Used Biesse Drilling Grooving Machine With Inserting for sale (74,454)

Condition: used, Technical details: Ksdpju N E Evefx Ag Aedu material thickness: 1,0 mm material width: 17,0 mm internal diameter: 30,0 mm external diameter: 78,0 mm Spare part for bench drill BT 2 Patt spring - Return spring - Spiral spring Declaration of conformity according to ISO/IEC 17050-1 Acceptance test certificate 3.1 according to DIN EN 10204 available *

Condition: used, Radial Drilling Machine GSP type 49S22 Spindle: Ø 125 mm Cone: CM6 Spindle exit: 600 mm Spindle speed: from 17 to 1050 RPM Arm travel: 1800 mm Maxi height column travel: 1800 mm Column diameter: Ø 600 mm Total column height: 3000 mm Ksdpfx Asz Nxnhjg Aodu Spindle speed: 11 kW Drilling/tapping function Mechanical locking of the column Hydraulic locking of the trolley Auto descent Delivered with one cube Cube dimensions: L 800 x W 560 x H 600 mm Table size: L 3300 x W 1400 x H 320 mm Voltage: 380 V Weight: 12 T

Condition: used, Year of construction: 2011, working width: 1,300 mm, workpiece height (max.): 50 mm, working length: 3,000 mm, TECHNICAL DETAILS Working area, X-axis: 3,000 mm Working area, Y-axis: 1,300 mm Maximum workpiece thickness: 50 mm Number of working areas: 2 Number of controlled axes: 3 Drilling units Number of drilling units: 4 Drilling unit 1: Top Vertical drilling spindles: 51 Horizontal drilling spindles in X-direction: 4 Drilling unit 2: Top Vertical drilling spindles: 51 Horizontal drilling spindles in X-direction: 4 Drilling unit 3: Bottom Horizontal drilling spindles in Y-direction: 42 Drilling unit 4: Bottom Horizontal drilling spindles in Y-direction: 42 Milling units Number of milling units: 2 Milling unit 1: Top Controlled axes: 3 Motor power: 6.6 kW Milling unit 2: Top Controlled axes: 3 Motor power: 6.6 kW Sawing units Number of sawing units: 2 Sawing unit 1: Top Design: Fixed unit for grooving in X-direction Maximum tool diameter: 125 mm Sawing unit 2: Top Design: Fixed unit for grooving in X-direction Maximum tool diameter: 125 mm Ksdpfsz Ekggjx Ag Aedu EQUIPMENT Albatros machine programming software Collets for workpiece clamping The machine is sold and delivered in its actual and legal condition (“as is, where is”) based on photo documentation and technical/commercial documents of a descriptive nature. The buyer has the right to inspect the goods before collection and assumes responsibility for the installation, securing, and use of the machine at the destination. External reference: 5446

Condition: used, Year of construction: 1997, Technical details: bore capacity in steel (diameter): 32 mm x-travel: 750 mm y-travel: 520 mm drill capacity in cast iron: 45 mm revolution per minute: 90 - 4500 U/min feed steps: 6 bore spindle stroke: 250 mm boring spindle diameter: 30 mm drill spindle - Morse Taper: MK4 vertical adjustment of the arm: 520 mm throat max.: 1000 mm throat min.: 250 mm column diameter: 400 mm swivel range of the arm: 180 ° table clamping surface LxW: 1150 x 800 mm total power requirement: 3,5 KW weight of the machine ca.: 2000 kg dimension machine approx.LxWxH: 1,7 x 1,07 x 2,61 m Ksdpfxjzgwgfe Ag Aedu The KOVOSVIT VO 32 is a robust and versatile radial drilling machine designed for industrial applications. The machine is suitable for drilling, boring, countersinking, reaming, and tapping operations in steel, cast iron, and other materials. Thanks to its swiveling radial arm and large reach, even large and heavy workpieces can be machined conveniently without the need for complex repositioning. The machine features a massive cast-iron construction, a powerful main drive, and an automatic feed system. The drilling head can be moved along the radial arm, providing a large working area. Its solid design ensures high precision, reliability, and a long service life, even under continuous operation. Equipment: ·Including coolant pump ·1 × boring tool block (boring cube) ·1 × machine vise *

Condition: used, Technical details: bore capacity in steel (diameter): 16 mm throat: 190 mm bore stroke: 60 mm Distance spindle/table max.: 250 mm range of revolution per miute: 410 / 725 / 1100 / 1700 bei 4step U/min spindle taper MT: MK 2 table surface area: 155 x 155 mm vertical adjustment: Tisch/table = 180 mm table rotating: 360 ° base plate surface area: 175 x 175 mm distance spindle center to floor plate:: max. 360 mm column diameter: 70 mm machine weight ab.: 65 kg dimensions L x W x H: 0,6 x 0,3 x 0,85 m Drill sleeve equipped with drill chuck 1 - 16 mm table rotatable * Kedpfx Asu Id Dzjg Asdu

