Used Soraluce Slp-6000 for sale (2,474)

Condition: used, Year of construction: 2017, controller manufacturer: Heidenhain, controller model: TNC 640, _____ Description: Year of manuf. : 2017 Control : Heidenhain TNC 640 Speed : 5000 rpm Movement X/Y/Z : 4500/1800/1300 mm In General: Year of manufacture:2017 Control system:Heidenhain TNC 640 Travel range X/Y/Z:4,500/1,800/1,300 mm Spindle speed:5,000 rpm Tool holder:SK 50 Milling head (spindle): Technology:Diagonal head with gear spindle Index:0.001° Speed:5,000 rpm Tool holder:SK 50 Max. power:43 kW Max. torque:1,045 Nm Coolant supply:Coolant + blast air Working table: Clamping surface:6,000 x 1,100 mm T-slots:6 x 22H12, spacing 140 mm Tool magazin: Technology:Chain magazine Number of stations:40 Tool changer:Double gripper (horizontal/vertical) Max. tool diameter:125 (250) mm Max. tool length:400 mm Gjdpfxoy Eu Tve Afuokc Equipment: Position measurement systems:Direct scales Chip removal:Chip conveyor Coolant supply:Internal coolant system with filter, 20 bar Workpiece measurement:Funk M&H probe Set-up operation:HR 510 electronic handwheel Software option:Adaptive Control

Year of construction: 2021, condition: ready for operation (used), - USED - TRAVELLING COLUMN MILLING MACHINE LONGITUDINAL TRAVEL: 4500 mm TRANSVERSAL TRAVEL: 1300 mm VERTICAL TRAVEL: 1800 mm RAPID FEEDS L-T-V: 35 m/min TABLE SIZE: 6000 x 1100 mm TABLE HEIGHT FROM FLOOR LEVEL: 850 mm SPINDLE: 20-4000 rpm; 37-43 kW; 900-1045 Nm; ISO 50 HEAD: MILLING AND BORING AXIAL HEAD TOOL MAGAZINE: CHAIN-TYPE ; 60 POS Gkodpfox Dfkgsx Afuoc CONTROL UNIT: HEIDENHAIN TNC 640 WEIGHT: 24800 Kg OVERALL DIMENSIONS: 6970 x 4310 x 4150 mm ACCESSORIES: SWARF CONVEYOR ; LINEAR SCALES ; TOUCH PROBE NOTE: OPERATOR'S PLATFORM

Condition: like new (used), Year of construction: 2020, operating hours: 12,000 h, functionality: fully functional, machine/vehicle number: 5645, travel distance X-axis: 6,000 mm, travel distance Y-axis: 4,000 mm, travel distance Z-axis: 1,600 mm, feed rate X-axis: 25,000 m/min, feed rate Y-axis: 25,000 m/min, feed rate Z-axis: 25,000 m/min, total length: 6,550 mm, table length: 2,500 mm, table width: 2,500 mm, total width: 15,900 mm, spindle speed (max.): 4,000 rpm, total height: 11,500 mm, overall weight: 57,000 kg, working range: 2,500 mm, grinding spindle motor power: 46,000 W, Ladies and Gentlemen, Gkjdpfx Afottri Tsuec Enclosed we advertise our portal bed milling machine. Installation winter 2019/2020. 12,000 operating hours. Price on request. The machine is currently still in operation. The price is for the machine only. Dismantling, transportation and installation are the responsibility of the buyer. We are looking forward to serious inquiries. Many thanks in advance.

