Used Hyundai Excavator for sale (157)

Condition: like new (used), Year of construction: 2021, AUTOMATIC PALLET CHANGER Usable pallet dimensions mm2 x 650 x 400 Maximum permitted load on pallet kg2 x 250 TRAVELS AND FEEDS X axis mm 520 Y axis mm 400 Z axis mm 330 Rapid traverse X, Y mm/min 56,000 Rapid traverse Z mm/min 56,000 Working feedrate mm/min 1 ÷ 20,000 DIRECT DRIVE MOTOR SPINDLE Tool taper and shank BT30 Spindle speed rpm 12,000 Spindle motor power 30 min/continuous kW 7.5/5.5 TOOL MAGAZINE Hsdpfjyiu Duex Afcoi Umbrella-type tool magazine capacity 24 Maximum tool diameter mm 80/100 Maximum tool length mm 200 Fixed position tool selection

Condition: ready for operation (used), Year of construction: 2009, operating hours: 13,000 h, functionality: fully functional, turning diameter over cross slide: 600 mm, turning length: 450 mm, turning diameter: 355 mm, spindle bore: 75 mm, spindle speed (max.): 4,000 rpm, spindle speed (min.): 20 rpm, travel distance X-axis: 250 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 600 mm, spindle motor power: 15 W, rotational speed (min.): 50 rpm, rotational speed (max.): 4,500 rpm, bar passage: 65 mm, bar diameter (max.): 65 mm, Twin-spindle lathe with BMT65 driven tools, Y-axis, TOP Automazioni bar feeder, parts unloading arm, chip conveyor, tool presetter, toolholder kit. CNC FANUC. Hodpfx Asyiurxjfcji

Condition: ready for operation (used), Year of construction: 2019, operating hours: 2,900 h, travel distance X-axis: 1,060 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 635 mm, controller manufacturer: SIEMENS, controller model: SINUMERIK 828D, table load: 800 kg, spindle speed (max.): 8,000 rpm, number of axes: 3, This 3-axis Hyundai WIA F500 + was manufactured in 2019. It features a Siemens SINUMERIK 828D control unit, a spindle speed of up to 8,000 rpm, and a spindle motor power of 15/11 kW. The machine includes a CNC vertical machining center, chip conveyor, automatic tool changer, and internal cooling system. If you are looking to get high-quality milling capabilities, consider the Hyundai WIA F500 + machine we have for sale. Contact us for more information. • Coolant: internal cooling; through-spindle coolant (TSC) • Automatic tool changer: Yes • Hours: working hours approx. 2,900 h; cutting time 2,917 h; power-on time approx. 7,000 h • Status: machine under power; available for testing Additional equipment Hsdex D Nb Njpfx Afcji • Chip conveyor • Workholding on table: precision vise and chuck (as shown)

Condition: used, machine/vehicle number: N80711249, Power: 147 kW, operating weight: 31,530 kg, with quick coupler system, operating hours: approx. 24,800 h Hjdpfx Ajyf R Dvefcji

Condition: used, Year of construction: 2014, machine/vehicle number: HHKHZ601H00002345, Power: 107 kW, operating weight: 20,900 kg, with quick coupler system, with air conditioning, operating hours: approx. 8,720 h Hedpjyf R Dpefx Afcoi

Condition: used, Year of construction: 2012, machine/vehicle number: HHKHZ801EC0001577, Power: 147 kW, operating weight: 29,500 kg, with quick coupler system, operating hours: approx. 10,950 h, with air conditioning Hodpfx Aoyf R D Nefcei

Condition: used, Year of construction: 2014, machine/vehicle number: HHKHZ803JE0000148, Power: 158 kW, operating weight: 29,600 kg, with quick-change system, operating hours: approx. 11,900 h, with air conditioning Hjdpfx Afoyf R Dcocei

Condition: used, functionality: fully functional, Equipment: documentation/manual, rotational speed infinitely variable, FOR SALE Hjdpfx Afjydp E Nscoi Hyundai HiT 30M CNC Lathe — Technical Overview 3 AXIS Brand: Hyundai (Hyundai WIA) Model: HiT‑30M Machine: CNC Lathe (Turning Center)

