Used Hestika Hand Lever Turret Lathe for sale (14,373)

Condition: good (used), Year of construction: 1959, HESTIKA 22N Hand lever turret lathe Gedpfx Aorm R Duobfsuf

Condition: used, Mechanic's Lathe SCHAUBLIN Type 102 Mach. No. 1998 Centre distance: 350 mm Bed length overall from headstock: 635 mm Swing over bed: 200 mm Centre height over bed: 102 mm Swing over cross slide: 120 mm Centre height over cross slide: 61 mm Spindle bore: 18/20 mm Spindle speed, gear stage 1: approx. 120 / 190 / 320 rpm Spindle speed, gear stage 2: approx. 590 / 970 / 1500 rpm Chuck mounting: external thread M38 x 3 mm Tailstock taper: MT 1 Drive motor: 0.55 kW, 920 rpm Power supply: 380 Volt, 50 Hz - Spindle speeds adjustable via 2 gearbox stages and 3-step drive belt shifting - Main spindle with forward and reverse operation - Spindle mount with M38 x 3 mm thread - 3-jaw scroll chuck Ø 128 mm with stepped jaws Guedpfx Abjy Dvf Rsfef - Collet clamping system with 6 round collets Ø 3 / 4 / 5 / 6 / 8 / 20 mm - Integrated dividing plate on main spindle with 48 / 60 / 100 holes - Toolholder slot approx. 10 x 18 mm with clamping screw - Sturdy wooden base with 42 mm laminated board Required space (with stand): L x W x H: 1160 x 750 x 1300 mm Weight with stand: 150 kg Good condition

Condition: used, Manual lever lathe SCHAUBLIN Type 102 Precision mechanic lathe Machine no. 208322 Year of manufacture: approx. 1970 Total bed length: 650 mm Center height over bed: 102 mm Center height over carriage: 53 mm Medium spindle speed: approx. 2,800 rpm (3 speed stages) Drive motor: 0.37 kW, 2800 rpm Power supply: 380 Volt, 50 Hz - Manual lever parting and grooving slide with precisely adjustable stops - Tool holder with precise height adjustment - Collet chuck device (only one collet included) - Speed change by shifting the drive belt Gedpfsw Iq Umex Abfouf Space requirement with stand: L x W x H 1150 x 600 x 1200 mm Weight with stand: 130 kg Good condition

Condition: used, Year of construction: 2000, faceplate diameter 3200 mm swing diameter 3500 mm turning height 2200 mm range L-W-H 7730 x 6240 x 6700 mm control Typ 840 D sl voltage 3 x 400 V frequency 50 Hz turning speeds 0,8 - 40 U/min max. turning diameter 3500 mm total power requirement 51 kW weight of the machine ca. 86 t Technical specifications Machine type: CNC vertical lathe Manufacturer: Rafamet Year of manufacture: 1973 conventional General overhaul with control retrofit 2010 Control upgrade 2016 Control: Siemens 840 D Sl Condition: very good faceplate Turning diameter of the faceplate 3,200 mm Number of rotation stages of the face plate 3 (infinitely variable) Speed ??ranges of the faceplate 0.8 - 40 rpm Level I 0.8 – 3 rpm Level II 0.8 - 11 rpm Level III 0.8 – 40 rpm processing of workpieces Max. turning diameter 3,500 mm Max. turning height of the workpieces above the faceplate 2,200 mm vertical supports Smallest axis distance between the vertical supports 470 mm Largest ram travel of the left vertical support 985 mm Largest ram travel of the right vertical support 985 mm Axis Feeds - Infinitely variable feed Max.: X1.2 3m/min max.: z1.2 2.5 m/min Plunger cannot be pivoted Support — crossbar Rapid feed of the cross beam 600 mm/min Larger distance of the cross beam to the faceplate 2,300 mm load sizes +Permissible turning force when turning workpieces with a turning diameter of 2,000 mm and a turning speed of 20 m/min. 8,000kg +Largest chip cross-section for workpieces made of steel Fz = 50 kg/mm² at a turning speed of 20 m/min for all supports 45 mm² +Largest chip cross-section for workpieces made of steel Fz = 50 kg/mm² at a rotation speed of 20 m/min for a vertical support with max. plunger length 985 mm 2.5 mm² +Largest chip cross-section for cast iron workpieces HB = 160 kg/mm² at a turning speed of 20 m/min for all supports 120 mm² +Largest chip cross-section for cast iron workpieces HB = 160 kg/mm² at a rotation speed of 20 m/min for a vertical support with max. plunger length 985 mm 22.5 mm² +Largest permitted workpiece weight at 0.8 - 3.15 rpm 17,500 kg +Largest permitted workpiece weight at 4 - 40 rpm 7,500 kg electric motors Main drive motor power and revolutions 51 kW Power of the feed motors of: - Vertical support beam (2 pieces) 16 Nm (gear 1:10) Gusdpfsuddcgox Abfsf - Tappet (2 pieces) 16 Nm (gear 1:12) Power and revolutions of the drive motor of the hydraulic pumps (2 pieces) 3kW - 1,500 rpm Power and revolutions of the clamp hydraulic motor of the vertical support beam 1.5 kW - 1,500 rpm Power and rotation for crossbar adjustment 15 kW - 1500 rpm 3.5 Information on the compressed air supply and other consumables Compressed air connection: 6 bar free of oil and water 3.6 Energy Consumption Conditions Voltage: 3 x 400V Control Voltage: 24V Frequency: 50Hz Fusing: 315 A Main dimensions and weight of the machine Length 7,730mm Width 6,240mm Height: 6,700mm Weight: 85,750 kg Tool: Capto 60 recording Not powered front panel Turning diameter of the front plate 3,200 mm Clamping disc diameter 3,400 mm Number of rotation levels of the front panel 3 (continuously adjustable) Front panel speed ranges 0.8 - 40 rpm Level I 0.8 - 3 rpm Level II 0.8 - 11 rpm Level III 0.8 - 40 rpm processing of workpieces Max. turning diameter 3,500 mm Max. turning height of the workpieces above ...

