Used Biglia Quattro Cnc Lathe for sale (11,495)

Condition: excellent (used), Year of construction: 2004, operating hours: 1,000 h, functionality: fully functional, turning diameter over cross slide: 380 mm, turning length: 350 mm, turning diameter: 200 mm, travel distance X-axis: 240 mm, rapid traverse X-axis: 12 m/min, Hembrug Mill-Turn Machine Model: Slantbed Mikroturn 100 CNC Siemens 840D Control Pedpowcfgbjfx Abyogl Approximate Actual Run Time Hours: 1,000 Hydeostatic Spindle Hydrostatic Ways Scale Feedback Suspended Granite Bed Garnite Spindle Housing Coolant Pump Coolant Circulation Pump Pneumatic Bearing Purge Hydraulic Temperature Control Coolant Temperature Control Return Oil Pump and Reservoir for Remote Location of Hydraulic / Cooling Unit. Options & Additional Purchased Features: Tailstock Vacuum Pump for Vacuum Chucking Programable Controlled Spray Mist C-Axis Milling / Drilling Renishaw Tool Touch Probe Non-Contact Tool Incoming Air Dryer / Filter Thousands of Dollars of Brand New Tooling: Live Center Tailstock Taper Adapter 8” Micro-Centric Pneumatic Chuck 3 Sauter Straight Live tooling heads 2 Sauter 90 degree Live tooling heads 1 Special VDI offset Tooling holder 16 VDI Tool Holders for Turning, boring, and on center drilling. Tool Pick-up Video System Extra Siemens Control Pannel Complete Set of Manuals Machine Upgrades I added at additional cost. New Digital Hard Drive New Backup Hard Drive with software already loaded, plug and play ready, no downtime. New Z-Axis Heidenhain Scale Rewound Hydraulic Pump Motor, factory motor was running too hot for my liking. Replaced Operator Panel, back light on monitor went out, have the original, back light needs replacing. 50 Foot Extended Wiring Harness For Remote Location of Hydraulic / Cooling Unit.

Condition: excellent (used), Year of construction: 2000, INDEX ABC CNC Lathe. Mfd. 2000 Control: Siemens 840C Capacity 65mm Ran oil Still in production, running nylon With 12-ft Bar Feed (pictured) Chip Conveyor Comes the a good amount of tooling Control Type: Siemens SINUMERIK 840C Spindle Speed (max.): 6,000 RPM Power Requirements (V/Hz/PH): 400/60/3 Main Spindle Speed (max.): 6,000 RPM Bar Capacity: 65 mm Power: 20 kW (at 100%) Power: 27 kW (at 40%) Synchronous Spindle Speed (max.): 4,500 RPM Pjdpfxjw Td U Re Abyegl Power (max.): 4.2 kW Capacity Tool Carrier 1: 8 (7 + synchronous spindle) Tool Carrier 2: 6 Dimensions Bar Feeder: L 150" x W 27" x H 52" Turning Center: L 80" x W 48" x H 65" Power Enclosure: L 52" x W 18" x H 70" Chip Conveyor: L 88" x W 48" x H 35"

Condition: good (used), Year of construction: 2015, machine/vehicle number: 190630, turning length: 150 mm, turning diameter: 200 mm, spindle bore: 42 mm, spindle speed (max.): 4,500 rpm, spindle speed (min.): 50 rpm, travel distance X-axis: 150 mm, travel distance Z-axis: 155 mm, rapid traverse X-axis: 24 m/min, rapid traverse Z-axis: 24 m/min, turning diameter over bed slide: 220 mm, overall weight: 5,000 kg, spindle nose: 140 Flat, bar diameter (max.): 51 mm, power: 0.015 kW (0.02 HP), The innovative front-facing spindle of the 2SP-150H helps create an automation-friendly lathe for small parts production. By moving the spindle off the side and incorporating the Okuma Gantry Loader (OGL) into the production line, parts can be loaded and unloaded automatically. An extremely compact footprint improves floor space utilization, while the popular dual spindle option significantly reduces cycle time. Equipped with: Podpsrtrlzefx Abyogl Okuma OSP-P300L CNC Control 8" 3-Jaw Chuck Expanding Mandrel Turret Tooling Gantry Loader Pendant Controller Chip Auger Stack Light

