Used Turret Lathe for sale (5,739)

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, Technical details faceplate diameter 1800 mm swing diameter 2000 mm turning height 1270 / 1120 mm Control SIEMENS 840 D workpiece weight max. 5000 kg ram head dimension 250 x 250 mm table turning speeds 1 - 320 U/min cross rail - adjustment 400 mm ram head - cross travel (X) -2770 / +2275 mm ram head - vertical travel (Z) 1250 mm c-axis 360° (0,001°) deg milling drive 37 kW turning speed range - milling 10 - 3000 U/min power capacity - table 100 kW Torque 31784 Nm feed range (X/Z) 0,1 - 15000 mm/min weight of the machine ca. 55 t Additional information Used CNC vertical lathe for turning, drilling and milling First machine installation in the year 2011. The machine was meticulously maintained by the previous owner. It was sold due to a factory closure Max. workpiece diameter: 2040 mm Max. workpiece height: 1270 mm Ram stroke: 1250 mm Max. workpiece weight: 5000 kg (per pallet/chuck) Table speed range: 1.0 - 320 rpm Table drive motor: 100 kW Drilling and milling spindle: 37 kW Crossbar travel: 2 steps of 200 mm each Total electrical connection value: 218 kVA CNC control: Siemens 840 D Number of NC axes: 4 (X, Z, C, crossbar adjustment) Travels: X-axis: -1650 to + 2165 mm Z-axis: 1250 mm Rapid traverse X- Z-axis: 15 m/min Number of tool magazine spaces: 80 spaces in the chain magazine, of which 60 x HSK 100 and 20 x Capto C6 Disc magazine 12-pos. for rotary holders and attachment heads Coolant system with filter and circulation unit Chip conveyor Oil-mist-extractor 1 pallet with jaws, diameter 1800 mm 1 hydraulic chuck with base jaws, diameter 1800 mm Various drilling and milling heads 2 measuring probes Several turning tool holders Special feature: Pallet changer with two stations, equipped with a face plate Ø1800 mm and a six-jaw lever compensation chuck with mechanical centrifugal force compensation Ø1800 mm. Note: The machine is in a pit. Condition description: The cross roller bearing on the Carnaghi was replaced about half a year ago. Kdjdpfx Aezzwgujkwjt The Siemens components in the control cabinet were also completely replaced at the end of 2023. The machine also has a measuring probe for tool measurement and an external Renishaw measuring probe for workpiece measurement. As a special feature, the machine also has a measuring probe installed on the Z-axis (Z1-axis). This brings an advantage in terms of accuracy and time, as the tool does not have to be put down for measuring. However, it is currently shut down and should be overhauled when it is put back into operation. The machine also has a Rotomors six-jaw lever compensating chuck with centrifugal force compensation, which was completely overhauled in 2020/21.

Condition: new, Year of construction: 2026, faceplate diameter 1600 mm swing diameter 2000 mm Ksdpfxszzd R Te Akwjdt turning height 1600 mm control Fanuc 0i-D stroke of vertical slide 1000 mm tool holder 1 distance face plate/tool carrier 1065- 1865 mm vertical adjustment of the crossrail 800 mm workpiece weight 10 t faceplate turning speed range -stepless- 1 - 250 U/min feeds mm/min rapid traverse 10/12 m/min horizontal adjustment of slide -200 - +1125 mm adjustment speed of cross-rail 300 mm/min milling spindle - taper SK 50 KVA weight of the machine ca. 28,5 t This machine is a new machine with (C) or without milling spindle. It will be sold with full service and warranty by Wirths GmbH (Price without live tooling). Control: Fanuc 0i-D. Machine has safety guard and 12/18 (C) position ATC.

Condition: new, Year of construction: 2026, faceplate diameter 1250 mm swing diameter 1600 mm turning height 1250 mm control Fanuc 0i-D stroke of vertical slide 900 mm tool holder 1 distance face plate/tool carrier 700- 1500 mm Kdsdezzd R Hepfx Akwjt vertical adjustment of the crossrail 800 mm workpiece weight 6 t faceplate turning speed range -stepless- 1 - 300 U/min feeds mm/min rapid traverse 10/12 m/min horizontal adjustment of slide -200 - +950 mm weight of the machine ca. 20,7 t This machine is a new machine with (C) or without milling spindle. It will be sold with full service and warranty by Wirths GmbH (Price is without live tooling). Control: Fanuc 0i-D. Machine has safety guard and 12/18 (C) position ATC.