Condition: excellent (used), Year of construction: 2009, x-travel 6000 mm y-travel 2100 mm z-travel 1500 mm control HEIDENHAIN iTNC 530 feed 2- 20 m/min spindle turning speed range 20 -4000 U/min Gkedjvwgl Aspfx Afuec table dimension - longitudinal 7000 mm table dimension - cross 2000 mm total power requirement 79 kW weight of the machine ca. 55 t dimensions of the machine ca. 15 x 7 x 4,6 m The SORALUCE FP6000 is in very good condition. accessories as option: # clamping angle: 5'000.-€ # Clamping cube: 2'000.-€ # Div. tools & workbench: 2'000.-€ Description: - CNC control: HEIDENHAIN ITNC 530 Orthogonal milling head: - Tool holder: ISO 50, DIN69871 AD - Automatic tool clamping: Clamping force 20,000 N - Indexing accuracy / repeatability: ± 3 sec. == ± 0.002 mm - Tightening bolt: DIN 69872 form A - Number of swivel positions: 1 x 1 ° milling head ( 360 positions rear plane, 270 positions front plane) 270 positions front plane) - Diameter spindle bearing: 90 - Sealing air: 0,7 bar Main drive: - Drive type: three-phase motor - Drive power: 100 % ED 32 kW spindle: - Spindle speed: 20 - 4000 rpm - Full power from: 340 rpm - Torque at 32 kW/S1: 910 Nm - Speed control: 2 ranges infinitely variable via star/delta connection Rapid traverse: max. 35000 mm/min

Condition: reconditioned (used), Year of construction: 2016, travel distance X-axis: 6,500 mm, travel distance Y-axis: 1,800 mm, travel distance Z-axis: 1,300 mm, feed length X-axis: 10,000 mm, feed length Y-axis: 10,000 mm, feed length Z-axis: 10,000 mm, rapid traverse X-axis: 35 m/min, rapid traverse Y-axis: 35 m/min, rapid traverse Z-axis: 35 m/min, spindle speed (max.): 7,000 rpm, spindle speed (min.): 20 rpm, table length: 8,000 mm, table width: 1,100 mm, RepairFIT by Dornhöfer The difference. Including installation & commissioning! Year of manufacture: 2016 Capacities / Travel distances: Longitudinal (X): 6,500 mm Vertical (Y): 1,800 mm Cross (Z): 1,300 mm Table size: Length: 8,000 mm Width: 1,100 mm Number of T-slots on the table surface: units: 7 Width of T-slots: 22 mm Distance between slots: 140 mm Paintwork: RAL 7021 (black grey) RAL 7035 (light grey) ref F-38 (DanobatGroup Blue) Tool holder: ISO 50, DIN 69871 AD Pull stud: DIN 69872 Type A Main drive: Drive power: 100% duty cycle 43 kW Spindle speed range: Max. spindle speed: 20 – 7,000 rpm Torque: 900 Nm Feeds: X, Y, and Z axis mm/min 2 – 10,000 Max. rapid traverse speed: X, Y, and Z axis 35,000 mm/min Base area SLP8000: (without enclosure) 13.0 x 4.5 m Overall height: approx. 4.4 m Weight: approx. 34,000 kg Heidenhain TNC 640 HSCI Automatic milling head, Diagonal H207 Adapter angle milling head SK50 with Hirth gearing Automatic tool changer, 60 magazine places Chip conveyor Preparation / integration of NC rotary table Adaptive control ACCURA HEADS Coolant system 2 Gkedpfx Asxvx Amefuoc RepairFIT is our proven solution for a profitable entry into our product lines. The machines offered in this line are procured by us through a strict selection process and undergo a thorough inspection (Deep-Dive Check). After intensive cleaning, any identified defects or faults are professionally repaired by our expert service team.

Year of construction: 2011, condition: ready for operation (used), Travel X/Y/Z: 5500mm/1200mm/1800mm, milling head indexing: 2.5°, drive power: 28kW, spindle speed: 4000rpm, feed X/Y/Z: 25m/min, table diameter: 1600mm, table speed: 250rpm, max. workpiece weight: 8000kg, panel field dimensions X/Y/Z: 6000mm/2000mm/300mm, machine weight: approx. 16500kg, control: Heidenhain iTNC 530. Workpiece weight: 8000kg, panel field dimensions X/Y/Z: 6000mm/2000mm/300mm, machine weight: approx. 16500kg, control: Heidenhain iTNC 530. Including internal coolant supply and chip conveyor. Documentation available. On-site inspection is possible. Gjdpsvx Twuofx Afuskc

Condition: ready for operation (used), Year of construction: 1997, travel distance X-axis: 4,500 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,000 mm, rotational speed (max.): 3,000 rpm, CNC Heidenhain TNC 426 30-tool changer Gkjdpezh U Hfofx Afuoc SA 50 spindle with automatic tool changer Maximum spindle speed: 3000 RPM Table size: 6000 x 1100 mm Travel: 4500 x 1200 x 1000 mm Chip conveyor 4th axis Tooling