Condition: used, functionality: fully functional, Equipment: documentation/manual, rotational speed infinitely variable, FOR SALE Hyundai HIT 18S CNC Lathe This 2-axis model (X + Z) is designed for machining medium-sized parts, offering high precision and reliable CNC control. Main technical specifications Machining capabilities - Maximum turning diameter: approx. 254 mm - Maximum turning length: approx. 500 mm - Swing over bed: approx. 440 mm Axis travel - X axis (cross travel): approx. 180 mm - Z axis (longitudinal travel): approx. 510 mm - Note: 2-axis CNC (X + Z) — no native C-axis on this model. CNC control - System: Siemens 840C or HiTrol variant (840C), depending on configuration. Spindle and tooling - Max. spindle speed: approx. 3600 rpm - Spindle motor power: approx. 15 kW - Turret: 1 turret with 8 tool stations - Chuck: 3-jaw standard with through-hole clamping Accessories and options - Chip conveyor: generally included - Automatic tool presetting: often included - Tailstock / bar feeder: generally not included Dimensions and weight - Dimensions (L × W × H): approx. 2600 × 1650 × 1830 mm Hjdjydp Drepfx Afcei - Weight: approx. 4300 kg Best regards,

Condition: used, Technical details: x-travel: 800 mm y-travel: 460 mm z-travel: 620 mm control: YASNAC-J50M table-size: 1100 x 460 mm table load capacity: 800 kg tool taper: BT40 Revolution per minute: 30 - 10 000 U/min. spindle head: MAS / BT 40 distance spindle nose and table: 150 mm feed speeds infinitely variable: 8 m/min. rapid traverse:: x+y+z: 30+30+24 m/min tool changer with: 24 spindle hours: 1317 h operating hours - idle run: 7148 h air-pressure connection: ja bar total power requirement: 30 (kVA) Weight approx.: 5,0 t dimension machine xH: 2,9 x 2,5 x 2,85 m dimension swarf conveyor LxWxH: 3,0 x 0,9 x 1,3 m other technical characteristics: max. drill Ø 40mm Facing 245 cc/min (cc/min) Thread cutting up to M 36 Compressed air connection Equipment: Chip conveyor with cooling water tank Interior lighting Operation via swivelling control panel CTS Machine feet Hsdpfxsu Idf Ej Afcoi Accessories: approx. 26 clamping spigots *

Condition: used, Year of construction: 2022, Technical details: Rated capacity: 13,5 kVA Revolution per minute: 20 U / min capacity: 11 KW type of fuel: Diesel voltage: 230-250 V / Hz battery: 45 A/h motor power: 11 kw weight: 318 kg dimensions L x W x H: ca. 1,2 x 0,7 x 0,9 m 2 St. Soundproofed (Silent) Diesel engine: LA290F; 2-cylinder; 3,600 rpm; tank capacity 53 liters; Battery voltage 12V Generator: LDG12S-3; voltage 400V / 230V; 3.600 rpm; power: normal power 10kW max. power 11kW Power class G1 Hedpfxsu Nvd No Afcei *

Condition: new, Year of construction: 2019, functionality: fully functional, Stock machine, new Control: Fanuc 0i-M with Manual Guide Hyundai Wia Fanuc Series Main drive: 18.5/11 kW - 117.7 Nm Spindle speed range: 12,000 rpm Number of axes: 3 Travel distances X-axis: 1,060 mm Hjdpfx Afoyf Nkzocei Y-axis: 510 mm Z-axis: 635 mm Rapid traverse: X/Y 36 m/min, Z 30 m/min Table: 1200x500 mm Table load capacity: 800 kg Tool stations: 30 Tool holder: BBT40 Coolant through spindle: 20 bar Hinged belt chip conveyor / left side Further details can be found in the attached brochure. Machine is available immediately. We would be happy to arrange an inspection appointment in Idstein.

