CNC turn-mill center

INDEX G200

Condition: used, Year of construction: 2007, Technical Specifications: • Power supply: 3-phase / 50 Hz • Voltage: 400 V • Control voltage: 24 V • Rated current: 68 A Included Equipment: • Bar feeder IEMCA Master 880 MP/33 L Serial number: 020721SA07 Year of manufacture: 2007 Air pressure: 6 bar Voltage: 400 V / 3 ~ / 50 Hz Current: 6 A Weight: 1,360 kg Manufacturer: IGMI S.p.A. (BUCCI Industries), Faenza, Italy Iodpfxexnlv Ro Agqsa

Condition: excellent (used), Year of construction: 2004, functionality: fully functional, Description WE OFFER AN NICE WORKING CONDITION INDEX ABC 42 - TWO MACHINES WE HAVE AWAILIBLE TWIN SPINDLE TWIN TURRET INCLUDIN COMPLETE TOOLINGS AND SPARE PARTS MACHINE IS CONECTED ON POWER AND CAN BE INSPECTED UNDER POWER FOR CUSTOMER WE CAN ORGANIZE TRANSPORT AS WELL Machine Category CNC Turning- and Milling Center Make INDEX Type ABC 42 (*934) Year 2004 Control C200-4 / 840C Siemens Country of origin Germany Other information CNC - Turning- and MillingCenter INDEX - ABC 42 - two turrets - live tool stations - subspindle on upper turret - 1x back drilling device - with percussion unit - many accessories Technical Details Backside processing: C-Axis 0,001 ° change-time tool to tool 0,2 sec clamping diameter max. 42 mm clamping length max. 38 mm control C200-4 / 840C Siemens dimensions of the machine ca. 7,0 x 3,0 x 2,5 m Driven Tool Positions: 8 Feed force X: 8,3 / Z: 5,5 kN Fixed tools max. 5 pos Main spindle: max. Torque 7,5 Nm number of toolpositions 6 pos. power capacity - driven tools 3,3 kW power capacity - main spindel 13 / 21 kW rapid traverse X: 16 / Z: 24 m/min shaft cross cut 25 x 48 DIN 69880 spindle bore 15,5 mm spindle diameter in front bearing 85 mm spindle hollow 36 mm spindle passage 36 (42) mm Spindle speed - driven tools 6.000 min -1 Spindle speed range subspindle max. 4.500 min/-1 Subspindel: total power requirement ca. 30 kW travel -x axis 81 mm travel -z axis 80 mm turning length max. 280 mm turning speed range - main spindle max. 6.300 min/-1 Turret 1: Turret 2: weight of the machine ca. 3,0 t Accessories Isdevk E Nmopfx Agqea bar feeder Index LM 3200 Chip conveyor Coolantsystem Documents driven tool stations hydraulic system parts catcher Subspindle Turret 2x

Condition: used, Year of construction: 2007, controller manufacturer: SIEMENS, controller model: SINUMERIK, number of spindles: 2, CONTROLS .. CNC controls SIEMENS SINUMERIK BASIC FUNCTIONS .. design principle: inclined bed Iedpsxwty Nofx Agqoa .. number of spindles: 2 .. - counter spindle: yes .. live positions: yes .. number of c-axes: 2 .. number of y-axes: 1 WORKING RANGE TURNING .. swing diameter (max): 420 mm .. turning diameter (max): 200 mm .. bar diameter (max): 60 mm .. worpiece length max.: 400 mm MAIN SPINDLE .. spindle revolutions (max): 5000 /min .. spindle bore diameter: 60 mm .. c-axis: yes COUNTER SPINDLE .. spindle revolutions (max): 5000 /min .. c-axis: yes X/Z SLIDE .. number of tool positions (total): 14 .. - rotation speeds (max): 6000 /min .. - drive power: 5.5 kW TOOL MAGAZINE .. number of positions: 14 ELECTRICAL SPECIFICATIONS .. total power consumption: 44 kW .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. space requirements -left/right-: 2450 mm .. space requirements -front/back-: 1400 mm .. total height: 1850 mm .. total weight approx.: 5500 kg ATTACHMENTS (TURNING) .. chip conveyor: yes Accessories - Chip conveyor - Iemca Master 880MP bar feeder

Condition: used, Year of construction: 1997, turning diameter 420 mm turning length 400 mm spindle tunring speed 5.000 U/min Isdpfx Agexp R Etsqsa power capacity 44 kW bar material dia. 60 mm In our opinion, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are only included in the scope of delivery if noted in the additional information. Subject to changes and errors in the technical data and information, as well as subject to prior sale!

Condition: ready for operation (used), Year of construction: 2000, operating hours: 45,000 h, General Data Measurements width 1910 mm Measurements depth 3580 mm Measurements height 2050 mm Machine weight 4000 kg Control Unit Brand INDEX Model C200-4 / C200-8 Additional Equipment Synchronous device for counter spindle machining Tool carrier 3 for synchronous spindle (rear end machining) Additional milling spindle Thread milling and polygon turning device Gripperless tool changer (6 tools, HKS-50 B, KM40) Workpiece handling WHU100 This 5-axis Index G200 C turn-mill centre was manufactured in 2000. Consider the opportunity to buy this Index G200 C turn-mill centre. Contact us for more information. Ijdpfx Agexfwzmeqja Application Types Turning

