Used Alzmetall Ab 3 / Esv for sale (68,392)

Condition: good (used), Year of construction: 1979, bore capacity in steel (diameter) 35.0 / 40.0 mm throat 300 mm bore stroke 180 mm turning speeds 110 - 1450 U/min table-size Ø 455 mm column diameter 155 mm feed 0.1 / 0.2 / 0.3 m/min spindle taper MT 4 MK engine output 1.5 kW weight 450 kg range L-W-H 800 x 650 x 1850 mm Features: - Heavy-duty column drill press (V-belt drive) - Automatic spindle feed - Infinitely variable speed control - Fixed depth stop - Round machine table with T-slots Lsdjzl E Tkjpfx Amtohi * Height-adjustable via hand crank * Rotatable - Emergency stop button on the front - Coolant system with separate reservoir - Operatorâ??s manual

Condition: used, Year of construction: 1980, machine/vehicle number: 17209, power: 1.5 kW (2.04 HP), input voltage: 400 V, input frequency: 50 Hz, spindle mount: MK 3, height adjustment type: mechanical, rotational speed (max.): 1,750 rpm, rotational speed (min.): 130 rpm, total height: 2,000 mm, throat depth: 290 mm, Equipment: rotational speed infinitely variable, Used column drill press Manufacturer: Alzmetall Type: AB 3 ESV Machine number: 17209 Year of manufacture: 1980 Drilling capacity in cast iron: Ø 35 mm Drilling capacity in steel (diameter): 28 mm Spindle speed via 2 gear stages, 2 motor speeds, and continuously variable via a variator gear 130 - 1750 rpm Spindle taper: MK 3 Feed rate: 0.1; 0.2; 0.3 manually/automatically mm/rev Distance spindle/table min/max: 80 - 680 mm Table clamping surface: 500 x 370 mm Table rotatable: 360° Drill table adjustment: 600 vertical mm Overhang: 290 mm Quill stroke: 165 mm Column diameter: Ø 120 mm Equipment: - Coolant system Lhsdpfozldquex Amtji - Speed indicator - Work light - Röhm Spiro quick-change chuck 1-13 mm - Ejector on chain - Emergency stop button Machine weight approx.: 285 kg Machine dimensions approx.: 0.9 x 0.6 x 1.9 m (LxWxH)

Condition: used, 1 used column-type drilling machine Brand: Alzmetall Model: AB 3 ESV Lsdsyqr Dhepfx Amtehi Drilling capacity: Ø 32 mm 3 automatic feed rates Spindle taper: MK 3 Distance spindle nose - table: 545 mm Throat: 290 mm Quill travel: 160 mm Column diameter: Ø 220 mm Dimensions: 1150 x 650 x 2000 mm Weight: 850 kg

Condition: used, Year of construction: 1983, machine/vehicle number: 18071, Ref. No. 25393 Technical Data: - Drilling capacity in steel ST 60: 28 mm - Maximum drilling capacity in steel ST 60: 32 mm - Drill spindle taper: MT 3 - Drill spindle stroke: 180 mm - Drill spindle speeds steplessly adjustable: - Range 1: 130 – 480 rpm - Range 2: 480 – 1750 rpm - 3 feeds: 0.1; 0.2; 0.3 mm/rev - Throat depth: 290 mm - Maximum distance table - drill spindle: 620 mm - Table with 2 T-slots: 450 x 450 mm - Height adjustable by rack-and-pinion and handwheel Lhedpfx Amjy En I Hjtsi - Separate coolant unit - Drive: 400 V / 0.9 / 1.3 kW - Space requirement approx.: W 660 x H 1900 x D 700 mm - Weight approx.: 280 kg

Condition: used, Column drilling machine ALZMETALL, type AB 3 ESV Machine no. 15967, year of manufacture 1977 Drilling capacity 32 mm Lhedpsharwvefx Amtei Spindle mount MK 3 – short quill Distance from spindle nose to table 545 mm (short quill) Distance from spindle adapter to table 395 mm (MK adapter) Overhang 290 mm Quill stroke 160 mm Table size Ø 545 mm Column diameter 220 mm Spindle speed 55 – 1450 rpm, continuously variable Motor power 1 / 1.6 kW Power connection 380 volts, 50 Hz - Spindle speed controlled via 2 gear stages, 2 motor speeds, and continuously variable via a variator gearbox - Pre-selection stage for high torque at low speeds - MK adapter from MK3 to MK4 - Automatic feed 0.1 - 0.2 - 0.3 mm/rev - Rotatable drilling table - Table height adjustment via hand crank - Heavy machine base with machined workpiece support surface (not original Alzmetall) - Lighting for the work area Space requirement L x W x H 1150 x 650 x 2000 mm Weight 850 kg Good condition

