Used Deckel Maho 60E for sale (1,112)

Condition: good (used), Year of construction: 2012, Parts shown by hand not come. Fodpfx Adoyw Naue Njgb Technical details are shown on picture.

Condition: used, Year of construction: 1997, operating hours: 10,227 h, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 525 mm, travel distance Z-axis: 500 mm, table width: 540 mm, table length: 1,000 mm, overall weight: 4,500 kg, spindle speed (max.): 12,000 rpm, For sale is a machining centre from Deckel Maho, model DMU 60 E. The machine is fully functional and ready for immediate use. Particularly noteworthy are the low program run hours. Technical data: Year of manufacture (estimated): 1997 Control: HEIDENHAIN TNC 426PB Control ON: 8,283 h Machine ON: 31,148 h Program run: 10,227 h Total power requirement: approx. 26 kVA Travel X-axis: 600 mm Travel Y-axis: 525 mm Travel Z-axis: 500 mm Clamping surface: 1,000 x 540 mm Max. table load: 350 kg Spindle speed range: 20 - 12,000 rpm Tool holder: SK 40 Feed speed: 20 - 10,000 mm/min Fodpfow I R I Hex Ad Nogb Rapid traverse X/Y-axis: 18 m/min Rapid traverse Z-axis: 15 m/min Tool changer: 25 positions Dimensions (L x W x H): approx. 2.95 x 2.1 x 2.26 m Weight: approx. 4,500 kg Transport and loading can be organised throughout Europe at additional cost, upon request. All prices are subject to VAT. Inspection possible by appointment. Contact us — our team will be happy to assist you. Trade-in or exchange possible! Machinery purchase / sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINERY AND MORE. Do you require a high-quality yet affordable metalworking machine for your production? Or are you looking to sell yours? For more information or contact options, please visit our website.

Year of construction: 2000, condition: ready for operation (used), Travel X/Y/Z: approx. 600mm/525mm/500mm, table dimensions X/Y: 1000mm/550mm, max. table load: 350kg, tool holder: SK40, speed: 12000rpm, tool positions: 25, rapid traverse: 24m/min. Machine dimensions X/Y/Z: approx. 2900mm/2000mm/2300mm, weight: approx. 4500kg, control: Heidenhain, operating hours: approx. 87955h, spindle hours: approx. 21800h. Documentation available. On site inspection is possible. Fjdsyg Nuiopfx Ad Nogb

Condition: used, Year of construction: 1999, x-travel 600 mm y-travel 525 mm Fsdpfjtqqmhjx Ad Nogb z-travel 500 mm table surface area 1000 x 543 mm spindle taper SK 40 spindle taper DIN 69871 spindle turning speed - stepless 20 - 12.000 U/min feed X/Y/Z-axis 20 - 10.000 mm/min rapid traverse X/Y/Z axis 18 / 18 / 15 m/min table load max. 350 kg control HEIDENHAIN MillPlus milling-head swivable +/- 90 ° total power requirement 26 kVA weight of the machine ca. 4,2 t dimensions of machine L x W x H 2,95 x 2,1 x 2,26 m Accessories: various tool fixtures, coolant

Condition: defective spare-parts repository (used), Year of construction: 2005, operating hours: 38,534 h, functionality: not functional, machine/vehicle number: 29310001024, travel distance X-axis: 750 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 560 mm, controller model: Heidenhain iTNC530, rotational speed (max.): 18,000 rpm, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel X-axis: 750 mm Travel Y-axis: 600 mm Travel Z-axis: 560 mm Worktable size: 950 x 650 mm Table load: 1,000 kg Spindle speed: 18,000 rpm Number of axes: 3 Fodpfx Aey Ib H Iod Negb Tool changer: 30 positions Tool holder: HSK63 MACHINE DETAILS CNC control: Heidenhain iTNC530 Dimensions & Weight Dimensions (L x W x H): 3,500 x 3,000 x 3,200 mm Transport dimensions (L x W x H): 3,500 x 3,000 x 3,200 mm Weight: 10.2 t Operating hours Spindle hours: 38,534 h Operating hours: 98,381 h Note: DMG has measured the clamping force on the machine, which is so low that there is a risk of the tool falling out. The machine has suffered spindle damage. There are various leaks, for example at the chip conveyor or in the door area.

