Used Index G200 for sale (15)

Condition: excellent (used), Year of construction: 1998, Machine in very good condition. It has worked to the end, now it is on warehouse not connected to power. Guodpfx Ajwq Rwnod Hoa Machine in 100% completed Parts conveyor, chips conveyor, available. Spindels bore 42 mm 2x 3 jaws chuck 160 mm 2x Hainbuch collets chuck 42 mm

Condition: ready for operation (used), Year of construction: 2000, spindle motor power: 22,000 W, total height: 2,050 mm, overall weight: 4,000 kg, controller manufacturer: INDEX, controller model: C200-4 / C200-8, This 5-axis Index G200 C turn-mill centre was manufactured in 2000. Consider the opportunity to buy this Index G200 C turn-mill centre. Contact us for more information. Additional equipment • Synchronous device for counter spindle machining • Tool carrier 3 for synchronous spindle (rear end machining) • Additional milling spindle • Thread milling and polygon turning device • Gripperless tool changer (6 tools, HKS-50 B, KM40) • Workpiece handling WHU100 • with c-axis • no driven tools Machine Benefits Guedpfx Asyailzed Hja Technical Machine Benefits • Space requirement (without material guide): 3580 x 3108 mm • Control unit: resolution: 0. 001 mm (input/output/correction) • Comprehensive movement range with multiple axes configuration • High precision with 0. 001 mm resolution in numerical control • Versatile expansion stages and additional equipment for enhanced functionality Extra Information Movement Cross slide 1 (top) - XYZB axes: X-axis: Slide path 155 mm, feed force 5000 N, rapid traverse 20 m/min, resolution 0.0005 mm Y-axis: Slide travel 120 mm, feed force 10000 N, rapid traverse 7.5 m/min, resolution 0.0005 mm Z-axis: Slide path 590 mm, feed force 5000 N, rapid traverse 30 m/min, resolution 0.001 mm B-axis (rotating): 360° swivel range, angular steps 5° (with locking), resolution 0.001° (with clamping), switching time for 180°: 1 s Cross slide 2 (bottom) - XZ axes: X-axis: Slide travel 105 mm, feed force 5000 N, rapid traverse 20 m/min, resolution 0.0005 mm Z-axis: Slide path 307 mm, feed force 5000 N, rapid traverse 30 m/min, resolution 0.001 mm Turret Turret right: X-axis: Slide path 120 mm Z-axis: Slide travel 400 mm Tail Stock Center distance: 400 mm Pressure force (max): 5500 N Drive: Hydraulic or electric Media Power supply: 400 V, 50/60 Hz Connected load: 20-45 kVA Current consumption: 35-80 A Hydraulic system: Delivery rate: 18 l/min System pressure: 90 bar Filling capacity: 70 liters Cooling lubricant system: Pump capacity (switchable): 20 l/min at 18 bar / 50 l/min at 3 bar / 60 l/min at 5-7 bar Filling quantity: Approx. 230 liters Chip conveyor: Hinged belt or scraper Workpiece holder: Main spindle: DB5 internal mount / D140 external mount, optional short taper Counter spindle: D140 external mount (only tensile clamping permitted for collet and chuck clamping) 1st spindle data (main/counter spindle): Spindle clearance (collet clamping): Variants: 30 mm / 42 mm / 60 mm / 65 mm Spindle Ø in front bearing: 75 mm (with 30 mm clearance) / 85 mm (42 mm) / 100 mm (60+65 mm) Speed (max): 7500 rpm (30 mm) / 6300 rpm (42 mm) / 5000 rpm (60 mm) Spindle nose: ISO 702/1 (size 4 or 5) Chip diameter (workpiece Ø): 110-130 mm (30 mm) / 140-160 mm (42 mm) / 165 mm (60 mm) Torque (Md max 100%): 33-62 Nm (30 mm) / 35-95 Nm (42 mm) Power (P max 100%): 7-13 kW (30 mm) / 7.5-20 kW (42 mm) Dimensions Machine Depth 3580 mm

Condition: used, Year of construction: 1996, Type: Multispindle lathe Make: Index Model: G200 Year of manufacture: 1996 Condition: Used Guodjyn Hmxspfx Ad Hsa Quantity: 1

Year of construction: 1995, condition: ready for operation (used), A CNC counter-spindle lathe Index with Y-axis and bar feeder MBL 42 is available. Turning length: 400mm, turning diameter: 420mm, bar capacity: 60mm, speed: 6000rpm, machine dimensions X/Y: 4750mm/1950mm. Documentation available. An on-site inspection is possible. Gjdpfoym Dgmjx Ad Hsua