Condition: used, Year of construction: 1980, turning diameter 7000 mm faceplate diameter 3500 mm workpiece height 3000 mm 160 mm Gusdpfouddlzox Abfof 1998 Control Siemens 840 C max. table load 60000 kg electr. connected load 400 V Serial number 11 33 0051 total power requirement 71 kW weight of the machine ca. / t required space 13 x 6 m The SCHIESS-FRORIEP 40 DV is a vertical lathe built in 1980. The machine was modernized and improved in 1998. Among other things, a driven tool system (C-axis) was installed. In addition, the control system was modernized to SIEMENS 840 C. The large open-sided vertical boring mills with travelling column - type DV - are particularly suited to situations where likely workpieces frequently change in diameter but where maximum workpiece dimensions are rare. Decisions in favour of this type of machine are generally due to minimum floor space requirement, universal adaptability and economical advantages. The modern design of these machines is characterized by rigid all-steel construction optimized by computer - SCHIESS can claim to have done much valuable pioneering work in this area of heavy-duty machine tool building.

Condition: used, Year of construction: 1962, faceplate diameter 2250 mm swing diameter 4500 mm turning height 2000 mm Godpeuc Aldefx Abfouf turning diameter 3150 mm workpiece weight max. 25000 kg total power requirement 55 kW weight of the machine ca. ca. 32 t required space / m

Condition: used, Year of construction: 1961, turning diameter Max. 4200 mm faceplate diameter 3700 mm turning height Max. 2600 mm workpiece weight Max. 35 t Power 80 PS DIGITAL CONTROL DISPLAY Largest diameter with the crossbeam supports: 4200mm Largest turning diameter with side support: 3900mm Largest turning height above faceplate: 2500 Side support Guodsuddnvspfx Abfsf 1 vertical grinding ram: 1200mm stroke (out of operation) 1 turning ram: 1400mm stroke

Condition: used, Year of construction: 1990, turning diameter 2400 mm faceplate diameter 2200 mm turning height 2100 mm control SIEMENS Sinumerik 850T workpiece weight 17 t Tol measurements 32 Werkzeuge Crossbeam travel: 700mm Crossbeam support Travel from centre of rotation to the right: 700mm Crossbeam support Travel from centre of rotation to the left: 700mm Machine table drive Main drive power: 80kW Number of gearboxes: 2 Gedpfeygx D Hsx Abfouf Step change: 3.84 Speed range of the 1st gear stage: 2-32-139 rpm Speed range of the 2nd gear stage: 9-125-500 rpm Max. Machine table load: 6 tonnes Feed drive Cross beam support Horizontal feed speed: 0.1 - 8 m/min Cross beam support Vertical feed speed: 0.1 - 8 m/min Cross beam support Rapid traverse speed horizontal/vertical: 8 m/min Cross beam adjustment speed: 425 mm/min Tool system Tool system: 180.1 Cutting force on the turning tool: 30 kN