Condition: used, Year of construction: 2013, x-travel 6000 mm y-travel 4750 mm z-travel 1500 mm control Siemens 840 D SL Table Verschiebetisch table load max. 20 t Tool changer 120 pos. tool taper SK 50 size of pallet 2200x1500 mm spindle power 46 kW Aggregate (pick-up max. 5 positions): Ortho head 1x1 degree Short vertical milling attachment Heavy angle head Long angle head The tech. Data are manufacturer or operator information and therefore non- Gedpoyr Aq Ujfx Afuekc binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: reconditioned (used), Year of construction: 2006, travel distance X-axis: 5,500 mm, travel distance Y-axis: 1,400 mm, travel distance Z-axis: 1,000 mm, spindle speed (max.): 5,000 rpm, spindle speed (min.): 15 rpm, table width: 1,200 mm, table length: 6,000 mm, RepairFIT by Dornhöfer The difference. Including installation & commissioning! Machine year of manufacture: 2006 Capacities / Travel: Longitudinal (X): mm 5,500 Vertical (Y): mm 1,400 Lateral (Z): mm 1,000 Work table: Length: mm 6,000 Width: mm 1,200 Number of T-slots on the table surface: pieces 12 Width of T-slots: mm 22 Distance between slots: mm 100 Max. workpiece weight: kg 13,500 NC rotary table: Position: Right, flush integrated into the table surface Clamping surface: Ø mm 1,000 Positioning accuracy: ° 360x0.001 Max. workpiece weight: kg 3,500 Number of T-slots: pieces 9 Gsdpfx Asy Tkgbefuskc Size of T-slots: mm 22 Distance of T-slots: mm 100 Paint finish: RAL 7035 light gray / RAL 5011 steel blue Tool interface: ISO 50, DIN 69871 AD Pull stud: DIN 69872 Form A Main drive: Drive power: 100% ED KW28 Spindle speed range: Spindle speed: min-1 15 - 5,000 Torque: Nm 815 Feeds: X, Y and Z axis mm/min 2 – 10,000 Max. rapid traverse speed: X, Y and Z axis mm/min 25,000 Max. feed force: N 10,000 Footprint FLC6000: m (approx.) 11.0 x 5.6 Overall height: m (approx.) 3.5 Weight: kg approx. 35,000 HEIDENHAIN iTNC 530 HSCI Automatic MTE milling head, diagonal Automatic tool changer Chip conveyor Coolant system with 70 bar & (IKZ) RepairFIT is our proven offer for a profitable entry into our product lines. The machines available in this line are procured by us after a strict selection process and undergo a thorough inspection (deep-dive check). After intensive cleaning, the identified obvious defects and errors were professionally repaired by our expert service team.

Condition: used, Year of construction: 2013, functionality: fully functional, travel distance X-axis: 3,500 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,250 mm, spindle speed (max.): 4,000 rpm, table width: 1,000 mm, table length: 3,700 mm, spindle motor power: 28 W, SORALUCE TA-A 35 CNC milling and boring center, equipped with a HEIDENHAIN iTNC 530 HSCI numerical control system, an automatic milling head, and a 40-position tool changer. Technical specifications Manufacturer: SORALUCE Model: TA-A 35 Year: 2013 Numerical control: HEIDENHAIN iTNC 530 HSCI Longitudinal travel X: 3,500 mm Vertical travel Z: 1,250 mm Transverse travel Y: 1,200 mm Table dimensions: 3,700 × 1,000 mm Spindle power: 28 kW Spindle speed: 20 to 4,000 rpm Spindle torque: 479 Nm Spindle taper: ISO 50 / DIN 69871 A Rapid traverse rates: 25,000 mm/min Machine weight: approximately 18,500 kg Equipment and options Automatic milling head with 2.5° × 2.5° indexing Automatic 40-tool changer, with horizontal and vertical tool change Gedpsz Nhzdsfx Afuekc HEIDENHAIN control with HR 410 electronic handwheel M&H 20.41-MULTI workpiece measurement system HEIDENHAIN TT 140 tool measurement probe Longitudinal chip conveyor Transverse chip conveyor Protective enclosure with access doors 3D thermal compensation Automatic centralized lubrication Preparation for the integration of a CNC dividing head