Condition: good (used), Year of construction: 2013, control Siemens 840D sl turning length 2000 mm turning speeds max. 3100 1/min Torque 1200 Nm diameter of quill 140 mm quill power 5-30 kN total power requirement 125 kW weight of the machine ca. 20 t The machine can still be inspected under power at the seller's factory. It is in good condition, the precision of the turning operation is very good. The milling drive is not functional. An offer from Niles for the repair of the milling drive is available on request. Hydraulic steady rest included. Technical details: Turning length 2000 mm Control Siemens 840 D sl Main spindle: Speed max.3800 1/min Main spindle: Torque max. 1200 Nm Pinole diameter 140 mm Center point MK6 Quill force 5 - 30 kN Feed speed Z-axis mm/min Pgjdpfjv Nw Npox Abyol Rapid traverse Z-axis 40 m/min Feed rate X-axis - mm/min Rapid traverse X-axis 25 m/min Total power requirement 125 kW Machine weight approx. 20 tons

Condition: used, Year of construction: 2007, turning length 2500 mm control Sinumerik 840 D spindle head A 11 tool numbers 48 swing diameter over bed slide 750 mm swing over bed 780 mm c-axis 0,1-30 1/min diameter of quill 160 mm taper bore MK 5 tool length - max. 500 mm weight of tools max. 15 kg weight of the machine ca. 27 t dimensions of the machine ca. 8,4 x 4,0 x 2,5 m Technical details: Nominal turning length: 2,500 mm Swing diameter over bed slide: 750 mm Psdpfswwaruox Abysgl Swing diameter over bed: 780 mm Working height: 1,300 mm Spindle head to DIN 55026: A 11 Bore through: 123 mm Diameter in front bearing: 200 mm Oriented spindle stop: 0-359 degrees Drive power at 100/60 % duty cycle: 37/45 kW Total speed range: 10-2,500 1/min Number of speed ranges: 2 Speed range I: 10-775 1/min Speed range II: 20-2,500 1/min Max. torque at 60 % duty cycle: 2,500 rpm. Torque at 60 % ED: 2,083 Nm (up to 186 rpm)

Condition: excellent (used), Year of construction: 2018, operating hours: 2,300 h, functionality: fully functional, machine/vehicle number: KC1811242, turning diameter over cross slide: 325 mm, turning length: 1,285 mm, turning diameter: 570 mm, spindle bore: 80 mm, spindle speed (max.): 1,600 rpm, spindle speed (min.): 40 rpm, travel distance X-axis: 310 mm, travel distance Z-axis: 1,285 mm, spindle motor power: 7,500 W, rapid traverse X-axis: 6 m/min, rapid traverse Z-axis: 10 m/min, rotational speed (min.): 1,600 rpm, rotational speed (max.): 40 rpm, total height: 1,700 mm, total length: 3,070 mm, total width: 1,300 mm, quill travel distance: 150 mm, quill diameter: 75 mm, quill stroke: 150 mm, swing diameter over cross slide: 325 mm, turning diameter over bed slide: 570 mm, turning diameter over top slide: 325 mm, type of input current: three-phase, overall weight: 2,560 kg, swing diameter over bed slide: 570 mm, bar passage: 75 mm, chuck outer diameter: 300 mm, swing diameter over top slide: 325 mm, center height: 280 mm, bar diameter (max.): 75 mm, mount diameter: 32 mm, Equipment: documentation/manual, 2018 Dugard Lunan 570MF CNC Lathe – Excellent Condition 📍 Location: Ireland 🔧 Machine Type: CNC Lathe 🛠️ Manufacturer: Dugard 📅 Year of Manufacture: 2018 ⏱️ Machine Hours: Only 2,300 ✅ Condition: Very Good / Fully Functional 💡 Why Choose This Machine? The Dugard Lunan 570MF is a solid, well-built CNC lathe designed for medium to heavy-duty turning applications. With Siemens 828D control, only 2300 working hours, and a complete set of chucks, steadies, and accessories, this machine is ideal for general precision engineering, subcontractors, and educational/training use. It’s well maintained, ready to work, and represents excellent value. Buy a 2018 Dugard Lunan 570MF CNC Lathe in excellent condition. Featuring 570mm swing, Ø80mm spindle bore, 400mm chuck, and 7.5kW power. Available now from Used Machine Tools Ireland. International delivery available. 🧰 Machine Includes: Siemens 828D CNC Control System 320 mm 3-Jaw Chuck 400 mm 4-Jaw Chuck Travelling Steady Fixed Steady Coolant Equipment Tailstock Operator Manuals Selection of Tool Holders & Chuck Jaws 🔹 Technical Specifications Max Swing Diameter Over Bed: Ø570 mm Max Swing Diameter Over Slide: 325 mm Distance Between Centres: 1500 mm Span of X/Z Axis Guide Rails: 420 mm Max Turning Length: 1285 mm Center Height: • To Bed: 280 mm • To Ground: 1170 mm Spindle Bore Diameter: Ø80 mm Bar Capacity: Ø75 mm Spindle End Type: D8 Chuck Size: Ø300 mm or Ø400 mm Spindle Speeds: 3-Speed Manual Ranges: • 40–150 rpm • 130–470 rpm • 450–1600 rpm Taper of Spindle: Metric 90, 1:20 Turret: 4-Position Electric Turret Tool Size: 32 × 32 mm Tailstock: • Quill Diameter: Ø75 mm • Stroke: 150 mm • Taper: MT5 End Bracket: Hand-operated type Screw Model: • X-Axis: FFZD2504-3-P3 • Z-Axis: FFZD4008-5-P3 Rapid Traverse (X/Z): 6 / 10 m/min X-Axis Stroke: 310 mm Minimum Set Unit: 0.001 mm Main Motor Power: 7.5 kW Power of Main Supply: 12.5 kW Net Weight: 2560 kg Dimensions (L×W×H): 3070×1300×1700 mm 💡 Features & Benefits: Robust and versatile CNC lathe ideal for medium to heavy-duty turning High-torque spindle and large bore suitable for tough materials Reliable FANUC control system with user-friendly interface Well maintained and fully serviced – ready to run Ideal for sub-contract machine shops, tool rooms, and general precision engineering 🚚 Delivery Options Available We offer nationwide & International delivery Dugard Lunan 570MF CNC Lathe for sale Used Dugard CNC lathe Ireland 2018 Dugard Lunan CNC lathe CNC lathe Ø570mm swing Large bore CNC lathe used Psdpfewv Sx Rsx Abysgl Heavy-duty CNC turning lathe CNC lathe with 80mm spindle bore 4-position turret CNC lathe CNC lathe with tailstock and 12.5kW power supply CNC lathe for shaft turning manual turret CNC lathe industrial CNC lathe for metal turning Notes: *Specifications are given in good faith but not guaranteed*

