Used Heesemann Ukp Cnc Quer for sale (8,874)

Year of construction: 1974, condition: refurbished (used), functionality: fully functional, machine/vehicle number: 1293, CNC Radial Forging Machine GFM mod. SX-16 Manufacture: GFM (Austria) YOM: 1974 / 2022 Model: SXL-16 Machine number: 1293 PLC: Siemens S7 - Technology V4.2 with CNC Bosch Rexroth XM Dujdpfx Adeq U Sa So Njt Numbers of Hammers: 4 Forging force: 800 Ton (200 t per Hammer) Strokes per minute: 580 Hammer length: 320 mm Maximum hammer setting scope - calculated by diameter: 100 mm Maximum diameter of forging regarding: - structural steel: circular cross section – Ø 160 mm square cross section – 130 mm - high alloy steel: circular cross section – Ø 120 mm square cross section – 100 mm Extreme quadrangle: 12 x 120 mm Maximum length of forging: 6000 mm Min and Max diameter of mounting in manipulator: 30 - 160 mm Feed of manipulator A: 6800 mm Feed of manipulator B: 7200 mm Passage through manipulator: Ø 130 mm Manipulators speed in fast move: 400 mm/s Feed speed of manipulators (stepless adjustment): 10 ÷ 115 mm/s Cooling water pressure: 3 ÷ 5 bar Temperature of inlet water: max. 30˚C Cooling water consumption: 34m3/h Pipe diameter for cooling water: 2” Compressed air pressure: min. 5 bar Pipe diameter for compressed air: Ø20 mm Consumption of compressed air: 1,5 Nm3/h Power supply (nominal power): 350 kW Motor voltage: 500 V Control voltage 220 V Power of main engine: 200 kW Power of pump motors: 185 kW Power of manipulators motors: 2 x 22 kW Dimensions of the machine Axis height of forging above the hall level: 750 mm Maximum height of machine above the hall level: 2.050 mm Maximum length of machine on the hall level: 33.740 mm Foundation length: 34.200 mm Maximum width of machine on hall level without loading equipment: 4350mm Foundation width: 15.600mm Machine net weight: 124.490 kg

Condition: refurbished (used), Year of construction: 1974, functionality: fully functional, machine/vehicle number: 1276, CNC Hot Radial Forging GFM SX-13 New in 1974 / 2022 New control system PLC SIEMENS S7 Machine number: 1276 No. of Hammers: 4 Forging force each hummer: 160 Ton Hammer stroke / min: 700/min Hammer lenght: 240 mm Diameter setting range: 80 mm Maximum forging diameter: Structural steel, round-cross section: Ø 130 mm square cross section: Ø 115 mm Smallest dimensions forged: Ø 25 mm Manipulator A max. displacement: 6820 mm Djdpoq U R T Njfx Ad Njut Manipulator B max. displacement: 7150 mm Maximum workpiece length: 6000 mm Rapid speed manipulator: 400mm/sec Total connected power: 300 kW 380 V, 50 Hz Machine dimensions: Forging height over floor: 615 mm Total height pf the machinr over floor: 1665 mm Total machine lenght: 32670 mm Total foundation lenght: 33400 mm Tot. machine width (without auxliary equipments): approx 3885 mm Total foundation width: 16000 mm Total weight of the machine: 84.000 Kg

Condition: used, Year of construction: 2012, Model Year: 2012 Width: 1,050 mm Length: 515 mm Duodpfx Asx Tudded Net Height: 600 mm Number of Axes: 3 Holder: BT40 Spindle Speed (RPM): 8,000 Processable Materials: Steel, Aluminum, Titanium, Graphite, Copper, Invar, Composite, Delrin, Peek

Condition: good (used), Year of construction: 2008, spindle speed (min.): 4,000 rpm, travel distance Z-axis: 500 mm, throat depth: 300 mm, Year of manufacture: 2008 Chuck diameter: 8" Number of axes: 3 Length: 500 mm Djdpfx Aex Nvm Sed Nout Neck diameter: 300 mm Spindle speed (rpm): 4000 Machinable material types: Steel, Aluminum, Titanium, Graphite, Copper, Invar, Composite, Derlin, Peek

Condition: good (used), Year of construction: 2008, spindle speed (min.): 4,000 rpm, travel distance Z-axis: 500 mm, throat depth: 300 mm, Model Year: 2006 Chuck Diameter: 8" Number of Axes: 3 Length: 500 mm Swing Over Bed: 300 mm Spindle Speed (RPM): 4000 Machinable Materials: Steel, Aluminum, Titanium, Graphite, Copper, Invar, Composite, Delrin, PEEK Dujdpex Nvm Esfx Ad Njt