Condition: used, Year of construction: 2008, functionality: fully functional, Number of axes: 4 X-axis travel: 850 mm Y-axis travel: 700 mm Z-axis travel: 750 mm Max. tool weight: 8 kg Hodpfx Afoyd Rw Tjcei Spindle power: 22 kW Spindle speed: 12,000 RPM Further technical details upon request

Condition: ready for operation (used), Year of construction: 2018, operating hours: 23,000 h, spindle speed (max.): 4,000 rpm, travel distance X-axis: 220 mm, travel distance Z-axis: 560 mm, number of axes: 2, This Hyundai Wia L230LA was manufactured in 2018. It features X-axis travel of 220 mm, Z-axis travel of 560 mm, a swing over the bed of 600 mm, and a swing over the carriage of 355 mm. Spindle speed reaches up to 4000 RPM. Two units available. Contact us for more information. • Swing over bed: 600 mm • Swing over carriage: 355 mm • Availability: 2 machines Additional equipment Hjdpfx Asyf Hqrofcsi • Chip conveyor: not included • Other accessories: not specified

Condition: ready for operation (used), Year of construction: 2013, operating hours: 57,600 h, spindle speed (max.): 4,000 rpm, travel distance X-axis: 210 mm, travel distance Z-axis: 550 mm, controller manufacturer: SIEMENS, controller model: Sinumerik 828D, number of axes: 2, This Hyundai Wia L210LA was manufactured in 2013. It features a spindle speed of 4000 rpm, X travel of 210mm, Z travel of 550mm, a maximum turning diameter of 350mm, and a maximum turning length of 530mm. It includes a chip conveyor. Consider the opportunity to buy this Hyundai Wia L210LA horizontal turning machine. Contact us for more information. • Max. turning diameter: 350 mm • Max. turning length: 530 mm • Quantity available: 2 Additional equipment Hsdsyffptepfx Afcei • Chip conveyor

Condition: used, Year of construction: 2022, operating hours: 3,179 h, 2022 | Hyundai HX520AL | Used Tracked Excavator | 3179 hours 📍Location: Germany 🚛 Delivery available to your destination – Use our shipping calculator to estimate transport costs! 💰 Buy Now for EUR 183000 or Make an Offer. Payment at delivery available for an affordable fee (subject to approval)* 👷‍♂️ Inspected by an independent expert 68 inspection points 62 approved ✅ 5 imperfect ℹ️ 1 issues ⚠️ 📌 Inspector's Comment: Young but well-used machine, has worked with the hammer for a long time, play in the slewing ring and bucket cylinder, mechanically and optically in order, SOLD WITHOUT HAMMER. 📄 Want to see the full inspection, extra photos, or a video? Tip: The reference "39198 Equippo" is commonly used when looking up more details online. 💡 Why this machine and our service stands out: ✔ Thorough inspection by professionals ✔ Jobsite delivery available Hsdpfxeyfit Aj Afcei ✔ Money-Back Guaranteed ✔ Secure and flexible payment options 🔄 Considering other equipment options? We offer helpful tools and resources for all equipment owners and operators – easily accessible on our platform.

