Used Cursal Trv 1700 for sale (2)

Condition: ready for operation (used), Technical characteristics Numerical control pusher with defect reader and cutting optimization The defect is detected by a camera which identifies a mark made with fluorescent chalk Pusher carriage with advancement speed 60/230 m/min with Brushless motor Useful stroke from 500 mm to 6100 mm Group of 6 chains for the loading and the approach of the boards Pneumatic lifting Capacity 50 kg per meter Variable distance between centres, length of chains 1200 mm Automatic crosscut saw TRV1700 P 500 Vertical pneumatic press Advancement from right to left Cutting time adjustable from 0.1 to 1 s Thickness of boards min 10 mm, max 120 mm Board width min 30 mm, max 300 mm Blade motor HP 5.5 and automatic braking Discharge belt Pneumatic ejector selector Max weight of the board 15 kg Length of the piece to be ejected min 200 mm, max 500 mm Numerical control sorting belt With NC ejector Fixed speed 50m/min Chain transfer inclined discharge/side load Inclination max 15° (= height 120 mm, length 1000 mm) Center distance 2500 mm, chain length 1600 mm Discharge belt Motor 0.5 HP Fixed speed 50 m/min Length 3000 mm x depth 400 mm x height 900 mm Conveyor belt for the discharge of inclined cuts 45° inclined waste discharge belt with blind h 40 mm, pitch 300 mm Speed 8m/min Lifting height from 500 mm to 1900 mm Data transmission to PC Transmission mode via USB stick, RS232 cable Njdpfx Afjt Hncqsxjlh Power and Motors Pluging: Three-phased Overall dimensions

Condition: new, Year of construction: 2025, TRV 1700: High-Performance Optimizing Saw for Finger Joint and Moulders The TRV 1700 is the ultimate solution for woodworking professionals, offering precision, speed, and advanced optimization. Designed in three different configurations with Ø 500, 550, and 600 mm blades, this optimizing saw is available in the following versions: TRV 1700A – Automatic with programmed cutting TRV 1700E – EB – Optimized cutting to maximize yield and reduce waste Nljdev Iqbpopfx Afxoh TRV 1700S – Simple cutting on mark for essential operations Thanks to its high versatility, the TRV 1700 is perfect for quickly removing knots and defects from wooden boards. It is the ideal machine for applications where maximum length is a priority, such as parquet flooring, or when only defect selection is required. Advanced Optimization Software Over 100 cutting plans, customizable by width and quality Smart optimization algorithm for: Commercial value Waste reduction Quantity Length Mixed optimization Pre-cut simulation for maximum efficiency Real-time monitoring of processed quantities Integrated optimization within the saw, simplifying the workflow Machine Structure & Technical Features Reliable conveyor belt traction system without adhesive parts Non-slip rubberized pressure wheels, suitable for all materials Thick pressor for safe clamping of chips and irregularities PLC-controlled silent blowers for continuous workspace cleaning The TRV 1700 integrates seamlessly with moulders and finger jointers via Cursal’s feeding systems, ensuring a smooth and efficient in-line production process. With a wide range of customizable accessories (see the dedicated section), it can be upgraded from a standard version to a fully equipped high-end configuration. Recommended Applications Parquet flooring – Ideal Windows and construction – High compatibility Furniture components – Well-suited Laminated beams, planks, structures – Well-suited Finger joint recovery – Ideal Choose the TRV 1700 for optimized cuts, reduced waste, and maximum production efficiency.