Condition: good (used), Column Drilling Machine ALZMETALL AB3 ESV Lsdozmxw Eepfx Amtehi Spindle: CM3 Rotation: 1 range 220 -800 RPM + 1 range 800-2900 RPM Table size: Length 615 mm x Width 470 mm Spindle travel: 160 mm Throat depth: 280 mm Speed adjustment by belt drive Rotative table at 360° Automatic Descent 3 speeds: 0,006 - 0,12 - 0,18 mm/min. Lubricant pump Voltage: 380 V Width: 800 mm Depth: 1300 mm Total height: 1900 mm Weight: approx 800 kg

Condition: excellent (used), Year of construction: 1989, functionality: fully functional, spindle mount: MK 3, rotational speed (max.): 1,750 rpm, rotational speed (min.): 65 rpm, throat depth: 180 mm, For sale is a pillar drilling machine from the brand Alzmetall in good, used condition, as can be seen in the pictures. Technical data: • Manufacturer: Alzmetall • Model: AB3-ESV • Speed: approx. 65 - 1,750 rpm • Spindle stroke: approx. 180 mm • Feed rates: 0.1/0.2/0.3 mm/rev • Thread cutting function with foot switch • With coolant pump • Year of manufacture: 1989 • Weight: approx. 470 kg • Condition: Used, functional The machine can be inspected and tested at any time! Shipping costs via freight forwarder: approx. €190 International buyers are welcome! Lhedpfx Ajzl U Rromtoi You will receive an invoice with VAT shown. Inspection/collection is possible by arrangement in 42855 Remscheid. Sale from location 42855 Remscheid, free loading. Errors in technical data and prior sale are reserved.

Condition: good (used), functionality: fully functional, spindle mount: MK 3, rotational speed (max.): 1,450 rpm, rotational speed (min.): 55 rpm, table width: 600 mm, table length: 470 mm, For sale is an Alzmetall column drill press in good used condition, as shown in the photos. Lhedpsy Uxhiefx Amtji Technical specifications: • Manufacturer: Alzmetall • Model: AB3-ESV • Speed: approx. 55–1,450 rpm • Spindle stroke: approx. 180 mm • Feed rates: 0.1/0.2/0.3 mm/rev • Table dimensions: approx. 600x470 mm • T-slot width: approx. 14 mm • Year of manufacture: 1977 • Condition: Used, in working order Shipping costs via freight forwarder: approx. €190 International buyers are welcome! You will receive an invoice with VAT shown. Viewing/pickup is possible by appointment in 42855 Remscheid. Sale from location 42855 Remscheid, loaded ex works. Subject to errors in technical data and prior sale.

Year of construction: 1970, condition: good (used), machine/vehicle number: Unbekannt, OFFER Technical data: - Drilling capacity in steel ST 60: 28 mm - Drilling capacity in steel ST 60: 32 mm - Drill spindle mount: MK 3, long spindle - Drill spindle stroke: 180 mm - Drill spindle speeds, stepless: approx. 140 - 1600 rpm - 3 feed rates: 0.1; 0.2; 0.3 mm/rev - Overhang: 290 mm - Max. distance, table to drill spindle: 620 mm - Rotary table with 2 T-slots: 450 mm - Height adjustable via rack and pinion with hand crank - Coolant system - Drive: 380 V / 0.9 / 1.3 kW - Space requirement: approx. W 750 x H 1900 x D 700 mm Ledpfx Ajhglvkjmtshi - Weight: approx. 280 kg

Condition: ready for operation (used), Column drilling machine / ALZMETALL AB 3 ES - Well-maintained, original condition - Drilling capacity / steel max. 35mm - Arm reach approx. 280mm - Table size approx. 600x470mm - Drilling stroke approx. 180mm Lsdpfx Amozkv N Tstshi - Taper shank MK 3 - Stepless speed control - Speed range 65 - 1750 rpm - Drilling depth stop - Spindle guard - Emergency stop - Foot switch - Analog speed display - Drill chuck - Documentation Dimensions: L x W x H 1.2 x 0.8 x 2 meters / Weight approx. 500 kg Errors and omissions excepted.