Condition: new, Year of construction: 2024, functionality: fully functional, HYUNDAI-WIA SE2200M CNC LATHE WITH FANUC 0IT PLUS CONTROL AND C-AXIS MACHINE CONSTRUCTION & FEATURES  8” STANDARD CHUCK SIZE.  30° SLANT BED ONE PIECE HEAVY DUTY CAST IRON CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY.  HIGH PERFORMANCE ROLLER LM GUIDEWAYS.  12 STATION HIGH SPEED RIGID SERVO DRIVEN TOOL TURRET - BMT45. [24 POSITION INCLUDED]  4,500 RPM HIGH POWER MAIN SPINDLE.  30 X 36 M/MIN RAPID TRAVERSE RATES - X & Z AXES.  C-AXIS MAIN SPINDLE.  ERGONOMIC DESIGN FOR EASY ACCESS TO CHUCK & TURRET. MACHINE CAPACITIES Swing Over the Bed Ø 600 MM Swing Over the Carriage Ø 390 MM Maximum Turning Diameter Ø 300 MM Maximum Turning Length 288 MM Bar Capacity - Main Ø 65 MM MAIN SPINDLE Chuck Size 8” Ø 203 MM Spindle Bore Ø 75 MM Spindle Speed (Rpm) 4,500 RPM Motor (Max / Cont.) 15.0 / 11.0 KW Torque (Max.) 167 NM Spindle Type BELT Spindle Nose A2-6 C-Axis Indexing 360° (0.001°) FEED Travel X 210 MM Travel Z 340 MM Rapid Speed X 30 M / MIN Rapid Speed Z 36 M / MIN Slide Type ROLLER LM GUIDE TURRET Number of Tools 12 [24 POSITION INDEX] Tool Size - OD 20 MM² Tool Size - ID Ø 32 MM Indexing Time 0.15 SEC / STEP LIVE TOOL Motor (Max / Cont.) 2.75 / 1.85 KW Milling Tool Speed 6,000 RPM Torque (Max.) 26.2 NM Collet Size ER 20 - Ø 13 Type BMT45 TAILSTOCK HYDRAULIC NC TAILSTOCK (STD LIVE CENTRE) Taper MT 4 Quill Diameter Ø 56 MM Tailstock Travel 580 MM TANK CAPACITY Coolant Tank 150 L Lubricating Tank 0.7 L POWER SUPPLY Electric Power Supply 18 KVA Thickness of Power Cable OVER 16 MM² Voltage 415V / 50HZ / 3PH MACHINE Floor Space (L x W) 2,220 X 1,610 MM Height 1,700 MM Weight 3,250 KGS INCLUDED FACTORY FITTED MACHINE OPTIONS CONVEYOR SIDE HINGED WITH CHIP BOX Hjdpfx Afox Trgcocei HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD CALL LAMP (3 COLOUR) - IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE TRANSFORMER - 415V 3PH 50HZ QUICK TOOL SETTER - AUTO (RENISHAW) HYDRAULIC TYPE NC TAILSTOCK TURRET UPGRADE - 12 STATION 24 POSITION BMT45, LIVE TOOLS 6K RPM, 2.75 KW STANDARD FACTORY FITTED MACHINE OPTIONS CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 8 INCH 3 JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR FOR FANUC FOR STANDARD CNC SPECIFICATION - SEE MANUFACTURER'S BROCHURE HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) MANUAL VIEWER OPERATION MEMO PREMIUM TOOL OPERATION SCHEDULING SMART GUIDE-i (CONVERSATIONAL PROGRAMMING) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD COOLANT TANK 150 LITRES FRONT DOOR INTERLOCK FULL SPLASH GUARDING SYSTEM STANDARD HYDRAULIC UNIT 35 BAR (15 LITRES) CALL LIGHT (1 COLOUR) BACK SPIN TORQUE LIMITER TOOLBOX STANDARD TOOLING PACKAGE