Year of construction: 1995, condition: ready for operation (used), Max. speed range: 5000 rpm, bar capacity: 65 mm, max. turning diameter: 200 mm, max. turning length: 400 mm. Number of spindles: 2, tool changer: 2x 14, Siemens control. Including outfeed conveyor, KNOLL 400S-1 chip conveyor (year of manufacture: 2016), switch cabinet with cooling unit, CO2 extinguishing system and INDEX bar loader. General overhaul in 2016. Gusdetdwwmspfx Ad Hsa

Year of construction: 2003, condition: ready for operation (used), Max. turning diameter: 200mm, max. turning length: 400mm, spindle speed: 6000rpm, bar capacity: 42mm, weight: approx. 4300kg. Guodpfx Astdwwqsd Hoa

Year of construction: 1997, condition: ready for operation (used), Turning diameter: 200mm, turning length: 400mm, turning diameter: 420mm, bar diameter: 60mm, max. spindle chuck diameter: 160mm, speed: 5000rpm, turret: 2, positions: 2x14, rapid traverse X/Z: 20m/min/30m/min. Machine dimensions X/Y/Z: approx. 7500mm/2100mm/2100mm, weight: approx. 4500kg. Documentation available. On-site inspection is possible. Gujdpfxju T Rgkj Ad Hea

Condition: used, TECHNICAL DETAILS - Number of axes : 7 - Number of spindles : 2 - Number of turrets : 1 MAIN SPINDLE - Spindle nose : A2-5 - Spindle power : 22 [kW] - Spindle speeds : 6000 [rpm] - Max. bar diameter : 60 [mm] - Max. turning diameter : 200 [mm] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Spindle nose : A2-5 - Spindle power : 22 [kW] - Spindle speeds : 6000 [rpm] - Max. bar diameter : 60 [mm] - C axis indexing precision : 0.001 [°] - Z stroke : 445 [mm] TURRET 1 - Number of positions : 14 - Number of motorized positions : 14 - X/Z stroke : 105/400 [mm] - Y stroke : 120 [mm] - B Axis stroke : +90/-270 [°] - Tool type : VDI 25 - Live tools speed : 6000 [rpm] - Live tools power : 5.5 [kW] POWER SUPPLY - Supply voltage : 400 [V] WEIGHT & DIMENSIONS Gjdpfx Aeu Hadhsd Hsua - Machine floor space : 4.975 X 2.890 [mm] - Machine height : 2.050 [mm] - Machine weight : 4800 [kg] EQUIPMENT - CNC : Siemens 840C - Coolant tank * with high-pressure pump - Chips conveyor - Parts catcher - Parts conveying strip - Bar loader : LNS

Condition: used, Year of construction: 1997, turning diameter 420 mm turning length 400 mm spindle tunring speed 5.000 U/min power capacity 44 kW bar material dia. 60 mm In our opinion, the machine is in good used condition and can be inspected under power by appointment. Gjdpeylp Awofx Ad Heua Accessories, tools, and clamping devices shown are only included in the scope of delivery if noted in the additional information. Subject to changes and errors in the technical data and information, as well as subject to prior sale!

Condition: used, Year of construction: 1998, turning diameter 200 mm turning length 400 mm control Siemens type C 200-4 840 C spindle passage 65 mm Tool changer 2 x14 Pos. live tooling 2x Revoler weight of the machine ca. 4 t Main and counter spindle 3-jaw chuck with numerous jaws Hainbuch collets Many tool holders Various driven tools Bar loader "Index MBL" Chip conveyor with coolant unit Complete set of spindle reducers etc. see photo The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop Guedpfjyqvygsx Ad Hsa If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: ready for operation (used), Year of construction: 2003, operating hours: 92,000 h, controller manufacturer: SIEMENS, controller model: 840D, number of axes: 5, This 5-axis Index G 200 RATIO LINE was manufactured in 2003. It features a Y-axis travel of 120 mm, a main spindle diameter of D65, and a counter spindle diameter of D60. The machine is equipped with a turret that has 12 stations and driven tools on turret 1 and 2. If you are looking to get high-quality turning and milling capabilities, consider the Index G 200 RATIO LINE turn-mill centre we have for sale. Contact us for further details. • C-axis on main and counter spindle • Thread cutting without compensating chuck • Electronic shaft • Additional V24 RS232 interface in control cabinet • Transmit-/Tracyl function Gsdpfx Asylw Dced Hjua • MDE interface (machine on, machine running, parts counter) • Marposs (Brankamp) collision monitoring CMS100 • 3D machine model for kinematic simulation in CAM programming system • Control cabinet cooling unit • Main spindle D65 • Counter spindle D60 • Coolant flushing of counter spindle (electrically controlled shut-off valve) • Foot switch • Turret (12 stations) bottom and top • Driven tools on turret 1 and 2 • Control function “synchronous tailstock” for turret 2 • Y-axis 120 mm • Automatic sliding door (hydraulic) • Coolant pump 80 l / 8 bar • High-pressure coolant connection slide 1 and 2 with solenoid valve • Coolant flushing gun • Preparation for extraction and filter system connection • Operating hours approx. 92,000 h Additional equipment • Portal unloading device with actuated gripper, NC-controlled • Gripper fingers D4–45 mm and D40–65 mm • Indexed conveyor belt • UNIMAG interface • Chip conveyor (hinged belt), discharge height 1250 mm • Vacuum rotary filter KNOLL (emulsion use) • High-pressure pump 80 bar • Workholding: • Collet chucks for draw tube, HAINBUCH (main and counter spindle) • Power chucks D210 with quick jaw change, Schunk (main and counter spindle) • Stop device • Optional: large number of powered tool holders and spare parts warehouse

