Press Brake

TRUMPF V 85

Condition: good (used), Year of construction: 2001, functionality: fully functional, Hydraulic press brake Make: TRUMPF Model: TrumaBend V85S Year of manufacture: 2001 Technical specifications Manufacturer: Trumpf Model: TrumaBend V85 S Year: 2001 Pressing force: 85 t Bending length: 2550 mm Throat depth: 420 mm Stroke: 215 mm Dimensions: L 3.1 x W 1.80 (plus 0.5 m support arms) x H 2.40 m Weight: 8.8 t Equipment - Controlled axes: Y1, Y2, X, R, Z1, Z2 - 2 movable support arms - CNC-controlled crowning - Hydraulic upper tool clamping system (Trumpf system) - Pneumatic die shifting - Delem 2D graphical control - Tool package: Upper tool, straight, H 140 mm, R 1 28°, L 2500 mm, segmented Lower tool V8/86°, H 100 mm, L = 2500 mm, segmented All specifications without guarantee. Lodoy Dr Ibspfx Akyshf A demonstration is possible at any time in our showroom.

Year of construction: 2001, condition: used, Technical details: x-travel: 400 mm y-travel: 300 mm z-travel: 500 mm table clamping surface:: 400 x 300 mm table load: 50 kg semi-automatic operated: LASERSOFT 3D laser capacity: 100 W total power requirement: 27 kVA weight of the machine ca.: 2,5 t dimensions of the machine ca.: 3 x 3,5 x 2,8 m CNC engraving/texturing/labeling/contouring-laser maschine, Lhjdpfoikbtnsx Akyef approx. 9.000h "machine on", approx. 5.500h "laser on" *

Condition: good (used), Year of construction: 2005, Used 2-meter CNC press brake from Trumpf Model: TrumaBend V85s Ledsy Dpufjpfx Akyohf Capacity: 2050 x 85 tons Control: Delem DA69 Axes: Y1, Y2, X, R, Z1 and Z2 Hydraulic WILA upper and lower clamping Year of manufacture: 2005

Condition: ready for operation (used), Year of construction: 1998, pressure 85.0 t chamfer lenght 2050 mm distance between columns 1750 mm column arm 410 mm stroke 365 mm dayligth 535 mm ajustment speed 200 mm/sec working feed 1.0 - 10.0 mm/sec return speed 135 mm/sec back stop - adjustable max. 600 mm table width 120 mm work height max. 1050 mm Number of working hours 28.500 h oil volume 200 l operating pressure 340 bar total power requirement 14.0 kVA weight of the machine ca. 9050 kg range L-W-H 2680 x 2100 x 2885 mm with increased installation height / piston stroke very well maintained condition (!!) Ledpfexaa Ursx Akyjhf with only approx. 28.500 operating hours - in checked condition - machine video - ?v=ZuwyPKJSYLw Equipment: - CNC electro-hydraulic press brake - including DELEM CNC control * swiveling control panel at the front left - CNC controlled axes: Y1 - Y2 - X - R - Z1 - Z2 - I + CNC crowning - CNC electro-motorized back stop (X axis) - CNC electro-motorized height adjustment of the back stop (R axis) - CNC electro-motorized adjustment of the stop fingers (Z axes) - CNC pneumatic die displacement (I axis) - CNC motorized table crowning - WILA electro-hydraulic upper tool clamping - WILA electro-hydraulic Lower tool clamp - 1x freely movable 2-hand / foot control - 2x front, stable support arms including "sliding system" - side protective device (swinging doors) - rear protective device (swinging doors) - bending tool storage cabinet (right front, side) - original operating instructions + circuit diagram etc. further technical data: - feed speed X axis .. 500 mm/sec. - feed speed R axis .. 300 mm/sec. - feed speed Z axis .. 1000 mm/sec. - travel range X axis .. max. 600 mm - travel range R axis .. max. 250 mm

Condition: excellent (used), mileage: 582,537 km, first registration: 04/2009, fuel type: diesel, axle configuration: 10x4, fuel: diesel, brakes: retarder, color: white, driver cabin: sleeper cab, gearing type: mechanical, emission class: euro5, Year of construction: 2009, Equipment: ABS, air conditioning, crane, cruise control, electric window regulation, parking heater, power mirror, retarder, soot filter, spoiler, = Additional options and equipment = - Aluminum fuel tank - Low noise emission - Speed limiter - Refrigerator - Air suspension - Air horn - Particulate filter - Sun visor - Stability control - Auxiliary heater - Toolbox - Power take-off (PTO) - Central lubrication system = Further information = Axle configuration Front axle 1: Steered Front axle 2: Steered Rear axle 1: Steered Rear axle 2: Twin tires Rear axle 3: Twin tires Weights Unladen weight: 36,399 kg Payload: 17,601 kg Gross vehicle weight: 54,000 kg Functional Mast: Telescopic (8 sections) Mast length: 24 m Lifting capacity: 30,000 kg Lifting height: 2,400 cm Crane: FASSI F1500AXP.28, mounted behind the cabin Superstructure brand: FASSI F1500AXP.28 CE marking: yes Condition Technical condition: very good Visual condition: very good Financial information Price: On request Identification Registration number: BV-XP-06 DAF XF 105.510 10X4 Tractor Unit + FASSI F1500AXP.28 Crane EURO 5 L PACKAGE 480 HP DRIVE 10X4 WHEELBASE 570 CM AIR SUSPENSION XF SLEEPER CAB WITH AIR CONDITIONING, AUXILIARY HEATER, REFRIGERATOR MANUAL TRANSMISSION FIFTH WHEEL MULTIPLE TOOLBOXES Lhjdpfeuxu Thox Akyof FASSI F1500AXP.28 CRANE 150 T/M CRANE!!! 2X OIL COOLERS FOR CRANE HYDRAULICS 8X HYDRAULICALLY EXTENDABLE WORKING HEIGHT 24 METERS MAX LIFTING CAPACITY 30,000 KG MAX LIFTING CAPACITY AT 19.4 METERS 4,465 KG CENTRAL LUBRICATION SYSTEM FOR THE CRANE 4X OUTRIGGERS RADIO REMOTE CONTROL FOLLOW US ON INSTAGRAM: GEURTSTRUCKS WE SPEAK GERMAN WE SPEAK ENGLISH HABLAMOS ESPANOL

