Bed type milling machine

Knuth KB 1400

Condition: ready for operation (used), Year of construction: 2018, travel distance X-axis: 950 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 500 mm, total height: 2,120 mm, total width: 1,770 mm, overall weight: 3,660 kg, spindle speed (max.): 1,800 rpm, product length (max.): 2,290 mm, number of axes: 3, This 3-axis KNUTH KB 1400 was manufactured in 2018. It features a travel of 950 mm on the X-axis, 400 mm on the Y-axis, and 500 mm on the Z-axis. The machine is equipped with a spindle speed range of 30 to 1800 rpm and a table setup area of 1400 mm x 400 mm. If you are looking to get high-quality milling capabilities, consider the KNUTH KB 1400 vertical machining centre we have for sale. Contact us for further details. • Feed • Feed speed X-axis: 18–627 mm/min • Feed speed Y-axis: 18–627 mm/min • Feed speed Z-axis: 18–627 mm/min • Rapid feed • Rapid feed X-axis: 1670 mm/min • Rapid feed Y-axis: 1670 mm/min • Rapid feed Z-axis: 1670 mm/min • Vertical milling head • Throat: 510 mm • Spindle speed (vertical): 30–1800 1/min (rpm) • Quill stroke: 105 mm Ppsdjzgfiuopfx Aqlow • Head swivel range: ±30° • Working area • Spindle axis-to-table surface distance: 150–650 mm • Table set-up area: 1400 × 400 mm • Number of T-slots: 3 • T-slot width: 18 mm • T-slot spacing: 100 mm • Speed height-adjustment (max.): 1670 mm/min • Coolant pump flow rate: 12 l/min Technical Specification Taper Size SK 50

Year of construction: 1981, condition: used, Manufacturer: Deckel Type: FP 4 Table: Dimensions: 1000 x 470 mm Longitudinal movement (X-axis): 700 mm Transverse movement (Y-axis): 400 mm Vertical movement (Z-axis): 450 mm Spindle overhang: 50 - 450 mm Spindle mount: ISO 40 Number of spindle speeds: 18 Spindle speed range: 31.5 - 1600 rpm Number of horizontal spindle speeds: 18 Horizontal spindle speed range: 31.5 - 1600 rpm Ppsdpfx Aqsihp U Dolsw Machine weight: 2000 kg Feeds (X, Y, Z axes): 18, 10 - 500 mm/min Accessories: Milling head with quill Table: 1000 x 470 mm

Condition: used, Year of construction: 1977, Technical details: x-travel: 1050 mm y-travel: 500 mm z-travel: 500 mm spindle taper ISO: SK40 spindle head swivable left - right: 90 ° quill travel: 180 mm range of revolution per miute: 36 - / 18 step U/min feed:: X+Z: mm/min feed:: Y: - 900 mm/min. rapid traverse : X/Z: / Y: 900 mm/min table surface area: 1200 x 550 mm total power requirement: ca. 10 kW machine weight approx.: 4400 kg dimension machine xH: 3,1 x 2,5 x 2,2 m Console design with tilting, tilting and swiveling table, as well as adjustable vertical milling head. Machine with 3-axis digital readout (with resolution 0.01mm) with feed and individual drive of all three axes stepless feed X-axis: Support lengthwise = 700mm; univ. milling table lengthwise 350mm = total lengthwise: 1050mm Accessories: Comparable with the pictures Pjdju Ndd Rspfx Aqlopw *

Condition: good (used), Year of construction: 1980, Table size 1300 x 355 mm Tool holder, vertical + horizontal ISO 50 Travel X-axis 1000 mm Y-axis 350 mm Z-axis 450 mm Vertical milling head, swiveling R + L Quill stroke 100 mm Speed range 22.4 – 1400 rpm Feed range 6.3 – 630 mm/min Rapid traverse 2.5 m/min Drive power approx. 5 kW Space requirement L x W x H 1900 x 1800 x 2100 mm Weight 3200 kg Accessories / Special features: • 3-axis digital display, make FAGOR • Swiveling vertical milling head (R-L) with quill adjustment 100 mm • Vertical and horizontal milling spindle ISO 50 • Milling spindle vertical + horizontal • Large Clamping table 1350 x 350 mm • Feed and rapid traverse in all axes • Wide, stable guideways Psdpfxovu Dv Te Aqlspw • Central lubrication • Swiveling control panel • Coolant system • EMERGENCY STOP switch Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: good (used), VEB Fritz Heckert FU 250x1000 milling machine Manufacturer: VEB Fritz Heckert Type: FU 250x1000 X-axis: 900 mm Y-axis: 300 mm Z-axis: 380 mm Speed: 28-2800/min Ppsdpfxstryc Nj Aqlsw Speed: 10-630 mm/min Dimensions: 1240 x 340 mm Speed: 6 kW, 35 A Load: 1.7 t Dimensions: 1580 x 1420 x 1470 mm

