Used Copying Lathe for sale (5,828)

Year of construction: 2016, condition: ready for operation (used), Swing diameter over bed/slide/bed bridge: 660mm/460mm/960mm, max. machining length: 300mm, distance between centers: 4000mm, turning length: 3680mm, bed width: 480mm. Spindle power: 15kW, torque: 1600Nm, speed: 2000rpm, travel X/Z: 316mm/3730mm, quill diameter: 105mm, quill stroke: 300mm, tool positions: 8, tool holder: VDI 40, chuck diameter: 500mm. Machine dimensions X/Y/Z: approx. 6700mm/2250mm/2300mm, weight: approx. 7200kg, control: Siemens Sinumerik 828D ShopTurn. Including additional 400mm three-jaw chuck, shims, hinged chip conveyor and working area enclosure. The lead screws of the X and Z axes were renewed in 2023. Documentation vorhanden. An on-site inspection is possible. Lrjdpfx Aasyx H E Ro Ror

Year of construction: 2009, condition: ready for operation (used), A CNC flatbed lathe Optimum is available. Swing diameter over bed/slide: 280mm/170mm, center distance: 700mm, spindle bore: 27mm, speed: 4000rpm, travel X/Z: 165mm/660mm, feed X/Z: 2m/min/3m/min, tool stations: 4, quill stroke: 85mm. Machine dimensions X/Y/Z: approx. 2000mm/750mm/1550mm, weight: approx. 450kg, control: Siemens Sinumerik. Documentation available. An on-site inspection is possible. Lsdsyyplijpfx Aa Rsrr

Year of construction: 2006, condition: ready for operation (used), A Doosan CNC lathe is available. Turning diameter: 300mm, turning diameter over bed/face slide: 550mm/390mm, max. turning length: 510mm, travel path X/Z: 205mm/580mm, rapid traverse: 24m/min, C-axis: 360°, bar capacity: 65mm, spindle bore: 76mm, speed: 4500rpm, tool stations: 12. Machine dimensions X/Y/Z: approx. 3500mm/1650mm/1800mm, weight: approx. 4250kg, control: Fanuc Series 18i-TB. Documentation vorhanden. An on-site inspection is possible. Lrjdpfsyvuvxox Aa Ror

Year of construction: 2004, condition: ready for operation (used), Two identical Index CNC lathes including peripheral equipment and accessories are available. Main spindle: D90/Size 8, max. main spindle bore: 90mm, max. workpiece diameter: 340mm, max. workpiece length: 450mm, max. workpiece weight: 100kg, speed: 4200rpm, power: 35.5kW, torque: 550Nm, front bearing diameter: 140mm, clamping stroke: 32mm, clamping pressure: 80bar, travel X/Z: 1500mm/340mm, rapid traverse: 30m/min, feed force: 8kN, tool stations 1/2: 10/10, mounting plate dimensions X/Y: 300mm/490mm. Including coolant system, tool holders, clamping equipment and angle toolholders. Documentation available. An on-site inspection is possible. Expected to be available from autumn 2026. Individual sale possible. Lrsdpfxozkld To Aa Rsr

Year of construction: 1997, condition: ready for operation (used), Distance between centers: 2000mm, control: Siemens Sinumerik 810, the control's flash memory is currently probably defective, but the parameters can still be accessed. an on-site inspection is possible. Lrsdpfx Aaezt Sk Se Rjr

Year of construction: 2002, condition: ready for operation (used), Max. turning diameter: 1000mm, max. swing diameter: 1250mm, max. workpiece diameter: 1000mm, max. workpiece length: 850mm, max. workpiece weight: 1000kg, X/Z travel: 1250mm/1000mm, max. speed: 900rpm, feed rate: 14m/min, rapid traverse: 20m/min, spindle nose: DIN 55026 short taper size A15, tool interface: DIN 69880 VDI60 tool holder, spindle diameter at the front bearing: 240mm, control: Siemens Sinumerik 840D. Machine weight: approx. 25t, space requirement: 85m². Equipment: SMW IN-D 1000 chuck, chip conveyor. The machine has no driven tools. Documentation available. Inspection possible by appointment. Lodpfjzukr Rjx Aa Rerr