Condition: new, Year of construction: 2023, functionality: fully functional, HYUNDAI-WIA HD2200 FANUC 0IT PLUS CNC LATHE MACHINE CONSTRUCTION & FEATURES ▪ 8” STANDARD CHUCK SIZE. ▪ 45° SLANT BED ONE PIECE HEAVY DUTY CAST IRON CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. Hsdex Tqppspfx Afcsi ▪ HARDENED & GROUND BOX GUIDEWAYS FOR HEAVY DUTY CUTTING. ▪ 12 STATION HIGH SPEED RIGID SERVO TURRET. ▪ 4,500 RPM HIGH POWER MAIN SPINDLE. ▪ 24 X 30 M/MIN RAPID TRAVERSE RATES – X & Z AXES. ▪ ERGONOMIC DESIGN FOR EASY ACCESS TO CHUCK & TURRET. Swing Over the Bed Ø 550 MM Swing Over the Carriage Ø 390 MM Maximum Turning Diameter Ø 380 MM Maximum Turning Length 565 MM Bar Capacity Ø 65 MM MAIN SPINDLE Chuck Size Ø 8” – 203 MM 10” - [254] MM Spindle Bore Ø 76 MM Spindle Speed (rpm) 4,500 RPM Motor (Max/Cont.) 18.5 / 15.0 KW Torque (Max/Cont.) 206 / 125.3 NM Spindle Type BELT Spindle Nose A2-6 FEED Travel X 215 MM Travel Z 580 MM Rapid Speed X 24 M/MIN Rapid Speed Z 30 M/MIN Slide Type HARDENED & GROUND BOX GUIDEWAYS TURRET Number of Tools 12 Tool Size - OD 25 MM² Tool Size - ID Ø 40 MM Indexing Time 0.12 SEC / STEP TAILSTOCK Taper MT 4 Quill Diameter Ø 65 MM Quill Travel 80 MM Travel 513.7 MM TANK CAPACITY Coolant Tank 150 L Lubricating Tank 1.8 L POWER SUPPLY Electric Power Supply 23 KVA Thickness of Power Cable Over 16 MM² Voltage 415V / 50Hz / 3Ph MACHINE Floor Space (L x W) 2,925 x 1,650 MM Height 1,820 MM Weight 4,100 KGS INCLUDED MACHINE OPTIONS CONVEYOR SIDE HINGED WITH CHIP BOX COOLANT GUN HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD OIL SKIMMER BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE TRANSFORMER - 415V 3PH 50HZ QUICK TOOL SETTER - AUTO PROGRAMMABLE TAILSTOCK IN LIEU OF STD STANDARD FACTORY FITTED MACHINE OPTIONS CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 8 INCH 3 JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" TOUCH SCREEN MONITOR FOR FANUC (SMART GUIDE i) HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD COOLANT TANK 150 LITRES FULL SPLASH GUARDING SYSTEM STANDARD HYDRAULIC UNIT 35 BAR (15 LITRES) CALL LIGHT (1 COLOUR) MACHINE MANUALS & OPERATOR HANDBOOKS TOOLBOX STANDARD TOOLING PACKAGE QUILL TYPE TAILSTOCK - 4MT WITH STD LIVE CENTER

Condition: new, Year of construction: 2023, functionality: fully functional, HYUNDAI-WIA SE2200LY WITH FANUC 0i-T PLUS CONTROL CNC LATHE WITH Y AXIS. TURRET UPGRADE - 12 STATION 24 POSITION BMT45, LIVE TOOLS 6K RPM, 2.75 KW MACHINE CONSTRUCTION & FEATURES ▪ 8” STANDARD CHUCK SIZE. ▪ 30° SLANT BED ONE PIECE HEAVY DUTY CAST IRON CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. ▪ HIGH PERFORMANCE ROLLER LM GUIDEWAYS. ▪ 12 STATION HIGH SPEED RIGID SERVO DRIVEN TOOL TURRET - BMT45. [24 POSITION OPTION] ▪ 4,500 RPM HIGH POWER MAIN SPINDLE. Hsdpfx Afox Tqkmocji ▪ 30 X 36 M/MIN RAPID TRAVERSE RATES – X & Z AXES. ▪ C-AXIS SPINDLE & WEDGE TYPE Y-AXIS. Swing Over the Bed Ø 600 MM Swing Over the Carriage Ø 600 MM Maximum Turning Diameter Ø 300 MM Maximum Turning Length 508 MM Bar Capacity – Main Spindle Ø 65 MM MAIN SPINDLE Chuck Size Ø 8” - 203 MM Spindle Bore Ø 75 MM Spindle Speed 4,500 RPM Motor (Max / Cont.) 15.0 / 11.0 KW Torque (Max / Cont.) 167 [150.3] NM Spindle Type BELT Spindle Nose A2-6 FEEDS Travel X 210 MM Travel Y 110 (± 55) MM Travel Z 560 MM Rapid Speed X 30 M / MIN Rapid Speed Y 10 M / MIN Rapid Speed Z 36 M / MIN Slide Type ROLLER LM GUIDEWAYS TURRET Number of Tools 12 [24 POSITION INDEX] Tool Size - OD 20 MM² Tool Size - ID Ø 32 MM Indexing Time 0.15 SEC / STEP Y-Axis Type WEDGE TYPE Milling Tool Speed 6,000 RPM Motor (Max / Cont.) 2.75 / 1.85 [2.8 / 3.8] KW Torque (Max / Cont.) 26.2 [27.0] NM Collet Size ER 20 - Ø 13 Type BMT45 HYDRAULIC NC TAIL STOCK (STD. LIVE CENTER) Taper MT#4 Quill Diameter Ø 56 MM Travel 580 MM Coolant Tank 200 L POWER SUPPLY Electric Power Supply 18 KVA Thickness of Power Cable OVER 16 MM² Voltage 415V / 50HZ / 3PH Floor Space (L x W) 2,960 X 1,730 MM Height 1,920 MM Weight 4,200 KGS STANDARD FACTORY FITTED MACHINE OPTIONS SPINDLE POSITIONING MAIN - 0.001 DEG INDEX (C1-AXIS) CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 8 INCH 3-JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR FOR FANUC FOR STANDARD CNC SPECIFICATION - SEE MANUFACTURER'S BROCHURE HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) MANUAL VIEWER OPERATION MEMO PART PROGRAM STORAGE - 2MB (1,000 REGISTERABLE PROGRAMS) PREMIUM TOOL OPERATION SCHEDULING SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD COOLANT TANK 200 LITRES FULL SPLASH GUARDING SYSTEM STANDARD HYDRAULIC UNIT 35 BAR (15 LITRES) CALL LIGHT (1 COLOUR) BACK SPIN TORQUE LIMITER FRONT DOOR INTERLOCK TOOLBOX MAIN SPINDLE - 4,500 RPM, 15.0 / 11.0 KW, 167 NM BELT DRIVEN STANDARD TOOLING PACKAGE - SEE MANUFACTURER'S BROCHURE HYDRAULIC TYPE NC TAILSTOCK - MT#4 56 MM QUILL, STD LIVE CENTER 12 STATION BMT45 TURRET, LIVE TOOLS 6K RPM, 2.75 KW, 26 NM INCLUDED FACTORY FITTED MACHINE OPTIONS CHIP - BUCKET STANDARD CONVEYOR SIDE HINGED HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD CALL LAMP (3 COLOUR) - IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE TRANSFORMER - 415V 3PH 50HZ QUICK TOOL SETTER - AUTO QUILL FORWARD / REVERSE CONFIRMATION DEVICE