Condition: good (used), Year of construction: 2008, spindle speed (min.): 5,000 rpm, travel distance Z-axis: 600 mm, throat depth: 300 mm, Year of manufacture: 2008 Chuck diameter: 10" Number of axes: 3 Length: 600 mm Dodpfx Adjx Nvmrj Njut Swing diameter: 300 mm Spindle speed (rpm): 5000 Processable materials: Steel, Aluminium, Titanium, Graphite, Copper, Invar, Composite, Delrin, Peek

Condition: ready for operation (used), Year of construction: 2004, operating hours: 60,425 h, functionality: fully functional, turning length: 1,050 mm, turning diameter: 465 mm, travel distance X-axis: 300 mm, chuck outer diameter: 325 mm, controller model: Fanuk Series 21I-TB, TECHNICAL DETAILS Max. turning length: 1,050 mm Duodpsy Hg S Hefx Ad Njt Turning diameter over cross slide: 350 mm Max. turning diameter: 465 mm Chuck diameter: 325 mm X-axis travel: 300 mm Z-axis travel: 1,050 mm Max. spindle speed: 3,500 rpm Max. torque: 630 Nm Spindle bearing diameter: 120 mm Max. bar diameter: 90 mm Tailstock stroke: 850 mm Quill stroke: 150 mm Rapid traverse X/Z axis: 30 m/min Number of tool turret positions: 12 Tool holder: VDI 40 MACHINE DETAILS Control: Fanuk Series 21I-TB Drive power: 33 kW

Condition: ready for operation (used), Year of construction: 2006, operating hours: 16,093 h, functionality: fully functional, turning length: 1,000 mm, spindle speed (max.): 5,000 rpm, controller model: MITSUBISHI M-720BM (MAPPS 2), counter spindle speed (max.): 5,000 rpm, milling spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Turning length: 1,000 mm Main Spindle Max. spindle speed: 5,000 rpm Drive power: 22/15 kW Spindle bore: 73 mm Counter Spindle Max. spindle speed: 5,000 rpm Drive power: 22/15 kW Spindle bore: 73 mm Milling spindle speed: 0 - 12,000 rpm Tool holder: Capto C6 Tool stations: 100 positions Hollow clamping device: 67 mm MACHINE DETAILS Control unit: MITSUBISHI M-720BM (MAPPS 2) Operating Hours Operating hours: 26,875 h Spindle hours: 16,093 h EQUIPMENT Y-axis Fully indexable B-axis Chip conveyor, discharge right Standard coolant system Interface for high-pressure coolant system, 70 bar Tool spindle with through-spindle cooling Coolant spray gun Blow air through sub spindle Manual tool presetting on main spindle 3-color signal tower Double foot switch Djdoy Eydyjpfx Ad Njut Simultaneous 5-axis machining Automatic power off Tool offset for 5-axis machining Programmable data input Dynamic interchange diameter/radius Stroke check prior to movement

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2011, operating hours: 18,972 h, machine/vehicle number: 363/11, actuation type: hydraulic, number of rollers: 4, roller (bottom) diameter: 150 mm, working width: 1,500 mm, sheet thickness (max.): 5 mm, TECHNICAL DETAILS Dujdpjy Hhwqefx Ad Net Max. sheet thickness: 5 mm Max. working width: 1,500 mm Diameter of upper roll: 130 mm Diameter of lower rolls: 150 mm MACHINE DETAILS Control: CNC Drive: Hydraulic Number of rolls: 4 Number of driven rolls: 4 Dimensions & Weight Dimensions (L x W x H): 3,700 x 1,200 x 1,200 mm Transport weight: 2,000 kg Transport packages: 2 Operating hours: 18,972 h EQUIPMENT Cone bending CE marking

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, machine/vehicle number: 71, turning length: 360 mm, turning diameter: 440 mm, spindle speed (max.): 5,000 rpm, bar passage: 45 mm, controller model: Fanuc 18iTA, TECHNICAL DETAILS Turning diameter: 440 mm Turning length: 360 mm Spindle speed: 50 - 5,000 rpm on both spindles Bar capacity: 45 mm Spindle nose: ASA A2-5 C-axis: 0.001 on both spindles MACHINE DETAILS Control: Fanuc 18iTA Upper turret: 12 driven stations Lower turret: 12 driven stations Main spindle: 11 / 7.5 kW Sub spindle: 7.5 / 5.5 kW EQUIPMENT Chip conveyor Parts catcher Dujdpfxey E Hpij Ad Nst Bar loader interface Bar loader: LNS Mini-Sprint S2 42/3M

