Used Heller Component for sale (6,980)

Condition: ready for operation (used), Year of construction: 2007, travel distance X-axis: 800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, controller manufacturer: SIEMENS, controller model: 840D, spindle speed (max.): 6,000 rpm, number of slots in tool magazine: 100, number of axes: 4, This 4-axis HELLER MCH 250 was manufactured in 2007. It features a spindle speed of 6000 rpm and a BT50 tool holder. The machine is equipped with an automatic tool changer that holds 100 tools, enhancing productivity. If you are looking to get high-quality machining capabilities, consider the HELLER MCH 250 horizontal machining centre we have for sale. Contact us for further details. Ljdpfjy Epfvsx Akyjaa • 4th axis rotary table, 1-degree indexing • Probe (workpiece/tool probing system) Technical Specification Taper Size BT 50

Condition: good (used), Year of construction: 2011, Ref. -No.: 10598 Manufacturer: HELLER Type: MC 2000 Year of construction: 2011 Type of control: CNC-Steuerung Control: Siemens 840 D sl Storage location: Halberstadt Country of origin: Hermany Machine-No.: 50XXXX X-Travel: 800 mm Y-Travel: 800 mm Z-Travel: 1000 mm Work spindle torque (25% ED): 242 Nm Tool Taper: SK 40 Numbers Of Tools In Magazin: 54 Tool Piece Magazine With: 80 Pcs./pcs. Turning Speeds: 10000 RPM Drive Capacity - Spindle Motor: 17 kW High-Pressure Pump: 50 bar Speed range - main spindle: 10000 RPM Numbers Of Pallets: 2 Size Of Pallet: 630 x 500 mm Weight Of The Machine Ca.: 13000 t spindle running time: 7000 H Operating hours: 14000 H Preparation area: 4 x 90° Laedpfxjx Hn D Rj Akyja hydraulic pressure: 200 bar Further information: - The machine has been measured - The geometry is in excellent condition - The spindle runs a little rough - Clamping towers and cutting tool holders are also included - 2 additional clamping towers - 2 replacement pallets - 2-axis servo tool changer - Scraper conveyor for dry machining - Cold light in the work area - Central cooling unit for motor spindle and control cabinet - Control unit at the workpiece setup station - NC-controlled rotary table - Clamping hydraulics The machine can be viewed under power by appointment.

Condition: good (used), Year of construction: 2017, Ref. -No.: 10596 Manufacturer: HELLER Type: H - 2000 Year of construction: 2017 Type of control: CNC-Steuerung Control: Siemens 840 D Storage location: Halberstadt Country of origin: Germany Machine-No.: 56XXX X-Travel: 630 mm Y-Travel: 630 mm Z-Travel: 630 mm B-Axis: 0,001 ° Table Load: 500 kg Max. Tool Length: 350 mm Max. Tool Diameter: 160 mm Tool Taper: HSK 63 Numbers Of Tools In Magazin: 80 Laedpfex Hn D Dox Akyea Turning Speeds: 16000 RPM Tool changer: Doppelgreifer Max. Workpiece height: 850 mm Max. Torque: 95 Nm Rapid Travel X/Y/Z: 60 mm / min Rapid Traverse X-Axis: 80 m / min Rapid Travel Y-Axis: 80 m / min Rapid Traverse Z-Axis: 90 m / min Drive Capacity - Spindle Motor: 40 kW Internal cooling: 50 bar Numbers Of Pallets: 2 Size Of Pallet: 400 x 500 mm spindle running time: 1000 H Operating hours: 3000 H Workpiece interference circuit max.: 720 mm Media interface: 5 - fach Further information: - Equipped with NC rotary table. - State-of-the-art spindle technology. - Ideal for precise machining tasks. - Spindle hours: 1000. - Pallet can be rotated manually 4 x 90 - Hydraulic pressure 200 bar - Quick drill breakage check Machine can be viewed under power by arrangement