Condition: new, Year of construction: 2022, functionality: fully functional, HYUNDAI-WIA HD3100L FANUC 0IT PLUS CNC LATHE MACHINE CONSTRUCTION & FEATURES 12” STANDARD CHUCK SIZE. 30° SLANT BED ONE PIECE HEAVY DUTY CAST IRON CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. HARDENED & GROUND BOX GUIDEWAYS FOR HEAVY DUTY CUTTING. 10 STATION HIGH SPEED RIGID SERVO TURRET. 2,800 RPM 26.0 /18.5 KW HIGH POWER MAIN SPINDLE. 24 X 30 M/MIN RAPID TRAVERSE RATES – X & Z AXES. ERGONOMIC DESIGN FOR EASY ACCESS TO CHUCK & TURRET. MACHINE CAPACITIES Swing Over the Bed Ø 750 MM Swing Over the Carriage Ø 500 MM Maximum Turning Diameter Ø 500 MM Maximum Turning Length 1,300 MM Bar Capacity Ø 102 MM MAIN SPINDLE Chuck Size Ø 12” – 305 MM Spindle Bore Ø 115 MM Spindle Speed (rpm) 2,800 RPM Motor (Max/Cont.) 26.0 / 18.5 KW Torque (Max/Cont.) 1,123 / 657 NM Spindle Nose A2-11 FEED Travel X 265 MM Travel Z 1,350 MM Rapid Speed X 24 M/MIN Rapid Speed Z 30 M/MIN Slide Type HARDENED & GROUND BOX GUIDEWAYS TURRET Number of Tools 10 Tool Size - OD 25 MM² Tool Size - ID Ø 50 MM Indexing Time 0.15 SEC / STEP TAILSTOCK Type QUILL TYPE TAILSTOCK [PROGRAMMABLE TAILSTOCK] Taper MT5 [MT4] Quill Diameter Ø 100 MM Quill Travel 120 MM TANK CAPACITY Coolant Tank 220 L Lubricating Tank 1.8 L POWER SUPPLY Electric Power Supply 27 KVA Thickness of Power Cable Over 16 MM² Voltage 415V / 50Hz / 3Ph MACHINE Floor Space (L x W)4,405 x 1,978 MM Height 1,850 MM Weight 7,200 KGS INCLUDED FACTORY FITTED MACHINE OPTIONS CONVEYOR SIDE HINGED WITH CHIP BOX SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) COOLANT GUN HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE TRANSFORMER - 415V 3PH 50HZ QUICK TOOL SETTER - AUTO STEADY REST PREPARATION - PROGRAMMABLE CLAMPING & TRAVEL PROGRAMMABLE TAILSTOCK IN LIEU OF STD QUILL TYPE TAILSTOCK - MANUAL TYPE MT#5 100 MM DIA QUILL, 120 MM QUILL TRAV Hjdpfx Aox Tiggofcsi STANDARD FACTORY FITTED OPTIONS CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 12 INCH 3 JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR FOR FANUC FOR STANDARD CNC SPECIFICATION - SEE MANUFACTURER'S BROCHURE HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) COOLANT TANK (SIDE TYPE) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR FULL SPLASH GUARDING SYSTEM STANDARD HYDRAULIC UNIT 35 BAR (30 LITRES) CALL LIGHT (1 COLOUR) TOOLBOX STANDARD TOOLING PACKAGE - SEE MANUFACTURER'S BROCHURE STANDARD LIVE CENTER