Condition: new, Year of construction: 2026, faceplate diameter 2000 mm swing diameter 2500 mm turning height 1600 mm control Fanuc 0i-D stroke of vertical slide 1000 mm tool holder 1 distance face plate/tool carrier 1075 - 1875 mm vertical adjustment of the crossrail 800 mm workpiece weight 13 t Kodpfjzzd Ryjx Akwjdt faceplate turning speed range -stepless- 1 - 200 U/min feeds mm/min rapid traverse 10/12 m/min weight of the machine ca. 42 t This machine is a new machine with (C) or without milling spindle. It will be sold with full service and warranty by Wirths GmbH (Price without live tooling). Control: Fanuc 0i-D. Machine has safety guard and 12/18 (C) position ATC.

Condition: used, Year of construction: 2007, Technical details: faceplate diameter: 1600 mm power requirement: 80 kW weight of the machine ca.: 25 t Ksdpfxsx Aq E Ho Akwodt dimensions of the machine ca.: 4,4 x 4,62 m max. workpiece diameter: 2000 mm max. diameter of face turning: 1800 mm tool taper: ISO50 The machine has been regularly serviced and is in good technical condition. With C-Axis *

Condition: used, turning diameter 1.600 mm max. swing diameter 1.700 mm control SIEMENS - 840 D faceplate turning speed range 1 - 320 U/min rapid traverse 3.000 mm / min feed range 1 - 3.000 mm/min size of pallet 1.168 mm numbers of pallets 2 main drive 55 kW Vertical turret lathe with cnc | SCHIESS MOWEG - BERTHIEZ TFM 125 Kjdpjvp Shgjfx Akwjdt has been overhauled by SCHIESS MOWEG (RETROFIT) in 2007. The machine video from the production plant will be shared on request. The machine is in very good condition and was in operation at an aviation company until recently. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: TFM125 | TFM-125

Condition: used, functionality: fully functional, We are selling this machine. It is connected and can be tested. A video of the machine can be sent via the WhatsApp application. Documentation for the machine is available. Speeds: 1st range: 0.35-3.5 rpm 2nd range: 1.4-14 rpm Drive: 2 regulating motors, each with 120 kW, powered by a 240 kW Ward-Leonard converter. Diameter of the clamping plate: 8,000 mm Largest turning diameter: 12,500 mm Turning height: 2,200 mm The machine underwent a major overhaul and modernization in 1991. Maximum workpiece weight: 200,000 kg Machine weight: 550,000 kg Please submit your offer. Kdsdpfx Akeydqfdswot

Condition: used, Year of construction: 1969, Automatic turret lathe brand: INDEX type: B60 new in: 1967 equipped with: 6x turret Thread turning device Material feed Kdjdpfxoylht Us Akwst

Condition: excellent (used), Year of construction: 1978, functionality: fully functional, turning height: 1,000 mm, turning diameter: 1,500 mm, total height: 5,600 mm, total width: 4,400 mm, total length: 3,900 mm, rotary table diameter: 1,250 mm, type of input current: AC, rotational speed (max.): 315 rpm, rotational speed (min.): 1 rpm, spindle speed (min.): 1 rpm, spindle speed (max.): 315 rpm, table diameter: 1,250 mm, year of last overhaul: 2016, Equipment: documentation/manual, Berthiez TFM 125 Vertical boring and turningmill with toolholder changiging device The machine its from 1978 but has been retroifit in 2016 with new Siemens Sinumerk 840D solutionsline Kdsdjzvydljpfx Akwot This is an high presition vertcal turningmachine with grinding device. Lots of tools its following the machine. The machine its in very good condition! Diameter of table 1250mm Max turningdiameter 1500mm Max turninghigh 1000mm Table high 670mm Max turning table speed 315rpm Spindle 39KW Scale on both axis

Condition: used, Year of construction: 2015, Control system: Fanuc series 32i Max. workpiece diameter: 800 mm Clamping diameter of rotary table: 450 mm Max. table load: kg Max. workpiece height: 750 mm Ram travel (Z): 780 mm Ram size: mm Driven tools: yes Tool magazine: YES Number of positions in magazine: 8 Travel X-axis: 390 mm Travel Z-axis: 780 mm Table rotation: 20 - 2000 /min Main motor power: 30/37 kW Max. spindle torque: 2243/2766 Nm Machine weight: 9000 kg Machine dimensions (l x w x h): 2000x2800x3300 mm Kodpfezxgcysx Akwjdt

Condition: good (used), Year of construction: 1968, functionality: fully functional, Plate diameter …. 8000 mm Max. turning diameter 12,500 mm Machining height 4,000 mm Kdsdpfxozx Hcte Akwot Maximum workpiece weight on the plate 120,000 kg. Approximate weight 556,000 kg.