Condition: new, WM6350F ROGI universal milling machine, 400V-3Ph Drilling capacity in steel ----- 50 mm Milling capacity in steel ----- 25 mm Face milling capacity ----- 100 mm Horizontal motor ----- 2.2 KW Vertical motor ----- 2.2 KW Speed range, horizontal milling spindle ----- 60 ~ 1350 rpm Speed range, vertical milling spindle ----- 90 ~ 2000 rpm Spindle taper ----- ISO 40 Table ----- 1270 x 320 mm Pjdpfxoga T Are Aqlepw Weight ----- 1500 KG INCLUDED * 3-axis digital readout, brand SINO * Automatic feed for work table X, Y, Z * Automatic spindle feed * LED lighting * Cooling system * Deluxe control panel * Tilting milling head, left/right, 0 - 45 degrees * Rotatable work table OPTIONAL * Pneumatic draw-in bar

Condition: used, Year of construction: 1977, Technical details: x-travel: 450 mm y-travel: 200 mm z-travel: 400 mm spindle taper ISO: SK 30 distance table/horizontal spindle: max. 400 mm cross rail adjustment - horizontal: 400 (manuell) mm range of revolution per miute: horizontal: 30 - 1275 / 18 step U/min spindle taper: horiz.+vertikal: SK30 distance between table/spindle: vertikal: max. 430 mm quill travel: 60 mm swival range +/-: 90° Grad range of revolution per miute: Vertikalspindel: 50 - 215 / 18 step U/min clamping surface area: 860 x 240 mm table swivable approx.: 45° Pedpfx Aqovc Awfolopw feed:: 0 - 1.000 / steples mm/min rapid traverse: 2.000 mm/min. total power requirement: 6,0 kW machine weight approx.: 3100 kg dimension machine xH: 1,6 x 1,6 x 1,9 m Coolant device 3-way DRO Heidenhain control panel Optional accessories *

Condition: ready for operation (used), A CNC universal tool milling machine Hermle is available. Travel X/Y/Z: 700mm/550mm/500mm, table dimensions X/Y: 1000mm/500mm, quill stroke: 100mm, tool holder: SK40, spindle speed: 3150rpm, feed rate: 2m/min, rapid traverse: 5m/min, max. workpiece weight: 400kg. Machine dimensions X/Y/Z: approx. 3900mm/3300mm/2100mm, weight: approx. 3300kg, control: Heidenhain TNC 150. An on-site inspection is possible. Ppodpfxjxwcu Ae Aqljw

Condition: not inspected (used), JAFO FYN 50 NB – CNC Vertical Milling Machine For sale is a CNC vertical milling machine from JAFO, model FYN 50 NB, year of manufacture 1988. The machine is fully operational and ideal for precise milling operations on workpieces up to 700 kg including clamping device. ⸻ Technical Data • Travel (X/Y/Z): 800 × 500 × 500 mm • Table working area: 500 × 1,400 mm • Number of T-slots: 7 • Slot width: 18 mm • Slot pitch: 63 mm • Max. longitudinal table travel: 800 mm • Max. vertical knee travel: 500 mm • Max. transverse spindle head travel: 500 mm • Feed rate: stepless 0–4,000 mm/min • Spindle taper: ISO 50 • Head swivel angle: ±45° • Distance spindle axis to vertical guides: max. 590/90 mm • Spindle speed: 56–1,800 rpm • Rapid traverse: 4,000 mm/min • Spindle drive motor power: 5.5 kW • Operating voltage: 380 V, control voltage 24 V • Total power consumption: 10 kW • Dimensions (L×W×H): 2,080 × 1,700 × 2,260 mm • Total weight incl. hydraulic unit: 4.5 t ⸻ Equipment & Features • Vertical, swivelling milling spindle on a transversely adjustable ram • Hydromechanical tool clamping system • Separate feed drives with DC motors and permanent magnets • Power transmission via toothed belt to preloaded ball screws • Automatic lubrication system for spindle drive and guideways • Hydraulic counterweight for the knee • Manual adjustment via electronic handwheel • Heidenhain control at the swivelling control panel, control cabinet mounted on the machine base • Documentation and operating manual included • Additional images and videos available upon request ⸻ The machine is immediately ready for operation. • Inspection possible at any time • Europe-wide transport available ⸻ Contact Maschinenhandel Nord Gerstenstraße 2 17034 Neubrandenburg 📞 All prices net plus VAT. Subject to modifications and errors. Ppedpjxk Tzgofx Aqljw

Condition: used, Year of construction: 1970, functionality: fully functional, 1 used: Universal milling machine, second-hand • Manufacturer: Klopp Podpfxjw R T A Ee Aqlepw • Model: FW 11/4 • Year of manufacture: unknown, approx. 1970 • Table clamping area: 1100 x 300 mm • Spindle taper: SK 40 • Swivelling milling head: 2x 110° • Spindle speeds: 40/80/120/240/480/960 • Feeds: 12–340 mm/min Accessories: Various tool holders and cutters, 1 set of collets Hydraulic vice with pneumatic support pins Vice jaw width: 160 mm