Condition: defective spare-parts repository (used), Year of construction: 2003, operating hours: 30,434 h, functionality: not functional, machine/vehicle number: 1114 000402 3, travel distance X-axis: 1,060 mm, travel distance Y-axis: 710 mm, travel distance Z-axis: 710 mm, controller model: Heidenhain iTNC530, rotational speed (max.): 10,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS X-axis travel: 1,060 mm Y-axis travel: 710 mm Z-axis travel: 710 mm Working area: Ø800 NC rotary table Spindle speed: 10,000 rpm Number of axes: 5 Tool changer: 30 stations Tool holder: HSK63 MACHINE DETAILS Control: iTNC530 Dimensions & Weight Machine dimensions (L x W x H): 4,080 x 4,490 x 3,117.5 mm Transport dimensions (L x W x H): 3,500 x 2,500 x 2,410 mm Weight: 9.7 t Fgedpfsy Ib A Nsx Ad Neb Operating hours Spindle hours: 30,434 h Operating hours: 66,001 h Note: The machine temperature rises immediately, and in the past there has even been smoke. The machine has spindle damage. Various cable insulations are worn.

Year of construction: 2001, operating hours: 26,266 h, condition: used, Colour: Grey Empty weight: 7.000 kg Dimensions (LxBxH): 350 x 220 x 240 cm Price: On request Milling machine, VMC Model: CNC Manufacturer: DMG / Deckel MAHO Type: DMU60T Year of manufacturing: 2001 Control: Heidenhain Working-hours: 26266 Travel: 630x560x560mm Spindle-speed: 10.000 rpm Table-dimensions: 1000x600mm Spindle-take: ISO40 Max. Workpiece-weight: 400kg Incl. Filter Interlit SK200-760 Fjdoywt Nyepfx Ad Njgb Incl. Automatic toolholder Incl. Documents Incl. Video available Machine-weight: 6700kg Machine-dimensions: 3500x2400x2200mm - Year: 2001 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Operating hours: 26266 - Drive system: CNC - Number of axes [pcs]: 3 - X-axis travel [mm]: 630 - Y-axis travel [mm]: 560 - Z-axis travel [mm]: 560 - Table length [mm]: 1000 - Table width [mm]: 600 - Tool holder: SK40 - Max. spindle speed [rpm]: 10000 - Options: External cooling, Tool magazine - Transport dimensions: 3500mm x 2200mm x 2400mm (l x w x h) - Transport weight [kg]: 7000kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: like new (used), Year of construction: 2008, travel distance X-axis: 700 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 700 mm, feed rate X-axis: 60 m/min, feed rate Y-axis: 60 m/min, feed rate Z-axis: 60 m/min, nominal power (apparent): 68 kVA, controller manufacturer: HEIDENHAIN iTNC 530, workpiece height (max.): 1,000 mm, workpiece diameter (max.): 800 mm, workpiece weight (max.): 600 kg, total height: 2,547 mm, total length: 5,866 mm, total width: 4,196 mm, table width: 500 mm, table length: 500 mm, overall weight: 12,000 kg, spindle speed (max.): 18,000 rpm, spindle motor power: 34,000 W, number of slots in tool magazine: 120, Equipment: chip conveyor, documentation/manual, CNC controller: HEIDENHAIN iTNC 530 Axes: X-axis travel mm: 700 Y-axis travel mm: 700 Z-axis travel mm: 700 Distance spindle nose - table surface mm: 100 - 800 Rapid traverse m/min: 60 Acceleration in the axes m/s2: 6 / 6 / 5 Worktable: Number of pallets: 2 + 5 Table dimensions mm: 500 x 500 Maximum workpiece size (D x H) mm: 800 x 1.000 Max. workpiece weight kg: 600 T-Slot version: DIN 55201-A2 APC time s: 9,5 División estandar Grados: 360º (1º) Spindle: Spindle speed rpm: 18.000 Spindle drive power kW: 34 / 28 Spindle torque Nm: 110 Tool system: Tool holder: HSK-A63 Tool magazine slots: 120 Max. Tool Diameter: 80 Max. Tool Length mm: 550 Max tool weight kg: 12 Chip-to-chip time s: 2,9 Equipment: Electronic Handwheel Chip conveyor Rotating inspection windows Rinsing gun Signal lamp Tool breakage probe 3D quickSET Workarea light CE conformity Cooling device blowing air through spindle center, selectable via M-function MPC – Machine Protection Control Fgedpswhdhzjfx Ad Nsb Paper band filter Infrared Probe Heidenhain TS640 Blum laser tool measurement Taper clear brushes Blum laser NT Hybrid Round pallet Storage (RPS 5) Measuring probe Heidenhain TS 640 Production package Internal cooling supply 40 BAR Cooling: Cooling through the Spindle Center bar: 40 BAR Tank capacity: 980 High-pressure bar: 40 BAR Machine running times: Under power: 95.210 Operating Time: 44.971 Rated power kVA: 68 Basic machine dimensions / weight: Length mm: 5.866 Width mm: 4.196 Height mm: 2.547 Weight kg: 12.000.