Condition: ready for operation (used), Year of construction: 2016, functionality: fully functional, turning height: 2,200 mm, turning diameter: 4,000 mm, faceplate diameter: 3,100 mm, table diameter: 3,100 mm, workpiece diameter (max.): 4,000 mm, FULLTONTECH CK5240 CNC vertical turret lathe, year of construction 2016. The machine was purchased new by us in 2016 and is offered for sale by the first owner. It is equipped with a Siemens control and has a double turret: one side CNC-controlled, the other side manually operated. Technical data: - Faceplate / chuck diameter: 3,100 mm - Max. internal clamping / turning diameter (X): 4,000 mm - Machining capacity (Y): 2,200 mm - Control: Siemens - CE marked Kdjdpfx Aoz Anr Djkwjt Well maintained, in full working order and ready for immediate delivery.

Condition: used, Landonio turret for lathe Ksdpozxg Ebefx Akwedt

Condition: good (used), Year of construction: 1972, functionality: fully functional, turning height: 1,000 mm, turning diameter: 1,600 mm, faceplate diameter: 1,400 mm, Retrofit: 2001 Siemens control system SINUMERIK 840D Faceplate diameter 1,400 mm Turning diameter 1,600 mm Turning height 1,000 mm Fully functional. Please refer to the photos for further information. A video of the machine in operation can be provided upon request. Inspection appointments are possible by arrangement. The buyer must arrange the collection. Loading onto a truck/container provided by the buyer is included. Invoice with VAT shown. Since these are used machines/used accessories, we exclude any warranty or guarantee. The information is provided to the best of our knowledge, and we assume no liability. We reserve the right to make changes to technical data and to correct any errors in the description. Kdsdpozvl R Refx Akwjt The buyer has the right to inspect the goods for condition and functionality before concluding the contract. We exclude any warranty for obvious and hidden defects, as well as compensation for damages of any kind, including damages that did not occur to the delivered item itself.

Condition: used, Technical details: table diameter: 4500 mm Kdsdpfx Aksu Ix H Dewet faceplate diameter: 4500 mm operating hours: 0 h swing diameter: 5000 mm turning diameter: 5000 mm workpiece height max.: 2500 mm control: Sinumerik 840D SL x-axis: 300 Hub/ram Slide mm x-axis: 2850 Hub / ram travel mm x-axis: 2850 working without tool mm x-axis: 5000 with tool changer mm w-axis: 1800 Querwegelevating cross rail mm tool holder / places: 12 tool taper: HSK 100 (spindle) workpiece weight: 100 t table speed: 1 - 50 U/min T-slots: 8 Stück (36 H12) stroke speed: fräsen ram speed: 4000 U/min rapid power traverse in X-and Z direction: 8000 mm/min Torque: fräsen: 100.000 Nm Torque: drehen: 200.000 Nm total power requirement: 80 (2x40) kW weight of the machine ca.: 140 t dimension machine approx.LxWxH: 11,5 x 6,6 x 8,4 m NEW CNC vertical turret lathe - manufactured upon official order and deposit. The photos shown are of a newly built machine that we delivered to a customer. (The photos are for illustrative purposes only.) Application of the manufacturing processes: Turning, such as external longitudinal turning, internal and external facing and profile machining. Grooving, such as internal and external Drilling, such as short hole drilling and deep hole drilling Milling, such as face-corner profile and T-slot milling Thread cutting But also suitable for roughing and end machining. The machine bed, designed with a welded construction, absorbs extreme cutting forces. The table is made of high-strength meehanite cast iron. To withstand heavy loads, the part weight is supported by two high-precision tapered roller bearings. Furthermore, the table is equipped with hydrodynamic support for the workpiece. other features: automatic tool change jaw chuck (8 pieces with power clamping spindle and hardened jaws) incl. cooling system 40bar with filter unit hydraulic and lubrication equipment ATOS and Dropsa with measuring system of axes Heidenhain Renishaw NEW - with guarantee & service via WWM AG *

Condition: used, Automatic lathe Manufacturer: STROHM Model: M125 Kodpfoyllr Iex Akwedt

