filtering unit - Bar loader : TORNOS SBF326-3.2M - Fire extinguisher * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer. - Electric transformer

Condition: used, TECHNICAL DETAILS - Number of axes : 8 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 13 [mm] - Max. machining length : 190 [mm] - Spindle speeds : 15000 [rpm] - Spindle power : 4 [kW] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Max. bar diameter : 13 [mm] - Spindle speeds : 15000 [rpm] - Spindle power : 4 [kW] - C axis indexing precision : 0.001 [°] GUIDE BUSH HOLDER 1 - Number of positions : 8 - Number of motorized positions : 3 - Live tools speed : 6000 [rpm] - Live tools power : 1 [kW] GUIDE BUSH HOLDER 2 - Number of positions : 8 - Number of motorized positions : 2 - Live tools speed : 6000 [rpm] - Live tools power : 1 [kW] END ATTACHMENT - Number of positions : 4 SECONDARY OPERATION - Number of positions : 8 - Number of motorized positions : 4 - Live tools speed : 6000 [rpm] - Live tools power : 0.75 [kW] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 26 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2170 X 1140 [mm] - Machine height : 1890 [mm] - Machine weight : 2800 [kg] MACHINE HOURS - Number of hours under power : 44456 [h] EQUIPMENT - CNC : Fanuc 31i-B Redpfx Aeyacvajd Ajt - 3 colors status lamp - Rotating tool motor on : S11,S21,S51 - Rotating guide bush - Parts catcher - Ejection of workpiece - Parts conveying strip - Chips conveyor - Coolant tank : KNOLL * with high-pressure pump * with paper filtering unit - Bar loader : TORNOS SBF326-3.2M - Fire extinguisher * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer. - Electric transformer

Condition: used, TECHNICAL DETAILS - Number of axes : 8 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 13 [mm] - Max. machining length : 190 [mm] - Spindle speeds : 15000 [rpm] - Spindle power : 4 [kW] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Max. bar diameter : 13 [mm] - Spindle speeds : 15000 [rpm] - Spindle power : 4 [kW] - C axis indexing precision : 0.001 [°] GUIDE BUSH HOLDER 1 - Number of positions : 8 - Number of motorized positions : 3 - Live tools speed : 6000 [rpm] - Live tools power : 1 [kW] GUIDE BUSH HOLDER 2 - Number of positions : 8 - Number of motorized positions : 2 - Live tools speed : 6000 [rpm] - Live tools power : 1 [kW] END ATTACHMENT - Number of positions : 4 SECONDARY OPERATION - Number of positions : 8 - Number of motorized positions : 4 - Live tools speed : 6000 [rpm] - Live tools power : 0.75 [kW] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 26 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2170 X 1140 [mm] - Machine height : 1890 [mm] - Machine weight : 2800 [kg] MACHINE HOURS - Number of hours under power : 44449 [h] EQUIPMENT - CNC : Fanuc 31i-B - 3 colors status lamp - Rotating tool motor on : S11,S21,S51 Rsdpsyacu Nefx Ad Aot - Rotating guide bush - Parts catcher - Ejection of workpiece - Parts conveying strip - Chips conveyor - Coolant tank : KNOLL * with high-pressure pump * with paper filtering unit - Bar loader : TORNOS SBF326-3.2M - Fire extinguisher * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer. - Electric transformer