Condition: ready for operation (used), Year of construction: 2003, Immediately available ex works: 5-axis (3 plus 2) machining centre Deckel Maho Type DMU 35 M Year of manufacture: 2003 Siemens 810 D control Electronic handwheel Universal tilting/rotary table 400 x 290 mm Travel X/Y/Z: 350/240/340 mm Spindle taper SK 40 Spindle speeds: 20 – 6300 rpm Drive: 6.3/10 kW Table load: 100 kg Rotation range: 360 degrees Fjdpfx Adjy N Ad Rj Nsgb Swivel range: plus 105 / minus 15 degrees Distance spindle nose – table: 145/485 mm Feed rates up to 3000 mm/min Weight: 1750 kg Price: Euro 4,500.—plus VAT ex location

Condition: ready for operation (used), Year of construction: 2001, Immediately available ex-site: 5-Axis Machining Centre Deckel Maho Model: DMU 50 M Year of manufacture: 2001 Control system: Heidenhain TNC 124 5 axes (3 + 2) Manual rotary axes with B and C swivel rotary table B and C axes are displayed on the control Table size: 700 x 500 mm Travel paths X/Y/Z: 500 / 400 / 400 mm Table load capacity: 200 kg Spindle taper: SK 40 Spindle speeds: 20 – 4,500 rpm Drive power: 9 / 13 kW C-axis rotation range: 360 degrees Swivel range: plus 95 / minus 10 degrees Feed rate up to 5,000 mm/min Spindle speeds: 20 – 4,500 rpm Fgedpey N Ad Djfx Ad Nsb Weight: 3 tonnes Coolant system Price: EUR 8,500.— net, ex-site, plus VAT.

Condition: ready for operation (used), Year of construction: 2000, Immediately available from Swiss toolmaking: 5-axis milling machine Deckel Maho Type DMU 35 M Year of manufacture: 2000 CNC control: Heidenhain TNC 310 M Electronic handwheel Table 400 x 280 mm Fgjdpey Nz Uzofx Ad Nsb Table load up to 100 kg Travel X/Y/Z: 350/240/340 mm Infinitely variable spindle speeds: 0 – 5,000 rpm Taper SK 40 Rapid traverse 5 m/min Servo motors for X/Y/Z axes Swivel range 360 degrees Table clamping plus 105/minus 150 degrees Weight 2 t Accessories, hydraulic vise Price: EUR 5,000.—plus VAT, ex works