Year of construction: 2005, condition: ready for operation (used), A lathe (Universal Turning Solution) is offered, control: Fanuc, tool turret: 12-station, tailstock, 3-jaw chuck. Tool setting arm: Renishaw HPRA. Inspection is possible by arrangement. Ljdpfx Aex I Rpxja Rerr

Year of construction: 2008, condition: ready for operation (used), Offered is a CNC lathe (sub-spindle, milling/C-axis, Y-axis). Equipped with bar feeder for balls smaller 120mm and CNC singulation for balls larger 120mm, incl. Fanuc six-axis robot M-16iB with R-30iA control for automated loading and unloading as well as a bunker for raw material supply. Machine is operational. Inspection possible by prior arrangement. Lrodpfx Ajx Th Nmsa Rjr

Year of construction: 1995, condition: ready for operation (used), Max. speed range: 5000 rpm, bar capacity: 65 mm, max. turning diameter: 200 mm, max. turning length: 400 mm. Number of spindles: 2, tool changer: 2x 14, Siemens control. Including outfeed conveyor, KNOLL 400S-1 chip conveyor (year of manufacture: 2016), switch cabinet with cooling unit, CO2 extinguishing system and INDEX bar loader. General overhaul in 2016. Lrodpfetdwwmox Aa Ror

Condition: used, Year of construction: 1973, turning diameter over bed 630-640 mm turning diameter over slide rest ca 380 mm turning length ca 2000-4000 mm total power requirement 15 kW Lrsdpfx Ajztfwrea Rsr weight of the machine ca. 7-8 t

Condition: used, TECHNICAL DETAILS - center height : 102 [mm] - Max. diameter on bench : 200 [mm] - Distance between centers : 470 [mm] - Type of spindle clamp : W20 - Boring : 20 [mm] - Passage of bar in clamp : 14.5 [mm] WEIGHT & DIMENSIONS - Machine floor space : 1500 x 800 [mm] - Machine height : 1300 [mm] - Machine weight : 500 [kg] Lodpfew Ihttex Aa Rjrr

Condition: used, TECHNICAL DETAILS - Number of axes : 10 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 25.4 [mm] - Max. machining length : 200 [mm] - Spindle speeds : 10000 [rpm] - C axis indexing precision : 0.1 [°] COUNTER-SPINDLE - Max. bar diameter : 20 [mm] - Spindle speeds : 10000 [rpm] Ljdpfx Aozi E U Aoa Rjrr - Spindle power : 3.7 [kW] - C axis indexing precision : 0.1 [°] - Number of guide bush holders : 2 GUIDE BUSH HOLDER 1 - Number of positions : 5 GUIDE BUSH HOLDER 2 - Number of positions : 5 - Number of motorized positions : 4 - Live tools speed : 8000 [rpm] END ATTACHMENT - Number of positions : 4 - Number of motorized positions : 4 - Live tools speed : 6000 [rpm] SECONDARY OPERATION - Number of positions : 7 - Number of motorized positions : 3 - Live tools speed : 8000 [rpm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 14 [kW] WEIGHT & DIMENSIONS - Machine floor space : 2270 x 1650 [mm] - Machine height : 2200 [mm] - Machine weight : 3500 [kg] - Number of hours under power : 88873 [h] - Number of working hours : 47253 [h] EQUIPMENT - CNC : Fanuc - Rotating tool motor on : S2,S3,S5 vertical et horizontal - Rotating guide bush - Parts catcher - Ejection of workpiece - Coolant tank - Bar loader : IEMCA BOSS 542 R 32L

Condition: used, TECHNICAL DETAILS - Number of axes : 9 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 20 [mm] - Max. machining length : 200 [mm] - Spindle speeds : 10000 [rpm] - Spindle power : 2.2/3.7 [kW] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE Lrsdpfx Aszk Rtmja Ror - Max. bar diameter : 20 [mm] - Spindle speeds : 10000 [rpm] - Spindle power : 0.75/2.2 [kW] - C axis indexing precision : 0.001 [°] GUIDE BUSH HOLDER 1 - Number of positions : 8 - Number of motorized positions : 3 - Live tools speed : 9000 [rpm] - Live tools power : 2.2 [kW] END ATTACHMENT - Number of positions : 6 + 4 - Number of motorized positions : 3 + 4 - Live tools speed : 7500 [rpm] - Live tools power : 0.75 [kW] SECONDARY OPERATION - Number of positions : 8 - Number of motorized positions : 4 - Live tools speed : 7500 [rpm] - Live tools power : 0.75 [kW] POWER SUPPLY - Supply voltage : 200 [V] - Total installed power : 7.3 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2.120 x 1.220 [mm] - Machine height : 1.835 [mm] - Machine weight : 2.350 [kg] EQUIPMENT - CNC : Mitsubishi MELDAS M70LPC-VU - B Rotary Axis : [°] (+/-) - Rotating guide bush - Ejection of workpiece - Parts catcher - Parts conveying strip - Coolant tank - Bar loader : IEMCA BOSS 338 HD/R / 32 LL - Electric transformer

