Universal Machining Centre

MIKRON HPM 1350U

Condition: excellent (used), Year of construction: 2015, travel distance X-axis: 1,350 mm, travel distance Y-axis: 1,170 mm, travel distance Z-axis: 700 mm, table width: 850 mm, table length: 1,000 mm, rotational speed (max.): 24,000 rpm, 1. MAIN MACHINE DATA Control: HEIDENHAIN iTNC 530 Number of Axes: 5-axis Travels: X-axis: 1,350 mm | Y-axis: 1,170 mm | Z-axis: 700 mm Spindle: Manufacturer: STEP-TEC (motor spindle) Max. speed: 24,000 rpm Tool holder: HSK63 Gjdpfx Ajycr Uwoacjin Table & Pallet System: CNC rotary table with swiveling spindle 3-position pallet changer (APC) Pallet size: 1,000 x 850 mm 2. TOOL MANAGEMENT & AUTOMATION Tool magazine: 238-position high-capacity magazine Magazine design: 5-level rack system Cooling system: BMF belt filter system with ICS (internal coolant supply) Workpiece measurement: probe from RENISHAW Enclosure: full guard cabin 3. TOOL AND ACCESSORY PACKAGE (Included) Storage systems: 1x tool cabinet (4 drawers, 1 door) 2x table trolleys 1x telescopic drawer cabinet (11 drawers) Clamping devices & fixtures: FCS Breil zero-point clamping system 3x grid plates (grid spacing: 25 mm)

Condition: reconditioned (used), Year of construction: 2006, CNC Universal Milling & Drilling Machine DECKEL MAHO DMU 80 P duoBlock With MILL PLUS iT path control system Year of manufacture: 2006 Travel paths: X 800 Y 800 Z 800 mm Spindle speed range: 0 – 8,000 rpm, stepless (SK 50) Including the following accessories: - NC rotary table, 900 mm x 700 mm clamping surface (maximum table load 1.4 t) - Universal milling head with controlled B-axis - Universal tool changer with 40 magazine stations, double gripper (SK 50) - Fully enclosed guard cabin with sliding doors and interior lighting - ICS – 40 bar (internal coolant supply) - Chip conveyor - Rotoclear - 3D tactile probe Heidenhain TS 641 - Operating modes 3 + 4 - Electronic handwheel Gedpfsxn Aczsx Aacein - 50 pcs. tool holders SK 50 - 3 height-adjustable machine feet - Transport device - Operating manuals

Condition: used, Year of construction: 2006, x-travel 1.000 mm y-travel 1.000 mm z-travel 1.200 mm C-axis 360 x 0,001 ° A - axis ° Control SINUMERIK 840D Powerline SIEMENS Godjw E Nnnepfx Aacoin Size of table plate 900 x 700 mm milling spindle - taper HSK - A100 spindle turning speed - stepless 12000 U/min toolpiece magazine: chain magazine 180 Stück total power requirement 85 kW weight of the machine ca. 20,5 t dimensions of the machine ca. 6,5 x 6,1 x 3,5 m 5-axis machining center with horizontal milling spindle arrangement SIEMENS SINUMERIK 840D Powerline control system Electronic handwheel NC swivel rotary table Rotoclear window Measuring probe ready Blum laser tool measurement Vibration sensor Tool taper cleaning 4th operating mode Internal coolant system with 2 pumps, 40 bar and 80 bar Chip conveyor Belt filter system Mist and smoke separator Cooling/heating unit

Condition: excellent (used), max. workpiece diameter 600 mm threading length 7000 mm max. module 8 / 12 min. module 1 swival range ° diameter of hob 63 - 140 mm spindle turning speed - stepless 45 - 450 U/min weight of the machine ca. 12,5 t dimensions of the machine ca. 9,0 x 2,0 x 2,2 m Condition: In good condition, checked and partially overhauled by a specialist. The existing milling head was replaced by an overhauled universal milling head. Furnishing: Differential for inclined machining Automatic indexing device (indexing discs changeable!) For multi-wedge, multi-thread parts, then extensive bushings, support rollers and around 70 Change gears. Gijdpfx Aaswgizdocen Conversion of the milling head speed to a frequency converter with corresponding powerful motor is a great thing and saves a lot of set-up time. Equipment: Around 70 change gears, 3 bushing sticks of different sizes, around 20 Bushings, 2 roller mountings, 2 tips for direct mounting on the Clamping spindle, 350 mm chuck, 2 spare part disks.