Condition: refurbished (used), Year of construction: 2017, functionality: fully functional, machine/vehicle number: 510864, turning length: 200 mm, CNC lathe INDEX G200 Overhauled: 2017 Machine number: 510864 max. turning length: 200 mm Bar loading magazine INDEX MBL Main spindle Spindle passage collet clamping: 42mm Spindle diameter in front bearing: 85mm Spindle nose ISO702/1: 5 Chuck diameter: 140/160 Max. Nominal turning diameter: 200mm Max. Rotation diameter: 420mm Power Pmax 100%: 7.5/13/20 Torque Mdmax 100%: 35/61/95 Speed: 6300 Counter spindle Spindle passage collet clamping: 42mm Spindle diameter in front bearing: 85mm Spindle nose ISO702/1: 5 Chuck diameter: 140/160 Power Pmax 100%: 7.5/13 Torque Mdmax 100%: 35/61 Speed: 6300 Min. distance collet: 15mm Longitudinal travel: 445mm Rapid traverse: 22.5mm Cross slide 1 XZ (top) XZ: 120x400mm Feed force: 5000N Cross slide 2 (bottom) XZ: 105x400mm Ijdpfx Ageulhinoqja Feed force: 5000N Further information on request!

Condition: used, TECHNICAL DETAILS - Number of axes : 9 - Number of spindles : 2 - Number of turrets : 2 MAIN SPINDLE - Spindle nose : A2-5" - Spindle power : 20/29 [kW] - Spindle speeds : 5.000 [rpm] - Max. bar diameter : 65 [mm] - Max. turning diameter : 200 [mm] - C axis indexing precision : 0,001 [°] COUNTER-SPINDLE Ijdpfxsuhaf Ee Agqsa - Spindle nose : A2-5" - Spindle power : 13/22 [kW] - Spindle speeds : 5.000 [rpm] - Max. bar diameter : 60 [mm] - C axis indexing precision : 0,001 [°] - Travel : 445 [mm] TURRET - Number of positions : 14 - Number of motorized positions : 14 - X/Z stroke : 155/590 [mm] - Y stroke : 120 [mm] - B Axis stroke : 360 [°] - Tool holder type : VDI 25 - Live tools speed : 6.000 [rpm] MILLING SPINDLE - Spindle speeds : 6.000 [rpm] - Spindle power : 5,5 [kW] LOWER LEFT TURRET - Number of positions : 14 - Number of motorized positions : 14 - X/Z stroke : 105/400 [mm] - Tool holder type : VDI 25 - Live tools speed : 6.000 [rpm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 39 [kW] WEIGHT & DIMENSIONS - Machine floor space : 3.450 x 2.520 [mm] - Machine height : 2.650 [mm] - Machine weight : 4.800 [kg] EQUIPMENT - CNC : INDEX C200-4 (Siemens 840D) - Tailstock option with counterspindle - Coolant tank - Chips conveyor : Droite KNOLL - Tool probe : Renishaw - Tool breakage detection - Parts catcher - Chuck 3 jaws : SMW 210BH - Collet chuck : HAINBUCH Spanntop 65 - Number of fixed tool holders : 28 - Number of turning tool holders : 5

Condition: used, Year of construction: 2001, Technical Specifications: • Power supply: 3 Ph / 50 Hz • Voltage: 400 V • Control voltage: 24 V • Rated current: 76 A • Total power: 42 kW • Machine weight: 4,800 kg • Electrical cabinet weight: 440 kg Included Equipment: • Bar feeder IEMCA Master 880/33R P Serial number: 0200141S02 Year of manufacture: 2001 Supply voltage: 380 V / 3 Ph / 50 Hz Control voltage: 220 V / 24 V Power consumption: 6 A Machine weight: 120 kg Iodpfx Agexnlk Uoqsa

Year of construction: 1995, condition: ready for operation (used), Max. speed range: 5000 rpm, bar capacity: 65 mm, max. turning diameter: 200 mm, max. turning length: 400 mm. Number of spindles: 2, tool changer: 2x 14, Siemens control. Including outfeed conveyor, KNOLL 400S-1 chip conveyor (year of manufacture: 2016), switch cabinet with cooling unit, CO2 extinguishing system and INDEX bar loader. General overhaul in 2016. Iodpfxetdwwmj Agqja

Condition: used, TECHNICAL DETAILS - Number of axes : 7 - Number of spindles : 2 - Number of turrets : 1 MAIN SPINDLE - Spindle nose : A2-5 - Spindle power : 22 [kW] Iodpfxou Hadhj Agqja - Spindle speeds : 6000 [rpm] - Max. bar diameter : 60 [mm] - Max. turning diameter : 200 [mm] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Spindle nose : A2-5 - Spindle power : 22 [kW] - Spindle speeds : 6000 [rpm] - Max. bar diameter : 60 [mm] - C axis indexing precision : 0.001 [°] - Z stroke : 445 [mm] TURRET 1 - Number of positions : 14 - Number of motorized positions : 14 - X/Z stroke : 105/400 [mm] - Y stroke : 120 [mm] - B Axis stroke : +90/-270 [°] - Tool type : VDI 25 - Live tools speed : 6000 [rpm] - Live tools power : 5.5 [kW] POWER SUPPLY - Supply voltage : 400 [V] WEIGHT & DIMENSIONS - Machine floor space : 4.975 X 2.890 [mm] - Machine height : 2.050 [mm] - Machine weight : 4800 [kg] EQUIPMENT - CNC : Siemens 840C - Coolant tank * with high-pressure pump - Chips conveyor - Parts catcher - Parts conveying strip - Bar loader : LNS

Year of construction: 2003, condition: ready for operation (used), Max. turning diameter: 200mm, max. turning length: 400mm, spindle speed: 6000rpm, bar capacity: 42mm, weight: approx. 4300kg. Ijdpfx Aotdwwqsgqsa
