Vertical Turret Lathe - Double Column

SCHIESS BRIGHTON Vertimaster

Condition: ready for operation (used), Year of construction: 2017, turning length: 3,000 mm, turning diameter: 1,050 mm, spindle speed (max.): 1,500 rpm, chuck outer diameter: 375 mm, Multitasking Machine OKUMA MULTUS B750 C3000 YEAR2017 OSP-P300SA 15" chuck Max Machining dia:1050mm Length:3000mm Dedpfx Aewi Ezreh Secb

Condition: used, Year of construction: 1981, machine/vehicle number: 78.977, Equipment: documentation/manual, Year of manufacture: 1981 / Year of retrofit: 1996/1997 Control: Siemens 840 C Siemens control for X/Y/Z/W/U/B/V axes Spindle diameter: 200 mm Main motor Siemens: 68 kW Spindle speeds: I gear: 3 - 202 rpm Dodpfx Ahoqc Umge Secb II gear: 180 - 808 rpm X travel: 12,000 mm Y travel: 4,500 mm Z travel: 2,400 mm (supporting sleeve □ 520 mm/travel 1200 mm + W axis 1200 mm) Mount: SK60 (SK50) Facing slide: yes Milling head: 2 units Prepared for CNC rotary table (4th axis) Without rotary table and clamping field (available separately) Full documentation Net weight: approx. 140 tons Video available!

Condition: excellent (used), FANUC Professional 6 Control Working travels 900 x 900 x 1020 mm Tool changer with 136 Positions Spindle speeds -10'000 rpm Spindle taper HSK100 2 paletts 630 x 630 mm Dodox A E Enepfx Ah Sscb B-axis 0.001° Palett changer FASTEMS FPC1500 Cooling through spindle 3D measuring taper Tool breakage control device Tool lenght measuring device Chip conveyor Misc. accessories MARCELS MASCHINEN AG

Condition: excellent (used), Year of construction: 2010, travel distance X-axis: 800 mm, travel distance Y-axis: 950 mm, travel distance Z-axis: 1,020 mm, controller model: Siemens 840D sl, spindle speed (max.): 9,000 rpm, operating hours of spindle: 10,590 h, spindle motor power: 65,000 W, SLIDE Working travels in X- / Y'- / Z-axis [mm] 800 / 950 / 1020 B-axis 360° A-axis -185°/+45° Max. speeds in X- / Y'- / Z-axis [m/min] 90 / 50 / 90 Max. acceleration in X- / Y'- / Z-axis [m / s2] 8.5 / 4.5 / 14 Max. feed force in X- / Y'- / Z-axis [kN] 8 / 8 / 12 MAIN SPINDLE Dsdpfx Asxrcureh Secb Tool interface for short hollow taper tools acc. to ISO 12164-1 HSKA100 Diameter at front bearing of spindle bearing [mm] 110 Speed nmax [rpm] 9000 Max. drive power at 100% / 40% duty cycle [kW] 54 / 65 Max. spindle torque at 100% / 40% duty cycle [Nm] 470 / 575 PART Table diameter [mm] 770 Table load [kg] (with / without pallet) 700 / 800 Interference diameter [mm] 900 EQUIPMENT LEVELS Automatic pallet changer 2-fold Pallet size [mm] 630 x 630 Pallet change time [s] 13.0 Tool magazine expansion TM180 (HSK-A100)

Condition: good (used), Year of construction: 1998, functionality: fully functional, workpiece weight (max.): 10,000 kg, FMS with Pietro Charnaghi AC 16 TM and Colgar Prog 213 TR 120-90 Both Siemens Sinumerk controller Dedpfxswma H Re Ah Sjcb 7 stk. Palett Ø1300mm

Year of construction: 1987, condition: ready for operation (used), A CNC travelling column boring and milling machine Schiess is available. Travel X/Y/Z: 10500mm/5000mm/1200mm, quill stroke: 1250mm, quill diameter: 225mm, speed: 750rpm, spindle power: 100kW, spindle torque: 18000Nm, tool holder: SK50/SK60. Machine dimensions: approx. 17000mm/11000mm/8400mm, controls: Siemens 850M. Without platen field. Documentation available. An on-site inspection is possible. Dcodexrf Ibepfx Ah Ssb