Condition: used, TECHNICAL DETAILS - Number of axes : 8 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 13 [mm] - Max. machining length : 190 [mm] - Spindle speeds : 15000 [rpm] - Spindle power : 4 [kW] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Max. bar diameter : 13 [mm] - Spindle speeds : 15000 [rpm] - Spindle power : 4 [kW] - C axis indexing precision : 0.001 [°] GUIDE BUSH HOLDER 1 - Number of positions : 8 - Number of motorized positions : 3 - Live tools speed : 6000 [rpm] - Live tools power : 1 [kW] GUIDE BUSH HOLDER 2 Rodpfxsyacu Ao Ad Aot - Number of positions : 8 - Number of motorized positions : 2 - Live tools speed : 6000 [rpm] - Live tools power : 1 [kW] END ATTACHMENT - Number of positions : 4 SECONDARY OPERATION - Number of positions : 8 - Number of motorized positions : 4 - Live tools speed : 6000 [rpm] - Live tools power : 0.75 [kW] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 26 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2170 X 1140 [mm] - Machine height : 1890 [mm] - Machine weight : 2800 [kg] MACHINE HOURS - Number of hours under power : 48838 [h] EQUIPMENT - CNC : Fanuc 31i-B - 3 colors status lamp - Rotating tool motor on : S11,S21,S51 - Rotating guide bush - Parts catcher - Ejection of workpiece - Parts conveying strip - Chips conveyor - Coolant tank : KNOLL * with high-pressure pump * with paper filtering unit - Bar loader : TORNOS SBF326-3.2M - Fire extinguisher * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer. - Electric transformer

Condition: used, TECHNICAL DETAILS - Number of axes : 7 Rsdpfxjuha U Hs Ad Aot - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 25.4 [mm] - Max. machining length : 195 [mm] - Spindle speeds : 10000 [rpm] - Spindle power : 8.2 [kW] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Max. bar diameter : 25.4 [mm] - Spindle speeds : 10000 [rpm] - Spindle power : 8.2 [kW] - C axis indexing precision : 0.001 [°] GUIDE BUSH HOLDER 1 - Number of positions : 9 - Number of motorized positions : 4 - Live tools speed : 5000 [rpm] GUIDE BUSH HOLDER 2 - Number of positions : 8 SECONDARY OPERATION - Number of positions : 8 - Number of motorized positions : 4 - Live tools speed : 7500 [rpm] POWER SUPPLY - Supply voltage : 400 [V] WEIGHT & DIMENSIONS - Machine floor space : 2.912 x 1.300 [mm] - Machine height : 1.720 [mm] - Machine weight : 2.400 [kg] MACHINE HOURS - Number of hours under power : 44140 [h] - Number of working hours : 28118 [h] - Number of spindle hours : 15281 [h] EQUIPMENT - CNC : Fanuc 31i-B - 3 colors status lamp - Rotating tool motor on : S11, S51 - Rotating guide bush - Parts catcher - Parts conveying strip - Ejection of workpiece - Chips conveyor - Coolant tank : KNOLL KF 200/1200 * with high-pressure pump - Bar loader : Tornos Robobar SBF 326 - Fire extinguisher * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer.

Condition: used, TECHNICAL DETAILS - Number of axes : 8 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 16 [mm] - Max. machining length : 180 [mm] - Spindle speeds : 12000 [rpm] - C axis indexing precision : 0.1 [°] COUNTER-SPINDLE - Max. bar diameter : 16 [mm] - Spindle speeds : 12000 [rpm] - C axis indexing precision : 0.1 [°] - Number of guide bush holders : 2 GUIDE BUSH HOLDER 1 - Number of positions : 6 - Number of motorized positions : 3 - Live tools speed : 8000 [rpm] GUIDE BUSH HOLDER 2 - Number of positions : 6 - Number of motorized positions : 3 - Live tools speed : 8000 [rpm] END ATTACHMENT - Number of positions : 4 - Number of motorized positions : 4 - Live tools speed : 8000 [rpm] SECONDARY OPERATION - Number of positions : 6 POWER SUPPLY - Supply voltage : 400 [V] MACHINE HOURS - Number of working hours : 53892 [h] EQUIPMENT - CNC : FANUC PNC DECO - Rotating tool motor on : S2,S5 - Rotating guide bush Rjdpfeuhayijx Ad Aet - Parts catcher - Ejection of workpiece - Coolant tank

