Gear hobber

PROFILATOR RM 80

Condition: good (used), Year of construction: 2000, gear diameter: 449 mm, Equipped with: Fanuc 150MB CNC Control Dry Cutting Cutter Shroud Chip Evacuation System Auto Doors Hydraulic System Lubrication System Work light Stack Light Specifications: Largest Speed Ratio: 10:01 Work Area (Continuous): Largest Depth of Teeth: 15.24 mm Largest Width of Tooth Face: 50.8 mm Work Area Axis: Horizontal Movement X Axis: -114 - 178 mm Vertical Movement Y Axis: -178 - 190 mm Movement of the Carriage Baseplate Z-Axis: -10.16 - 500 mm Workpiece Headstock Swiveling Range B-Axis: -3 - 90 Degree Maximum Distance Machine Center to Spindle Side: 165 mm Number of Teeth: 5-200 Inclusive Max. Gear Pitch Dia. of Typical 35 Deg. Spiral Angle Gear Using Max. Cutter Dia. 12" Cutter at the Following Ratios: Face Milling 1 x 1 - 13.5" - 342.9mm 2 x 1 - 16.0" - 406.4mm 5 x 1 - 17.7" - 450.0mm Face Hobbing (210mm Dia. Cutter) 1 x 1 - 10.560" - 268.22mm 2 x 1 - 10.286" - 275.00mm 5 x 1 - 11.810" - 300.00mm Milling Head Diameter: Helixact: 100,125,169,200,250,320mm Continuous Gumption Procedure, Teichloroethylene: 102 - 210 mm Workpiece Spindle: Drilling of Large Diameters: 5 3/64" Cone Upward Gradient on 304.8 mm (1 Foot): 21/32" Deep One of the Cone: 5.29" Diameter of the Whole Spindle Perforating: 3.35" Speeds: B-Axle Workpiece Headstock Drag Axis: 30 Degrees A-Axle Workpiece Spindle Number of Revolutions: 0 83 min-1 X-Axis Horizontal: 80 mm/sec Y-Axis Vertically: 80 mm/sec Z-Axis Carriage Baseplate: 80 mm/sec Hedpsruakgsfx Ahusfb Space Requirement L x W x H (Approximate): 4.75 x 3.40 x 2.54m / 188" x 134" x 100" Machine Weight (Approximate): 10980 kg / 24,156#

Condition: excellent (used), Year of construction: 2015, With a view to optimized and energy-saving drives in the vehicle industry, significantly higher demands are placed on the components of the drive system. Higher power transmission and higher torques combined with smaller size are the challenges. This development has increased the demand for cold-formed splines. With the Vertical Splines Press (VSP) Sack & Kiesselbach provides the customer with a solution that offers technological and also logistical advantages compared to conventional technologies (such as roller burnishing or broaching). The relatively small and very user-friendly press can be configured both manually and as an automated system. In addition to the splines press, the customer can also obtain the appropriate die system and process technology from a single source. 1 used Vertical Splines Press make Sack & Kiesselbach type VSP 50/30 Year 2015 Technical data: Pressing force 500KN ram stroke 450 mm Closing speed 200 mm/s pressing speed 5,5 mm/s opening speed 120 mm/s table dimension 500 x 400 mm installation height 1000mm width between columns 530 mm splines cylinder speed 3-9,5 mm/s Dimensions height 2900 mm Hfjdpfx Ahjgtty Toujb width 3100 mm depth 1400 mm Drive power 8 KW Special equipment Digital measuring system Splines tool for internal splines

Condition: used, Year of construction: 2006, Technical details: grinding diameter: 5-55 mm grinding length: 500 mm total power requirement: 44 kW Hfedpfx Ajvg Thiohuob -- Intended use and general information -- Fully automated external and surface grinding of synchronous rings Centre height: 200 mm Grinding length: 500 mm Grinding wheel arrangement: right, 30° angled Grinding wheel dimensions: 600 x 30 x 203.2 mm Drive power: 7 kW X/Z axis drive: ball screw Travel speed: 0.01 - 10,000 mm/min. Resolution: 1 µm Concentricity of workpiece spindle: < 1 µm Workpiece changing system: Fanuc robot Control: Siemens Sinumerik 840-D Machine weight: 7,000 kg Centre height: 200 mm Grinding length: 500 mm *