Condition: used, Year of construction: 1977, faceplate diameter 2500 mm swing diameter 2700 mm turning height 2000 mm cross rail - adjustment 1500 mm workpiece weight max. 20.000 kg total power requirement 71 kW Control Siemens Sinumerik 840 Single-column vertical lathe 2000 x 2000mm Retrofit: 1997 Gr. turning diameter: 2700mm Gr. distance f. face plate to bottom of toolholder: 2150mm chisel holder: 2150mm Support swivelling up to 30° Chisel cross-section: 240x240mm small plunging diameter: 300mm Gedpfxeuddpge Abfsuf Special equipment: Re-moulding, taper turning, thread cutting, constant cutting speed

Condition: ready for operation (used), A CNC-controlled REM vertical lathe is available. Working diameter: 2500mm-7000mm, working height: 1000mm, control: Siemens 840D. Including driven tools. On-site inspection is possible. Godpfx Aevriq Dobfsuf

Year of construction: 1968, condition: ready for operation (used), A vertical large-format vertical turning lathe TOS is available. Turning diameter cross rail support/side support: 1150mm/1000mm, max. workpiece weight: 3000kg, max. workpiece height: 900mm, travel X/Y/Z: 500mm/500mm/750mm, table diameter: 1000mm, max. table torque: approx. 8800Nm, machine dimensions X/Y/Z: approx. 2600mm/2700mm/4000mm, weight: approx. 13000kg. Documentation available. An on-site inspection is possible. Expected to be available from Q3 2026. Guedpfxeyiflts Abfof

Condition: good (used), Hand lever shears, long-blade sheet metal and round steel shears, lever shears -Manufacturer: Mubea, sheet metal and round steel shears -Cutting insert length: 200 mm -Round steel: up to approx. 20 mm -Rectangular profile: up to approx. 19x19 mm -Lever arm: with rack and pinion transmission -Overall dimensions: 455/170/H1540 mm Godpfeibitmjx Abfouf -Transport dimensions: 1230/170/H440 mm -Weight: 49 kg

Condition: new, Year of construction: 2024, faceplate diameter 1200- 2000 mm swing diameter 1400- 2500 mm turning height 1000- 2000 mm Control Siemens/Fanuc Godsix A Avopfx Abfjuf We offer brand new CNC vertical lathes, with and without live tooling. Swing diameter could be between 1,4 to 2,5 m. Please send your enquiry if you are interested.

Condition: used, Year of construction: 2009, faceplate diameter 1250 mm Godpfozhxi Rjx Abfouf turning height 1250 mm Control 0i-TD Fanuc max. torque at faceplate 12500 Nm max. turning diameter 1600 mm max. workpiece weight 5000 kg table speed 2- 300 min/-1 x-axis 1475 mm z-axis 900 mm rapid traverse 10 m/min spindle cone ISO BT50 tool capacity 12 pos. total power requirement 75 kW weight of the machine ca. 32 t dimensions of the machine ca. 4,7 x 5,8 x 5,5 m CNC vertical lathe with 12 positions ATC. Spindle reception is BT 50. Control: Fanuc 0i-TD

Condition: used, Technical details: faceplate diameter: 1400 mm swing diameter: 1470 mm turning height: 1325 mm ram stroke range: 750 mm adjustment of cross-rail: 850 mm max. workpiece weight: 12000 kg faceplate turning speed range: 4,5 - 224 U/min feed per revolution: 0,06 - 8 mm rapid speed: 1,8 m/min total power requirement: 50 kW weight of the machine ca.: 16 t Gujdpeztn U Tsfx Abfjf Machine was modernized in 2008 with new electric 2-axes digital readout 5-station turret head autom. swivelling diverse toolholders *

Condition: used, Craven Double-Column Vertical Boring & Turning Mill (VTL) Table Diameter: 9 ft / 2,743 mm Maximum Swing: 9 ft 6 in / 2,895 mm Maximum Machining Height: 6 ft 6 in / 2,000 mm (Table top to underside of crossrail) Gusdpfxezq Dc Uj Abfjf Maximum Workpiece Weight: Up to 15,000 kg (Approx. 15 Tons) Table Speed Range: 1 to 50 RPM Ram Travel (Vertical Z-Axis): Up to 1,000 mm