Condition: used, Year of construction: 1962, faceplate diameter 2250 mm swing diameter 4500 mm turning height 2000 mm turning diameter 3150 mm Kjdsuc Aldspfx Akwsdt workpiece weight max. 25000 kg total power requirement 55 kW weight of the machine ca. ca. 32 t required space / m

Condition: used, Year of construction: 2000, faceplate diameter 3200 mm swing diameter 3500 mm turning height 2200 mm range L-W-H 7730 x 6240 x 6700 mm control Typ 840 D sl voltage 3 x 400 V frequency 50 Hz turning speeds 0,8 - 40 U/min max. turning diameter 3500 mm total power requirement 51 kW weight of the machine ca. 86 t Technical specifications Kdedjuddcgspfx Akwst Machine type: CNC vertical lathe Manufacturer: Rafamet Year of manufacture: 1973 conventional General overhaul with control retrofit 2010 Control upgrade 2016 Control: Siemens 840 D Sl Condition: very good faceplate Turning diameter of the faceplate 3,200 mm Number of rotation stages of the face plate 3 (infinitely variable) Speed ??ranges of the faceplate 0.8 - 40 rpm Level I 0.8 – 3 rpm Level II 0.8 - 11 rpm Level III 0.8 – 40 rpm processing of workpieces Max. turning diameter 3,500 mm Max. turning height of the workpieces above the faceplate 2,200 mm vertical supports Smallest axis distance between the vertical supports 470 mm Largest ram travel of the left vertical support 985 mm Largest ram travel of the right vertical support 985 mm Axis Feeds - Infinitely variable feed Max.: X1.2 3m/min max.: z1.2 2.5 m/min Plunger cannot be pivoted Support — crossbar Rapid feed of the cross beam 600 mm/min Larger distance of the cross beam to the faceplate 2,300 mm load sizes +Permissible turning force when turning workpieces with a turning diameter of 2,000 mm and a turning speed of 20 m/min. 8,000kg +Largest chip cross-section for workpieces made of steel Fz = 50 kg/mm² at a turning speed of 20 m/min for all supports 45 mm² +Largest chip cross-section for workpieces made of steel Fz = 50 kg/mm² at a rotation speed of 20 m/min for a vertical support with max. plunger length 985 mm 2.5 mm² +Largest chip cross-section for cast iron workpieces HB = 160 kg/mm² at a turning speed of 20 m/min for all supports 120 mm² +Largest chip cross-section for cast iron workpieces HB = 160 kg/mm² at a rotation speed of 20 m/min for a vertical support with max. plunger length 985 mm 22.5 mm² +Largest permitted workpiece weight at 0.8 - 3.15 rpm 17,500 kg +Largest permitted workpiece weight at 4 - 40 rpm 7,500 kg electric motors Main drive motor power and revolutions 51 kW Power of the feed motors of: - Vertical support beam (2 pieces) 16 Nm (gear 1:10) - Tappet (2 pieces) 16 Nm (gear 1:12) Power and revolutions of the drive motor of the hydraulic pumps (2 pieces) 3kW - 1,500 rpm Power and revolutions of the clamp hydraulic motor of the vertical support beam 1.5 kW - 1,500 rpm Power and rotation for crossbar adjustment 15 kW - 1500 rpm 3.5 Information on the compressed air supply and other consumables Compressed air connection: 6 bar free of oil and water 3.6 Energy Consumption Conditions Voltage: 3 x 400V Control Voltage: 24V Frequency: 50Hz Fusing: 315 A Main dimensions and weight of the machine Length 7,730mm Width 6,240mm Height: 6,700mm Weight: 85,750 kg Tool: Capto 60 recording Not powered front panel Turning diameter of the front plate 3,200 mm Clamping disc diameter 3,400 mm Number of rotation levels of the front panel 3 (continuously adjustable) Front panel speed ranges 0.8 - 40 rpm Level I 0.8 - 3 rpm Level II 0.8 - 11 rpm Level III 0.8 - 40 rpm processing of workpieces Max. turning diameter 3,500 mm Max. turning height of the workpieces above ...