Condition: new, Year of construction: 2022, functionality: fully functional, HYUNDAI-WIA HD2200Y FANUC 0IT PLUS CNC LATHE WITH Y AXIS. MACHINE CONSTRUCTION & FEATURES ▪ ONE PIECE HEAVY DUTY CAST IRON BED CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. Hodpfx Aex Th Nysfcei ▪ 4,000 RPM MAIN SPINDLE. ▪ 6,000 RPM LIVE TOOLING SPEED. ▪ HEAVY DUTY CUTTING WITH EXCELLENT PERFORMANCE. ▪ WEDGE TYPE Y-AXIS. ▪ 12 STATION HIGH SPEED RIGID SERVO TURRET - BMT55P ▪ HARDENED & GROUND BOX GUIDEWAYS Swing Over the Bed Ø 820 MM Swing Over the Carriage Ø 650 MM Maximum Turning Diameter Ø 300 MM Maximum Turning Length 610 MM Bar Capacity – Main Spindle Ø 65 MM MAIN SPINDLE Chuck Size Ø 8” - 203 MM Spindle Bore Ø 76 MM Spindle Speed (Rpm) 4,000 RPM Motor (Max / Cont.) 18.5 / 15.0 [22.5 / 15.0] KW Torque (Max / Cont.) 206.2 / 125.4 [215.0 / 143.3] NM Spindle Type BELT Spindle Nose A2-6 Travel X 215 MM Travel Y 110 (± 55) MM Travel Z 680 MM Rapid Speed X 24 M / MIN Rapid Speed Y 10 M / MIN Rapid Speed Z 30 M / MIN HARDENED & GROUND BOX GUIDEWAYS Number of Tools 12 [24] Tool Size - OD 25 MM² Tool Size - ID Ø 20 MM Indexing Time 0.2 SEC / STEP Y-Axis Type WEDGE TYPE LIVE TOOL Motor (Max / Cont.) 5.5 / 3.7] KW Milling Tool Speed 6,000 RPM Torque (Max / Cont.) 52.5 / 26.5 NM Collet Size Ø 16 – ER25 Type BMT-55P TAILSTOCK Taper MT 4 Quill Diameter Ø 80 MM Quill Travel 120 MM Travel 680 MM TANK CAPACITY Coolant Tank 200 L Lubricating Tank 2.0 L Electric Power Supply 27 KVA Thickness of Power Cable OVER 25 MM² Voltage 415 V / 50 HZ / 3PH Floor Space (L x W) 3,380 x 1,800 MM Height 1,950 MM Weight 4,700 KGS INCLUDED FACTORY FITTED MACHINE OPTIONS CHIP - BUCKET STANDARD CHIP - CONVEYOR SIDE HINGED HIGH PRESSURE COOLANT SYSTEM 6.0 BAR IN LIEU OF STD CALL LAMP (3 COLOUR) - IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE 30 KVA TRANSFORMER AND CABLE QUICK TOOL SETTER - AUTO PROGRAMMABLE TAILSTOCK IN LIEU OF STD TURRET UPGRADE - 12 STATION 24 POSITION BMT55P, LIVE TOOLS 6K RPM, 5.5 KW STANDARD FACTORY FITTED MACHINE OPTIONS SPINDLE POSITIONING MAIN - 0.001 DEG INDEX (C1-AXIS) CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 8 INCH 3 JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR FOR FANUC HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) COOLANT TANK (SIDE TYPE) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD HYDRAULIC UNIT 35 BAR (30 LITRES) CALL LIGHT (1 COLOUR) FRONT DOOR INTERLOCK TOOLBOX STANDARD TOOLING PACKAGE QUILL TYPE TAILSTOCK WITH STD LIVE CENTER

