Used Hebrock K36 for sale (7)

Condition: excellent (used), Year of construction: 2024, Hebrock adhesive basin / exchange basin For Hebrock K36 Year of manufacture: 2024 Location: in stock at warehouse 54634 Bitburg Nedpjznnlhjfx Alxelf - immediately available -

Condition: used, Year of construction: 2020, Edge banding machine K36, 1 unit, with PLC control (incl. touchscreen) and hot melt adhesive application to the workpiece; rabbeting cutter (incl. DIA tool) up to 3 mm cutting depth; glue reservoir with quick-change reservoir preparation, incl. adhesive dispensing device; high-frequency miter saw station (approx. 16,000 rpm); high-frequency milling station (approx. 16,000 rpm with separate pneumatic milling adjustment); corner rounding cutter (min. workpiece length 300 mm, max. workpiece height 40 mm); radius cutting blade; flush cutting blade (incl. pneumatic extraction); cleaning station; 1 free space for a 2nd milling station or a slot cutting saw (slot cutting saw only if the cleaning station is removed); robust chain drive, ball-bearing mounted double roller pressure pad, viewing window from the rear of the machine, extendable workpiece support, signal lamp for workpiece sequence. Technical data: Max. edge thickness: 3 mm Max. rabbet thickness: 3 mm Min. workpiece height: 8 mm Max. workpiece height: 60 mm Max. rabbet height: 40 mm Min. workpiece length: 160 mm Feed rate: approx. 10 m/min Ready for operation: approx. 5 min. Power consumption: (400V – 3Ph – 50 Hz) Working height: approx. 900 mm Machine dimensions: approx. 5250x1250x2050 mm (L x W x H) Weight: approx. 1700 kg Dust extraction nozzle: 1x140 mm + 1x80 mm 8 mm version K36, 1 unit, quick-change fitting for corner milling cutter Nledpfjzvhk Hjx Alxsf K36, 1 unit, extra charge for multi-radius cutting blade (R2/R1) K36, 1 unit, rabbeting up to 60 mm workpiece thickness K36, 1 unit, release agent spray device, plate K36, 1 unit, cleaning agent spray device, plate K36, 1 unit, nesting for milling station K36, 1 unit, nesting for radius cutting blade K36, 1 unit, pneumatic 3-point adjustment K36, 1 unit, Airtronic K36, 1 unit, extension of the support in the infeed and outfeed by 440 mm each; 1 unit. With the help of the plug-in extension of the infeed and outfeed of the table extension, Hebrock offers a solution for an enlarged support surface for improved workpiece handling by 450 mm. Level monitoring without reservoir, 1 unit. Thanks to a sensor on the top of the glue application roller, the operator can be shown a minimum glue level. A warning is displayed on the screen. Once this warning appears, a maximum panel processing length of 100 m (19 mm chipboard) is possible. Ball bearing for corner rounding cutter, 24.1 mm, 1 unit Ball bearing for corner rounding cutter, 24.2 mm, 1 unit Packaging surcharge, 1 unit Additional quick-change reservoir incl. level sensor Manufacturer: Hebrock Type: 36/14/1 Article No. H36/14/1, 1.0 unit Additional change motor for corner milling cutter K36 Manufacturer: Hebrock Type: 36/08/2 Article No. H36/08/2, 1.0 unit R1 Location: Supplier