Condition: ready for operation (used), Year of construction: 2005, travel distance X-axis: 800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, controller manufacturer: SIEMENS, controller model: 840D, spindle speed (max.): 6,000 rpm, number of axes: 4, This 4-axis HELLER MCH 250 was manufactured in 2005. It features an XYZ travel of 800 x 800 x 800 mm and a pallet size of 630 x 630 mm. The machine is equipped with a 100-tool automatic tool changer and a 6-pallet pool for enhanced productivity. If you are looking to get high-quality machining capabilities, consider the HELLER MCH 250 horizontal machining centre we have for sale. Contact us for further details. • Pallet size: 630 x 630 • Tool magazine: 100 ATC • 4th axis: 360° Additional equipment • 6x pallet pool • Probe Technical Specification Taper Size SK 50 Lsdpfxjy Egbrj Akyoaa

Condition: ready for operation (used), Year of construction: 1999, travel distance X-axis: 630 mm, travel distance Y-axis: 630 mm, travel distance Z-axis: 630 mm, controller manufacturer: SIEMENS, spindle speed (max.): 8,000 rpm, number of slots in tool magazine: 40, number of axes: 4, This 4-axis HELLER MC 16 was manufactured in 1999. It features a maximum spindle speed of 8000 rpm and an automatic tool changer with 40 positions. The machine is equipped with twin pallets and offers an XYZ travel of 630 x 630 x 630 mm. If you are looking to get high-quality machining capabilities, consider the HELLER MC 16 horizontal machining centre we have for sale. Contact us for further details. • Pallet system: Twin pallet Technical Specification Ljdpfx Akoy Ef Idjyoaa Taper Size SK 40

Condition: ready for operation (used), Year of construction: 2000, travel distance X-axis: 800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 710 mm, controller manufacturer: SIEMENS, controller model: 840D, spindle speed (max.): 6,000 rpm, number of slots in tool magazine: 52, number of axes: 4, This 4-axis HELLER MCP 250 was manufactured in 2000. It features a maximum spindle speed of 6000 rpm and an automatic tool changer with 52 positions. The machine is equipped with twin pallets and offers an XYZ travel of 800 x 800 x 710 mm. If you are looking to get high-quality machining capabilities, consider the HELLER MCP 250 horizontal machining centre we have for sale. Contact us for further details. • Automatic tool changer (ATC): 52 tools Additional equipment • Twin pallet changer Laedpfjy Ef D Esx Akyoa Technical Specification Taper Size SK 50

Condition: ready for operation (used), Year of construction: 2012, travel distance X-axis: 1,100 mm, travel distance Y-axis: 1,100 mm, travel distance Z-axis: 1,000 mm, controller manufacturer: SIEMENS, controller model: 840D sl, total height: 2,800 mm, number of axes: 5, This 5-axis HELLER MC 20 was manufactured in 2012. It features an impressive X-axis travel of 1100 mm, Y-axis travel of 1100 mm, and Z-axis travel of 1000 mm. The machine is equipped with a Siemens 840D sl control unit and has a maximum fixture height of 1980 mm. If you are looking to get high-quality machining capabilities, consider the HELLER MC 20 horizontal machining centre we have for sale. Contact us for further details. • Voltage: 400 V (3~) • Frequency: 50 Hz • Nominal current: 42 A • Interference circle: Ø1260 mm • Maximum fixture height: 1980 mm • Table height from floor: 1100 mm • Suction connection: Ø265 mm Laodpfx Aoy Dd Hcskyja Technical Specification Taper Size HSK 100