Condition: used, Year of construction: 2002, operating hours: 14,700 h, machine/vehicle number: 15115220514, travel distance X-axis: 2,200 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 720 mm, controller manufacturer: Siemens, controller model: Sinumerik 840D/810D, total height: 2,650 mm, total length: 4,472 mm, total width: 2,780 mm, overall weight: 12,500 kg, spindle speed (max.): 12,000 rpm, operating hours of spindle: 14,700 h, number of spindles: 1, number of slots in tool magazine: 30, input voltage: 400 V, Equipment: documentation/manual, Particularly interesting for export customers: Proper disassembly allows the machine to be loaded onto a standard semi-trailer with approximately 2.45 m loading width. Our disassembly team can prepare and load the machine accordingly. As a result, transport costs can be significantly reduced compared to a special transport. Technical Data Manufacturer: DECKEL MAHO Model: DMF 220 linear Year of manufacture: 2002 Machine No.: 15115220514 Control: Siemens SINUMERIK 840D/810D Operator interface: ShopMill ShopMill version: 06.02.04 PLC version: 06.03.06 Tool holder: SK 40 Working spindle: up to 12,000 rpm Tool magazine: 30 stations Table size: 2,600 × 600 mm Max. table load: 2,200 kg Travel paths: X 2,200 mm / Y 560 mm / Z 720 mm Feed rate: up to 20,000 mm/min Rapid traverse X: 18,000 mm/min Rapid traverse Y/Z: 15,000 mm/min Machine weight: approx. 12,500 kg Transport weight: approx. 14,000 kg Max. installation weight: approx. 16,000 kg Electrical Data Connected load: 50 kVA Max. current consumption: 60 A Main fuse: 80 A Power supply: 400 V / 50 Hz Control voltage: 24 V Supply voltage: 230 V Electrical diagram available Equipment / Special Features Siemens SINUMERIK 840D/810D ShopMill operator interface Fsdpfxoy Nn Eyj Ad Nogb SK40 tool holder 30-station tool magazine Large X-axis with 2,200 mm travel Rigid table design Documentation / technical documents available Electrical diagram available Machine under power Year of manufacture: 2002 Made in Germany Transport optimization possible through disassembly Loading onto standard semi-trailer possible Considerably lower transport costs compared to wide-load/special transport

Condition: used, Year of construction: 2013, x-travel 400 mm y-travel 400 mm z-travel 375 mm Fjdpey Nd U Rofx Ad Nsgb weight of the machine ca. 7150 kg

Condition: ready for operation (used), Deckel Maho 2238-4630 rotary table SN: 0174 for FP4-60 machine – diameter: 63cm / height: 43cm, used, normal signs of wear, 100% functional, delivery as per photos. ATTENTION: Please enquire separately for costs of packing and shipping! Fedpfx Adjy Np Nao Nogb

Condition: ready for operation (used), Deckel Maho tool holder for Deckel Maho FP4-60 milling machine, used, in good condition, 100% functional, scope of delivery as per photos. ATTENTION: Please enquire for charges for packing and transport separately! Fgodpfxjy Np Ngo Ad Nob

Condition: used, Year of construction: 2013, x-travel 635 mm y-travel 510 mm z-travel 460 mm control Sinumerik 840 D SL Siemens turning speed range - main spindle 20 - 10.000 min/-1 power capacity - main spindel 13 / 9 kW tool taper SK 40 DIN 69871 max. Torque 83 / 57 Nm tension force 8 kN table surface area 790 x 560 mm number of T-slots 4 + 1 T-slot - distance 100 mm T-slot - width 4x 14H12 / 1x 14H7 mm max. table load 600 kg table height over floor 720 mm distance spindle nose and table 120 - 580 mm number of toolpositions 30 pos. Max. mould width 80 / (130) mm max. tool length 250 mm Fgsdpfx Aoym Dz Red Neb max. tool weight 6 kg max. total weight 80 kg change-time tool to tool 1,6 sec change-time chip to chip 6,0 sec rapid traverse 30 m/min feed speeds 1 - 20.000 mm/min Feed force max. 5 kN total power requirement 28 kVA weight of the machine ca. 3,8 t dimensions of the machine ca. 3,5 x 4,0 x 2,7 m CNC - MachiningCenter Vertical DECKEL MAHO - DMC 635 V New Design - ShopMill - WITHOUT perforated plate - WITHOUT clamping device - WITHOUT tools