Year of construction: 2013, condition: used, Number of machnines 4 St Control Siemens Tool changer 1 Pos Plant Consists of 4 Machines Soraluce FR 9000I Soraluce RR 9000II Soraluce FP 8000 Gkodpfoyr Skkex Afuoc Soraluce PM 6000 Workpiece Setup Stations Replacement Pallets Automatic Tool Supply System (WBG) Automatic Pallet System Pallet Storage Rack The technical data is provided by the manufacturer or operator and is therefore non-binding. We reserve the right to prior sale; our terms and conditions of business and sale apply exclusively. About Us More than 400 of our own machines in stock Over 15,000 m² of warehouse space, 70-ton crane capacity More than 10,000 accessories for your workshop If you want to sell machines, production lines, or your business, please contact us. Further offers can be found on our website. Viewings are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 2017, operating hours: 15,218 h, functionality: fully functional, machine/vehicle number: 5639, travel distance X-axis: 10,000 mm, travel distance Y-axis: 3,600 mm, travel distance Z-axis: 1,900 mm, position of the milling head: 0.001°, mount diameter: 50 mm, rotational speed (max.): 4,000 rpm, torque: 2,000 Nm, coolant supply: 70 bar, spindle motor power: 60,000 W, Equipment: documentation/manual, rotational speed infinitely variable, SORALUCE CNC gantry milling and boring center with complete equipment x-10000mm y-3600mm z-1900mm - Automatic indexing milling head H 342 0.001° x 0.001° - Additional long angular head 90° - Capto C6 tool holder, horizontal/vertical with automatic tool clamping - Main drive 60KW 2000Nm - Machine weight 80 t - Safety package for the rear machine area - Safety package for the working area - Heidenhain iTNC 640 - Dynamic Active Stabilizer - Cross-axis compensation - Automatic head changing system - Milling slide extension z-1900mm - High-performance milling head 4000 rpm 1531Nm 0.001° x 0.001° - Additional long angular milling head 90° 2000 rpm 700Nm - Capto C8 turning tool holder horizontal / vertical with automatic clamping - Fixed storage station for 8 heads - Heidenhain handwheel - Coolant tank 200 liters - Automatic tool changer 120-fold - Increased tool weight 35 Kg - SORALUCE rotary table, diameter 3500mm with 2000mm travel, payload 40 t - Measuring probe M+H - Tool measurement M+H - Adaptive Control - Industry 4.0 machine status in real time - Swivel machining - 3-sided complete splash guard for the rotary table - Plate table 5000x3000x300mm Gkedpez Iy Irsfx Afuoc - Chip conveyor - Teleservice remote diagnostics - 3D volume model - Interpolation turning HEIDENHAIN

Condition: excellent (used), functionality: fully functional, Year of construction: 2005, Beam on time: 12,577 hours Gsdpfxeznir As Afujkc Laser on time: 68,745 hours including Sheetmaster

Condition: good (used), functionality: fully functional, Year of construction: 2007, including Sheetmaster, Gripmaster, and Toolmaster Year of manufacture: 2007 Gedpfx Aezr Ha Esfuskc