Year of construction: 2025, condition: new, functionality: fully functional, the Seamark XC1000 X-Ray Component Counter: Smarter, Faster, and Fully Automated At Active-PCB Solutions, we know that accuracy, efficiency, and seamless integration are not optional, they’re an essential part of our manufacturing process. That’s why we’re excited to introduce our new Seamark XC1000 X-Ray Component Counter which has just been installed on our shop floor by Advanced Manufacturing Solutions Ltd. The next-generation offline X-ray component counting system is designed to redefine how we manage and verify our SMD component inventory. You can find out more about this new technology and how we intend to put it to full use below! Introducing the Seamark XC1000 X-Ray Component Counter Precision Counting Powered by AI Leveraging an advanced AI algorithm, this intelligent Seamark XC1000 X-Ray Component Counter system provides 99.99% counting accuracy for all SMD components sized 01005 and above, meaning we can say goodbye to manual errors and time-consuming reel unpacking. The XC1000 counts 1 to 4 reels simultaneously with no unspooling, no guesswork, and no downtime. Ergonomic Design Meets Automation Lajdpeyzpkzofx Akyea The XC1000 features an ergonomically designed workstation where the operator can sit comfortably and monitor the easy-to-read counter screen. With an automated stage movement system and anti-pinch safety design, reel handling is simple, safe, and efficient. The unit is compact and mobile, thanks to built-in wheels for easy relocation. Smart Labeling and Real-Time Integration Mislabeling and manual input errors are inevitable and costly. However, with its error-proof labeling function, the XC1000 automatically detects and recognises each reel, instantly printing the correct label via a TSC industrial printer. This intelligent workflow is further enhanced by seamless real-time integration with MES, ERP, and WMS systems, enabling live data exchange and automatic result uploads. Built for the Modern SMT World The XC1000 is built to handle the full range of reel sizes (7”–15”), heights (5–80mm), and component types, including moisture-proof bag packaging, bulk materials, and JEDEC trays. Its amorphous silicon flat panel detector delivers sharp, high-resolution images with a 430mm × 430mm field of view, supported by four optional cameras for automatic barcode reading. Industry-Leading Database & Cloud Intelligence What sets the Seamark XC1000 X-Ray Component Counter apart is its dynamic, global X-ray component database, which includes: 15,000+ material profiles 60 million+ testing images 700,000+ core reference images Weekly updates with 160,000 new images Over 8.6 million classification training images This continually evolving database ensures compatibility with 99.2% of global components. Updates are cloud-synced monthly, keeping the whole system current and reliable. Key Technical Specs at a Glance Input Power: 220V, 10A, 50–60Hz Control System: Windows 10 64-bit X-Ray Source: Sealed microfocus (30–80KV, up to 1000 μA) Detector: 3072×3072 matrix, 139μm resolution Max Output Power: 56W Counting Speed: Fully automated, operator training not required.

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, Control: Siemens SL Tool positions: 160 Tool holder: HSK 63 Spindle speed: 10,000 min⁻¹ / 242N Lajdey Ap Euopfx Akyja Pallet size: 630×500 mm Number of pallets: 2 X-axis: 800 mm Y-axis: 800 mm Z-axis: 1000 mm Max. table load: 1000 kg

Condition: ready for operation (used), Year of construction: 2003, operating hours: 54,000 h, travel distance X-axis: 800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, controller manufacturer: SIEMENS, controller model: Sinumerik 840D, spindle speed (max.): 12,000 rpm, number of slots in tool magazine: 80, number of axes: 4, This 4-axis HELLER MCi 25 was manufactured in 2003. It features a generous X, Y, and Z-axis travel of 800 mm each, along with a B-axis capable of 360° indexing. The machine is equipped with a tool magazine holding 80 slots and supports a total of 6 pallets. If you are looking to get high-quality machining capabilities, consider the HELLER MCi 25 horizontal machining centre we have for sale. Contact us for further details. • B-axis: 360° (indexing/rundtisch) Ledpfx Asyzzr Dskyjaa • Tool magazine: 80 slots • Pallet quantity: 6 total (2 in use, 4 standby) • Operating hours: approx. 2,700–3,000 hours per year (counter reported defective) • Total estimated hours: approx. 54,000–60,000 (based on 2-shift operation since 2006) • Coolant volume: 1,500 liters • Voltage: 400 V • Frequency: 50 Hz • Full load current: 100 A • Connection load: 65 kVA • Status: Fully functional, under power, currently in production Technical Specification Taper Size HSK 63

Condition: ready for operation (used), Year of construction: 1999, For sale Heller MCP-H 460 HS Unipro controller Horizontal 4 axis machine center with direct drive spindle Working range X 2000mm Y 1400mm Z 1250mm Thermo-symmetric gantry column design Pallet system designed for high performance/ production Manufactured 1998 Currently in production, being decommissioned very soon Laodpfxjyw Rwzs Akysa Additional tool carriage at rear to standard one also controlled with a separate unipro controller Please feel free to contact if you require any additional information

Condition: used, Year of construction: 2006, x-travel 800 mm y-travel 800 mm Lajdpfoyb S H Rex Akyoa z-travel 800 mm Control Siemens 840 D total power requirement --- kW weight of the machine ca. 19,0 t dimensions of the machine ca. --- m