Condition: good (used), Year of construction: 1987, travel distance X-axis: 11,500 mm, travel distance Y-axis: 4,500 mm, travel distance Z-axis: 2,000 mm, feed length W-axis: 1,600 mm, x-travel 11,500 mm y-travel 4,500 mm w-axis 1,600 mm z-axis 2,000 mm Spindle diameter 200 mm Rotary table 3,000 x 4,000 mm Bed length of rotary table 4,600 mm Tool holder SK50 Workpiece weight on rotary table 80 t Total power requirement 83 kW Additional information Kode Aax Axepfx Ag Aedu incl. 15 plates

Condition: refurbished (used), Year of construction: 2017, BUCK TBFZ 3000 CNC incl. tools and clamping wedges The machine has been comprehensively overhauled and modernized. Conversion to Heidenhain iTNC530 including completely new control cabinet Travel: X-3000 mm, Y-1.500 mm, Z-1500 mm Z1: 500 mm A-axis: +/- 20° Depth of drilling in a single pass Z: 1.500 mm Drill depth by readjusting Z1: 2.000 mm Drilling performance with single-lip internal thread drilling tools: 3-40 mm diameter NC rotary table 360° B-axis: 2.500 x 2.300 mm Kdsdpez Ntr Isfx Ag Asu max. Tischladung: 25.000 kg Internal coolant supply (IKZ): 70/100 bar Spindle drive power at 60%: 20.5 kW Express travel X/Y/Z: 15.000 mm/min Spindle speed: 0-6,000 RPM Control: Heidenhain iTNC530 tool holder: SK50 Space requirements: approx. 8.5 m x 8.5 m x 3.5 m machine weight: approx. 24,000 kg max. table load: 25.000 kg

Condition: good (used), Friedrich Deckel FP 2 LB Tool Milling Machine The accessories are not included in the scope of delivery but can be purchased in another auction at this link. Lot of Milling Tools The universal milling machine Deckel FP 2 LB is characterized by its extremely stable base and is designed as a floor-standing machine. This means that the machine retains its precision even when machining heavy workpieces weighing up to 1000 kg. Another feature is the 45-degree inclined bed. After removing the universal table, this design allows for direct clamping and machining of V-engine blocks with a 90-degree cylinder angle, such as American V8 engines. Furthermore, the long travel of 800 mm is advantageous in this application. Technical data: Deckel Universal Milling Machine FP 2 LB Digital display: 3-axis digital display Heidenhain Travel X-axis: 800 mm Travel Y-axis: 300 mm Travel Z-axis: 400 mm Tool holder: SK 40 clamping thread S 20 x 2 Milling head type: Vertical milling head Kdsdpfegyw S Tsx Ag Aou Speed range: 40 - 2000 rpm Number of steps: 18 Table type: universal swivel/tilt table (± 45° / ± 15°) Table clamping surface: 1000 x 520 mm T-slot size: 16 mm Vise 160 mm Connected load: 9.5 kVA Weight: approx. 1900 kg Dimensions: approx. 1570 x 1675 x 1850 You can find more new and used items in our shop! International shipping costs available upon request!

Condition: used, machine/vehicle number: 007869, Max. panel width: 3200 mm Max. panel length: 800 mm No of Bottom Units: 5 Lateral horizontal groups: yes Ksdpfewimzyex Ag Aedu

Condition: excellent (used), Year of construction: 2001, functionality: fully functional, travel distance X-axis: 585 mm, travel distance Y-axis: 240 mm, travel distance Z-axis: 145 mm, spindle speed (max.): 2,340 rpm, spindle speed (min.): 32 rpm, spindle mount: MK 0, throat depth: 293 mm, quill diameter: 72 mm, quill stroke: 145 mm, total length: 1,340 mm, total height: 2,050 mm, table width: 225 mm, total width: 1,280 mm, table length: 800 mm, drilling capacity: 40 mm, spindle nose: ISO40, spindle diameter: 72 mm, nominal power: 3 kW (4.08 HP), Milling-/Drilling Machine, DRO, drilling capacity Ø 40 mm, motor 2,2/3,0 KW, table size 800x225 mm, spindle speed 32-3240 rpm stepless, ISO40, pneum. tollclamping el. tapping device, table stroke X/Y 585/240 mm, automatic spindle feed, coolant device, dimensions 1340x1280x2050 mm, weight ca. 780 kg Kedsz Rqfzopfx Ag Ajdu