Condition: used, Year of construction: 1987, functionality: fully functional, turning height: 3,000 mm, workpiece weight (max.): 50,000 kg, turning diameter: 4,000 mm, Technical data Siemens Sinumerik 840 DSL control system Main dimensions and travels Face plate diameter 3,500 mm Rotation diameter (max.) 4,000 mm Workpiece height (max.) 3,000 mm Total height of the machine 7,250 mm Maximum workpiece weight 50,000 kg Table base Y Horizontal table displacement 2,000 mm Cross beam Vertical adjustment of the crossbeam in 50 steps 1,500 mm Crossbeam support (right) Horizontal adjustment of support -25 + 2170 mm Dcodju R D Tnspfx Ah Seb Vertical displacement of the chisel slide 1,800 mm Cross-section of the chisel slide 250x210 mm Tool positions Cross beam support (left) Horizontal adjustment of support -25 + 2170 mm Vertical displacement of the chisel slide 1,800 mm Cross-section of the chisel slide 250x210 mm Tool changer without side support (right) Main drive: Power of the main motor 100 kW Speed range of the faceplate 1-100 rpm. Maximum torque on the face plate 100 kNm Drilling and milling drive vertical support: Power of the drive motor 22.5 kW Maximum torque 900 Nm Without drilling and milling drive side support Total weight Connection values of the machine Machine connection voltage 380 Volt / 50Hz Control voltage 220V AC / 24V DC Total connected load 150 kVA Required back-up fuse 400 A Equipment and accessories: Operator platform Chip conveyor Cooling lubricant system Tool changer Tool measuring probe RENISHAW

Condition: used, Year of construction: 1995, functionality: fully functional, Technical data Control system Siemens Sinumerik 840 Dsl Main dimensions and travels Face plate diameter 3,600 mm Rotation diameter (max.) 4,200 mm Workpiece height (max.) 4,800 mm Total height of the machine 8,700 mm Maximum workpiece weight 80,000 kg. Table base Y Horizontal table displacement 2,000 mm Cross beam Vertical adjustment of the cross beam in 100 mm steps 2,800 mm Crossbeam support (right) Horizontal adjustment of support - 1,800 to + 2,200 mm Vertical adjustment of the chisel slide 1,500 mm Cross-section of the chisel slide 240x240 mm Tool positions 20 pcs. Without vertical support (left) Lateral support (right) Vertical adjustment of support 2,800 mm Horizontal displacement of the chisel slide 1,000 mm Cross-section of the chisel slide 240x240 mm Turning diameter max./min. 4500/2500 mm Tool changer Main drive: Power of the main motor 105 kW Speed range of the faceplate 0.4-90 rpm Maximum torque on the faceplate Drilling and routing drive Vertical support: Power of the drive motor 22.5 kW Maximum torque 900 Nm Side support drilling and milling drive: Dodju R Imlepfx Ah Secb Power of the drive motor 22.5 kW Maximum torque 900 Nm Connection values of the machine Machine connection voltage 380 Volt / 50Hz Control voltage 220V AC / 24V DC Total connected load 150 kVA Required back-up fuse 400 A Equipment and accessories: Operator platform Chip conveyor Cooling lubricant system Tool changer Tool measuring probe RENISHAW

Condition: used, Used Netzsch model LMZ2 stainless steel bead mill with associated parts. Unit has stainless steel peg style rotor and stainless steel jacketed chamber. Unit driven by 7.5hp, 230/460volt, 1770rpm, 3/60 electric motor with transformer. Unit includes mechanical seal. Approximately 2 litre capacity. Unit includes feed pump and control panel. All mounted on stainless steel base. Dodpfjx Niwqsx Ah Sjcb

Condition: used, Year of construction: 1992, functionality: fully functional, turning height: 1,500 mm, workpiece weight (max.): 130,000 kg, turning diameter: 6,500 mm, Technical Datas: Dcedpfx Aheu R Euas Sob CNC-Control SIEMENS Sinumerik 880T Faceplate diameter 6.000 mm max. turning high 2,300 mm max. turning diameter 6,500 mm Ram 2 pieces Ram travel 1,000 mm Cross beam adjustment 800 mm Max. Table load 130 to Speed faceplate 0,56 - 63rpm Machine weight 180 to Power main motor 105 kW Dimensions L/W/H 16.500x10.600x5.500 mm Accessories: - 2 supports with live spindle 30 KW, 2160 rpm, with 2 gear stage. - Chip conveyor - cooling lubrication system