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, travel distance X-axis: 4,000 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 1,600 mm, Travel ranges: Longitudinal (X): 4000 mm Vertical (Z): 1600 mm Lateral (Y): 1300 mm Rotary table: Diameter: 1600 mm Maximum speed: 250 min⁻¹ Drive power (100% duty cycle): 53 kW Maximum transport load (positioning): 8000 kg Maximum transport load (rotation): 3000 - 8000 kg Work table: Length: 4000 mm Gkodpezi S E Ujfx Afusc Width: 1240 mm Height of work table: 760 mm Automatically indexing milling head: Tool interface: ISO 50, DIN 69871 AD Automatic tool clamping: Clamping force 20000 N Spindle speed range: Spindle speed: 20 - 5000 min⁻¹ Full power from 340 min⁻¹ Torque at 32 kW/S1: 900 Nm Main drive: Drive power: 43 kW Maximum rapid traverse rate: X-axis 45000 mm/min Y- and Z-axis 35000 mm/min Maximum feed force: X, Y and Z-axis 16000 N Automatic tool changer Magazine positions in M version: Maximum tool positions: SK 50 40 positions Maximum tool positions: Capto C8 20 positions Machine weight: approx. 32,100 kg Equipment: - Work table 4000 x 1240 x 760 mm with integrated rotary table Ø 1600 mm - Swiveling control panel with telescopic arm with HEIDENHAIN TNC 640 HSCI (6 axes + spindle) control, including 19" flat screen, metallic keyboard with integrated mouse and USB interface on the control panel. Processor speed 0.5 ms including HEIDENHAIN smarT.NC. - Interpolative turning with HEIDENHAIN TNC 640 HSCI consisting of CAM system, HEIDENHAIN postprocessor, software adaptation for C-axis (spindle). - Portable electronic hand-held unit HEIDENHAIN HR 520 with 5 m cable. - Automatically indexing milling head / 2 levels with 2.5° x 2.5° division and a tool clamping force of 20,000 N (H200), 32 kW / 900 Nm, tool interface ISO 50 - DIN 69871 AD. Mounting flange with Hirth gearing for adapting turning tool holders, grinding spindles or additional milling heads and a protective ring to cover the Hirth gearing; not required if H205 is selected. - Spindle drive 43 kW at 100% duty cycle via water-cooled HEIDENHAIN inline motor with direct power transmission. The motor is integrated into the milling slide. - Turning tool holder with Capto C8 interface (manual tool clamping) for turning operations incl. Hirth gearing and SK 50 interface according to DIN 69871 AD for adaptation to SORALUCE milling heads. (Semi-automatic changing with additional manual fastening by 8 x M8 screws); not required with fully automatic changing of the turning tool holder. - Pneumatically adjustable pick-up station (travel 500 mm) in the tool changer area for the turning tool holder and protective ring for semi-automatic changing. - Work table with integrated NC rotary table Ø 1,600 mm, for turning operations and for positioning operations with hydraulic clamping. - Rack and pinion drive in the X-axis via two servomotors controlled in a master-slave process.

Condition: reconditioned (used), Year of construction: 2012, functionality: fully functional, travel distance X-axis: 8,000 mm, travel distance Y-axis: 2,600 mm, travel distance Z-axis: 1,500 mm, RepairFIT by Dornhöfer The difference. KEY TECHNICAL DATA Machine year of manufacture: 2012 Capacities / Travel: Longitudinal (X): mm 8,000 Vertical (Y): mm 2,600 Lateral (Z): mm 1,500 Table size: Length: mm 10,000 Width: mm 2,500 Distance between grooves: mm 250 Paint finish: RAL 5011 (steel blue) RAL 7035 (light gray) Tool holder: ISO 50, DIN 69871 AD Pull stud: DIN 69872 Form A Drive power: 100% ED 32 kW Spindle speed: min-1 20-4,000 Gjdpfx Ajzz H Emofujkc Torque: Nm 900 Max. rapid traverse speed: X, Y and Z axes mm/min 25,000 Weight: kg approx. 34,200 Heidenhain iTNC530 Automatic milling head, diagonal, stepless Tool changer (60 magazine slots) Chip conveyor Coolant system 20 bar & internal coolant Preparation for NC rotary table RepairFIT is our proven offering for a profitable entry into our product lines. The machines available in this line are sourced by us after a rigorous selection process and undergo a thorough inspection (deep-dive check). After intensive cleaning, the identified obvious defects and errors were professionally repaired by our expert service team.