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 918106, turning diameter over cross slide: 500 mm, turning length: 560 mm, turning diameter: 420 mm, spindle bore: 65 mm, spindle speed (max.): 4,000 rpm, spindle speed (min.): 40 rpm, travel distance X-axis: 230 mm, travel distance Y-axis: 110 mm, travel distance Z-axis: 600 mm, spindle motor power: 15,000 W, rapid traverse X-axis: 20 m/min, rapid traverse Z-axis: 20 m/min, rotational speed (min.): 40 rpm, rotational speed (max.): 4,000 rpm, total height: 2,260 mm, total length: 3,430 mm, total width: 1,810 mm, feed length X-axis: 230 mm, feed length Y-axis: 110 mm, feed length Z-axis: 600 mm, swing diameter over cross slide: 500 mm, feed rate X-axis: 20 m/min, feed rate Z-axis: 20 m/min, turning diameter over bed slide: 650 mm, workpiece weight (max.): 230 kg, turning diameter over top slide: 500 mm, type of input current: three-phase, torque: 287 Nm, overall weight: 5,800 kg, swing diameter over bed slide: 650 mm, bar passage: 65 mm, chuck outer diameter: 250 mm, center width: 560 mm, spindle nose: A2-8, bar diameter (max.): 65 mm, Equipment: rotational speed infinitely variable, 🔹 FOR SALE: 2006 Goodway GS-260MYS CNC Lathe – Very Good Condition – Ireland 🔹 Make: Goodway Model: GS-260MYS Year: 2006 Control: Fanuc Series 18i-TB Machine Type: CNC Turning Centre with Sub Spindle, Driven Tools, Y Axis & C Axis Condition: Very Good Location: Ireland Availability: Immediately available 📌 Description: For sale is a 2006 Goodway GS-260MYS CNC Lathe, a powerful multi-axis CNC turning centre equipped with live tooling, Y-axis milling, and a sub spindle. This robust machine is ideal for complex turning and milling operations in a single setup — perfect for modern precision engineering environments. Maintained in very good working condition, it includes a selection of manual and driven tool holders, 2 chucks, and a swarf conveyor. 🔧 Technical Specifications: Main Spindle: Chuck Size: 10" (250 mm) Bar Capacity: 65 mm Spindle Nose: A2-8 Max Swing: 650 mm Swing Over Saddle: 500 mm Max Turning Diameter: 420 mm Standard Turning Diameter: 205 mm Max Turning Length: 560 mm Max Part Weight: 230 kg Hole Through Drawtube: 65.5 mm Hole Through Spindle: 76 mm Spindle Drive: Direct Belt Drive Spindle Speeds: 40 – 4,000 rpm Continuous Spindle Motor: 11 kW 30-Min Spindle Motor: 15 kW Spindle Torque (Cont.): 210 Nm Spindle Torque (30 Min): 287 Nm Axes: X Axis Travel: 230 mm Z Axis Travel: 600 mm Y Axis Travel: ±55 mm X/Z Rapid Traverse: 20 m/min Z2 Axis Travel (Sub Spindle): 600 mm Z2 Rapid Traverse: 24 m/min Tooling: Turret Stations: 12 OD Tool Shank Size: 25 mm ID Tool Shank Size: Up to 40 mm Live Tooling Stations: 12 Live Tool Drive Motor: 4.5 kW Live Tool Torque: 22 Nm Sub Spindle: Chuck Size: 6" Spindle Nose: A2-5 Hole Through Spindle: 46 mm Continuous Motor Output: 5.5 kW 30-Min Motor Output: 7.5 kW Spindle Speed Range: 60 – 6,000 rpm Drive: Built-in Motor Construction: Slideways: Hardened & Ground Box Ways Machine Dimensions: 3430 x 1810 x 2260 mm Machine Weight: 5,800 kg 🧰 Included with the Machine: Selection of Driven Tool Holders Selection of Manual Tool Holders 2x Chucks Swarf Conveyor Note: Tools shown in photos are not included – only the holders are provided. Podpfjwtpdfex Abyogl 🛠 Suitable For: Precision turning, mill-turn applications, production of complex components in aerospace, medical, automotive, and general engineering sectors. Used CNC Lathe Ireland, Goodway GS-260MYS for Sale, CNC Lathe with Y Axis and Sub Spindle, Live Tool CNC Turning Centre, CNC Turning Machine Europe, Fanuc CNC Lathe for Sale, Multi-Axis Lathe Machine Used Notes: *Specifications are given in good faith but not guaranteed*

