Used injection moulding machineKraussMaffei
KM 500 - 3500 C2
Machine data
- Machine type:
- Used injection moulding machine
- Manufacturer:
- KraussMaffei
- Model:
- KM 500 - 3500 C2
- Year of construction:
- 2006
- Condition:
- ready for operation (used)
- Functionality:
- fully functional
- Operating hours:
- 77,000 h
Price & Location
- Location:
- Hermann - Hollerith Str. 9, 52249 Eschweiler, Deutschland
Technical details
- Clamping force:
- 5,000 kN
- Screw diameter:
- 100 mm
Details about the offer
- Listing ID:
- A190-49721
- Reference number:
- 14198
- Update:
- 30.04.2025
Description
Mould opening force, max. 280 kN
Travel force movable platen opening 137 kN
Travel force movable platen closing 136 kN
Size of mould platens (h x v) 1270 x 1200 mm
Distance between tie bars (h x v) 900 x 800 mm
Mould opening stroke 1170 mm
Mould height min 480 mm
Max. daylight 1650 mm
Hydraulic ejector - stroke 250 mm
Ejector force 95/48 kN
Injection unit:
Screw diameter 100 mm
Ls/D ratio 18
Injection pressure 1411 bar
Stroke volume 2411 ccm
Shot weight (PS) 2194 gr.
Injection rate 801 ccm/s
Screw speed 189 1/min
Plasticising rate max. 161 g/s
Nozzle pressure 173 kN
Electric and Hydraulic Equipment:
Njdpfx Afewgni Hjdjwp
Nominal capacity of pump motor 90 kW
Installed heating capacity 44 kW
Adjustable barrel heating zones 7
Oil Reservoir capacity 1075 ltr.
Dimensions and weights:
Dimensions of the machine ca. 7,50 x 2,50 x 2,50 m
Total machine weight 27090 kg
Max. mould weight 7900 kg
Accessories:
- Anti vibration pads
- 2 x 8 fold water flow regulator
Additional Options:
- 2 x hydr. core pull on movable plate
- 2 x hydr. core pull on fix plate
- Robot interface according to Euromap 12
- 16 x hotrunner controller
- 1 x air valve on movable plate