Condition: ready for operation (used), Year of construction: 1979, machine/vehicle number: 20945, Drill diameter: 28/35 mm Spindle mount: MK 3 Overhang: 293 mm Table size: 400 x 400 mm Table can be swiveled on a round column and its height can be adjusted using a hand crank and rack and pinion mechanism. Large distance between table and drill chuck: 630 mm Chuck travel: 180 mm Lhjdpfx Ajzh H I Uemtji Spindle speeds, infinitely adjustable in 4 groups: 65 - 1750 rpm Drive motor: 380 V, 0.9/1.5 kW Weight: 340 kg Space required: 600 x 920 x 1880 mm

Condition: good (used), bore capacity in steel (diameter) 28 mm arm length 700 mm workpiece height max. 1300 mm tool taper MK3 feeds 0,1-0,3 mm/U spindle turning speed range 100-1.220 U/min total power requirement 1,4 kW weight of the machine ca. 1,3 t dimensions of the machine ca. LBH 1,8 x 0,8 x 2,3 m Incl. cube table Lhsdpfx Aozfqmcjmtji Incl. drilling feed Mechanical clamping

Condition: good (used), Year of construction: 1975, machine/vehicle number: 16344, Offer 25511 Technical data: - Drilling capacity in steel ST 60: 28 mm - Maximum drilling performance in steel ST 60: 32 mm - Thread cutting device - Drill spindle mount: MK 3 long spindle - Drill spindle stroke: 180 mm - 10 spindle speeds: 250 – 2100 rpm - Throat approx.: 290 mm - Max. distance table – spindle approx.: 620 mm Lodpsy Rz Dfefx Amtshi - Table with 2 T-slots, height adjustable: 520 x 450 mm - Drive: 400 V / 1.0 / 1.3 kW - Required space approx.: W 600 x H 1850 x D 700 mm - Weight approx.: 280 kg

Condition: ready for operation (used), Column Drilling Machine / ALZMETALL AB 3 ES from vocational school - Well-maintained original condition Lsdpfx Amoyzakrjtjhi - Drilling capacity / steel max. 35 mm - Throat depth 280 mm - Table size 600x470 mm - Drilling stroke 180 mm - Morse taper MK 3 - Infinitely variable speed control - Drill depth stop - Speed display - Drill chuck - Documentation Dimensions: L x W x H 1.2 x 0.8 x 2 meters / Weight 480 kg Errors and omissions excepted.

Condition: used, Column Drilling Machine ALZMETALL Type AB 3 ES Machine No. 21703 Year of manufacture: 1981 Drilling capacity: 32 mm Spindle taper: MK 3 - long quill Throat depth: 290 mm Quill stroke: 160 mm Table size: 510 x 300 mm Column diameter: 115 mm Spindle speed: 55 - 1450 rpm, stepless Motor power: 0.9 and 1.3 kW, pole-changeable Ljdpfx Ajvu Dv Hemtehi - Spindle speed via 2 gearbox stages, 2 motor speeds, and stepless through variator gearbox - Intermediate gear stage for high torque at low speeds - RPM counter for spindle speed - Table height adjustable by handwheel - Machine lamp - Emergency stop via foot switch and kick switch - Quick-action drill chuck 1 to 13 mm Space requirement L x W x H: 1200 x 650 x 1900 mm Weight: 400 kg Very good condition Machine tested with 30 mm drill diameter in steel - runs very well

Condition: used, Year of construction: 1989, Technical details: Lhjdpsu Idkzsfx Amtei bore capacity in steel (diameter): 28 mm throat: 285 mm bore stroke: 165 mm drill capacity in cast iron: Ø 35 mm spindle taper MT: MK 3 spindle speed:: 65 - 1.750 / 4x steples U/min feed: 0,1; 0,2; 0,3 manuell/automatisch mm/U Distance spindle/table max.: 80 - 680 mm table clamping surface:: 500 x 370 mm table rotating: 360 ° drill table adjustment: 600 vertical mm column diameter: Ø 130 mm total power requirement: 7,5 kW weight of the machine ca.: 273 kg dimension machine xH: 0,9 x 0,6 x 1,9 m The machine can cut threads, change of direction left/right selectable via foot switch and/or depth stop Table can be swiveled and adjusted in height. *

Condition: ready for operation (used),

Condition: ready for operation (used), Bench drill – ALZMETALL AB 35 S - Drilling capacity in steel approx. 45 mm - Drilling capacity in cast iron approx. 48 mm - Spindle mount MK 4 - Arm reach approx. 350 mm - Drilling stroke approx. 180 mm - Spindle speeds / 2 stages / 65 - 1450 rpm (VARIABLE) - Automatic feed rates 0.1-0.2-0.3-0.4 mm/rev - Drilling depth stop - Table clamping surface approx. 600x460 mm - Table adjustment approx. 600 mm - Table height adjustable via crank - Column diameter approx. 200 mm - Motor power approx. 3.5 kW Lsdpfx Asznlf Esmtehi - Coolant system - Work light - Speed indicator Dimensions: L x W x H 1.1 x 0.7 x 2.1 meters / Weight approx. 1200 kg Errors and omissions excepted.

