TOS Vertical Lathe model SK 12 A

Tos SK 12 A

Condition: good (used), Year of construction: 2014, spindle turning speed range 170 - 18000 U/min weight of the machine ca. 7,5 t dimensions of the machine ca. 5,00 x 4,00 x 2,20 m --> Control conversion (2014) to Siemens Sinumerik 840D Solutionline --> Overhaul of the new control system in 2016 --> Technical data Grinding diameter: 20 - 300 mm --> Oscillation diameter: 350 (500) mm Dodpfx Adew Intae Nekl --> Workpiece length: 300 (1300) mm --> Recommended grinding depth up to: 300 mm --> Grinding table stroke Z-axis (total): 650 (950) mm --> Resolution: 0.001 mm --> Rapid traverse: 12 m/min-1 --> Grinding stroke speed: 0 - 9.99 m/min-1 --> Feed rate: 0 - 99.99 m/min-1 --> Step feed value during reversal: 0 - 0.999 mm --> Grinding table stroke X-axis (total): 150 mm --> Resolution: 0.001 mm / Ø --> Rapid traverse: 5 m/min-1/R --> Grinding stroke speed: 0 - 5 m/min-1/R --> Feed rate: 0 - 99.99 m/min-1/R --> Step feed value during reversal: 0 - 0.999 mm / Ø --> Swivel capability of the workpiece headstock: --> B-axis: -32° (-23°) / +2° --> Resolution: 0.0001° (0.36") --> U-axis stroke (total): 300 mm --> Resolution: 0.001 mm / Ø --> Travel speed: 5 m/min-1 --> Centre height above workpiece table: 200 (300) mm --> Centre height above grinding table: 330 (430) mm --> Workpiece spindle passage: 50 (70) mm --> new in 1988

Condition: reconditioned (used), functionality: fully functional, turning diameter over cross slide: 690 mm, spindle bore: 150 mm, turning diameter: 1,040 mm, turning diameter over top slide: 690 mm, center height: 500 mm, center width: 2,000 mm, spindle speed (max.): 5,000 rpm, travel distance X-axis: 160 mm, travel distance Z-axis: 380 mm, bar passage: 55 mm, Center height: 500 mm Distance between centers: 2.000 mm Maximum turning diameter: Over cross slide: 690 mm Over bed: 1.040 mm Over gap: 1.070 mm Bed width (hardened guides): 670 mm Gap length: 480 mm Gap length in front of the faceplate: 320 mm CARRIAGE Length of bed guideways: 1.020 mm Cross slide travel: 640 mm Compound slide travel: 360 mm SPINDLE Spindle nose: ASA 15’’ Spindle bore diameter: 150 mm Front bearing size (NN): 200 / 310 / 82 mm Rear bearing size (NNU): 190 / 260 / 69 mm Internal Morse taper reduction sleeve: No. 6 Number of spindle speeds: 24 Speed range: 4 ÷ 800 rpm THREADING Total number of threads: 398 Metric threads: 0.5 ÷ 224 mm Module threads: mod. 0.25 ÷ 11 Whitworth threads: 56 ÷ 1/8 TPI Diametral pitch threads: 112 ÷ 1/4 DP FEEDS Number of feeds: 108 Longitudinal, cross and compound feeds: 0.05 ÷ 22.4 mm/rev RAPID TRAVERSES Dkjdoyhhuwepfx Ad Nsl Longitudinal, cross and compound: 2.500 mm/min Longitudinal return: 5.000 mm/min TAILSTOCK Quill diameter: 130 mm Quill Morse taper: No. 6 Quill travel: 420 mm STEADY RESTS Bed steady rest capacity: 140 ÷ 500 mm Carriage steady rest capacity: 40 ÷ 350 mm PERMISSIBLE LOAD Cantilever load: approx. 1.500 kg Between centers, without steady rest: approx. 5.000 kg Between centers, with steady rest: approx. 6.000 kg Machine weight: approx. 7.800 kg

Condition: used, Year of construction: 1981, machine/vehicle number: 78.977, Equipment: documentation/manual, Year of manufacture: 1981 / Year of retrofit: 1996/1997 Control: Siemens 840 C Siemens control for X/Y/Z/W/U/B/V axes Spindle diameter: 200 mm Main motor Siemens: 68 kW Spindle speeds: I gear: 3 - 202 rpm II gear: 180 - 808 rpm X travel: 12,000 mm Y travel: 4,500 mm Z travel: 2,400 mm (supporting sleeve □ 520 mm/travel 1200 mm + W axis 1200 mm) Djdpfxsqc Umge Ad Nekl Mount: SK60 (SK50) Facing slide: yes Milling head: 2 units Prepared for CNC rotary table (4th axis) Without rotary table and clamping field (available separately) Full documentation Net weight: approx. 140 tons Video available!