Condition: used, Year of construction: 2000, machine/vehicle number: 883512, Dimensions: 257 cm width x 220 cm depth x 242 cm height Weight: 7,900 kg Max. pressing force: 850 kN (85 tonnes) Lodsylh Sqepfx Akyohf Max. bending length: 2,050 mm Distance between uprights: 1,750 mm X-axis travel: 600 mm Max. stroke: 215 mm Controlled axes: X, Y, R, I Control system: Delem Equipment: 4 stops Condition: R-axis has correction error. R-axis reaches bottom end switch, must be manually raised (needs new referencing). Y-axis (pressure beam) sinks at an angle. Crowning: wedge-type crowning The machine is operational and in good overall condition.

Condition: used, Year of construction: 1994, machine/vehicle number: 883050, functionality: fully functional, Dimensions: 257 cm width x 220 cm depth x 242 cm height Weight: 8,320 kg Max. pressing force: 850 kN (85 tons) Max. bending length: 2,050 mm Lsdpfx Akoylh N Nsyohf Distance between uprights: 1,750 mm X-axis travel: 600 mm Stroke height: 220 mm Controlled axes: X, Y, R, I Control system: Delem Equipment: 6 backgauges Condition: Technically sound, except for oil leakage Crowning: wedge-type crowning The machine is operational and in good overall condition.

Condition: good (used), Year of construction: 2007, travel distance X-axis: 750 mm, travel distance Y-axis: 750 mm, travel distance Z-axis: 725 mm, CNC control Sinumerik 840D NC-rotary table B-axis automatic tool changer for 320 tools pallet changing device, 2 pallets 500 mm x 500mm coolant through spindle device IKZ (80 bar) chip conveyor coolant device Technische Daten / technical details: X-Weg längs / X-travel longitudinal 750 mm Y-Weg senkrecht / Y-travel vertical 750 mm Ljdpfx Akeq Ui Hqeyjhf Z-Weg quer / Z-travel cross 725 mm B-Achse / B-axis 360 ° Spindelaufnahme / spindle taper HSK 63A Drehzahlbereich Spindel / spindle speed 50-10000 Upm /rpm Werkzeugplätze / tool places in changer 320 Vorschub / infeed 60000 mm/min Eilgang / rapid feed 60 m/min Antriebsleistung Spindel 40/100% ED / drive capacity spindle 40/100%ED 37/24 kW Gewicht der Maschine ca. / weight ca. 15000 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: excellent (used), Year of construction: 2003, functionality: fully functional, 85 t x 2500 mm Lhedpfsyxri Iex Akysf Weight: 9000 kg (without tools) Between columns: 2050 mm Service: In 10/2023, the pump was replaced by TRUMPF at a cost of EUR 10,000. Since then, the machine has operated approximately 200 machine hours.

Year of construction: 2001, condition: good (used), Used Trumpf V series cnc pressbrake for sale Trumpf v85 2.5m x 85ton – 6axis cnc pressbrake / with Extended daylight and stroke Make: Trumpf Model: v85 Year: 2001 Total axis: 4axis back gauge / total axis 7 – y1 y2 x r z1 z2 and i axis Complete with: • Usb upgrade on the control • Extended stroke and daylight: 365mm maximum stroke / 535mm daylight • 4axis back gauge Lodpfx Asf Txi Sekyohf • i axis – bottom base moves to use twin multi v without operator moving or changing the tooling • Fully serviced / Good condition • Full length of top and bottom tooling – brand new Trumpf pressbrake tooling in stock available for sale Delivery to your works, installation and tuition with your operators available.