Condition: good (used), Year of construction: 1995, bore capacity in steel (diameter) 35.0 / 40.0 mm throat 300 mm bore stroke 180 mm turning speeds 65.0 - 1.750 U/min table-size 615 x 420 mm column diameter 155 mm feed 0.1 / 0.2 / 0.3 mm/U spindle taper MT 4 MK engine output 0.9 / 1.5 kW weight 450 kg range L-W-H 800 x 650 x 1850 mm Features: - Heavy-duty column drill press - Continuously variable speed control (V-belt) - Automatic spindle feed * with electromagnetic engagement - Pole-changing motor - Right/left rotation of the drill spindle - Fixed drilling depth stop - Machine table with 2 T-slots Lodszl E Uhspfx Amtohi * Height-adjustable via hand crank - Emergency stop button on the front - User manual (PDF)

Condition: excellent (used), Year of construction: 1979, machine/vehicle number: Masch. Nr.3650, functionality: fully functional, power: 2.2 kW (2.99 HP), input voltage: 380 V, type of input current: three-phase, tool diameter: 32 mm, spindle mount: MK 4, actuation type: electric, total height: 187 mm, throat depth: 300 mm, overall weight: 430 kg, Equipment: CE marking, documentation/manual, rotational speed infinitely variable, Well-maintained ALZMETALL pillar drilling machine AB 35 S, machine no. 3650 Flange spindle, MK4 Ledpfx Ajzicxromtshi Overhang 300 mm Spindle stroke 160 mm Spindle speed 55-1500 rpm, stepless Spindle speed via 2 gear stages Drilling capacity 32 mm in steel, 45 mm in cast iron Space requirement 1.3 m x 0.9 m Height 1.87 m Weight 430 kg Collection only, cash payment only.

Condition: used, Year of construction: 1978, number of spindles 3 bore capacity in steel (diameter) 40 mm bore stroke 180 mm weight of the machine ca. 2,3 t Lsdpfx Amjd Ih S Sotohi

Condition: used, Year of construction: 1993, 1 used column drilling machine Brand: Alzmetall Model: AB 36 Year of manufacture: 1993 Spindle taper: MK 4 Drilling capacity in steel St 60: 34 mm Drilling capacity in cast iron GG 20: 40 mm Max drilling capacity in St 60: 40 mm Thread cutting in ST 60: M 24 Thread cutting in GG 20: M 30 Reach: 330 mm Column diameter: 145 mm Ljdpsy H Dfwefx Amtjhi Spindle stroke: 160 mm with automatic drilling feed Total power requirement: 1.3 kW Machine height: 1865 mm Weight approx. 470 kg

Condition: not inspected (used), Year of construction: 1996, bore capacity in steel (diameter) 32 mm morse taper MK 4 base plate 1700 x 700 mm feed 4 m/min Lodpjzb Raiofx Amtjhi weight of the machine ca. 1,5 t dimensions of the machine ca. 1800 x x1200 x 2480 m

Condition: used, I am selling a fully functional drilling machine made by Alzmetall. Please contact me if you have any questions. Ledezcg Rtopfx Amtehi

Condition: new, ALZMETALL AX3/SV pillar drilling machine NEW Manufacturer: Alzmetall Type: AX3 SV Condition: New Drilling capacity steel 40 mm Thread cutting steel M24 Cast M30 Short spindle MK 3 Spindle stroke 120 mm Usable projection 293 mm Column diameter 115 mm Lsdpjy S Auzofx Amtshi Machine table 515 x 360 mm Distance spindle-table 117/701 mm T-slots 2 x 14 x 224 mm Feed 0.1 + 0.2 mm/rev Machine height approx. 1840 mm Net weight approx. 270 kg Drive continuously variable Motor 750/ 1500 rpm Power 1.0 / 1.6 kW Spindle speed rpm 80-1125 Additional equipment: - Reversing switch - Machine light LED - Thread cutting device - Coolant device B Available immediately from stock