Condition: used, TECHNICAL DETAILS - Number of axes : 7 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 12 [mm] - Max. machining length : 135 [mm] - Spindle speeds : 15.000 [rpm] - Spindle power : 2.2/3.7 [kW] - C axis indexing precision : 0,001 [°] COUNTER-SPINDLE - Max. bar diameter : 20 [mm] - Spindle speeds : 10.000 [rpm] - Spindle power : 0.4/0.75 [kW] - C axis indexing precision : 0,001 [°] GUIDE BUSH HOLDER 1 - Number of positions : 10 - Number of motorized positions : 4 - Live tools speed : 10000 [rpm] END ATTACHMENT - Number of positions : 4 SECONDARY OPERATION - Number of positions : 4 POWER SUPPLY - Supply voltage : 200 [V] - Total installed power : 6.1 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 1760 X 820 [mm] - Machine height : 1610 [mm] - Machine weight : 1700 [kg] EQUIPMENT - CNC : Mitsubishi - 3 colors status lamp - Rotating guide bush - Ejection of workpiece - Parts catcher Ljdpfszk Rtgjx Aa Rsrr - Parts conveying strip - Coolant tank : Müller Combiloop CL2 * with high-pressure pump - Bar loader : IEMCA ELITE 112 E/R / 32 LL - Electric transformer

Condition: used, TECHNICAL DETAILS - Number of axes : 10 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 32 [mm] - Travel : 240 [mm] - Spindle speeds : 8000 [rpm] - Spindle power : 7.5 [kW] - C axis indexing precision : 0.1 [°] COUNTER-SPINDLE - Max. bar diameter : 32 [mm] - Spindle speeds : 6000 [rpm] GUIDE BUSH HOLDER 1 - Number of positions : 5 GUIDE BUSH HOLDER 2 - Number of positions : 5 - Number of motorized positions : 4 - Live tools speed : 6000 [rpm] END ATTACHMENT - Number of positions : 4 - Number of motorized positions : 4 - Live tools speed : 6000 [rpm] SECONDARY OPERATION - Number of positions : 7 - Number of motorized positions : 3 - Live tools speed : 6000 [rpm] POWER SUPPLY Ledouhax Eepfx Aa Rsrr - Supply voltage : 400 [V] MACHINE HOURS - Number of working hours : 56.433 [h] EQUIPMENT - CNC : Fanuc - Rotating tool motor on : S2,S3,S5 V+H - Rotating guide bush - Parts catcher - Ejection of workpiece - Chips conveyor - Coolant tank * with high-pressure pump - Number of turning tool holders : 3 - Number of fixed tool holders : 7

Condition: used, TECHNICAL DETAILS - Number of axes : 8 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 16 [mm] - Max. machining length : 180 [mm] - Spindle speeds : 12000 [rpm] - C axis indexing precision : 0.1 [°] COUNTER-SPINDLE - Max. bar diameter : 16 [mm] - Spindle speeds : 12000 [rpm] - C axis indexing precision : 0.1 [°] - Number of guide bush holders : 2 GUIDE BUSH HOLDER 1 - Number of positions : 6 - Number of motorized positions : 3 - Live tools speed : 8000 [rpm] GUIDE BUSH HOLDER 2 - Number of positions : 6 - Number of motorized positions : 3 Lodpfx Aouhayisa Rerr - Live tools speed : 8000 [rpm] END ATTACHMENT - Number of positions : 4 - Number of motorized positions : 4 - Live tools speed : 8000 [rpm] SECONDARY OPERATION - Number of positions : 6 POWER SUPPLY - Supply voltage : 400 [V] MACHINE HOURS - Number of working hours : 53892 [h] EQUIPMENT - CNC : FANUC PNC DECO - Rotating tool motor on : S2,S5 - Rotating guide bush - Parts catcher - Ejection of workpiece - Coolant tank