Condition: used, Year of construction: 2002, Brand and Model: SORALUCE SP-5000 Type: Traveling column Cnc: Heindehain 426 Year: 2002 Octagonal Head Indexed Degree-by- Degree Vertical course 1.600 mm Cross course 1.200 mm Longitudinal course 3.500 mm Width of the T slots: 22 mm Weight máximum carrying load on table: 3.000 kg/ m² Motor power : 30 kw Taper : DIN-69871 -AD Speed range : 4.000 r/min Range of maximum working feeds: 5.000 mm/min Total machine width : 1.560 mm Quick course vertical axis: 15.000 mm/min Quick course cross axis: 15.000 mm/min Gsdpfxsz Ekdro Afuokc Quick course longitudinal axis: 15.000 mm/min Maximum thrust from the spindle to the cutting tool: 11.000 N Internal cooling Machine equipped with a HIGH SPEED HEAD

Condition: excellent (used), functionality: fully functional, total length: 68,000 mm, total width: 1,100 mm, total height: 5,270 mm, load per truss pair (max.): 3,000 kg, load capacity per storage section: 15,000 kg, number of shelf rows: 4, shelf height: 5,270 mm, SLP SL 30 Pallet Racking Systems – approximately 68 m total length – 24 bay positions – Heavy-duty racking with pallet support rails For sale is a comprehensive package of four high-quality pallet racking systems from the manufacturer SLP, System SL 30 with RTS 110 crossbeam type. The racking systems come from industrial use and are ideally suited for warehouses, logistics centers, production facilities, and the machine and tool building industry. All racks are equipped with pallet support rails for Euro pallets and are designed for high loads. Gedpfezkunnjx Afuskc The racking systems were in industrial use until recently and are in used, well-maintained condition with the usual signs of wear and tear due to age and use. The sale is without the storage goods shown in the pictures and any other accessories. Total scope * 4 complete pallet racking systems * Manufacturer: SLP * System: SL 30 * Crossbeam type: RTS 110 * A total of 24 bay positions * Total length of all systems: approx. 68,000 mm (68 m) * Total height: approx. 5,270 mm * Total depth: approx. 1,100 mm * Pallet support rails throughout the entire racking area * Sale as a complete set or individually by agreement Technical data per racking system * Manufacturer: SLP * System: SL 30 * Crossbeam type: RTS 110 * Number of bay positions: 6 * Total length: approx. 17,000 mm * Height: approx. 5,270 mm * Depth: approx. 1,100 mm * Center distance: 2,700 mm * Shelf height: max. 1,050 mm * Shelf load: 3,000 kg * Bay load: 15,000 kg * Equipment: Pallet support rails for Euro pallets Scope of delivery for complete package * 4 complete pallet racking systems * 24 bay positions * a total of 119 crossbeam pairs * 2 systems with 36 crossbeam pairs each * 1 system with 24 crossbeam pairs * 1 system with 23 crossbeam pairs * Frames according to existing design * Pallet support rails for Euro pallet storage * Base plates and connecting parts according to existing design Load capacity * Shelf load per storage level: 3,000 kg * Bay load per bay position: 15,000 kg * Maximum theoretical total bay load of all 24 bay positions: 360,000 kg Special features * Robust, heavy-duty steel construction * Industrial design * Flexible plug-in system * Crossbeams height-adjustable * Suitable for Euro pallets and heavy storage goods * Partially different shelf configurations (23, 24, or 36 crossbeam pairs) * Modular and expandable A rack inspection according to DIN EN 15635 was carried out by B-Knape GmbH. Inspections are possible at any time by prior appointment. Sale preferably as a complete package. Individual sale is also possible. Subject to prior sale.