Condition: used, Year of construction: 2005, Technical details: x-travel: 2200 mm y-travel: 2200 mm z-travel: 1400 mm spindle taper ISO: 50 spindle diameter in front bearing: 110 mm spindle turning speed range: 45 - 6000 U/min pallet table size: 1000 x 1250 mm Laedjvgmitopfx Akyoa pallet worktable capacity: 6000 kg feed range: 1 - 60000 rapid traverse: 60 m/min spindle drive motor: 27 kW dimensions of the machine ca.: 15 x 8,5 x 5,7 m total power requirement: 133 kVA weight of the machine ca.: 50 t Machine with SIEMENS 840 D control - full B-axis - palette changer for 3 palettes - tool changer for 244 tools - coolant through spindle - max. workpiece swing 2200 mm *

Year of construction: 1985, condition: used, largest surface to be machined: 400 x 300 mm speed of the knife spindle infinitely variable: 1600 - 6000 rpm electrical connection: three-phase current 380 V space requirement: 900 x 800 x 600 mm Lsdpsb Nxdvjfx Akyeaa

Condition: used, Year of construction: 2012, functionality: fully functional, travel distance X-axis: 630 mm, travel distance Y-axis: 630 mm, travel distance Z-axis: 830 mm, torque: 80 Nm, controller manufacturer: Siemens, controller model: 840 D SL, table width: 500 mm, table length: 400 mm, spindle speed (max.): 16,000 rpm, spindle motor power: 40,000 W, number of spindles: 1, number of slots in tool magazine: 54, mount diameter: 63 mm, Year of manufacture: 2012 Control: Siemens 840 D SL Spindle: SCT63 16000 rpm, 40 kW, 80 Nm Tool clamping system: HSK 63 Magazine / stations (options): Chain / 54 Rotary table: 360,000° X 0.001° Coolant system: Knoll VRF 250; internal coolant supply 50 bar (work area rinsing) Working area XYZ (mm): 630 / 630 / 830 Pallet size (mm): 500 x 400 Lsdpfx Akjywkbgeyeaa Workpiece clamping: 60 bar Additional options, features: Receiver for wireless measuring probe (RENISHAW); Pneumatic support control at the workpiece setup station; Automatic setup process; Automatic removal process; Status indicator light; Scraper belt conveyor for wet machining;

Condition: ready for operation (used), Year of construction: 2023, operating hours: 8,900 h, functionality: fully functional, Heller HF5500 including Fastems FPT 1000 Heller HF5000 5-axis machining center Control: Siemens Sinumerik SL Spindle: HSK100 Tool magazine: 100 tools Fastems FPT1000 Ljdjw I Tupopfx Akyeaa 18 pallet stations Planning software (unmanned shift)

Condition: used, Year of construction: 2005, x-travel 2200 mm y-travel 2200 mm z-travel 1400 mm Control Siemens type 840 D size of pallet 1000x1250 mm 360 ° Table load 6000 kg spindle taper ISO 50 Tool changer 244 Pos. turning speeds 45-6000 U/min Ledpfx Akoyquvajyeaa transmission ratio 2 Feed 60.000 mm/min Cooling through the spindle 50 bar weight of the machine ca. 50 t dimensions of the machine ca. 15,5x8,5x5,7 m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 2002, x-travel 630 mm y-travel 630 mm z-travel 630 mm Control Siemens type 840 D size of pallet 400x500 mm numbers of pallets 4 360 ° turning speeds 10-16000 U/min Tool changer 160 Pos. Ljdeyqt Axopfx Akyeaa spindle taper: HSK 63 total power requirement 55 kW weight of the machine ca. 11 t Machine with Siemens 840 D control for 4 axes - Digital drive technology, direct position measuring systems - 4-position pallet changer - Full B-axis - Coolant system with internal coolant supply - Hydraulic workpiece clamping - Filtration system The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: ready for operation (used), Year of construction: 2017, operating hours: 2,339 h, travel distance X-axis: 630 mm, travel distance Y-axis: 630 mm, travel distance Z-axis: 630 mm, controller manufacturer: SIEMENS, controller model: 840D Solution line, table load: 600 kg, number of axes: 4, This 4-axis HELLER H2000 horizontal machining center was manufactured in 2017. It features a Siemens 840D Solution Line control, rapid traverse of 60,000 mm/min, and a spindle speed of 10,000 rpm. The machine can handle workpieces up to 720 mm in diameter and 850 mm in height, with a maximum table load of 600 kg. Consider the opportunity to buy this HELLER H2000 horizontal machining center. Contact us for more information about this machine. Additional equipment • Chip conveyor • Coolant filtration with paper filter KF 400 • Through-spindle coolant, 50 bar • Work area flushing Machine Benefits Technical Machine Benefits • Acceleration: 8 m/s² • Standard color: grey-white / sand grey / ultramarine blue • Max. Workpiece diameter: 720 mm • Max. Workpiece height: 850 mm • Nc rotary table, indexing 360000 × 0. 001° • Clamping station, manually operated pallet, 4 × 90° • 2 pallets, 400 × 500 mm • Tool magazine positions: 54 Ljdoyarzlepfx Akyeaa Extra Information Operating mode: Mode 3 Electrical: 50 Hz, 400 V Hydraulic interface for tool clamping, 5-fold, 60 bar Additional hydraulic control line Hydraulic connection kit with couplings (2 units) Nosepiece for multi-spindle head Infrared receiver for RENISHAW probe RENISHAW probe Drill breakage detection system Signal tower (red-yellow-green) Technology cycles package Additional operating panel at tool magazine