Condition: new, Year of construction: 2026, The Hebrock K 36 Top model with motorized adjustment – a new machine. This Hebrock bestseller offers unprecedented possibilities. Developed for the highest standards, the K 36 stands for absolute reliability and productivity in daily use. By enabling the machine to be equipped with a stepped cutter and a multi-radius trimming cutter, Hebrock sets new standards in the field of perfect edge finishing for various edge thicknesses. Max. edge thickness: 3 mm Max. workpiece thickness: 60 mm Ready for operation in 6 min. Max. edge thickness: 3 mm Min/Max. workpiece thickness: 8 – 60 mm Min. workpiece length: approx. 140 mm Feed speed: approx. 15 m/min Ready for operation: approx. 6 min Max. power consumption: approx. 7.4 kW Electrical connection: 400 V – 3 phases – 50 Hz Work table height: approx. 900 mm Machine dimensions: approx. 5250 x 1230 x 1430 mm (L x W x H) Weight: 1750 kg Equipment: Hebrock K 36. - 15 m/min Edge banding machine K36 With PLC control (incl. 15'' touchscreen), hot melt adhesive application to the workpiece for edge material up to 3 mm; trimming cutter (incl. diamond tool) up to 3 mm cutting depth, maintenance-free, coated glue tank with interchangeable tank preparation including glue discharge device, high-frequency double-motor trim saw station (approx. 12000 rpm), high-frequency milling station (approx. 12000 rpm) with pneumatic milling adjustment and interchangeable cutter (combination design), corner rounding cutter, radius trimming cutter, flush trimming cutter (incl. pneumatic retraction device), cleaning station, robust chain drive, ball-bearing double roller pressure, unit sight window from the machine rear and operator side, signal lamp for workpiece sequence, pull-out workpiece support, feed speed approx. 15 m/min, edge banding up to 60 mm workpiece thickness 36/08/1 Quick-change preparation for corner cutter 36/08/2/1 additional interchangeable motor for corner cutter R=1 36/09/1 Multi-radius trimming cutter Nedpfx Asi Am Ukelxelf 36/24/1 Release agent spray device 36/24/2 Cleaning agent spray device 36/25 Edge protection spray 36/27 Nesting (1x milling station + 1 x radius trimming cutter) 36/30 Pneumatic 3-point adjustment 36/30/1 Multi-tool for high-frequency milling station (R2/R1/chamfer) 36/45 Axis package Motorized adjustment for panel, edge thickness, and trimming cutter depth adjustment Location: in stock, 54634 Bitburg Available upon agreement.

Condition: excellent (used), Edge Banding Machine HEBROCK K36 Airtronic -used- - PC control with display - Touchscreen - Swiveling control panel - Program memory - Automatic pressure bridge adjustment - Feed via transport chain - Extendable workpiece support - Motorized adjustable infeed fence - Diamond jointing cutter, both with and against feed direction - Quick heating gluepot - Gluepot change system - Suitable for PUR adhesives - Cross-cut saw with HF motor - Flush milling unit - Flush, radius, and chamfer milling unit - Pneumatic changeover of milling unit - Multi-milling tool - Multi-radius scraper blade - Chip collection box for radius scraper blade - Air jet nozzle at the radius scraper - Flat scraper blade - Air jet nozzle at the flat scraper - Exchangeable motor for corner rounding - Spray device for separator agent - Spray device for cleaning agent - Spray device for antistatic coolant - Spray device for lubricant - LED lighting in the machine area - Exchange gluepots - Zero Joint Airtronic System ----- Technical Data ----- - Edge thickness, coil material: 0.5-3 mm - Max. edge thickness for corner rounding: 3 mm - Workpiece thickness: 8-60 mm - Workpiece thickness for corner rounding: 45 mm - Min. workpiece length: 200 mm - Feed speed: 7-10 m/min - Support plate Ø for edge material: 850 mm Nlsdpfeymyp Rjx Alxef - Guillotine for coil material up to: 3 mm - Jointing cutter power: 2x2.2 kW - Cross-cut saw power: 0.37 kW - Milling station power: 2x0.37 kW - Corner rounding unit power: 0.37 kW - Buffing unit power: 2x0.18 kW - Extraction port Ø jointing unit: 60 mm - Compressed air connection: 7 bar - Total length: 5,540 mm - Dimensions (LxWxH): 5,540x1,210x1,450 mm - Weight: 1,700 kg Quality Information: - All settings checked - Complete basic inspection - Complete basic cleaning - Electrical system checked - Pneumatics checked - Immediately ready for operation