Condition: good (used), Year of construction: 2002, functionality: fully functional, USED Soraluce Soramill Model SP 10000 Travelling Column, Table Type CNC Milling Centre, with Automatic Oil Mist Lubricated Orthogonal Milling Head with 1 X 1 Degree Indexing and HEIDENHAIN TNC 430 M Control System. Year 2002 SN 8647 Gjdjr Hr Arepfx Afuskc Table Area - 10000 x 1100 mm Column Traverse (X) - 8500 mm Vertical Traverse (Y) - 1600 mm Ram Traverse (Z) - 1200 mm Spindle Motor - 28 kW Spindle Taper - Standard ISO 50 BT50 tooling Pullstud - DIN 6987 2-Form A. ISO 7388/2-Form A Independent Gearbox with 2 Ranges Speed Range - 20 to 4000 RPM Feed Range - 5 to 5000 mm/min Rapid traverse rate - (X, Y, Z) 15,000 mm/min Preloaded double nuts and recirculating ballscrews to each axis. Linear Guiding System with recirculating cylindrical rollers and steel guideway assemblies in X, Y and Z axes Independent A.C Drive motor to each axis. Linear Transducer in X, Y and Z-axes with air purge system. Automatic tool clamping. Automatic hydraulic tool releasing device. CNC Control HEIDENHAIN TNC-430-M. (Flat TFT screen with digital drives) 9 axes CNC and 1 spindle, 5 of them simultaneously interpolated. Working area lighting Electrical cabinet cooling system Electrical cabinet lighting Heidenhain HR410 portable electronic handwheel with 3m spiral cable Horizontally articulated pendant for CNC control Orthogonal head 28KW, 800Nm, 1deg x 1 deg, 4000rpm oil lubricated Price includes oil cooling unit for both head and gearbox. Option G2, Ram prepared for 4000rpm, is also included. Coolant through the spindle type AD. Coolant system with 500l capacity tank with two pumps providing low and high pressure of 3 and 8 bars and 50l/min flow. The system includes a combined paper and magnetic drum-filtering unit. Standard operators platform fixed to the column 40 tools capacity toolchanger magazine, BT50 Max. Tool length = 400 mm. Max. Tool diameter: - With full magazine = 120 mm. With adjacent position empty = 250 mm. Max. Tool weight = 20 kg. Mean tool weight with full magazine = 10 kg. Max. Permitted total weight = 20 kg. Swarf Conveyor Hinge type conveyor belt Machine preparation for the addition of a 4th axis electro-mechanical table. Splash Guarding against swarf at the table front and both sides. Consists of four sliding front doors with a height from the floor of 2.100mm and a length of 1.700mm each one. Manually operated opening and closing with mechanical interlock. The doors can be opened for the full longitudinal traverse. The rear of the table is open. Protection in the back and both lateral sides of the machine column.

Condition: used, Year of construction: 2013, x-travel 30000 mm y-travel 3600 mm z-travel 1900 mm Control Heidenhain type TNC 530 i turning speeds 4000 U/min conus taper DIN 69871+AD mm Feed 10000 mm/min spindle drive 46 kW Rapid movement 25000 mm/min chip conveyor 2 St. Plate area 31000x2500 mm total power requirement 85 kW Soraluce No. 5619 Load hours 9332 On-time hours 27960 Panel array consists of: 1 panel 7000x2500 mm 4 panels 6000x2500 mm Optional: 4x clamping angles Tool package Clamping table The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. Godpfxoyqtnnj Afuekc About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2017, laser power: 6,000 W, CNC laser cutting machine TruLaser 3040 Fiber (L50) 6000 Watt X working area max.: 4000 mm Y working area max.: 2000 mm Z working area max.: 115 mm Control system: Siemens Sinumerik 840D SL Laser power: 6000 Watt Sheet metal thickness steel max.: 25 mm Sheet metal thickness stainless steel max.: 25 mm Sheet metal thickness aluminum max.: 20 mm Sheet metal thickness copper max.: 8 mm Standard equipment Standard features Machine - Closed machine frame - Integrated cabinet with roller shutter - Torque drive in combination with linear direct drives - Closed beam guidance via laser light cable (LLC) Gsdpfx Afjz Rl Eijuokc - Cooling unit - Integrated control cabinets with internal lighting - Automatic sheet metal changer in longitudinal direction - 19" touch color screen - Longitudinal conveyor belt - Work area lighting - Positioning laser diode - Spraying device - PierceLine - FocusLine - NitroLine - PlasmaLine - Automatic nozzle cleaning - Transport and assembly device TRUMPF Laser - Solid-state laser TruDisk 3001 with one LLC output - Excitation via pump diodes - Laser power control Cutting head - Universal cutting head - Single cutting head strategy - Protective glass against lens contamination - Condition monitoring of the protective glass - ControlLine: Height control and sheet metal edge detection Control system - SINUMERIK 840D SL control system - Simple workshop programming - TruTops Laser via network access - Fast reproduction - Integrated technology data - Automatic shutdown - Programmable cutting gas/pressure selection - ContourLine - FastLine - FlyLine - AdjustLine - Teleservice via Internet Data transfer - USB interface - RJ-45 network connection - Wireless Operation Point (basis for Visual Online Support) Safety - CE marking - Light curtains - Multi-chamber extraction system - Compact dust collection system - Machine enclosure, certified viewing window, door on the right - Sliding roof - Nozzle changer - CoolLine

