Bevel Gear Generator - Spiral

SARATOV 5A284

Condition: good (used), Year of construction: 2002, max. wheel diameter 275 mm gear width 55 mm max. module 6 Cedotumrpopfx Appsgu min. module 1 Control 840 C Siemens total power requirement 100 kW weight of the machine ca. 16,7 t dimensions of the machine ca. 5,2 x 2,3 x 2,4 m m

Condition: excellent (used), Year of construction: 2006, operating hours: 53,244 h, functionality: fully functional, Technical Data – Gleason Phoenix II 600HC (CNC Hypoid Gear Cutting Machine) Working Area Max. workpiece diameter: Ø 600 mm Max. tooth depth: 24.6 mm Max. gear width: 110 mm Number of teeth: 1–300 Cutterhead size face milling (FM): 18" diameter Cutterhead size hobbing (FH): 210 mm radius Max. cutter spindle speed: 600 min⁻¹ Work Spindle Front taper diameter: Ø 203 mm Taper bore diameter: Ø 181 mm Bore depth: 884 mm Max. work spindle speed: 600 min⁻¹ Cgjdpfoxwzu Iox Appou Dimensions and Weight Footprint L × W × H: 4.4 × 3.5 × 3.5 m (incl. peripherals) Machine weight: 26,000 kg Connection Data Total connected load: 139 kVA Main fuse: 200 A Operating voltage: 400 V Mains frequency: 50 Hz Control voltage: 24 V DC

Condition: ready for operation (used), Year of construction: 1980, Gleason Hypoid cutter Sharpener 13A -1 pcs Milling diameter 89-500 mm Grinding wheel dimensions 305x19x102 mm Cgsdper Elpvjfx Appou Feed 0,05-0,18 mm Grinding wheel drive motor - 1800 rpm (60 Hz) - 1500 rpm (50 Hz) Floor space 1240x2310 mm Height 1422 mm Machine weight 4083 kg Gleason 19 revacicle cutter checking machine - 1 pcs

Year of construction: 1996, condition: good (used), Mehrspindel Schütte SG18 Cgsdpfx Apog S Tx Iepeu

Condition: used, Year of construction: 2006, Brake force 300 tons Working length 6100 mm Distance between uprights 4550 mm Cgjdpfowhcycsx Appju Throat depth 400 mm Punch stroke 320 mm Table width 220 mm Fast speed (0 – 100) mm/sec Woriking speed (0 - 7) mm/sec Upstroke speed (0 – 90) mm/sec Hydraulic pressure (max) 255 bar Main electric motor 18,5 KW Length 7500 mm Width 2900 mm Height 3700 mm Weight (aproxim.) 32000 Κgr

Condition: used, ESCO ESCOMATIC D 6 SR is an Automatic lathe engineered for precision machining, high accuracy and reliable production. Capacity: diameter of work admitted 6 mm; with flat cames max turning length 62 mm; spindle hole 6 mm. Specifications: 3 spindle speeds from 2400 to 6000 rpm; 3 tool cutters; turret slide/revolver 1a (D6-8-Mp 103/a) with 4 tools; voltage 60Hz 220/440 V; total power 2.5 CV; machine weight approx. 1150 kg; footprint L1500 × W1000 mm. Key equipment: turret (D6-8-Mp 103/a) and cam disc. Delivers tight tolerances; suitable for automotive, watchmaking, machine tools, aerospace and medical sectors. Csdpfx Apsyxnv Depegu

Condition: ready for operation (used), Year of construction: 2010, controller manufacturer: FANUC, This ESCO Escomatic EC12 was manufactured in 2010. A Swiss type turning machine, it's ideal for precision and efficiency in small part production. Contact us for more information about this machine. Additional equipment • 3x automatic bar feeders • 1x decoiler unit Machine Benefits Technical Machine Benefits • Bar capacity (through spindle): up to 12 mm • Rated power: 15 kva • Rated current: 32 a • Working voltage: 3-phase, 400v / 50hz Csdpoyar E Refx Appogu • Control voltage: 24v dc • Type of current: ac • Lighting voltage: 24v dc Extra Information 3x identical, fully functional machines available Additional spare parts are also included

Condition: used, Year of construction: 1987, 6-spindle bar automatic lathe Csdsw S Hd Sepfx Appsgu Manufacturer: INDEX Model: MS25 Year of manufacture: 1987

Condition: used, Year of construction: 1999, Technical details: number of spindles: 6 Article: cam-controlled multi-spindle automatic lathe Manufacturer: Schütte Type: SG18 Yob: 1999 six-spindle automatic lathe 6 main spindles as a chucker automatic lathe control Siemens S7-200 PLC loading and disloading in position 6 spindle brake Please, contact us for getting more information and pictures on mail(at) or Cgjdpfx Ajw Hb Treppeu *

Condition: used, TECHNICAL DETAILS - Number of spindles : 8 - Number of counter-spindles : 1 Cgsdewdahiopfx Appou - Hirth teeth - Number of cross slides : 8 - Max. production : 50 [parts/min] SPINDLES * Max. bar diameter : 21 [mm] * Spindle speeds : 620-6000 [rpm] COUNTER-SPINDLE - Mechanical counter-spindle POWER SUPPLY - Supply voltage : 380 [V] WEIGHT & DIMENSIONS - Machine floor space : 4700x1200 [mm] - Machine height : 2250 [mm] - Machine weight : 5850 [kg] EQUIPMENT - CNC : Fanuc Power mate - Oscillating stop - Coolant tank - Bar loader : PRA 40/33F - Bar holder and stand