Condition: excellent (used), Year of construction: 2003, functionality: fully functional, machine/vehicle number: S2T238, turning diameter over cross slide: 210 mm, turning length: 1,000 mm, turning diameter: 330 mm, spindle bore: 42 mm, spindle speed (max.): 3,500 rpm, spindle motor power: 7,500 W, rapid traverse X-axis: 3 m/min, rapid traverse Z-axis: 6 m/min, feed length X-axis: 180 mm, feed length Z-axis: 1,000 mm, quill travel distance: 110 mm, quill diameter: 42 mm, quill stroke: 110 mm, swing diameter over cross slide: 210 mm, turning diameter over bed slide: 330 mm, type of input current: three-phase, swing diameter over bed slide: 330 mm, bar passage: 42 mm, spindle nose: D1-4, center height: 167 mm, bar diameter (max.): 42 mm, travel distance cross slide: 180 mm, Equipment: documentation/manual, rotational speed infinitely variable, 🔹 For Sale: 2003 Harrison Alpha 1330S CNC / Manual Lathe – 2-Axis, Fanuc Control 🔹 Make: Harrison Model: Alpha 1330S Year: 2003 Type: CNC / Manual Combination Lathe Control: Fanuc Series 21i-MB Condition: Very Good Location: Ireland 📌 Machine Overview: The Harrison Alpha 1330S is a versatile 2-axis CNC/Manual lathe, offering the perfect balance between traditional manual turning and modern CNC precision. Built in the UK and controlled via a Fanuc 21i-MB, this machine is ideal for small batch production, toolrooms, maintenance departments, and educational use. With a compact footprint and generous turning capacity, it’s a reliable and easy-to-use solution for both skilled machinists and CNC programmers. Whether you're running single parts manually or repeat jobs with CNC automation, the Alpha 1330S delivers flexibility and accuracy. ✅ Key Features: Combination CNC/manual functionality Compact, easy-to-install design Fanuc 21i-MB control – intuitive and reliable Dual spindle speed ranges for versatile applications Suitable for one-offs, training, and batch work Quickchange tool post system for rapid setups Comprehensive manuals included 🔧 Technical Specifications: Axis Configuration: 2-Axis Max Turning Diameter: 330 mm Max Turning Length: 1,000 mm Swing Over Bed: 330 mm Swing Over Cross Slide: 210 mm Height of Centres: 167 mm Spindle Bore: 42 mm Spindle Nose: D1-4 Spindle Taper: MT3 Spindle Speed Ranges: Range 1: 0 – 2,000 rpm Range 2: 0 – 3,500 rpm Main Spindle Motor: 7.5 kW Feedrate (Manual): 0.03 to 0.6 mm/rev Feedrate (CNC): Up to 5,750 mm/min Rapid Traverse: X Axis: 3,000 mm/min Z Axis: 6,000 mm/min Cross Slide Travel: 180 mm Tailstock Quill Diameter: 42 mm Tailstock Quill Travel: 110 mm Tailstock Taper: MT3 Electrical Requirements: 415V / 3-phase / 50Hz Power Supply Needed: 19 kVA 🧰 Included Accessories: Quickchange Tool Post & Tool Holders Set of Manuals 📈 Applications: General Turning Prototyping Educational Training Repair & Maintenance Work Toolroom Operations Short Batch CNC Machining Harrison Alpha 1330S for Sale CNC Manual Lathe with Fanuc Control Pedpfx Aswtq T Isbyegl Used CNC Lathe Ireland 2-Axis CNC Lathe for Sale Combination CNC and Manual Lathe Harrison Alpha Lathe with Fanuc 21i-MB Precision CNC Lathe for Small Batch Work Used Harrison Alpha 1330S UK / Ireland Educational CNC Lathe with Manual Option Compact CNC Lathe for Toolroom Used CNC Lathe for Sale in Ireland CNC Machinery Dublin / Cork / Galway Buy Harrison Alpha Lathe Europe Notes: *Specifications are given in good faith but not guaranteed*