Condition: like new (used), Year of construction: 2014, Siemens 840 D Swivelling control panel including SIEMENS 840 D Solution Line control system. Travel X axis: 8000 mm Travel Y axis: 1300 mm Travel Z axis: 2200 mm Tool system: SK 50; Capto C8 Main spindle: 20–4000 RPM 3D volume model of the machine HEIDENHAIN measurement system on all axes. Automatic central lubrication with pressure and time monitoring for all axes and moving components. Measuring probe system RENISHAW RMP60 M Tool breakage detection via probe BRANKAMP CMS collision monitoring with two measuring channels: Center height, Fibro rotary clamp: 1100 mm Gjdpfxjw Syv Uj Afujkc Center width, Fibro rotary clamp: 900–3000 mm Max. swing diameter, Fibro rotary clamp: 2200 mm Fibro rotary table D=1600; 250 RPM Carousel rotary table FIBRODYN 1600 mm: Table surface 6000x2000 mm d’Andrea facing slide Universal milling head Automatic tool changer ATC, 80 tool magazine slots in M version: 3 milling head slots High-pressure pump 30 bar Operating hours: 4261 h

Condition: used, Year of construction: 2013, x-travel 9000 mm y-travel 3200 mm z-travel 1900 mm w-axis 700 mm V-axis 3000 mm control Siemens 840 D SL Table Drehverschiebetisch 2 Stück table load max. 20 t Tool changer 120 pos. tool taper SK 50 size of pallet 2200x1500 mm spindle power 46 kW Workpiece interferece circle diameter: 2500 mm Orthotic head power: 46 kW Aggregate (pick-up max. 6 positions): Quill diameter 130 mm Orthotic head 1x1 degree The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. Gedpfx Afjyr Aqzoujkc About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2007, operating hours: 11,800 h, laser power: 3,200 W, sheet thickness steel (max.): 8 mm, sheet thickness stainless steel (max.): 8 mm, sheet thickness aluminum (max.): 4 mm, No minimum price – guaranteed sale to the highest bidder! Includes SheetMaster, ToolMaster, GripMaster! TECHNICAL DETAILS Laser power: 3,200 W Laser type: CO₂ laser TruFlow 3200 Combined punching/laser working area: 3,000 × 1,500 mm Punching mode working area: 3,000 × 1,500 mm Laser mode working area: 3,000 × 1,500 mm Max. sheet thickness, structural steel: max. 8 mm Max. sheet thickness, stainless steel: max. 8 mm Max. sheet thickness, aluminum: max. 4 mm Max. punching force: max. 220 kN Max. punching stroke rate at E = 1 mm: max. 900/min Max. marking stroke rate: max. approx. 2,800/min Max. number of multi-tools with 3 clamping units: max. 18 Tool capacity: 180 tools Max. axis speed X/Y simultaneously: max. 108 m/min Gkjdpfsz Izu Tsx Afujc MACHINE DETAILS Operating hours: 11,800 h Laser on time: 42,100 h EQUIPMENT SheetMaster ToolMaster GripMaster Large-format working area without repositioning Linear magazine with multi-tools SheetMaster with two large-format tables Automatic scrap sheet removal to lifting table

Condition: used, functionality: fully functional, Year of construction: 2007, machine/vehicle number: A0100A0637, laser type: CO₂ laser, laser source manufacturer: trumpf, laser power: 2,000 W, input voltage: 24 V, input current: 100 A, input frequency: 4,000 Hz, type of input current: three-phase, type of cooling: water, year of last overhaul: 2025, Equipment: CE marking, centralized greasing system, cooling unit, documentation/manual, dust extraction, emergency stop, fume extraction, nozzle changer, safety light barrier, Trumpf Trumatic 6000, manufactured in 2007 – still in use and fully operational (used for stainless steel sheets, 0.8 – 2 mm thick). Godoz Iwvgjpfx Afuokc