Condition: ready for operation (used), Year of construction: 2010, operating hours: 29,000 h, controller manufacturer: SIEMENS, controller model: 840 D, spindle speed (max.): 12,000 rpm, It is a system composed by a HELLER MCH 350 and a HELLER MCH 350 featuring a 22 pallet system with 800x800 pallets. Both models include a 70 bar pressure system, with the MCH 350 reaching up to 12,000 RPM and the MCH 350 C up to 8,000 RPM. Consider the opportunity to buy this HELLER MCH 350 + MCH 350 C horizontal machining centre system. Contact us for more information about this system. Additional equipment Lodpfxjx D Skme Akyoaa • Pallets: 22 of size 800x800 Machine Benefits Technical Machine Benefits • Pressure: 70 bar on both machines • Tool systems: 2 x 234 hsc 100 • Mch 350 c = 8000 rpm Extra Information MCH 300 Usage: 29000 hours MCH 350 C Usage: 22105 hours

Condition: ready for operation (used), Year of construction: 1999, spindle speed (max.): 10,000 rpm, number of axes: 4, This 4-axis HELLER MC 16-2 was manufactured in 1999. It features a Siemens control system, a robust tool magazine with 160 slots, and an HSK-63A tool holder. The spindle operates at a speed of 10,000 rpm, ideal for detailed machining tasks. If you are looking to get high-quality milling capabilities, consider the HELLER MC 16-2 machine we have for sale. Contact us for more information about this machine. Ledpfx Akex D I Alsyeaa

Condition: ready for operation (used), Year of construction: 2009, number of axes: 4, This 4-axis HELLER MCH 250 was manufactured in 2009. A horizontal machining centre with a voltage of 400 V, frequency of 50 Hz, and a rated current of 123 A. If you are looking to get high quality milling capabilities consider the HELLER MCH 250 machine we have for sale. Contact us for more information. • Voltage: 400 V • Frequency: 50 Hz • Rated current: 123 A Lsdpfsx D Rh Dsx Akyoaa

Condition: ready for operation (used), Year of construction: 1999, spindle speed (max.): 16,000 rpm, This HELLER MC 16 with pallet pool was manufactured in 1999. It features a Control Uni Pro system, a 120-tool magazine, and an HSK-63A tool holder. The spindle operates at a speed of 16,000 rpm. Consider the opportunity to buy this HELLER MC 16 horizontal machining centre. Contact us for more information. Lsdpfxex D Iz Uo Akyjaa