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, turning diameter over cross slide: 755 mm, turning length: 510 mm, turning diameter: 366 mm, spindle bore: 73 mm, spindle speed (max.): 5,000 rpm, travel distance X-axis: 260 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 590 mm, spindle motor power: 15,000 W, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 10 m/min, rapid traverse Z-axis: 30 m/min, rotational speed (max.): 6,000 rpm, total height: 2,120 mm, total length: 5,705 mm, total width: 1,922 mm, feed length X-axis: 260 mm, feed length Y-axis: 100 mm, feed length Z-axis: 590 mm, quill travel distance: 564 mm, quill diameter: 80 mm, swing diameter over cross slide: 755 mm, turning diameter over bed slide: 923 mm, type of input current: three-phase, overall weight: 5,700 kg, swing diameter over bed slide: 923 mm, bar passage: 65 mm, bar diameter (max.): 65 mm, Equipment: documentation/manual, rotational speed infinitely variable, 2009 Mori Seiki NL2000Y/500 CNC Lathe in very good condition. Plastics-only medical device use. Y-Axis, live tooling, tailstock, workpiece unloader. Available now in Ireland. Machine Type: CNC Turning Centre with Y-Axis & Live Tooling Manufacturer: Mori Seiki (DMG MORI) Model: NL2000Y/500 Year: 2009 Location: Ireland Availability: Immediate Machine Overview We are pleased to offer this 2009 Mori Seiki NL2000Y/500 CNC Lathe in very good condition, available through Used Machine Tools Ireland. This machine was used only for dry machining of plastics by a medical device manufacturer, meaning: No heavy metal cutting No coolant contamination Exceptionally low mechanical wear The Mori Seiki NL Series is globally recognised as a benchmark for high-precision CNC turning, and the NL2000Y/500 is especially sought after due to its Y-axis capability, live tooling, and BMT (Built-in Motor Turret) design. Key Features & Benefits Y-Axis CNC Lathe – complex milling and turning in one setup Podjyhqkzopfx Abyegl BMT Turret Technology – superior rigidity, accuracy, and thermal stability Live Tooling up to 6,000 RPM – ideal for milling, drilling, and tapping Medical / Plastics-Only Use – extremely clean operating history Tailstock & Workpiece Unloader – ideal for automated production MSX-850 III Control – powerful, reliable Mori Seiki control system Technical Specifications – Mori Seiki NL2000Y/500 Capacity Distance Between Centres: 500 mm Chuck : Collet Chuck Max Turning Diameter: 366 mm Standard Turning Diameter: 275 mm Max Turning Length: 510 mm Bar Capacity: 65 mm Swing Over Bed: 923.8 mm Swing Over Cross Slide: 755 mm Axis Travel X-Axis: 260 mm Z-Axis: 590 mm Y-Axis: ±50 mm (100 mm total) Spindle Max Spindle Speed: 5,000 RPM Spindle Nose: JIS A2-6 Through-Spindle Bore: 73 mm Spindle Motor: 15 / 15 / 11 kW Turret & Tooling Turret Type: BMT (Built-in Motor Turret) Tool Stations: 16 Max Live Tool Speed: 6,000 RPM Live Tool Torque: 29 Nm Turret Index Time: 0.2 seconds Feed Rates Rapid Traverse (X / Z): 30,000 mm/min Rapid Traverse (Y): 10,000 mm/min Tailstock Tailstock Travel: 564 mm Spindle Diameter: 80 mm Taper: MT4 Live Centre Automation Workpiece Unloader: Yes Max Workpiece Diameter: 80 mm Max Workpiece Length: 200 mm Max Workpiece Weight: 3 kg Electrical & Dimensions Power Requirement: 31.5 kVA Machine Dimensions (L × W × H): 2705 × 1922 × 2120 mm Machine Weight: 5,700 kg Included with Machine ✔ Selection of axial & radial driven toolholders ✔ Selection of static toolholders ✔ Extraction unit for plastic machining Additional Notes Used exclusively for dry plastic machining No coolant system fitted, however the machine is prepared for coolant installation and can be added at cost Specifications provided in good faith but not guaranteed Ideal Applications Medical device manufacturing Plastic & polymer machining Precision CNC turning & milling Aerospace, electronics & high-tolerance components This Mori Seiki NL2000Y/500 CNC Lathe represents a rare opportunity to acquire a premium Japanese turning centre with an exceptionally clean usage history.