Condition: used, TECHNICAL DETAILS - Number of axes : 6 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 16 [mm] - Max. machining length : 160 [mm] - Spindle speeds : 12000 [rpm] - Spindle power : 3.7 [kW] - C axis indexing precision : 0.1 [°] COUNTER-SPINDLE - Max. bar diameter : 16 [mm] - Spindle speeds : 12000 [rpm] - Spindle power : 2.2 [kW] - C axis indexing precision : 0.1 [°] - Number of guide bush holders : 1 GUIDE BUSH HOLDER 1 - Number of positions : 8 - Number of motorized positions : 3 - Live tools speed : 8000 [rpm] END ATTACHMENT - Number of positions : 3 SECONDARY OPERATION - Number of positions : 3 POWER SUPPLY - Supply voltage : 400 [V] WEIGHT & DIMENSIONS - Machine floor space : 1100 X 7270 [mm] - Machine height : 1950 [mm] - Machine weight : 3000 [kg] MACHINE HOURS - Number of hours under power : 22834 [h] EQUIPMENT - CNC : Fanuc PNS DECO - Rotating guide bush Rodpfsuhaz Tox Ad Aot - Parts catcher - Parts conveying strip - Ejection of workpiece - Coolant tank - Bar loader : ROBOBAR SSF

Condition: used, TECHNICAL DETAILS - Number of axes : 10 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 16 [mm] - Max. machining length : 180 [mm] - Spindle speeds : 12000 [rpm] - C axis indexing precision : 0.1 [°] COUNTER-SPINDLE - Max. bar diameter : 16 [mm] - Spindle speeds : 12000 [rpm] - C axis indexing precision : 0.1 [°] - Number of guide bush holders : 2 GUIDE BUSH HOLDER 1 - Number of positions : 6 - Number of motorized positions : 3 - Live tools speed : 8000 [rpm] GUIDE BUSH HOLDER 2 - Number of positions : 6 - Number of motorized positions : 3 - Live tools speed : 8000 [rpm] END ATTACHMENT - Number of positions : 4 - Number of motorized positions : 4 - Live tools speed : 8000 [rpm] SECONDARY OPERATION - Number of positions : 6 POWER SUPPLY - Supply voltage : 400 [V] MACHINE HOURS - Number of working hours : 30161 [h] EQUIPMENT Redpeuhaypsfx Ad Aot - CNC : FANUC PNC DECO - Rotating tool motor on : S2, S3, S5 - Rotating guide bush - Parts catcher - Ejection of workpiece - Coolant tank

Condition: excellent (used), Year of construction: 2019, machine/vehicle number: 14974, Tornos MultiSwiss 6x16  CNC Multi-Spindle Screw Machine Mfd. 2019 6 Motorspindles  5,5 kW max. speed 8’000 RPM Spindle capacity 16 mm, Z 50mm stroke (max. parts 40mm). 6 slides X 40mm stroke 1 counter-operation slide, 75mm stroke. Counter spindle with integrated motor 6 kW Max. speed 8’000 RPM, 150mm stroke. Rodpfx Adsv S H Uyj Ajt Numeric control Fanuc 30i Integrated PC with screen 17” Programming system TB DECO (DCS version) (requires 3003) contact us for more details

Condition: excellent (used), Year of construction: 2018, Tornos Multiswiss 6x32 Rsdjwf I Rzspfx Ad Aot Year of manufacture: 2018 Operating hours: 14,100 hours Including various accessories

Condition: used, TECHNICAL DETAILS - Number of axes : 21 - Number of spindles : 6 - Number of counter-spindles : 1 - Maximum number of tools : 18 - Maximum number of tools in counter-operation : 2 Rodouhavwopfx Ad Ajt SPINDLES - Max. bar diameter : 4 - 14 [mm] - Spindle speeds : 8000 [rpm] - Spindle power : 5.6 [kW] - Max. part length : 40 [mm] - Z stroke : 50 [mm] COUNTER-SPINDLE - Max. bar diameter : 14 [mm] - Spindle speeds : 8000 [rpm] - Spindle power : 5 [kW] - Z stroke : 150 [mm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 70 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 5.920 x 1.440 [mm] - Machine height : 2.120 [mm] - Machine weight : 7000 [kg] MACHINE HOURS - Number of hours under power : 35049 [h] EQUIPMENT - CNC : Fanuc - TB Deco ADV programming system (integrated PC) - Parts catcher - Ejection of workpiece - Chips conveyor - Coolant tank : 900 [l] * with high-pressure pump * with paper filtering unit - Bar loader : intégré * Bar length : 1500 [mm] - Fire extinguisher * * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer.