Condition: used, TECHNICAL DETAILS - Number of axes : 9 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 10 [mm] - Travel : 66 [mm] - Spindle speeds : 16000 [rpm] - Spindle power : 3.7 [kW] - C axis indexing precision : 0.1 [°] COUNTER-SPINDLE - Max. bar diameter : 10 [mm] - Spindle speeds : 12000 [rpm] - Spindle power : 3.7 [kW] - C axis indexing precision : 0.1 [°] GUIDE BUSH HOLDER 1 - Number of positions : 4 GUIDE BUSH HOLDER 2 - Number of positions : 4 - Number of motorized positions : 3 - Live tools speed : 12000 [rpm] END ATTACHMENT - Number of positions : 3 - Number of motorized positions : 3 - Live tools speed : 12000 [rpm] SECONDARY OPERATION - Number of positions : 4 - Number of motorized positions : 4 - Live tools speed : 9000 [rpm] POWER SUPPLY - Supply voltage : 400 [V] WEIGHT & DIMENSIONS - Machine floor space : 1700 X 1010 [mm] - Machine height : 2000 [mm] Lrodpfouhbakox Aa Rer - Machine weight : 1500 [kg] MACHINE HOURS - Number of hours under power : 89897 [h] EQUIPMENT - CNC : Fanuc - Rotating tool motor on : S2,S3,S5 - Rotating guide bush - Parts catcher - Ejection of workpiece - Coolant tank - Number of turning tool holders : 4 - Number of fixed tool holders : 6 - Number of turning tool holders : 7

Condition: used, TECHNICAL DETAILS - Spindle power : 10,5 [kW] - Spindle speed : 10 000 [Rpm] - Spindle type : A2-4 - X/Y/Z strokes : 280/280/145 [mm] Ljdpfx Aaouhbgwj Rerr - Rapid traverse : 50 [m/min] - Loading zone X/Z strokes : 110/90 [mm] - Number of tools : 8 - Live tools speed : 6000 [Rpm] - Live tools power : 9,5 [kW] - Tool type : Capto C4 - Dimensions : 1700 x 3000 x 2400 [mm] - Weight : 4000 [kg] - Total installed power : 2,5 [kW] EQUIPMENT - CN Siemens 840D - Axis C

Condition: used, Multispindle lathe GILDEMEISTER GM 20 AC Lredpfxszpzm Us Aa Ror

Condition: used, TECHNICAL DETAILS - Number of spindles : 6 - Crosses slides, in position : 1,2,4,5 - Max. travel of transverse slides : 28 [mm] - Max. travel of crossed slides : 45 [mm] - Max. travel of front spindles : 63 [mm] SPINDLES - Max. bar diameter : 16 [mm] - Spindle speeds : 400 - 6000 [rpm] - Spindle power : 15 [kW] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 31 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 3.800 x 1.300 [mm] - Machine height : 2.100 [mm] - Machine weight : 4400 [kg] Ljdswvvrhopfx Aa Rerr EQUIPMENT - Double mechanical cut and return slide, in position : 6 - Rotary front spindles, in position : 1,2,3,4,5 - Parts catcher - Parts conveying strip - Bar waste chute - Chips conveyor - Coolant tank - Bar loader : Iemca PRA 40/33/P - Bar holder and stand - Bar holder housing

Condition: used, TECHNICAL DETAILS - max. diameter over bed : 270 [mm] - max diameter over slide : 130 [mm] - distance between centers : 440 [mm] - spindle nose : CAMLOCK D1-3' - max bar diameter : 28 [mm] - power : 7.5 [kW] - spindle speed : 0-5000 [rpm] with variator - strokes X x Z : 180 x 400 [mm] - work feeds : 0-5000 [mm/min] with variator - quick feeds : 7500 [mm/min] - supply : tri 380V 50Hz 14kW - size : 1700 x 1226 x 1660 [mm] - weight : 1415 [kg] Ledpfxouhcarj Aa Rorr EQUIPMENT - numerical control FANUC 20-T - quick change turret Multifix 'A' - collets chuck SCHAUBLIN B32 - tail stock with capstan - coolant tank with pump

