Used Favretto Surface Grinding Machine for sale (8)

Condition: used, Year of construction: 1982, grinding length 2500 mm grinding width 600 mm Pgsdpfx Agsyqtbbs Dok workpiece height 800 mm Table dimensions 2500x600 mm vertical movement 800 mm throat 650 mm filter system The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: refurbished (used), functionality: fully functional, grinding length: 680 mm, grinding width: 350 mm, grinding height: 300 mm, table length: 600 mm, table width: 300 mm, grinding wheel width: 50 mm, spindle speed (max.): 1,400 rpm, CAPACITY Max. longitudinal table travel: mm 680 Max. cross travel of grinding wheel: mm 300 Max. grinding width: mm 350 Max. grinding height with standard wheel: mm 300 TABLE Table surface dimensions: mm 600 x 300 Length of T-slots: mm 850 Size and center distance of the three T-slots: mm 16 x 100 Continuously variable speed: m/min 2 – 30 GRINDING WHEEL Standard dimensions (diameter x bore): mm 356 x 127 Standard width: mm 50 Max. permissible width: mm 76 Max. external diameter – upon request: mm 406 Speed with 50 Hz motor: rpm 1,400 Incremental cross feeds: mm 1 – 10 Continuously variable cross movements: m/min 0.1 – 6 Automatic vertical feeds – upon request: mm/min 0.005 – 0.05 MOTORS, three-phase AC – 50 Hz: Grinding wheel rotation, 4 poles: kW (HP) 5.5 (7.5) Hydraulic unit, 2 poles: kW 2.2 (3) Pgodpfx Ajymlcvsg Djk Rapid vertical movements, 4 poles – upon request: kW 0.37 (0.5) Coolant unit, 2 poles: kW 0.22 (0.3) MISCELLANEOUS Overall floor dimensions, machine in operation: mm 2780 x 1240 Height from floor, standard machine: mm 1960 Machine height with raised column – upon request: mm 2110 Approx. net weight: kg 2,500

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, machine/vehicle number: 04374, grinding length: 1,000 mm, grinding width: 700 mm, grinding wheel diameter: 406 mm, table load: 1,000 kg, controller model: SIEMENS SINUMERIK 840 D, TECHNICAL DETAILS Grinding length: 1,000 mm Grinding width: 700 mm Travel X-axis: 1,120 mm Travel Y-axis: 690 mm Travel Z-axis: 635 mm Maximum workpiece weight on table: 1,000 kg Table length: 1,200 mm Table width: 500 mm Maximum grinding height above table: 650 mm Grinding wheel diameter: 406 mm Grinding wheel width: 100 mm Grinding wheel bore: 152 mm Grinding wheel speed (fixed): 1,400 rpm Maximum table speed: 40 m/min Max. automatic cross-feed (infinitely variable): 2 m/min Pgjdpfeyhnv Uox Ag Dsk Max. automatic vertical feed: 2 m/min MACHINE DETAILS Control: SIEMENS SINUMERIK 840 D Connection: 50 Hz 3x 400 Volt Grinding spindle motor: 11 kW Total power requirement: 31 kW Dimensions & Weight Dimensions (L x W x H): 4,750 x 3,485 x 2,680 mm Machine weight: approx. 7,800 kg EQUIPMENT Coolant system Paper filter unit Electro-magnetic chuck (1,000 x 500 mm) Set of grinding wheels Lamp

Condition: excellent (used), Grinding length without magnetic table: 1500 mm Maximum grinding width: 750 mm X-axis longitudinal travel: 1520 mm Y-axis transverse travel: 650 mm Pjdpfx Aowlh Adog Djgk Z-axis vertical travel: 690 mm Grinding wheel diameter: 406 x 100 mm Spindle speed: 1400 rpm Weight: 8600 mm Accessories: Braillon magnetic table 1000 x 500 mm Elcon 3 electronic control

Year of construction: 1973, condition: not inspected (used), Used tangential grinding machine for flat surfaces Brand: Favretto Model: TD 160/s Serial number: 0920 Year: 1973 Standard machine capacities: - Maximum grinding length: 1200mm - Maximum grinding length with a 75 wide wheel: 700mm - Maximum grinding height: 500mm TABLE: - Length of the fixing slots: 2000mm - Useful surface: 1600x600mm - Measurement of the T-slots: 14x200mm - Maximum longitudinal course: 1730mm TOOTH: - Dimensions: 457mm diameter x 203mm hole - Normal and maximum width: 75 and 100mm - Maximum transverse courses: 600 - Transverse advances little by little: 1 to 10mm - Continuous transverse displacement: 0.1 to 6 mm/min. ENGINES: - Main engine, power: 20CV Pedjh Rypkepfx Ag Dogk - Hydraulic group: 7'5CV Dimensions: - Measurement of the working machine: 4960x1770mm - Height: 2400mm - Weight: 8600kg *Original machine documentation available.

Condition: used, Year of construction: 2011, Maximum grinding length: 1200 mm Maximum grinding length with table dresser: 1000 mm Maximum grinding width: 600 mm Grinding height (table to underside of grinding wheel): 550 mm Table load with magnetic chuck: 975 kg Table load without magnetic chuck: 1200 kg Table speed: 1 - 40 m/min Grinding spindle Motor spindle: 11 kW Grinding wheel: 406 x 152.4 x 100 mm Speed: 1400 rpm Longitudinal axis (Z-axis) Rapid traverse: 5 m/min Adjustable feed: 1 - 50 mm Continuously variable feed: 0 - 2000 mm/min Smallest infeed: 0.001 mm Vertical axis (Y-axis) Rapid traverse: 1.5 m/min Pgjdpfx Agsxhdz Ej Djk Smallest infeed: 0.001 mm Space requirements approx.: 4450 x 2935 x 2540 mm Total weight approx.: 6700 kg Equipment: - Electro-permanent magnetic chuck 1000 x 500 mm incl. electronic control module and potentiometer - Coolant cleaning system with paper filter and magnetic separator 350 l – delivery rate 100 l/min - Static frequency converter incl. automatic dressing compensation - Complete extraction system - Siemens control with electronic handwheel - Various accessories, 2 flanges and 5 grinding wheels

Condition: good (used), Year of construction: 2011, functionality: fully functional, Accessories: Belt filter, magnetic separator, and various grinding wheel holders Grinding area: X 1000mm, Y 600mm, Z 550mm Pgjdpfxexvqtwj Ag Dsk

Year of construction: 1996, condition: ready for operation (used), overall weight: 8,600 kg, This FAVRETTO MC 130 surface grinding machine was manufactured in 1996. It features a table size of 1300 mm by 500 mm and is equipped with a DIGIT Favretto CNC system. The grinding wheel measures 406 mm in diameter and 152.4 mm in width. It has a powerful 15 kW grinding spindle motor and weighs 8,600 kg. Contact us for more information about this machine. • Table Length: 1300 mm • Table Width: 500 mm • Grinding Wheel Diameter: 406 mm • Grinding Wheel Width: 152.4 mm • Grinding Wheel Bore: 100 mm Pedpfx Agex U Dnno Degk • Grinding Spindle Motor Power: 15 kW