Year of construction: 2013, condition: ready for operation (used), Turning length: 6000mm, orbital diameter over bed/support: 820mm/515mm, spindle bore: 128mm, speed: 1600rpm, spindle power: 46kW, center height: 400mm, bed width: 560mm, quill diameter: 125mm, quill stroke: 280mm, connected load: 62kW. Machine dimensions X/Y/Z: approx. 6500mm/2500mm/2300mm, control: Heidenhain, operating hours: approx. 9000h. Including accessories such as a steady rest. Documentation available. On-site inspection is possible. Gisdpfx Aevwcwusacon

Condition: ready for operation (used), travel distance X-axis: 18,000 mm, travel distance Y-axis: 3,600 mm, travel distance Z-axis: 700 mm, spindle speed (max.): 1,600 rpm, spindle diameter: 160 mm, CNC FLOOR TYPE BORING MACHINE MAKE PAMA MODEL SPEEDRAM 2 X AXIS: 18000MM Y AXIS: 3600MM Z AXIS: 700MM Gisdpfx Asv Rv N Rsacjn V AXIS: 800MM (RAM TRAVEL) Z+V AXIS: 1500MM SPINDLE DIA: 160MM,ISO50 SPINDLE MOROR:65KW SPINDLE SPEED: 1600RPM ATC: 60POSITIONS MILLING HEAD: MANUEL MILLING HEAD: AUTOMATIC CNC ECS FLOOR PLATES 4NOS(4000X1500) 1NO(3000X2000) ROTRY TABLE: NOT AVAILABLE

Condition: good (used), centerless grinding machine Godpstrguvefx Aacjin

Condition: new, For sale, a pipe straightener from the German manufacturer SMS MEER, the machine is brand new, it was dismantled from a plant that collapsed during the delivery and assembly of the machine. The machine has two Siemens 200 kW drive motors each. Straightening rollers have a length of 460mm, diameter on the sides 400mm, diameter in the middle 300mm. The weight of the machine itself is 44 tons, the total weight is 55 tons. I can send a lot of photos before dismentling. Giedpfx Ajm H Unhoacsn

Condition: used, Year of construction: 1996, functionality: fully functional, travel distance X-axis: 10,000 mm, travel distance Y-axis: 2,600 mm, travel distance Z-axis: 700 mm, Manufacturer: PAMA Model:SPEEDRAM 1 CNC Giedpfx Ajwzh Apoacen Year1996 Spindle:140mm. Tranversal travel:10.000 mm. Vertical travel:2.600 mm. RAM travel:600 mm. Ram Size: 360x320 Spindle travel:700 mm. Spindle taper:ISO 50 Spindle motor power:50 Kw. Spindle speeds: 6 ÷ 2000 Rpm. Cnc:CNC Selca 3045 ATC: 60nos. Total weight:65 Tons. Features and Accessories Complete with: - n. 1 automatic universal milling head - n. 1 Floor plate 6000x2500x300mm -n. 1 Floor plate 4500x2000x300mm - Rotry Table 2000x1600 with long travel 2000mm -Loading capacity on table:15ton - levelling shoes

Condition: good (used), CHARACTERISTICS Plate diameter ⌀; 3200 mm Maximum turning/turning diameter ⌀; 3300 mm - With upright forward; 3300 mm - With upright set back; 5600 mm Min. turning/turning diameter ⌀ - With advanced upright; 800 mm - With upright set back; 3100 mm Max turning height; 750 mm Control; FAGOR 8025 Spindle RPM (2 ranges); - 0,5 - 10 rpm - 10 - 40 rpm Gedpor I Aykefx Aacsin Motor Power; 80 hp Maximum table load; 30.000 kg
