Used Haas St-25 for sale (3)

Condition: excellent (used), Year of construction: 2020, 2020 Haas ST-25 CNC Slant Bed Lathe & Tooling Package Kjdpfez Rqmrsx Ahisnc Haas Autogrip 3H-H12 Ø250mm 3 Jaw Power Chuck. Maximum Swing Ø806mm. Maximum Swing Over Cross Slide Ø527mm. Maximum Cutting (Varies With Turret) Ø381mm. Bar Capacity Ø76mm. Axis Traverses 'X'=236mm, 'Z'=527mm. Rapid Traverses 'X'=24m/min, 'Z'=24m/min. Spindle Bore Ø117.3mm. Maximum Spindle Speed 3,400rpm (22.4kW Motor). Spindle Nose A2-6. 12 Station Turret. Power On Hours 1,979. S/No. 3119435 (2020). With Coolant System (Tank Capacity 208L), Marposs Tool Setting Arm, Tailstock, Footswitches, Signal Tower, Tooling Package (Turning Tools, Jaws, Collets & coolant Fixings) & Manual. Machine Foot Print W3,630 x D2,290 x H2,340mm. Weight 4,536kg.

Condition: used, Year of construction: 2022, HAAS ST25Y with counter-spindle, year 2022 maximum machining diameter: 298 mm, cutting length: 572 mm, spindle through-hole: 76 mm, 12-position BMT65 turret, Y-axis travel: +/- 50.8 mm, HAAS control system, Knodpfozk H Hvsx Ahiec 3-jaw chuck, 254 mm, -counter-spindle -chip conveyor, -swarf tray with pump, -measuring probe, -parts catcher low operating hours, excellent condition.

Condition: ready for operation (used), Year of construction: 2022, spindle speed (max.): 3,400 rpm, travel distance X-axis: 213 mm, travel distance Y-axis: 102 mm, travel distance Z-axis: 572 mm, spindle motor power: 22,400 W, overall weight: 5,580 kg, number of slots in tool magazine: 12, number of axes: 3, This 3-axis HAAS ST-25Y was manufactured in 2022. It features a maximum cutting diameter of 11.75 in and a maximum cutting length of 22.5 in. The machine is equipped with a 10 in chuck size and a robust spindle speed of 3400 rpm. If you are looking to get high-quality turning capabilities, consider the HAAS ST-25Y horizontal turning machine we have for sale. Contact us for further details. • Working hours: 0 (showroom machine) • Chuck size: 10.0 in / 254 mm • Max part swing: 21.0 in / 533 mm • Max cutting diameter (with BMT65 turret): 11.75 in / 298 mm • Max cutting length: 22.5 in / 572 mm • Bar capacity: 3.00 in / 76 mm • Rapids (X / Y / Z): 472 ipm (12.0 m/min) / 472 ipm (12.0 m/min) / 945 ipm (24.0 m/min) • Max thrust (X / Y / Z): 4100 lbf (18238 N) / 2300 lbf (10231 N) / 5100 lbf (22686 N) • Spindle nose: A2-6 • Max spindle torque: 300.0 ft-lbf @ 500 rpm / 407.0 Nm @ 500 rpm • Spindle bore diameter: 3.50 in / 88.9 mm • Main spindle C axis max rating: 5.0 hp / 3.7 kW • Main spindle C axis max speed: 60 rpm • Main spindle C axis positioning: ± 0.01° • Main spindle C axis brake diameter: 13.9 in / 353 mm • Main spindle C axis brake holding torque: 250 ft-lbf / 339 Nm • Sub-spindle chuck size: 5.3 in / 135 mm • Sub-spindle nose: A2-5 • Sub-spindle max speed: 6000 rpm • Sub-spindle max sync speed with main spindle: 3400 rpm • Sub-spindle chuck throat: Ø 1.30 in x 1.37 in deep / Ø 33.0 mm x 34.8 mm deep • Sub-spindle drawbar bore (non-through): Ø 1.00 in x 4.50 in deep / Ø 25.4 mm x 114.3 mm deep • Sub-spindle bore (without chuck and drawbar): 1.50 in / 38.1 mm • Sub-spindle integrated brake torque: 17 ft-lbf / 23 N·m • Sub-spindle orientation accuracy: ± 0.02° • Sub-spindle rapids (B-axis): 400 ipm / 10 m/min • OD vs ID tools: Any combination • Boring bar rear clearance: 4.00 in / 102.0 mm Kjdpsz N Dmvefx Ahionc • Live tooling max speed: 4000 rpm • Live tooling interface: BMT65 • Coolant capacity: 55 gal / 208 L • Air requirements: 4 scfm @ 100 psi / 113.0 L/min @ 6.9 bar • Inline air hose and coupler: 3/8 in • Minimum air pressure: 80 psi / 5.5 bar • Drive system: Direct speed, belt drive • Electrical requirements: Low 220 VAC @ 70 A / High 440 VAC @ 35 A (3 Phase) • Shipping dimensions (domestic): 142.0 in x 90.0 in x 92.0 in / 361 cm x 229 cm x 234 cm Technical Specification Driven Tools Yes Counter Spindle Yes