Condition: used, Year of construction: 2016, Article: CNC-controlled multi-spindle automatic lathe Manufacturer: Tornos Type: MultiSwiss 8x26 Yob: 2016 full cross slide configuration, counter spindle, part-pre-drawing device, 2 x driven tools, Rsdpeldk R Rofx Ad Ast 3 x Y-axis, 1 rigid backworking, 1 x driven backworking, 2x 80 bar high pressure pumps optional: setting robot, manufacturer HandlingTech. The scope of delivery regarding the tooling equipment could be different like pictures. Please, contact us for getting more informations and pictures on or *

Condition: used, Year of construction: 2019, Article: CNC-controlled multi-spindle automatic lathe Rodpjldk R Hsfx Ad Ast Manufacturer: Tornos Type: MultiSwiss 8x26 Yob: 2019 full cross slide configuration, counter spindle, part-pre-drawing device, 2 x driven tools, 1 rigid backworking, 1 x driven backworking, 2x 80 bar high pressure pumps optional: setting robot make HandlingTech. The scope of delivery regarding the tooling equipment could be different like pictures. Please, contact us for getting more informations and pictures on or *

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 7213, Country of manufacture: Switzerland Net weight: approx. 2550 kg Customs tariff number: 8458.11 20 Dimensions: 2000 x 1260 x 1950 mm TECHNICAL CHARACTERISTICS 10-axis machine – standard version 10 axes, 6 spindles: Axes and spindle designation: - 1 sliding headstock: Z1, S1 - 2 independent vertical gangs: X1Y1, S6 – X2Y2, S2 Redsw T Tcwjpfx Ad Aet - 1 unit with 4 rotating spindles: X3Z3, S3 - 1 independent sub-spindle: Y4Z4, S4 - 1 independent rotating sub-operation axis: X4, S5 Bar feeder position: right of the operator Machine axis height: 1100 mm Main spindle travel: max. 255 mm Bar capacity: 1 to 16 mm Spindle speed: 12,000 rpm Spindle feed rate: max. 20 m/min Bar capacity, min./max.: 13 mm / 16 mm Max. workpiece length: Guide bush machining: 180 mm Collet machining: 30 mm Sub-spindle speed: 12,000 rpm Main spindle drive power: 2.2 kW (continuous) / 3.7 kW (intermittent) Sub-spindle drive power: 1.5 kW (continuous) / 2.2 kW (intermittent) Clamping collet, type: F20 (no. 76-201) Guide bush: fixed / rotating Collet for guide bush, type: Meister 605 Number of lateral tool stations, combined: Fixed: 2 x 5 Rotating: 3 + 3 Number of frontal tool stations, combined: Fixed: 4 Rotating: 3 Number of rear tool stations, combined: Fixed: 3 + 3 Rotating: 3 + 3 Tool section: 12 x 12 mm Standard revolving toolholder: ESX 20 Bar feeder: yes Part catcher: yes All technical details are provided without guarantee and subject to errors or omissions.

Condition: like new (used), Year of construction: 2022, operating hours: 3,800 h, functionality: fully functional, Year 2022 - 3800 hours MultiSwiss 8x26, 6 Y-axes 8 motor spindles, 11 kW – 8000 rpm max Spindle capacity 26 mm, Z stroke 75 mm (max. workpiece 65 mm) 2 X-slide units in positions 1-8, stroke 80 mm 6 X-Y slide units in positions 2-3-4-5-6-7, X stroke 55 mm, Y +/-16.5 mm Counter spindle 11 kW – 8000 rpm max Z stroke 150 mm, X 170 mm Redpfx Aexrfunod Aet HP ejector adaptation for counter spindle (requires 3010 or 3020) Fanuc 30iB CNC control Integrated PC with Windows 10 operating system 21.5" color touchscreen Independent C axis on each spindle in main and counter operations (requires 0060 or 0065 or 0070 or 0075)