Condition: good (used), Year of construction: 2011, 575mm centre height, 3000mm between centres, maximum cutting diameter 950mm, FANUC 21iTB, 230mm spindle bore, 22/26kW motor power, 7-400 rpm spindle speed, Pgsdey U Numepfx Abyol 12 station turret, steady, 4 jaw chuck, swarf conveyor

Condition: excellent (used), Swift L6500 x 3000mm CNC Roll Lathe Fanuc 18iTB Control, 700mm Swing Pedpfx Ajw U Ul Asbyogl 3000mm Between Centres, 600mm 3 Jaw Chuck, Tailstock, Conveyor

Condition: excellent (used), XYZ SLX 555 x 3M CNC Lathe (2016) Podpex Hp I Rjfx Abysgl Stock Number 2851 Protrak SLX CNC Swing over bed 560mm Swing in gap 935mm Swing over cross slides 350mm Distance between centres 3000mm Spindle bore 104mm Additional Features Protrack SLX Control Drilling Attachment 4 Way Toolpost 3 Jaw Chuck 3 Point Steady

Condition: good (used), Binns & Berry Versa Turn 7 x 7000mm CNC Lathe Serial Number 300013 Year 2011 800mm 4 Jaw, 1000mm Swing Over Bed, 7000mm Between Centres, 104mm Spindle Bore Pjdpfew U Ulcex Abyogl Spindle Speeds 1.5 – 1200 RPM, Main Motor 37kw / 50hp Tailstock, Steadies, 12 station turret, Fanuc OiTD Control Swarf Conveyor

Condition: excellent (used), Tuscan LC38 x 3000mm CNC Lathe Pgedevtw Imjpfx Abyjl Swing Over Bed 970mm Swing Over Cross Slide 420mm Centre Height 490mm Distance Between Centres 3000mm 12 Station Duplimatic Turret Tailstock Boring Bat Attachment Boring Bar 2 x 3 Point Fixed Steady 1 x Travelling Steady Fanuc OiTC Control C Axis & Driven Tools Serial Number LC223806086 Year 2010 /10

Condition: excellent (used), Tacchi HD/1450 – 725 x 4000mm CNC Lathe (2012) Serial Number: 7264 Year: 2012 Control: Fanuc OiTD CNC Condition: Used – good working order Technical Specifications: Centre height: 725mm Swing over bed: 1450mm Swing over cross slide: 1000mm Distance between centres: 4000mm Main drive motor: 60 kW Maximum weight between centres (unsupported): 15,000 kg Spindle speed range: 1.9 – 560 rpm Features & Equipment: 2 x 3-point steady rests Handwheel Swarf conveyor 4-position hydraulic toolpost 4-jaw chuck Pedpfxexc In So Abyjgl Fanuc OiTD CNC control

Condition: excellent (used), Tacchi HD/1450 X 4M Large Spindle Bore (515mm) Year 2002 Siemens CNC Control Psdpfx Ajxg Ivdebyegl Swing over bed 1450mm Swing over saddle 1000mm Hollow spindle 515mm Chucks front and rear of Headstock Speed range 1.5 – 450 rpm 15,000kg weight between centres Baruffaldi 4 way Auto Toolpost 2 x 3 point steadies