Condition: good (used), Year of construction: 2020, functionality: fully functional, operating hours: 5,800 h, travel distance X-axis: 1,250 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,100 mm, workpiece height (max.): 1,400 mm, workpiece weight (max.): 2,000 kg, controller manufacturer: Siemens, controller model: 840D SL, torque: 1,146 Nm, rotational speed (max.): 8,000 rpm, Machine name / type: HELLER / H 8000 Operating hours: 5800 Year of construction: 2020 Control unit: Siemens 840D SL Spindle: EPC-Unit (8.000 1/min, 60 kW, 1146 Nm) Tool clamping system: HSK 100 Tool magazine / places: Chain / 100 Lodpfeu Urgbjx Akyjaa Rotary table: 360.000° X 0,001° Coolant unit: KNOLL, KF 600, IKZ 70 bar, (work area flushing) Positioning range XYZ (mm): 1250 / 1200 / 1100 Pallet size (mm): 800 X 800 Workpiece clamping: mechanical Additonal options / Specifics: multi-spindle-head support (MSK); receiver for measuring probe (RENISHAW); fast drill fracture sensing (SBBK); interface exhaust system; screen blow-off device for operator door; codechip; Chip conveyor function check; Integrated process monitoring (IPM) + Monitoring function to minimize machine damage in case of collision; 3 colour status lamp; increased tool weight 35kg; scraping conveyor for wet machining; Coolant temperature control; Feed force display; Tangential control;

Condition: excellent (used), operating hours: 16,800 h, functionality: fully functional, travel distance X-axis: 1,600 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,700 mm, feed rate X-axis: 40 m/min, feed rate Y-axis: 40 m/min, feed rate Z-axis: 40 m/min, torque: 822 Nm, controller manufacturer: SIEMENS, controller model: 840D, workpiece length (max.): 1,890 mm, workpiece width (max.): 1,450 mm, table width: 800 mm, table length: 1,000 mm, rotational speed (max.): 6,000 rpm, spindle motor power: 43,000 W, spindle nose: ISO 50 DIN 69871, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, MODEL MCH 450 C DOUBLE PALLET 5-AXIS CNC Control: SIEMENS 840D WORKING AREA: X-axis travel (longitudinal): 1600 mm Y-axis travel (vertical): 1200 mm Z-axis travel (transversal): 1700 mm LINEAR GUIDES: Size 55 DRIVE SYSTEM: Diameter x Pitch: 50x25 mm FEED FORCE: X axis (S3-40%): 15,000 N Y axis (S3-40%): 15,000 N Z axis (S3-40%): 17,500 N FEED RATE: Working feed rate (X, Y, Z axes): 1 - 40,000 mm/min Rapid traverse (X, Y, Z axes): 40,000 mm/min Lasdpfjydfcdjx Akyea Acceleration (X, Y, Z axes): 4.0 m/s² SPINDLE: Front bearing diameter: 100 mm Spindle taper: ISO 50 DIN 69871 Spindle motor power (S1-100% / S6-40%): 28/43 kW from 500 rpm Max torque (S1-100% / S6-40%): 536/822 Nm up to 500 rpm Spindle speed: 45 – 6,000 rpm Positioning: 360° x 0.001° Positioning accuracy Tp as per VDI/DGQ 3441 (angular): s 10 ROTARY TABLE: Positioning: 360° x 0.001° Positioning accuracy Tp as per VDI/DGQ 3441 (angular): s 6 Max clamping weight on pallet: 2,500 daN Max tangential moment: 40,000 Nm Max tilting moment: 34,000 Nm Rotation time 45°: 2.9 s Rotation time 90°: 3.5 s Rotation time 180°: 4.6 s PALLET CHANGER: Coupling surface as per DIN 55201 A1 Pallet dimensions: 800 x 1000 mm Workpiece dimensions: - Positioning diameter in working area x height: 1890 x 1450 mm Pallet change accuracy (X, Y, Z axes): 0.02 mm Pallet change time: 27 s X/Y/Z AXIS POSITIONING ACCURACY: Direct measurement with optical scales Positioning tolerance as per VDI/DGQ 3441: 0.010 mm COOLING UNIT WITH ROTARY VACUUM FILTER – HIGH PRESSURE 70 BAR: Coolant tank capacity: 2,500 l Coolant pump 4 bar, flow rate: 230 l/min Coolant pump 4 bar, flow rate: 70 l/min High-pressure pump 50 bar, flow rate: 28 l/min TOOL CHAIN MAGAZINE WZM 100: Tool magazine positions: 100 Max tool length (from spindle nose): 600 mm Max tool diameter (with adjacent tools): 112 mm Max tool diameter (without adjacent tools): 228 mm EQUIPPED WITH: - Chip conveyor (modified for handling very long chips) - Tool breakage detection - Handwheel (for axis control and movement within the working area) - Tool change in masked time (tools can be loaded/unloaded from magazine automatically without stopping the machine program) USED MACHINE YEAR 2007