Condition: used, TECHNICAL DETAILS - Number of axes : 8 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 13 [mm] - Max. machining length : 190 [mm] - Spindle speeds : 15000 [rpm] - Spindle power : 4 [kW] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Max. bar diameter : 13 [mm] - Spindle speeds : 15000 [rpm] - Spindle power : 4 [kW] - C axis indexing precision : 0.001 [°] GUIDE BUSH HOLDER 1 - Number of positions : 8 - Number of motorized positions : 3 - Live tools speed : 6000 [rpm] - Live tools power : 1 [kW] GUIDE BUSH HOLDER 2 - Number of positions : 8 - Number of motorized positions : 2 - Live tools speed : 6000 [rpm] - Live tools power : 1 [kW] END ATTACHMENT - Number of positions : 4 SECONDARY OPERATION - Number of positions : 8 - Number of motorized positions : 4 - Live tools speed : 6000 [rpm] - Live tools power : 0.75 [kW] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 26 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2170 X 1140 [mm] - Machine height : 1890 [mm] - Machine weight : 2800 [kg] Rsdpoxyamujfx Ad Aot EQUIPMENT - CNC : Fanuc 31i-B - 3 colors status lamp - Rotating tool motor on : S11,S21,S51 - Rotating guide bush - Parts catcher - Ejection of workpiece - Parts conveying strip - Chips conveyor - Coolant tank : KNOLL * with high-pressure pump * with paper filtering unit - Bar loader : TORNOS SBF326-3.2M - Fire extinguisher * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer.

Condition: used, TECHNICAL DETAILS - Number of axes : 8 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 13 [mm] - Max. machining length : 190 [mm] - Spindle speeds : 15000 [rpm] - Spindle power : 4 [kW] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Max. bar diameter : 13 [mm] - Spindle speeds : 15000 [rpm] - Spindle power : 4 [kW] - C axis indexing precision : 0.001 [°] GUIDE BUSH HOLDER 1 - Number of positions : 8 - Number of motorized positions : 3 - Live tools speed : 6000 [rpm] - Live tools power : 1 [kW] GUIDE BUSH HOLDER 2 - Number of positions : 8 - Number of motorized positions : 2 - Live tools speed : 6000 [rpm] - Live tools power : 1 [kW] Rjdpsxyamnsfx Ad Ajt END ATTACHMENT - Number of positions : 4 SECONDARY OPERATION - Number of positions : 8 - Number of motorized positions : 4 - Live tools speed : 6000 [rpm] - Live tools power : 0.75 [kW] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 26 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2170 X 1140 [mm] - Machine height : 1890 [mm] - Machine weight : 2800 [kg] EQUIPMENT - CNC : Fanuc 31i-B - 3 colors status lamp - Rotating tool motor on : S11,S21,S51 - Rotating guide bush - Parts catcher - Ejection of workpiece - Parts conveying strip - Chips conveyor - Coolant tank : KNOLL * with high-pressure pump * with paper filtering unit - Bar loader : TORNOS SBF326-3.2M - Fire extinguisher * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer.