Condition: good (used), Year of construction: 2012, functionality: fully functional, Control: SIEMENS Spindle bore: 65 mm Turning length: 660 mm Max. speed: 6,000 rpm Counter spindle Z= 700 mm TOOL CARRIER 1 with milling spindle Milling spindle: 7,200 rpm B-axis: 360° 14 stations with driven tools Tool speed: 7,200 rpm Travel: X= 230 / Y= ±65 / Z= 845 TOOL CARRIER 2 14 stations with driven tools Tool speed: 7,200 rpm Travel: X= 140 / Y= ±45 / Z= 810 Chip conveyor Gjdpfx Aoyi Uk Ijd Houa Filter Bar feeder INDEX MBL

Year of construction: 2003, condition: ready for operation (used), A fully autonomous CNC dual-spindle turning machine Index is available. Turning diameter: 220mm, main spindle bar capacity: 65mm, main spindle power chuck diameter: 210mm, sub-spindle bar capacity: 60mm, sub-spindle power chuck diameter: 210mm, tool stations: 12, Y-axis travel: 120mm, gripper diameter range: 4mm-45mm/40mm-65mm, coolant pump pressure: 8bar, high-pressure pump capacity: 80bar, chip conveyor discharge height: 1250mm. Overall system dimensions X/Y/Z: approx. 9150mm/4350mm/2000mm, weight: approx. 10500kg, operating hours: approx. 92000h. Including bar loader FMB turbo 8-80 XT/3200A, automatic loading and unloading system alphaMAX 6-axis, chip conveyor, coolant system, high-pressure pump and spare parts. Operation with the loading and unloading system is designed for disc diameters from 80mm to 220mm. This is a fully automated system without operator. Documentation available. On-site inspection is possible. Expected to be available from June 2026. Gjdoyfv Nkepfx Ad Hsua

Condition: used, Year of construction: 1998, turning diameter 200 mm turning length 400 mm control SIEMENS SINUMERIC 840 C total power requirement 40 kW weight of the machine ca. 6.500 kg dimensions of the machine ca. m Guodpfjt Hw Rkjx Ad Hja

Condition: refurbished (used), Year of construction: 2017, functionality: fully functional, machine/vehicle number: 510864, turning length: 200 mm, CNC lathe INDEX G200 Overhauled: 2017 Machine number: 510864 max. turning length: 200 mm Bar loading magazine INDEX MBL Main spindle Spindle passage collet clamping: 42mm Spindle diameter in front bearing: 85mm Spindle nose ISO702/1: 5 Chuck diameter: 140/160 Max. Nominal turning diameter: 200mm Max. Rotation diameter: 420mm Power Pmax 100%: 7.5/13/20 Torque Mdmax 100%: 35/61/95 Speed: 6300 Counter spindle Spindle passage collet clamping: 42mm Spindle diameter in front bearing: 85mm Spindle nose ISO702/1: 5 Chuck diameter: 140/160 Power Pmax 100%: 7.5/13 Torque Mdmax 100%: 35/61 Speed: 6300 Min. distance collet: 15mm Longitudinal travel: 445mm Rapid traverse: 22.5mm Cross slide 1 XZ (top) XZ: 120x400mm Feed force: 5000N Cross slide 2 (bottom) XZ: 105x400mm Godpjulhinefx Ad Houa Feed force: 5000N Further information on request!