Condition: used, Year of construction: 1997, Second-hand machine Year of manufacture: 1997 Features and technical specifications: - Number of drilling spindles: 21, spaced at 32 mm intervals - Drilling direction: Bottom & end face - Swivel range: 0–90 degrees via handwheel Kjdpfezn Ah Rsx Ag Aodu - Pneumatic workpiece clamps: 3 pcs. - Opening: Max. 100 mm in height and max. 640 mm in width - Motor: 1.5 kW - Extraction diameter: 120 mm - Includes a wide range of stops (see pictures) Availability: at short notice Storage location: 63934 Röllbach

Condition: used, Year of construction: 1957, Technical details: Kdsdpou Id D Usfx Ag Aeu bore capacity in steel (diameter): 20 mm throat: 220 mm bore stroke: 85 mm Distance spindle/table max.: max. 260 mm range of revolution per miute: Keilriemen U/min spindle taper MT: 2 table surface area: 220 x 280 mm base plate surface area: 225 x 280 mm distance spindle center to floor plate:: max. 380 mm total power requirement: 0,33 kW machine weight ab.: 125 kg dimensions L x W x H: 0,8 x 0,4 x 0,8 m The machine is currently in the technical department. Table rotatable 380 V with connection cable 2500mm *

Condition: excellent (used), Year of construction: 2014, Axle: 920 mm X-axis: 3000 mm Material thickness: 12 mm - 30 mm Feed rate: 20 m/min A-axis: 360 degrees Minimum dimensions: Plate: x = 300 mm Y = 120 mm z = 12 mm The machine is equipped with a 4-position drill chuck and a saw blade. Maximum and minimum hole diameters that can be drilled: 3 - 35 mm The saw blade runs in the X direction. Max. cutting depth with saw blade: 10 mm Kdsdpfxefmdcqs Ag Aju Motor: 0.75 HP, 400 volts Required extraction capacity: 2300 m3/h Location: available at warehouse 54634 Bitburg - immediately available -

Condition: used, Donau DR52 Drilling capacity in steel (diameter) 52 mm Arm length 1140 mm Workpiece height max. 830 mm Drilling capacity in cast iron 60 mm Taper MK 5 Table size 1100 x 620 mm Drilling spindle stroke 225 mm Kdedpfxjz D U Tzs Ag Aeu Spindle speed range 28 - 1400 rpm Feed rate 0.1 - 0.5 mm/rev Total power consumption 10.0 kW Machine weight approx. 3.5 t Machine dimensions approx. 2.4 x 1.3 x 2.61 m

Condition: used, Year of construction: 1989, Technical details: bore capacity in steel (diameter): 28 mm throat: 285 mm bore stroke: 165 mm drill capacity in cast iron: Ø 35 mm spindle taper MT: MK 3 spindle speed:: 65 - 1.750 / 4x steples U/min feed: 0,1; 0,2; 0,3 manuell/automatisch mm/U Distance spindle/table max.: 80 - 680 mm table clamping surface:: 500 x 370 mm table rotating: 360 ° drill table adjustment: 600 vertical mm column diameter: Ø 130 mm total power requirement: 7,5 kW weight of the machine ca.: 273 kg dimension machine xH: 0,9 x 0,6 x 1,9 m The machine can cut threads, change of direction left/right selectable via foot switch and/or depth stop Table can be swiveled and adjusted in height. Kdedsu Idkzjpfx Ag Aou *

Condition: used, Quick-change drill chuck with inserts for holding drilling, reaming, countersinking, and threading tools. Tool holder - quick-change holder - quick-change chuck Type SF 46 MK4 presumably a West German product similar to BILZ / MAYSSO Tool holder: MK4 - only suitable for vertical use (sleeve is locked by its own weight) - suitable for clockwise and counterclockwise rotation Insert sleeve diameter: 46 mm 3 pieces of insert sleeve MK2, length = 105 mm 3 pieces of insert sleeve MK3, length = 109 and 122 mm 3 pieces of insert sleeve MK4, length = 135 mm - Quick-change system for drilling and radial drilling machines as well as CNC drilling machines - various operations can be performed with very quick tool changes in a single workpiece setup - with dual ball clamping system for secure torque transmission and play-free seating of the inserts in the chuck - Not suitable for radial loads, e.g., milling, and tensile loads, e.g., back-countersinking. Weight: 14 kg Kodpfez It Rmex Ag Asdu good condition The inserts can be quickly changed without any auxiliary tools and are automatically locked when inserted into the chuck. The inserts are unlocked by axially shifting the switching sleeve. The tool change can be performed with the spindle both stationary and rotating. Short insertion and retraction distances of the inserts allow for tool changes in seconds. The quick-change system can be used vertically for both clockwise and counterclockwise rotation.