Condition: ready for operation (used), Year of construction: 2024, workpiece height (max.): 60 mm, feed rate X-axis: 10 m/min, spindle speed (max.): 16,000 rpm, control type: PLC-controlled, The machine has already been disassembled and stored by a specialist. TECHNICAL DETAILS Rotational speed of the miter saw station: approx. 16,000 rpm Rotational speed of the milling station: approx. 16,000 rpm Maximum milling depth: 3 mm Design for edge thickness: 1 mm Hot melt adhesive specification for edge material max.: 3 mm Feed rate: approx. 10 m/min Maximum workpiece thickness: 60 mm EQUIPMENT Maintenance-free, coated glue basin with provision for interchangeable basins Glue dispensing device Pneumatic milling adjustment Combination design with interchangeable plate cutter Corner rounding milling cutter Radius drawing blade Surface drawing blade with pneumatic extraction device Cleaning station Robust chain drive Nedpfxjzb Idfj Alxjlf Ball-bearing mounted double roller pressure pad Aggregate viewing window from the machine's rear and operator side Signal lamp for workpiece sequence Extendable workpiece support ACCESSORIES Hebrock 8 mm version Hebrock quick-change system for corner milling cutter Hebrock jointing up to 60 mm workpiece thickness Hebrock protective spray for edges Hebrock nesting (milling cutter + radius drawing blade) Hebrock Airtronic Note: Accessories are provided without guarantee. The principle applies: "Item purchased as seen." The prospective buyer must verify the completeness of the item on-site.

Condition: new, Year of construction: 2026, Max. edge thickness 3 mm (optionally up to 8 mm) Min/Max. work piece thickness 8–60 mm* Min. workpiece length approx. 200 mm* Min. workpiece width approx. 80 mm* Feed speed approx. 10 m/min. Ready to operate approx. 6 min. Power consumption max. approx. 14 kW Electrical connection 400 V – 3 Ph – 50 Hz Machine dimensions 5,250 x 1,230 x 1,430 mm (LxWxH) Weight approx. 1,700 kg pre-milling head Whispercut radius for corner rounder R = 2mm heatable infeed fence quick change device f.motor corner rounder change motor for corner rounding unit including HM profile cutter radius for change motor R = 1mm Radius Multi-Radiusscraper R2/R1 wheels release agent spraying unit Nledpfsg Tu Rkox Alxef cleaning agent spraying unit protection spraying edge nesting pneumatic 3-point adjustment

Condition: used, Year of construction: 2021, machine/vehicle number: K3999, functionality: fully functional, operating hours: 5,384 h, power: 14.6 kW (19.85 HP), input voltage: 400 V, input current: 29 A, input frequency: 50 Hz, type of input current: three-phase, workpiece height (max.): 60 mm, edge thickness (max.): 3 mm, feed rate X-axis: 10 m/min, total height: 1,430 mm, total length: 5,250 mm, total width: 1,230 mm, overall weight: 1,700 kg, Equipment: CE marking, documentation/manual, Hebrock K36 AIRTRONIC edge banding machine – zero joint, 2021, low mileage Nedpjzvu Ekefx Alxslf We are selling a single-sided edge banding machine from Maschinenbau Hebrock GmbH (Hüllhorst, Germany), model K 36 with AIRTRONIC system, machine number K3999, year of manufacture 2021. The machine is currently in operation at our facility – fully functional and ready for immediate use. Zero joint – this is what sets this machine apart. The edge banding machine is equipped with an Airtronic hot air unit. Compressed air heated to 300–600 °C is directed through a nozzle directly onto the functional layer of the edge band, just before the pressing zone – the edge band fuses with the panel without a visible glue line. In practice, this means the ability to edge band acrylic, high-gloss, and lacquered fronts with quality comparable to laser technology, without investing hundreds of thousands of zlotys in a laser machine. This is the most expensive and rarest option in this class of edge banding machines – on the used market, there are literally only a few machines with a zero joint available across Europe. The machine can also operate in a conventional mode, using standard EVA and PUR hot melt adhesive. Mileage – documented by the machine’s counters: Operating hours: 5,384 mth Length of edge band applied: 619,339 m (619 km) Parameter Value Type K 36 Machine number K3999 Year of manufacture 2021 Voltage / frequency 400 V / 50 Hz Rated current 28.9 A Total power 14.6 kW Operating hours 5,384 mth Edge length 619,339 m Machine name Single-sided edge banding machine with Airtronic zero joint Machine number K3999 Functionality Fully functional Operating hours 5384 Live demonstration possible Weight / dimensions 1700 kg · 5250 × 1230 × 1430 mm Input current 28.9 A (rounded to 29) Workpiece height 60 mm X-axis feed 10 m/min Edge thickness 3 mm PRICE 250,000 NET