Condition: used, TECHNICAL DETAILS - Number of axes : 10 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 10 [mm] - Max. machining length : 100 [mm] - Spindle speeds : 14000 [rpm] - Spindle power : 10.1 [kW] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Max. bar diameter : 10 [mm] - Spindle speeds : 14000 [rpm] - Spindle power : 7 [kW] - C axis indexing precision : 0.001 [°] GUIDE BUSH HOLDER 1 - Number of positions : 8 GUIDE BUSH HOLDER 2 - Number of positions : 8 - Number of motorized positions : 4 - Live tools speed : 12000 [rpm] END ATTACHMENT - Number of positions : 3 Lrodpfx Asvm Dxrsa Rjr - Number of motorized positions : 3 - Live tools speed : 12000 [rpm] SECONDARY OPERATION - Number of positions : 4 - Number of motorized positions : 4 - Live tools speed : 9000 [rpm] POWER SUPPLY - Supply voltage : 400 [V] WEIGHT & DIMENSIONS - Machine floor space : 1850X1140 [mm] - Machine height : 1800 [mm] - Machine weight : 1650 [kg] EQUIPMENT - CNC : Fanuc 31i-B5 - Interface : Ethernet / RS232 / USB / PCMCIA - 3 colors status lamp - Rotating tool motor on : S2,S3,S5 - Rotating guide bush - Parts catcher - Ejection of workpiece - Coolant tank * with high-pressure pump : HP MÜLLER CL2 80 [bars] - Bar loader : IEMCA ELITE 112/33 - Oil mist extractor : ELBARON - Fire extinguisher * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer.

Condition: used, TECHNICAL DETAILS 8 spindles, bar capacity : 21 (round), 18 (hex.), 14 (square) [mm] - Spindle speed : 620-6000 [rpm] - Production cycle : 1 to 50 [parts/min] - Standard voltage : 380 [V] 50 [Hz] - Bar reel length : 3 [m] - Reel housing EQUIPMENT - Standard cross slide pos. 1,2,3,4,5,6,7 and 8 Lrjdpfx Ajuhaqnea Rer - Hirth cylinder barrel locking - Bar feeder Iemca PRA40/33F

Condition: used, TECHNICAL DETAILS 8 spindles, bar capacity : 21 (round), 18 (hex.), 14 (square) [mm] - Spindle speed : 620-6 000 [rpm] - Production cycle : 1 to 50 [parts/min] - Standard voltage : 380 [V] 50 [Hz] - Bar reel length : 3 [m] - Reel housing Lrsdouhaqzjpfx Aa Rjr EQUIPMENT - Standard cross slide pos. 1,2,3,4,5,6,7 and 8 - 1 Bar feed cam parts 60 [mm] - 1 Auxiliary camshaft drive - 1 Pick-up. 20 [mm] with lever - Hirth cylinder barrel locking - 8 cross slides, stroke 30 [mm], optional - Central slide, stroke 60 [mm] - Cutting oil tank with magnetic drum conveyor - Coolant pump capacity 150 [l/min] - Iemca PRA52/33F bar loader n°020651PA03, year 2006

Condition: used, TECHNICAL DETAILS - maxi bar diameter : 12.7 [mm] - main headstock strokes (fixed/rotary sleeve) : 130/80 [mm] - spindle power : 4 [kW] - rotation speed : 12 000 [rpm] - upper turret : 6 positions - lower turret : 6 positions - number of rotary positions on turret : 6 - sub-spindle maxi diameter : 12.7 [mm] - sub-spindle rotation speed : 12 000 [rpm] Lrsdpouhav Djfx Aa Rjr - dimensions : 2850 x 110 x 1480 [mm] - hours in production : 12408 [H] - spindle hours : 9400 [H] EQUIPMENT - CNC TRAUB TX 8i control - bar feeder LNS Alpha ST 320 - C axis on main spindle and sub-spindle - brake on main spindle and sub-spindle - parts catcher with conveying strip - anti fire device - lubricating tank with pump with cooling unit - chip conveyor - various fixed and driven tool holders