Condition: used, Year of construction: 2017, Technical details: Lsdpfx Aeyxpv Sskyehf turning diameter: 356 mm turning length: 705 mm control: CELOS M730 UM MAPPS swing dia.: 742 mm standard turning diameter: 275 mm travel -x axis: 260 mm travel -y axis: 100 ( ±50) mm travel -z axis: 795 mm rapid travel - longitudinal/face: 30 / 30 m/min Rapid travel B-axis (parts transfer subspindle): 734 m/min Spindle 1 RPM: 4000 1/min Spindle 1 Power: 15/18,5/18,5 kW Spindle 1 Torque: 409/505 /599 Nm Spindle 1 max. bar diameter: 80 mm Spindle 2 RPM: 4500 1/min Spindle 2 power: 7,5/11 kW turret stations / rotary tool stations: 20 / 20 BMT40 speed of driven tools: 10000 1/min : 3.7/5,5/5,5 kW torque rotary tools: 14 / 24 Nm total power requirement: 38 kVA weight of the machine ca.: 6,3 t dimensions of the machine ca.: 4 (9) x 2,1 x 2,2 m Accerories Chip conveyor Barfeeder Interface Parts catcher Sp. 1 und Sp. 2 Parts and total counter Signal lamp 3 colors Spindle 1 Chuck Kitagawa B 210 (250 mm) Spindle 2 Chuck Kitagawa B 206 (160 mm) Conveyor for partsdisposal Automatic door Interface for coolant through the spindle Coolant through spindle 70 bar Knoll Program restart Tool presetter Spindle 1 & 2 Coolant shower 1m Barfeeder magazine IRCO High precision Turning and Milling Centre with Y-axis and sub spindle. Easy programming by CELOS-MAPPS 4 Control. Very low cutting hours. Machine is like new. All existing toolholders and life tool holders come with the machine. *

Condition: excellent (used), Year of construction: 1996, functionality: fully functional, Used very clean, well maintained Trumpf V 85S series hydraulic down stroke cnc pressbrake with a large amount of tooling for sale Trumpf v85s 2.5 metre x 85ton – 4axis cnc pressbrake in good condition Make: Trumpf Model: Trumabend v85s Year: 1996 Max. pressing force: 850 kn / 85ton Max. stroke: 215mm Brake time: 86ms Total axis: 2axis back gauge / total axis 4 – y1 y2 x r and i axis Large amount of upper and lower Trumpf tooling, some tooling is brand new Complete with: • 2 axis back gauge • i axis – bottom base moves to use twin multi v without operator moving or changing the tooling Lsdpfxer Hcl Ao Akyjhf • Fully serviced / Good condition

Condition: ready for operation (used), Year of construction: 2001, number of axes: 5, This 5-axis TRUMPF TrumaBend V85 press brake was manufactured in 2001. It features an electro-hydraulic ram drive, CNC backgauge system, and a modern protective cover. The machine includes a 4-axis back gauge system and both hydraulic upper and lower tool clamping. If you are looking to get high-quality bending capabilities, consider the TRUMPF TrumaBend V85 machine we have for sale. Contact us for more information about this machine. Additional equipment • Top drive concept in two-cylinder design y1/y2 • Electro-hydraulic ram drive with proportional valve technology • Ram travel measuring system with spring deflection compensation via glass scales • Modern block hydraulics • Cnc backgauge system • Safe finger adjustment from the front Lhodpfxjx D Nkdo Akyjf • Self-centring, manual, hardened upper tool holder for vertical tool change • Hardened, manual lower tool holder • Programme-controlled lower tool displacement (i-axis) for 2 positions • Modern protective cover Machine Benefits Technical Machine Benefits • Oil cooler • Working width 2. 000mm Extra Information Special Equipment: Back gauge system 4 axes (X, R, Z1, Z2) Hydraulic and hardened upper tool clamping (Wila system) Hydraulic lower tool clamping (Wila system) CNC crowning BendGuard safety device 2 pcs. Support brackets Network No tools included

Condition: used, Year of construction: 2014, INDEX C200 CNC Lathe 3 Turrets 2 spindles Fanuc Control: 31i-Model B Axial Motorized Switches: 6 pcs Radial Motorized Switches: 13 pcs Tool Holders: 11 pcs Boring Bar Holders: 21 pcs Pin: 1 pcs Loader Bushings + Sleeves: Ø51/Ø46/Ø41 New MBL loader bushings: 2 sets 2 optical scales overhauled by HEIDENHAIN 1 Balluff Socket Gantry Arms Box with various sensors and proximity switches and cables Motorized Belts: 6 pcs Set of anti-vibration bushings for MBL loaders Start-up time: Lodpfx Akexxm Hfoyehf On time: 37946 Hydraulic hours: 37,500 Production time: 26,500 With MBL Bar Feed

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, stroke length: 215 mm, throat depth: 410 mm, bending force (max.): 85 t, distance between stands: 1,750 mm, working length: 2,050 mm, TECHNICAL DETAILS Press force: 85 t Bending length: 2,050 mm Distance between uprights: 1,750 mm Stroke: 215 mm Throat depth: 410 mm MACHINE DETAILS Control: DELEM Dimensions & Weight Machine dimensions: 2,700 x 2,100 x 2,400 mm Weight: 7,900 kg EQUIPMENT Two-hand operation 2 support arms Side safety doors Lasersafe Fissler Wila tool clamping Adjustable die position Lhodpeyhmdqofx Akysf Crowning system Tool cabinet