Condition: ready for operation (used), Year of construction: 2012, controller manufacturer: HEIDENHAIN, overall weight: 15,070 kg, spindle speed (max.): 14,000 rpm, number of slots in tool magazine: 30, number of axes: 5, This 5-axis DMG DECKEL MAHO DMF 260|11 was manufactured in 2012. It features a spindle speed of 14,000 RPM and a tool magazine with 30 stations, providing efficient tool management. The machine is equipped with a swivel milling head and an NC rotary table for enhanced versatility. If you are looking to get high-quality machining capabilities, consider the DMG DECKEL MAHO DMF 260|11 vertical machining centre we have for sale. Contact us for further details. • Power consumption: 46 kVA • Voltage: 400 V 3/N, PE • Frequency: 50/60 Hz • Nominal current (In max): 66 A • Maximum fuse: 80 A • B-axis: Swivel milling head • C-axis: NC rotary table (left side) • Cooling: Cooling unit for drives • Lighting: LED machine light • Axis drives: X/Y/Z feed drives Additional equipment • Spray gun Fsdpoy Nyvwofx Ad Nsgb Technical Specification Taper Size SK 40

Condition: not inspected (used), Year of construction: 2016, operating hours: 21,228 h, machine/vehicle number: 127300000073, travel distance X-axis: 2,100 mm, travel distance Y-axis: 2,100 mm, travel distance Z-axis: 1,250 mm, overall weight: 46,000 kg, spindle speed (min.): 12,000 rpm, spindle speed (max.): 12,000 rpm, coolant supply: 80 bar, 5-axis CNC universal machining center with controlled B-axis and NC rotary table (C-axis). Large working area approx. 2,100 x 2,100 x 1,250 mm. Equipped with a powerful SK50 spindle (52 kW, 430 Nm, up to 12,000 rpm) and internal coolant supply up to 80 bar. Tool changer with 60/63 positions (chain/wheel magazine, double gripper). Very well equipped with Blum Laser, 3D quickSET, ACC, and MPC. Including chip conveyor, oil mist separator, and coolant system. Fgodpeyxmicjfx Ad Neb Control ON: 47,888 h – Operating hours: 21,228 h

Condition: ready for operation (used), Year of construction: 2007, operating hours: 20,082 h, travel distance X-axis: 700 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, controller manufacturer: SIEMENS, controller model: 840D, spindle speed (max.): 10,000 rpm, number of axes: 4, This 4-axis DECKEL MAHO DMC 70 H duoblock was manufactured in 2007. It features a Siemens 840D control unit and a robust tool holder type of SK40. The machine is equipped with hydraulically clamped clamping towers, ensuring secure workpiece handling. If you are looking to get high-quality machining capabilities, consider the DECKEL MAHO DMC 70 H duoblock horizontal machining centre we have for sale. Contact us for further details. • Apparent power: 60 kVA • Nominal current (max): 86 A • Fuse protection: 100 A • Voltage: 400 V • Frequency: 50 Hz • Control voltage: 24 V Additional equipment • 2 hydraulically clamped clamping towers (workholding) Technical Specification Taper Size SK 40 Fgodpfx Ajy Ndibed Nob