Condition: good (used), Magnetic table 455 x 170 mm digital display Dkedotu Il Topfx Ad Njl water tank Honing device Wet sanding device

Condition: excellent (used), Year of construction: 1991, functionality: fully functional, travel distance X-axis: 500 mm, travel distance Y-axis: 350 mm, travel distance Z-axis: 120 mm, travel distance W-axis: 450 mm, For sale: Hauser coordinate grinding machine, model S35-400 The machine is in excellent condition and underwent a partial overhaul in 2024 for €15,000. The machine is equipped with 6 high-quality grinding motors, a face motor, and turbines. TECHNICAL DATA Distance between column and spindle: 365 mm Clearance between table and spindle: 485 mm Main spindle diameter: 100 mm X-axis: 500 mm Y-axis: 350 mm Z-axis: 120 mm W-axis: 450 mm U-axis: 5.5 mm Maximum taper grinding: 16° Table size: 600 x 380 mm T-slots: 6 units, 10 mm width, 50 mm spacing Table load capacity: 300 kg Speeds and Tool Holders Speed 22S: 4,500 - 22,500 rpm 45S/45ST: E19 Speed 45S/45ST: 9,000 - 45,000 rpm Dsdpfowtqthox Ad Nskl 80S: F6 Speed 80S: 40,000 - 80,000 rpm T10/T16: Ø 3 mm Speed T10/T16: 100,000 / 160,000 rpm Slot grinding attachment: 2,900 - 34,500 rpm Planetary movement: 5 - 250 rpm C-axis: 0 - 5 rpm X/Y feed: 0 - 1,200 mm/min W-axis feed: 900 mm/min Z-axis feed: 0.5 - 12,000 mm/min MACHINE DETAILS Digital measuring accuracy: 0.001 mm Base deviation: 0.003 mm Power: 7.5 kW Compressed air requirement: 20 m³ System pressure: 5 bar Footprint: 3.5 x 4.4 m Machine height: 3.5 m Connection value: 8.3 kVA Weight: 3.1 t EQUIPMENT - Slot grinding attachment - Rotary table, 300 mm diameter - Swivel table, 200 mm diameter - Coolant system - Extraction unit - Very high-quality accessories included Transportation and loading can be arranged across Europe at extra cost upon request. Prices plus VAT. Viewing by appointment is possible. Contact us—our team is happy to assist you. Trade-in or exchange possible! MACHINE PROCUREMENT / SALES PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MORE. Are you looking for a high-quality yet affordable metalworking machine for your production? Or do you want to sell yours? For more information or contact options, visit our website.

Condition: ready for operation (used), Broadbent Heavy Duty Lathe 1041mm x 10,000mm Year approx. 1973. Swing over bed 1041mm (41”) Swing bin gap1575mm (62”) Distance between centres 9300mm (30’ 6”) Spindle bore 115m (4 ½”) Spindle speeds (18) 3.3 – 360 rpm Spindle motor 30 HP or 40 HP (To be confirmed) Tailstock 6 MT Imperial Metric screw-cutting with change gears. 36” Faceplate with 4 adjustable jaws, 54” Faceplate, Taper turning attachment, Dsdov I T Ewopfx Ad Nskl Power feed to top slide, 2 x 18” 3 point steadies, 24”/28” Steady.

Year of construction: 1981, condition: excellent (used), faceplate diam 1300mm Djdpfx Adjk Dz N Ij Nskl max turning diam 1100mm range of turning diam 460-1250mm

Condition: excellent (used), 1 permanent - magnetic Chuck D = 315 mm Dksdpfxod Eaauj Ad Nsl with mounting flange DIN 55027 Gr. 6

Condition: used, Year of construction: 1991, bore capacity in steel (diameter) 50 mm arm length 1100 mm Djdpfju Sblwsx Ad Nskl workpiece height max. ca. 1000 mm bore capacity in cast iron 60 mm spindle taper MK 5 spindle turning speed range 28 - 2500 U/min feeds 0,05 - 2 mm/U quill stroke 300 mm distance basic plate - spindle nose 630 - 1380 mm crossrail adjustment vertical 750 mm total power requirement 6 kW weight of the machine ca. 4 t dimensions of machine L x W x H 2,74 x 1,14 x 2,59 mm - with thread cutting attachment - Accessories: box table 550 x 550 x 550 mm, vice, coolant

Condition: excellent (used), spindle bore: 84 mm, turning diameter: 1,000 mm, turning length: 5,000 mm, quill stroke: 300 mm, total length: 11,380 mm, total width: 2,200 mm, spindle speed (max.): 500 rpm, spindle speed (min.): 5 rpm, swing diameter over cross slide: 1,876 mm, metric thread diameter (min.): 1 mm, metric thread diameter (max.): 120 mm, overall weight: 17,730 kg, quill mount: MK 5, faceplate diameter: 1,000 mm, Heavy duty lathe is in a very nice condition, under power. It is equipped with lunette and steady rest. Carriage is overhauled, shaft bronze bushings are new. Djdpfxsxwd D Es Ad Nskl