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, turning diameter: 460 mm, spindle speed (max.): 3,500 rpm, controller model: Fanuc 32iTB iHMI, counter spindle speed (max.): 4,500 rpm, CMZ Turning and Milling Center including GL20II Gantry Loader! TECHNICAL DETAILS Swing diameter over bed: 760 mm Swing diameter over cross slide: 600 mm Maximum turning diameter: 460 mm Center distance: 689 mm Distance chuck to chuck: 625 mm X-axis travel: 310 mm Z-axis travel: 640 mm Y-axis travel: +70/-50 mm B-axis travel: 640 mm Rapid traverse (X/Y/Z/B): 30/30/15/30 m/min Maximum spindle speed: 3,500 rpm, ASA 8" A2 Maximum sub-spindle speed: 4,500 rpm, ASA 6" A2 Spindle bearing outer diameter: 200 mm Spindle bearing inner diameter: 130 mm Spindle bore: 86 mm Bar capacity: 78 mm Number of tool stations: 12, all driven, 12,000 rpm Dodpjy Hk Niefx Ad Nsut Tool holder: 25x25 (50) MACHINE DETAILS Control: Fanuc 32iTB iHMI Dimensions & Weight Machine weight: 6,500 kg Machine dimensions (L x W x H): 2,542 x 1,760 x 1,880 mm EQUIPMENT Gantry loader

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, turning diameter: 460 mm, spindle speed (max.): 3,500 rpm, spindle bore: 86 mm, bar passage: 78 mm, controller model: Fanuc 32iTB iHMI, center width: 689 mm,

Condition: repair required (used), Year of construction: 2014, machine/vehicle number: AA2/002546, number of slots in tool magazine: 24, overall weight: 6,600 kg, table length: 5,200 mm, table width: 1,300 mm, TECHNICAL DETAILS Table length: 5,200 mm Table width: 1,300 mm Number of milling spindles: 1 Type of milling table: Beam table Tool changer positions: 24 MACHINE DETAILS Voltage: 400 V Dodpoy Nybtjfx Ad Nsut Current consumption: 64 A Dimensions & Weight Dimensions (L x W x H): 10,300 x 2,450 x 2,800 mm Net weight: 6,600 kg Transport packages: 1 EQUIPMENT Drilling tool Vacuum pump Tools Becker Vtlf 250 vacuum pump: - Year of manufacture: 2008 - Main motor power: 5.5 kW - Connection diameter: 70 mm - Oil-free: Yes Note: The machine requires repair. There is an issue with the CAN bus system.

Condition: ready for operation (used), Year of construction: 2014, machine/vehicle number: 89867, functionality: fully functional, travel distance X-axis: 3,765 mm, travel distance Y-axis: 1,875 mm, travel distance Z-axis: 324 mm, number of slots in tool magazine: 12, overall weight: 4,000 kg, TECHNICAL DETAILS Working area X-axis: 3,765 mm Working area Y-axis: 1,875 mm Working area Z-axis: 324 mm Table length: 3,600 mm Table width: 1,800 mm Tool holding system: HSK-F63 Tool changer positions: 12 positions MACHINE DETAILS Number of milling spindles: 1 piece Dujdey Nxybspfx Ad Not Weight: 4,000 kg Transport packages: 1 piece EQUIPMENT Flat table BiesseWorks system/software Safety mat Drilling tool included Saw unit included Labelling machine Loading system Unloading system

Condition: used, machine/vehicle number: 006488, X axis working area: 2500 mm Y axis working area: 850 mm Main Electrospindle power: 5 KW Number of controlled axes: 3 axes Dsdpfx Ajwuclxsd Neut Total number of drilling spindles: 11

Condition: used, machine/vehicle number: 008255, X axis working area: 3050 mm Y axis working area: 850 mm Duedpfxsx A Td Eo Ad Nst Main Electrospindle power: 9 KW Number of controlled axes: 3 axes Total number of drilling spindles: 19 Total number of tool changer positions: 4

Condition: used, machine/vehicle number: 008407, X axis working area: 6700 mm Y axis working area: 1520 mm Working Table: Pod and Rail Main Electrospindle power: 12 KW Dedpfx Aeycdaxod Njut Number of controlled axes: 5 axes Total number of tool changer positions: 48

Condition: used, machine/vehicle number: 008471, X axis working area: 6360 mm Y axis working area: 1680 mm Working Table: Pod and Rail Main Electrospindle power: 12 KW Dsdpfxsywaf Uj Ad Njut Number of controlled axes: 5 axes Total number of drilling spindles: 10 Total number of tool changer positions: 36

Condition: used, machine/vehicle number: 008473, X axis working area: 4900 mm Y axis working area: 1680 mm Working Table: Pod and Rail Main Electrospindle power: 12 KW Number of controlled axes: 5 axes Total number of drilling spindles: 10 Dedpfx Adeywaf Ie Nsut Total number of tool changer positions: 36