Condition: used, Year of construction: 2009, turning diameter 465 mm turning length 1050 mm control Heidenhain Pgodpfx Aszaf Ewobysl x-axis 300 mm weight of the machine ca. 7600 kg

Condition: good (used), Year of construction: 2008, Used CNC turning lathe from MAS Type: MT 70 CNC Max. turning length: 3000 mm Center height: 450 mm Heidenhain control system Spindle bore: 128 mm Pgedpjy U I Dgjfx Abyol Includes: tailstock Includes: tool changer Excludes: chip extraction system

Condition: good (used), Year of construction: 1998, Used CNC turning lathe by Okuma Type: LCS 15 Includes tool holder Turning length: 280 mm Turning diameter: 270 mm Tool changer Year of manufacture: 1998 Pgodpfxsy U Iz Se Abyol Excluding bar feeder and chip extraction system.

Condition: like new (used), Year of construction: 2021, operating hours: 1,200 h, functionality: fully functional, turning length: 2,000 mm, turning diameter: 1,100 mm, power: 46 kW (62.54 HP), distance between centers: 2,000 mm, load hours: 1,200 h, Equipment: rotational speed infinitely variable, A DMT CD1100 lathe with Heidenhain control and only 1,200 operating hours is available. The working area offers a swing diameter of approx. 1,100 mm over the bed and approx. 800 mm over the cross-slide. The tool holder is a Multifix D1. The distance between centers is 2,000 mm. Pgsdjxlza Hopfx Abyol The main spindle drive is a motor with 46 kW output at 60% duty cycle and two gearbox stages. Tailstock: - Quill diameter: 125 mm - Taper: 6 Morse taper Delivery: Collection by the buyer Payment: 100% via bank transfer immediately upon invoicing, prior to collection All information is non-binding. Subject to prior sale. The machine is sold without any guarantee or warranty claims and remains our property until full payment is received.

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, Technical details faceplate diameter 1800 mm swing diameter 2000 mm turning height 1270 / 1120 mm Control SIEMENS 840 D workpiece weight max. 5000 kg ram head dimension 250 x 250 mm table turning speeds 1 - 320 U/min cross rail - adjustment 400 mm ram head - cross travel (X) -2770 / +2275 mm ram head - vertical travel (Z) 1250 mm c-axis 360° (0,001°) deg milling drive 37 kW turning speed range - milling 10 - 3000 U/min power capacity - table 100 kW Torque 31784 Nm feed range (X/Z) 0,1 - 15000 mm/min weight of the machine ca. 55 t Additional information Used CNC vertical lathe for turning, drilling and milling First machine installation in the year 2011. The machine was meticulously maintained by the previous owner. It was sold due to a factory closure Max. workpiece diameter: 2040 mm Max. workpiece height: 1270 mm Ram stroke: 1250 mm Max. workpiece weight: 5000 kg (per pallet/chuck) Table speed range: 1.0 - 320 rpm Table drive motor: 100 kW Drilling and milling spindle: 37 kW Crossbar travel: 2 steps of 200 mm each Total electrical connection value: 218 kVA CNC control: Siemens 840 D Number of NC axes: 4 (X, Z, C, crossbar adjustment) Travels: Psdpfszaa T Nox Abysgl X-axis: -1650 to + 2165 mm Z-axis: 1250 mm Rapid traverse X- Z-axis: 15 m/min Number of tool magazine spaces: 80 spaces in the chain magazine, of which 60 x HSK 100 and 20 x Capto C6 Disc magazine 12-pos. for rotary holders and attachment heads Coolant system with filter and circulation unit Chip conveyor Oil-mist-extractor 1 pallet with jaws, diameter 1800 mm 1 hydraulic chuck with base jaws, diameter 1800 mm Various drilling and milling heads 2 measuring probes Several turning tool holders Special feature: Pallet changer with two stations, equipped with a face plate Ø1800 mm and a six-jaw lever compensation chuck with mechanical centrifugal force compensation Ø1800 mm. Note: The machine is in a pit. Condition description: The cross roller bearing on the Carnaghi was replaced about half a year ago. The Siemens components in the control cabinet were also completely replaced at the end of 2023. The machine also has a measuring probe for tool measurement and an external Renishaw measuring probe for workpiece measurement. As a special feature, the machine also has a measuring probe installed on the Z-axis (Z1-axis). This brings an advantage in terms of accuracy and time, as the tool does not have to be put down for measuring. However, it is currently shut down and should be overhauled when it is put back into operation. The machine also has a Rotomors six-jaw lever compensating chuck with centrifugal force compensation, which was completely overhauled in 2020/21.