Condition: used, Technical details: faceplate diameter: 1400 mm swing diameter: 2000 mm turning height: 1270 mm main drive: 80 kW faceplate speeds from - to: 1 - 355 U/min max. workpiece weight: 6.000 kg milling motor: 37 kW milling head speed: 7 - 3000 U/min milling spindle - taper: ISO 50 cross rail adjustment - vertical: 800 (8 x 100 mm) mm ram head dimension: 240 x 240 mm max. ram stroke: 1250 mm weight of the machine ca.: 50 to total power requirement: 133 kVA Gedpfx Aovb Dcmsbfeuf dimensions of the machine ca.: 11 x 5 x 6,4 m Machine general overhould in 2008 and equiped with CNC SIEMENS 840 D control - tool changer for 72 tools - C-axis, live tooling - angular- and straight tool holder head with CAPTO taper - Transmit function - complete splash housing - coolant device, chip conveyor - diverse accessories *

Condition: excellent (used), Year of construction: 1983, Faceplate diameter: 1250 mm Max. swing diameter: 1400 mm Max. swing height: 1160 mm Max. ram stroke, vertical / horizontal: 755 / 840 mm Table load capacity: unlimited Faceplate speed range: 5.6 - 300 rpm Vertical slide angular adjustment: 45° Feed rate range: 0.044-8 mm/rev Rapid traverse rate: 2 m/min Drive power: 55 kW Footprint L x W x H: 2660 x 2710 x 3360 mm Total weight: 16,500 kg Accessories / Special features: • 2-axis digital display, manufacturer: ACU-Rite • Faceplate, Ø 1250 mm, with 4 chuck jaws • 5-position turret • Taper turning • Profile turning Guedpfxey Ex Epo Abfjf Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel / Germany

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, Technical details faceplate diameter 1800 mm swing diameter 2000 mm turning height 1270 / 1120 mm Control SIEMENS 840 D workpiece weight max. 5000 kg ram head dimension 250 x 250 mm table turning speeds 1 - 320 U/min cross rail - adjustment 400 mm ram head - cross travel (X) -2770 / +2275 mm ram head - vertical travel (Z) 1250 mm c-axis 360° (0,001°) deg milling drive 37 kW turning speed range - milling 10 - 3000 U/min power capacity - table 100 kW Torque 31784 Nm feed range (X/Z) 0,1 - 15000 mm/min weight of the machine ca. 55 t Additional information Used CNC vertical lathe for turning, drilling and milling First machine installation in the year 2011. The machine was meticulously maintained by the previous owner. It was sold due to a factory closure Max. workpiece diameter: 2040 mm Max. workpiece height: 1270 mm Ram stroke: 1250 mm Max. workpiece weight: 5000 kg (per pallet/chuck) Table speed range: 1.0 - 320 rpm Table drive motor: 100 kW Drilling and milling spindle: 37 kW Crossbar travel: 2 steps of 200 mm each Total electrical connection value: 218 kVA CNC control: Siemens 840 D Number of NC axes: 4 (X, Z, C, crossbar adjustment) Travels: X-axis: -1650 to + 2165 mm Z-axis: 1250 mm Rapid traverse X- Z-axis: 15 m/min Number of tool magazine spaces: 80 spaces in the chain magazine, of which 60 x HSK 100 and 20 x Capto C6 Disc magazine 12-pos. for rotary holders and attachment heads Coolant system with filter and circulation unit Chip conveyor Oil-mist-extractor 1 pallet with jaws, diameter 1800 mm 1 hydraulic chuck with base jaws, diameter 1800 mm Various drilling and milling heads 2 measuring probes Several turning tool holders Special feature: Pallet changer with two stations, equipped with a face plate Ø1800 mm and a six-jaw lever compensation chuck with mechanical centrifugal force compensation Ø1800 mm. Note: The machine is in a pit. Condition description: The cross roller bearing on the Carnaghi was replaced about half a year ago. The Siemens components in the control cabinet were also completely replaced at the end of 2023. The machine also has a measuring probe for tool measurement and an external Renishaw measuring probe for workpiece measurement. As a special feature, the machine also has a measuring probe installed on the Z-axis (Z1-axis). This brings an advantage in terms of accuracy and time, as the tool does not have to be put down for measuring. However, it is currently shut down and should be overhauled when it is put back into operation. The machine also has a Rotomors six-jaw lever compensating chuck with centrifugal force compensation, which was completely overhauled in 2020/21. Gusdpfx Aezr D Tcobfof