Condition: used, TECHNICAL DETAILS - Number of axes : 8 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 13 [mm] - Max. machining length : 190 [mm] - Spindle speeds : 15000 [rpm] - Spindle power : 4 [kW] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Max. bar diameter : 13 [mm] - Spindle speeds : 15000 [rpm] - Spindle power : 4 [kW] - C axis indexing precision : 0.001 [°] GUIDE BUSH HOLDER 1 - Number of positions : 8 - Number of motorized positions : 3 - Live tools speed : 6000 [rpm] - Live tools power : 1 [kW] GUIDE BUSH HOLDER 2 - Number of positions : 8 - Number of motorized positions : 2 - Live tools speed : 6000 [rpm] - Live tools power : 1 [kW] END ATTACHMENT - Number of positions : 4 SECONDARY OPERATION - Number of positions : 8 - Number of motorized positions : 4 - Live tools speed : 6000 [rpm] - Live tools power : 0.75 [kW] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 26 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2170 X 1140 [mm] - Machine height : 1890 [mm] - Machine weight : 2800 [kg] EQUIPMENT Rsdsxyamhjpfx Ad Ajt - CNC : Fanuc 31i-B - 3 colors status lamp - Rotating tool motor on : S11,S21,S51 - Rotating guide bush - Parts catcher - Ejection of workpiece - Parts conveying strip - Chips conveyor - Coolant tank : KNOLL * with high-pressure pump * with paper filtering unit - Bar loader : TORNOS SBF326-3.2M - Fire extinguisher * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer.

Condition: used, TECHNICAL DETAILS - Number of axes : 8 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 13 [mm] - Max. machining length : 190 [mm] - Spindle speeds : 15000 [rpm] - Spindle power : 4 [kW] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Max. bar diameter : 13 [mm] - Spindle speeds : 15000 [rpm] - Spindle power : 4 [kW] - C axis indexing precision : 0.001 [°] GUIDE BUSH HOLDER 1 - Number of positions : 8 - Number of motorized positions : 3 Rodjwr Ngkopfx Ad Aot - Live tools speed : 6000 [rpm] - Live tools power : 1 [kW] GUIDE BUSH HOLDER 2 - Number of positions : 8 - Number of motorized positions : 2 - Live tools speed : 6000 [rpm] - Live tools power : 1 [kW] END ATTACHMENT - Number of positions : 4 SECONDARY OPERATION - Number of positions : 8 - Number of motorized positions : 4 - Live tools speed : 6000 [rpm] - Live tools power : 0.75 [kW] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 26 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2170 X 1140 [mm] - Machine height : 1890 [mm] - Machine weight : 2800 [kg] MACHINE HOURS - Number of hours under power : 43982 [h] - Number of working hours : 15910 [h] EQUIPMENT - CNC : Fanuc 31i-B - 3 colors status lamp - Rotating tool motor on : S11,S21,S51 - Rotating guide bush - Parts catcher - Ejection of workpiece - Parts conveying strip - Chips conveyor - Coolant tank : KNOLL * with high-pressure pump * with paper filtering unit - Bar loader : TORNOS SBF326-3.2M - Fire extinguisher * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer. - Electric transformer

Condition: used, TECHNICAL DETAILS - Number of axes : 10 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 16 [mm] - Max. machining length : 184 [mm] - Spindle speeds : 10.000 [rpm] - C axis indexing precision : 0.1 [°] COUNTER-SPINDLE - Max. bar diameter : 16 [mm] - Spindle speeds : 10.000 [rpm] - C axis indexing precision : 0.1 [°] GUIDE BUSH HOLDER 1 - Number of positions : 5 - Number of motorized positions : 3 - Live tools speed : 8.000 [rpm] GUIDE BUSH HOLDER 2 - Number of positions : 5 - Number of motorized positions : 3 - Live tools speed : 8.000 [rpm] END ATTACHMENT - Number of positions : 4 - Number of motorized positions : 4 - Live tools speed : 8.000 [rpm] SECONDARY OPERATION - Number of positions : 6 - Number of motorized positions : 3 - Live tools speed : 8.000 [rpm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 14 [kVA] MACHINE HOURS - Number of working hours : 54.035 [h] EQUIPMENT - CNC : Fanuc PNC DECO Redpjuhhp Sefx Ad Aot - Rotating tool motor on : S2, S3, S5,S6 - Rotating guide bush - Parts catcher - Coolant tank * with high-pressure pump - Bar loader : IEMCA GENIUS 118 / 32LL - Cooling unit : MARKSA CSW 200 - Fire extinguisher * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer. - Number of turning tool holders : 3

Condition: used, Swiss-type cnc lathe TORNOS DECO 13A Rsdpfx Adouhhp Ej Ast