Condition: used, Technical details: bore capacity in steel (diameter): 25 mm throat: 310 - 315 mm bore stroke: 200 mm spindle taper MT: MK4 spindle speed:: 63 - 1000 U/min Distance spindle/table max.: 670 mm table clamping surface:: 640 x 540 mm Kdjdpjzfiy Ujfx Ag Aeu table rotating: 360 ° current- max.: 7 A total power requirement: 3 kW weight of the machine ca.: 700 kg dimension machine xH: 0,9 × 0,6 × 2,46 m

Condition: used, Empty weight: 4.200 kg - Documentation available: Yes - CE certificate present: No - Control: Conventional - Motor power: 2.0kW - Transport weight [kg]: 4200kg Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Kodpfx Agewnifrj Aedu Lukas van Rossum

Condition: used, Technical details: number of spindles: 1000 bore capacity in steel (diameter): 32 mm bore stroke: 200 mm range of revolution per miute: 63 - 1000 U/min bore capacity in cast iron: 50 mm drill spindle - Morse Taper: MK4 spindle throat: 315 mm spindle distance: 475 mm number of drilling stations: 3 headstock adjustment: 280 mm feed:: 0,08 - 1,25 (9 Steps) mm/U distance between table/spindle: 710 mm table surface area: 450 x 560 mm total power requirement: 12,4 kW weight of the machine ca.: 3,1 t dimension machine xH: 2,15 x 1,40 x 2,65 m The previous owner removed a drill spindle with box from the gang drilling machine! Kdedpfsw Th Nlex Ag Asu *

Condition: good (used), power: 1.1 kW (1.50 HP), overall weight: 200 kg, Prebomat, drilling head for fitting operations, with 7 spindles, in very good condition. Kdodez N T Uiepfx Ag Aeu

Condition: used, machine/vehicle number: 127963, functionality: fully functional, input voltage: 400 V, type of input current: three-phase, spindle mount: MK 3, drilling depth: 130 mm, total width: 420 mm, total length: 800 mm, total height: 1,800 mm, throat depth: 230 mm, overall weight: 190 kg, column diameter: 102 mm, spindle speed (max.): 1,880 rpm, spindle speed (min.): 160 rpm, Dear Sir or Madam, We are happy to answer any questions. This sale is made without any warranty or guarantee. Errors and typos cannot be ruled out. Kdodsv T Ax Djpfx Ag Aeu Please check the information in the PDF. No returns accepted.

Condition: used, Year of construction: 1989, bore capacity in steel (diameter) 32 mm arm length 1230 mm table surface area 1200 x 500 mm bore stroke 180 mm feed - independent 0,10 - 0,15 - 0,20 - 0,30 mm turning speeds 60 - 1800 U/min taper MK 4 total power requirement 2,7 kW weight of the machine ca. 1,8 t dimensions of the machine ca. 2,2 x 1,8 x 2,3 m Quick radial with: Kdjdpfx Agey Aa H Ne Aeu - Feed - Thread cutting device

Condition: as good as new (ex-display), Year of construction: 2013, machine/vehicle number: I1305008, functionality: fully functional, input voltage: 400 V, type of input current: three-phase, spindle mount: MK 3, drilling depth: 130 mm, height adjustment type: mechanical, throat depth: 250 mm, overall weight: 320 kg, drilling capacity: 25 mm, column diameter: 110 mm, spindle speed (max.): 2,880 rpm, spindle speed (min.): 125 rpm, Dear Sir or Madam, We are offering a demonstration pillar drill "HXMC model Z5025" with paint damage. We are happy to answer any questions. This sale is made without any warranty or guarantee. Errors and typos cannot be ruled out. Kodpfx Asv T Anrjg Aodu Please check the information in the PDF. No returns accepted.

Condition: used, Year of construction: 1998, Number of spindles in the hole row: 11 Kdodpfx Ajz I Ivdog Aou Number of horizontal spindles: 3 Pot-band drilling head: yes, Hettich Drill spacing: 32mm Power consumption: 2.2kW Drilling unit: swiveling

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 6234-3, drilling capacity: 40 mm, total length: 3,490 mm, quill stroke: 200 mm, total height: 2,950 mm, total width: 1,800 mm, table length: 1,800 mm, spindle speed (max.): 2,800 rpm, table width: 600 mm, type of input current: AC, overall weight: 2,900 kg, column diameter: 195 mm, input voltage: 400 V, input frequency: 50 Hz, distance table to spindle center: 705 mm, spindle motor power: 5 W, table height: 900 mm, distance table center to spindle nose: 95 mm, input current: 25 A, • Work table 1800 x 600 mm with 4T slots • Arm travel distance 1050 mm • Drilling spindle SK 40 with tool clamping device • Stepless speed programming • Stepless quill feed via three-phase servomotor • 2 T-slots 18 mm on the machine base at the rear • 2 T-slots 18 mm on the machine base on the left • Thread cutting device Kdsdez R Rv Ropfx Ag Aju • Central lubrication • Coolant system • CE marking • Includes attachments as shown in the photo