Condition: used, Year of construction: 2011, operating hours: 34,300 h, functionality: fully functional, machine/vehicle number: 1190 000077 3, travel distance X-axis: 800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, controller manufacturer: Siemens, controller model: Sinumerik 840D, workpiece weight (max.): 1,200 kg, total height: 3,100 mm, total length: 4,850 mm, total width: 4,350 mm, table width: 680 mm, table length: 680 mm, rotational speed (max.): 10,000 rpm, overall weight: 16,000 kg, spindle speed (max.): 10,000 rpm, operating hours of spindle: 13,400 h, coolant supply: 40 bar, input voltage: 4,000 V, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, DMG MORI DMC 80H duoBLOCK – 4-Axis Horizontal Machining Center with Pallet Changer – Used For sale is a used horizontal machining center, model DMG MORI DMC 80H duoBLOCK. The machine is currently still in productive operation and is reliably used for series production. It is primarily utilized for machining steel and cast materials. Condition: Fully functional and ready for operation. Inspection under power possible by appointment. Equipment: 4-axis machining Horizontal design for efficient chip evacuation Pallet changer to minimize non-productive times DuoBLOCK construction for high stability and precision Tool changer Spacious work area for complex components Further equipment details available on request Application area: Ideal for series production and demanding machining tasks in mechanical engineering, toolmaking, and industrial applications. Sales conditions: Price ex-foundation Disassembly, removal, loading, and transport to be arranged by the buyer Fgjdpfx Adsy Iwdpo Nob Inspection by appointment possible Price negotiable Delivery according to EXW (Ex Works)

Condition: good (used), Year of construction: 1995, operating hours: 28,099 h, functionality: fully functional, machine/vehicle number: 662280, travel distance X-axis: 500 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, controller manufacturer: DECKEL MAHO, controller model: CNC 425, total height: 2,000 mm, total length: 3,000 mm, total width: 2,400 mm, table width: 480 mm, table length: 900 mm, overall weight: 2,000 kg, number of slots in tool magazine: 16, mount diameter: 40 mm, input voltage: 400 V, power: 20 kW (27.19 HP), input frequency: 50 Hz, input current: 50 A, DECKEL MAHO MH 600 B CNC Vertical Machining Center - Tool holder: SK 40 Fgodpsy I Tgyjfx Ad Neb - Table with 7 T-slots - Including rotary table from manufacturer WALTER, type: TANIP125NEG, year of manufacture: 2010 Notice: The item must be collected on a binding date between 24.08. and 27.08.2026 at a time to be mutually agreed. FCA D-61352 Bad Homburg – loaded on truck

Condition: good (used), Year of construction: 2001, functionality: unexamined, travel distance X-axis: 350 mm, travel distance Y-axis: 240 mm, travel distance Z-axis: 340 mm, rapid traverse X-axis: 20 m/min, controller model: Siemens Sinumerik 840 D, total height: 2,100 mm, total length: 3,800 mm, total width: 3,600 mm, table load: 100 kg, rotational speed (max.): 15,000 rpm, overall weight: 1,600 kg, For sale is a 5-axis machining center from DMG, model DMU 35 M, equipped with two manual axes. The machine is in good condition. Technical specifications: DMU 35 M Year of manufacture: 2001 X-axis: 350 mm Y-axis: 240 mm Z-axis: 340 mm Spindle speed: 15,000 rpm Feed rate: Infinitely variable up to 5,000 mm/min Rapid traverse: 20 m/min Clamping surface: Ø 400 x 280 mm Rotary range: 360° (mechanical) Table clamping: +105 / -150 (mechanical) Max. table load: 100 kg Tool holder: SK 40 Tool clamping: pneumatic/mechanical Required space: 3,800 x 3,600 x 2,100 mm Transport dimensions: approx. 2,000 x 1,700 x 2,100 mm Weight: 1,600 kg Transport and loading can be arranged for an additional charge, Europe-wide. All prices are subject to VAT. Fodpoy Nz Nrofx Ad Njgb Inspection by appointment is possible. Contact us—our team will be happy to assist you. Trade-in or exchange possible! Machinery purchase and sales BUYING / SELLING OF PRODUCTION & METALWORKING MACHINERY AND MORE. Are you looking for a high-quality but affordable metalworking machine for your production? Or do you want to sell your machine? For further information or contact options, please visit our website.