Condition: like new (used), Year of construction: 2017, operating hours: 515 h, functionality: fully functional, turning diameter over cross slide: 350 mm, turning length: 650 mm, turning diameter: 350 mm, travel distance X-axis: 255 mm, travel distance Z-axis: 680 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, rotational speed (max.): 4,500 rpm, total height: 1,740 mm, total length: 2,610 mm, total width: 2,260 mm, torque: 240 Nm, overall weight: 3,400 kg, This machine is still in operation in a training workshop and is in like-new condition. Spindle hours: 564 Extensive accessories: Clamping devices, jaws, driven and fixed tool holders, Psdpezaaq Iofx Abysgl as shown in the images in the advertisement. CNC universal lathe NEF 400 V3 3D control Siemens SL Operate CELOS Internal clamping device 3-jaw chuck BBD210-66 Set of soft top jaws, 3 pieces Coolant spray gun Main spindle reduction sleeve Design variant "BLACK" Hydraulic unit Foot switch for tailstock operation Technology cycle, alternating speed Documentation in German NETSERVICE (CELOS) SERVICE AGENT (CELOS) MESSENGER (CELOS) Programming/training software Sinutrain oper. for 6 participants DMG MORI training box for turning CNC control: 👉 Siemens SINUMERIK 840D sl 👉 Siemens SINUMERIK 840D sl User interface: 👉 CELOS (DMG MORI) Programming: 👉 ShopTurn (dialog programming) Under "Documents" you will find technical data in PDF format, a brochure for the control system, and other PDFs about transport.

Condition: good (used), Year of construction: 1990, Control system: Siemens 840-C Faceplate diameter: 1800 mm Swinging diameter: 2000 mm Maximum turning height: 1100 mm (below tool) Table speed: 130 RPM Workpiece weight: 8000 kg Tool changer: 12 positions Pgjdpfx Abszadagjyjl

Condition: good (used), Year of construction: 2007, functionality: fully functional, Control: SIEMENS 840D PL ManualTurn turning diameter: 1.140 mm turning lenght: 4.200 mm turning diameter over slide: 800 mm faceplate diameter max.: 1.000 mm Support Length of the bed slide: 1.000 mm Travel of the cross slide: 650 mm Width of the cross slide: 425 mm bed width: 710 mm Pgjdpfx Ajzacdkobyjl Main Spindle spindle bore: 120 mm spindle diameter in front bearing: 190 mm Accessories 1 piece fix steady rest 10 pieces Multifix quick-change steel holder Typ D The machine has been general overhauled in 2007.

Condition: used, Year of construction: 2006, Turning diameter: 650 mm Turning length: 1,500 mm Total power requirement: 33 kW Center distance: 1,500 mm Swing diameter over bed: 650 mm Swing diameter in recess: 670 Turning diameter: 650 mm Turning length: 1,500 mm Total power requirement: 33 kW Center distance: 1,500 mm Swing diameter over bed: 650 mm Swing diameter in recess: 670 mm Swing diameter over face slide: 260 mm Face slide travel: 380 mm Main drive Drive power AC motor - 40/60/100% duty cycle: 33/27/22 kW Spindle box Spindle bore diameter: 106 mm Spindle diameter in front bearing: 140 mm Speed range (V constant): 1 - 2,000 rpm Cross slide Feed range, face: 0.001 - 1,000 mm/rev Feed range, face, optional up to: 5,000 mm/rev Feed range, longitudinal and thread pitch: 0.001 - 2,000 mm/rev Feed range longitudinal and thread pitch, optional up to: 13,000 mm/rev Feed force flat: 9,000 N Feed force longitudinal: 12,000 N Pgjdpfxjzacb Ae Abysl Automatic tool turret Number of tool stations: 12 With tool drive for 6 stations Tool holder system (DIN69880) VDI40 Equipment SIMENS SINUMERIK 840D sl (Shop Turn with manual functions) COMBI control station C-axis with drilling, milling, and engraving cycles Residual material detection and machining – during roughing and contour pockets MULTIFIX C forne setup Three-jaw chuck SMW AUTOBLOK: HI-GRIP HGF260-81-3 Oil emulsion mist filter for work area extraction: MAHLE LTA600