Condition: used, Year of construction: 1980, turning diameter 7000 mm faceplate diameter 3500 mm workpiece height 3000 mm 160 mm 1998 Control Siemens 840 C max. table load 60000 kg electr. connected load 400 V Ksdpfxeuddlzj Akwjdt Serial number 11 33 0051 total power requirement 71 kW weight of the machine ca. / t required space 13 x 6 m The SCHIESS-FRORIEP 40 DV is a vertical lathe built in 1980. The machine was modernized and improved in 1998. Among other things, a driven tool system (C-axis) was installed. In addition, the control system was modernized to SIEMENS 840 C. The large open-sided vertical boring mills with travelling column - type DV - are particularly suited to situations where likely workpieces frequently change in diameter but where maximum workpiece dimensions are rare. Decisions in favour of this type of machine are generally due to minimum floor space requirement, universal adaptability and economical advantages. The modern design of these machines is characterized by rigid all-steel construction optimized by computer - SCHIESS can claim to have done much valuable pioneering work in this area of heavy-duty machine tool building.

Condition: used, Year of construction: 1961, turning diameter Max. 4200 mm faceplate diameter 3700 mm turning height Max. 2600 mm workpiece weight Max. 35 t Power 80 PS DIGITAL CONTROL DISPLAY Kdsdouddnvepfx Akwst Largest diameter with the crossbeam supports: 4200mm Largest turning diameter with side support: 3900mm Largest turning height above faceplate: 2500 Side support 1 vertical grinding ram: 1200mm stroke (out of operation) 1 turning ram: 1400mm stroke

Condition: used, Year of construction: 1990, turning diameter 2400 mm faceplate diameter 2200 mm turning height 2100 mm control SIEMENS Sinumerik 850T workpiece weight 17 t Tol measurements 32 Werkzeuge Crossbeam travel: 700mm Crossbeam support Travel from centre of rotation to the right: 700mm Crossbeam support Travel from centre of rotation to the left: 700mm Machine table drive Main drive power: 80kW Number of gearboxes: 2 Step change: 3.84 Speed range of the 1st gear stage: 2-32-139 rpm Speed range of the 2nd gear stage: 9-125-500 rpm Max. Machine table load: 6 tonnes Feed drive Cross beam support Horizontal feed speed: 0.1 - 8 m/min Cross beam support Vertical feed speed: 0.1 - 8 m/min Cross beam support Rapid traverse speed horizontal/vertical: 8 m/min Cross beam adjustment speed: 425 mm/min Kedpfxsygx D Hj Akwodt Tool system Tool system: 180.1 Cutting force on the turning tool: 30 kN

Condition: used, Year of construction: 1977, faceplate diameter 2500 mm swing diameter 2700 mm turning height 2000 mm cross rail - adjustment 1500 mm workpiece weight max. 20.000 kg total power requirement 71 kW Control Siemens Sinumerik 840 Single-column vertical lathe 2000 x 2000mm Retrofit: 1997 Gr. turning diameter: 2700mm Gr. distance f. face plate to bottom of toolholder: 2150mm chisel holder: 2150mm Support swivelling up to 30° Kdodpfouddpgsx Akwjt Chisel cross-section: 240x240mm small plunging diameter: 300mm Special equipment: Re-moulding, taper turning, thread cutting, constant cutting speed

Condition: good (used), Year of construction: 2006, functionality: fully functional, Max. machining diameter: 2,800 mm Min. machining diameter: 1,400 mm Kdedpfezu Itrjx Akwet Max. machining height: 600 mm Max. workpiece weight: 5,000 kg Rotational speed of the chuck: 21–68 /min.

Year of construction: 1968, condition: ready for operation (used), A vertical large-format vertical turning lathe TOS is available. Turning diameter cross rail support/side support: 1150mm/1000mm, max. workpiece weight: 3000kg, max. workpiece height: 900mm, travel X/Y/Z: 500mm/500mm/750mm, table diameter: 1000mm, max. table torque: approx. 8800Nm, machine dimensions X/Y/Z: approx. 2600mm/2700mm/4000mm, weight: approx. 13000kg. Documentation available. An on-site inspection is possible. Expected to be available from Q3 2026. Kjdpfeyifltex Akwodt

Condition: used, Year of construction: 2009, faceplate diameter 1250 mm turning height 1250 mm Control 0i-TD Fanuc Kjdpfx Aszhxi Rjkwedt max. torque at faceplate 12500 Nm max. turning diameter 1600 mm max. workpiece weight 5000 kg table speed 2- 300 min/-1 x-axis 1475 mm z-axis 900 mm rapid traverse 10 m/min spindle cone ISO BT50 tool capacity 12 pos. total power requirement 75 kW weight of the machine ca. 32 t dimensions of the machine ca. 4,7 x 5,8 x 5,5 m CNC vertical lathe with 12 positions ATC. Spindle reception is BT 50. Control: Fanuc 0i-TD