Condition: used, swing diameter 2000 mm turning height 1800 mm Control Siemens Sinumerik 840 Dsl turning speeds range 2,8-315 U/min cross rail adjustment - vertical 1200 mm Gujdoy Dvlqepfx Abfsf cross rail adjustment - horizontal +/- 1150 mm 1500 mm bit feeder section 240 x 240 mm Minimum immersion diameter 340 mm cutting capacity 50 kN max. torque on the faceplate 50000 Nm speed range step 1 2,8 - 80 U/min speed range step 2 12 - 315 U/min Max. clamping weight 12000 Kg power capacity faceplate 105 kW weight of the machine ca. 33 t dimensions of the machine ca. 10 x 5 x 6,5 m Further technical data: - Feed range of three-phase servo motors: 1–3000 mm/min; 0.01–50 mm/rev - Crossbeam travel speed: 425 mm/min Features/Accessories - Increased turning height (+600 mm) - Z-axis extended to 1500 mm - Magazine capacity: 20 positions - Magazine type: disc magazine - Max. tool length: 525 mm - Chip conveyor - Workpiece measurement - Renishaw probe - Coolant tank capacity: approx. 2000 litres - Coolant pump flow rate: 60 litres/min at 2 bar Overhaul: - Extensively overhauled in 2012 by Siemens Industry Munich - Items overhauled included: control system, cabling, motors, measuring systems, etc. - Further information can be found in the PDF

Condition: excellent (used), turning diameter over bed 260 mm spindle passage 28 mm turning length 300 mm centre height 130 mm turning speeds 125 - 2800 U/min total power requirement 3 kW weight of the machine ca. 0,8 t Godozq Hmvopfx Abfjuf dimensions of the machine ca. 1,4 x 0,6 x 1,4 m

Condition: like new (used), Year of construction: 1970, turning height: 4,000 mm, workpiece weight (max.): 100,000 kg, turning diameter: 17,000 mm, faceplate diameter: 5,000 mm, Universal machine 5-axis (turning, milling) Froriep 40KE 500/600-400 Spheromill Year of construction: 1970 (modernized 1984 and 2006) Control: Siemens 840D Milling length: 8500 mm Working height max: 4000 mm Gedpoym Ri Uefx Abfsuf Maximum turning diameter: 17,000 mm Table diameter: 5000 mm Ram setting: -15 degrees to +90 degrees Table speed max: 40 rpm (100 kW) Maximum working load: 100 tons Accessories Milling head (800 rpm / 60 kW) Universal milling head (630 rpm) Facing slide for diameter max. 1000 mm Grinding equipment 90 degree angle head (630 rpm) 90 degree angle head (450 rpm) - small

Condition: ready for operation (used), Table diameter: 2250mm Max. swing diameter: 2500mm Guodsyxb I Tspfx Abfjf Max. workpiece height: 1600mm

Condition: used, Year of construction: 2007, Technical details: faceplate diameter: 1600 mm power requirement: 80 kW weight of the machine ca.: 25 t dimensions of the machine ca.: 4,4 x 4,62 m max. workpiece diameter: 2000 mm max. diameter of face turning: 1800 mm tool taper: ISO50 The machine has been regularly serviced and is in good technical condition. With C-Axis * Gjdpfsx Aq E Hsx Abfeuf

Condition: excellent (used), functionality: fully functional, turning height: 800 mm, turning diameter over cross slide: 800 mm, turning diameter: 1,000 mm, faceplate diameter: 800 mm, Manufacturer: – JUNGETHAL Machine: – VTL Type: – 800 Gedpfx Aozmqafsbfsuf Year of Manufacture: – Condition: – In production Total Machine Weight: – 11 tons TECHNICAL DETAILS Faceplate: 800 mm Height: 800 mm Turning Diameter: 1,000 mm Faceplate Turning Speed Range: 22 – 250 RPM Chuck Diameter: 800 mm Swing Diameter: 1,000 mm Height: Table Load: 3 tons Turntable: 4-station Drive Power: 37 kW Weight: 11 t Voltage: 380 V Total Power Requirement: 17 kW Machine Dimensions: 1000 mm (with side tool post) 2.3 x 2.3 x 2.6 m