Condition: used, machine/vehicle number: 005796, X axis working area: 3700 mm Y axis working area: 1550 mm Main Electrospindle power: 9 KW Number of controlled axes: 3 axes Total number of drilling spindles: 10 Total number of tool changer positions: 8 Dsdpfx Aohwi U Tsd Nsut

Condition: good (used), Year of construction: 2007, Traub TNX 65/42 Milling and Turning Center Mfd. 2007 Serial #7060107 Commissioned in 2010 TX 8i-S control (Mitsubishi/Traub based control with Mitsubishi drives and motors) 15 CNC axis’s (4) X-Y-Z turrets with 10 positions each. Up to 20 tools per turret 65 mm thru hole main and sub spindle (sub spindle has coolant flush) Foot pedal control for clamp/unclamp of spindle chucks Servo driven gantry receiver Hydraulic swivel w/ pneumatic finished part and bar remnant gripper Finished part conveyor belt RESY paper band coolant filter Knoll Coolant tank with BKW refrigerated coolant temperature control 20 Bar High pressure and 8 Bar Low pressure coolant pumps Knoll chip conveyor FMB Turbo 5-55 magazine bar feeder (new in 2010) 2) Single stick turning tool holders 2) Double stick turning tool holders 1) Cut-off tool holder 1) Overdriven double radial live ER Collet tool holder 1) Overdriven radial live ER Collet tool holder 4) Radial live ER Collet tool holders Duodpfxeq Npqme Ad Nst 1) Radial live End Mill tool holder 1) Angle adjustable live ER Collet tool holder 2) Radial live Shell Mill tool holders 2) Axial live End Mill tool holders 6) Axial live ER Collet tool holders 43) Additional tool holders on separate list (see supplemental attachment) Hainbuch main spindle collet chuck Rohm sub spindle 2 jaw chuck 2 Spare sets of spare Z-axis ball screws and bearing packs.

Condition: used, machine/vehicle number: 008238, X axis working area: 3660 mm Y axis working area: 1550 mm Working Table: Flat table Main Electrospindle power: 12 KW Dedpfxsx A E Tfe Ad Njut Number of controlled axes: 3 axes Total number of drilling spindles: 12 Total number of tool changer positions: 15

Year of construction: 2020, condition: excellent (used), machine/vehicle number: 101262, Porta Solutions MULTICENTER 3 SPINDLE 3 Spindle Machining Center Mfd. 2020 Dsdpfx Ajvn T Dajd Nout SN: 101262 Control: Fanuc Panel i Chip Conveyor

Condition: used, machine/vehicle number: 008369, X axis working area: 3100 mm Duedpjx A Tinofx Ad Not Y axis working area: 1600 mm Working Table: Flat table Main Electrospindle power: 10 KW Number of controlled axes: 4 axes Total number of drilling spindles: 14 Total number of tool changer positions: 6

Condition: excellent (used), Year of construction: 2004, operating hours: 1,000 h, functionality: fully functional, turning diameter over cross slide: 380 mm, turning length: 350 mm, turning diameter: 200 mm, travel distance X-axis: 240 mm, rapid traverse X-axis: 12 m/min, Hembrug Mill-Turn Machine Model: Slantbed Mikroturn 100 CNC Siemens 840D Control Approximate Actual Run Time Hours: 1,000 Dodpfowcfgbox Ad Nsut Hydeostatic Spindle Hydrostatic Ways Scale Feedback Suspended Granite Bed Garnite Spindle Housing Coolant Pump Coolant Circulation Pump Pneumatic Bearing Purge Hydraulic Temperature Control Coolant Temperature Control Return Oil Pump and Reservoir for Remote Location of Hydraulic / Cooling Unit. Options & Additional Purchased Features: Tailstock Vacuum Pump for Vacuum Chucking Programable Controlled Spray Mist C-Axis Milling / Drilling Renishaw Tool Touch Probe Non-Contact Tool Incoming Air Dryer / Filter Thousands of Dollars of Brand New Tooling: Live Center Tailstock Taper Adapter 8” Micro-Centric Pneumatic Chuck 3 Sauter Straight Live tooling heads 2 Sauter 90 degree Live tooling heads 1 Special VDI offset Tooling holder 16 VDI Tool Holders for Turning, boring, and on center drilling. Tool Pick-up Video System Extra Siemens Control Pannel Complete Set of Manuals Machine Upgrades I added at additional cost. New Digital Hard Drive New Backup Hard Drive with software already loaded, plug and play ready, no downtime. New Z-Axis Heidenhain Scale Rewound Hydraulic Pump Motor, factory motor was running too hot for my liking. Replaced Operator Panel, back light on monitor went out, have the original, back light needs replacing. 50 Foot Extended Wiring Harness For Remote Location of Hydraulic / Cooling Unit.