Condition: excellent (used), Year of construction: 2008, Vertical machining center Deckel Maho DMF 220 Linear Year of manufacture: 2008 Control: Siemens 840 D Technical specifications: CNC control: Siemens Sinumerik 840D Number of axes: 3 X-axis travel: 2,200 mm Y-axis travel: 560 mm Z-axis travel: 720 mm Max. clamping height: 600 mm Table size (LxW): 2,600 x 600 mm Max. table load: 2,200 kg Fgedpfx Ajy Nbbzod Njb Guideway type: Linear guide Max. power: 35 kW Tool holder: SK40 Tool magazine capacity: 60 Tool change time: 9.6 s The machine was in active serial production until recently and was predominantly used for machining steel and aluminum. Equipment: ⦁ Partition wall for setup time optimization (parallel machining / setup in one cabin half) ⦁ Conveyor belt filter system for coolant processing ⦁ Automatic tool changer ⦁ Generous working area for complex components

Condition: ready for operation (used), Year of construction: 2001, operating hours: 8,200 h, functionality: fully functional, machine/vehicle number: 28850018432, TECHNICAL DETAILS Tool diameter: max. 140 mm Speed at maximum diameter, max.: 6,500 rpm Balancing quality according to DIN ISO 1940: G 6.3 Tool Magazine Number of tools: 24 Tool diameter, standard tools: max. 80 mm Tool diameter, special tools with adjacent positions free: max. 140 mm Tool length: max. 300 mm Tool weight: max. 7 kg Magazine load: max. 72 kg Table Clamping surface with T-slots DIN 650-14: 800 x 500 mm Fedsy Rta Eepfx Ad Nogb Loading height, top of table: 850 mm Workpiece height: max. 240 mm Table load capacity: max. 500 kg Coolant System Tank capacity with standard chip container: 150 l Tank capacity with spindle cooling: 80 l Pump performance standard, flow rate: 30 l/min Pump performance standard, pressure: 1.2 bar Tank capacity with chip conveyor option: 750 l Pump performance, chip conveyor option, flow rate: 40 l/min Pump performance, chip conveyor option, pressure: 3.0 bar Tank capacity including chip conveyor: 750 l Pump performance, internal coolant supply, flow rate: 30 l/min Pump performance, internal coolant supply, pressure: 15 bar Chip Disposal Chip conveyor discharge height: 850 mm Chip conveyor type: scraper belt MACHINE DETAILS Rated power: 30 kVA Rated current: 42 A Delayed main fuse: 3 x 50 A Operating voltage: 400 V Frequency: 50 Hz Compressed air connection: 6 bar Required system delivery rate: 38 Nm³/h Ambient temperature: +5 to +40 °C Average temperature over 24 h: +35 °C Relative humidity: 30–95 % Dimensions & Weight Transport dimensions of the machine with table (L x W x H): 3.1 x 2.1 x 2.4 m Transport weight: approx. 4,200 kg Mounting elements: 4 x BNV 150/4 EQUIPMENT Fixed station coding Vertical tool changer Pick-up system via work spindle Coolant system Spindle cooling Chip conveyor Internal coolant supply Mounting elements BNV 150/4

Condition: used, Year of construction: 2012, x-travel 635 mm y-travel 510 mm z-travel 460 mm table surface area 790 x 560 mm spindle taper SK 40 spindle turning speed - stepless 20 - 12.000 U/min spindle drive 13 kW max. torque on the spindle 83 Nm feeds x/y/z -stepless bis 20.000 mm/min rapid traverse 30 m/min ATC 20 Pos. tool diameter if 2 vacant positions 130 mm Fedpfx Adox Nqu Do Njgb tool diametre at full load 80 mm tool length - max. 300 mm weight of tools max. 6 kg internal coolant system feed 12 bar control HEIDENHAIN, TNC 620 total power requirement 17 kVA weight of the machine ca. 3,9 t dimensions of machine L x W x H 3,0 x 1,92 x 2,35 m Accessories: electron. hand panel, chip conveyor,coolant