Condition: new, Year of construction: 2022, functionality: fully functional, HYUNDAI-WIA HD3100M FANUC 0IT PLUS CNC HIGH POWER TURNING CENTRE WITH HARDENED & GROUND BOX GUIDEWAYS, HIGH SPEED SERVO TURRET, C-AXIS & DRIVEN TOOLS & 12" STD CHUCK Swing Over the Bed Ø 750 MM Swing Over the Carriage Ø 500 MM Maximum Turning Diameter Ø 420 MM Maximum Turning Length 740 MM Bar Capacity - Main Ø 102 MM MAIN SPINDLE Chuck Size Ø 12” – 305 MM Spindle Bore Ø 115 MM Spindle Speed (Rpm) 2,800 RPM Motor (Max. / Cont.) 26.0 / 18.5 KW Torque (Max. / Cont.) 1,123 / 657 NM Spindle Type BELT [GEARLESS] Spindle Nose A2-11 C-Axis Indexing 360° (0.001°) Travel X 265 MM Travel Z 830 MM Rapid Speed X 24 M / MIN Rapid Speed Z 30 M / MIN Slide Type HARDENED & GROUND BOX GUIDEWAYS TURRET Number of Tools 12 Tool Size - OD 25 MM² Tool Size - ID Ø 40 MM Indexing Time 0.15 SEC / STEP LIVE TOOLS Motor (Max / Cont.) 5.5 / 3.7 KW Milling Tool Speed 5,000 RPM Torque (Max. / Cont.) 70.0 / 35.4 NM Collet Size ER32 - Ø 25 Type BMT65P QUILL TYPE TAILSTOCK [PROGRAMMABLE BUILT IN TAILSTOCK] Taper MT5 [MT4] Quill Diameter Ø 100 MM Quill Travel 120 MM Tailstock Travel 830 MM TANK CAPACITY Hsdpjx Thzvjfx Afcoi Coolant Tank200 L Lubricating Tank 1.8 L POWER SUPPLY Electrical Power Supply 27 [30 GEARLESS] KVA Voltage 415V / 50HZ / 3PH MACHINE Floor Space (L x W) 3,885 x 1,800 MM Height 1,850 MM Weight 6,050 KGS STANDARD FEATURES SPINDLE POSITIONING MAIN - 0.001 DEG INDEX (C1-AXIS) CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 12 INCH 3 JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" TOUCH SCREEN MONITOR FOR FANUC (SMART GUIDE i) HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) PART PROGRAM STORAGE - 2MB (1,000 REGISTERABLE PROGRAMS) SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) COOLANT TANK (SIDE TYPE) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR FULL SPLASH GUARDING SYSTEM STANDARD HYDRAULIC UNIT 35 BAR (30 LITRES) CALL LIGHT (1 COLOUR) TOOLBOX MAIN SPINDLE - 2,800 RPM, 26.0 / 18.5 KW, 1123 NM BELT DRIVEN TOOLING PACKAGE QUILL TYPE TAILSTOCK WITH STD LIVE CENTER 12 STATION BMT65P SERVO TURRET, LIVE TOOLS 5,000 RPM, 5.5 KW, 47.0 NM FACTORY FITTED MACHINE OPTIONS CHIP BUCKET STANDARD CHIP CONVEYOR SIDE HINGED HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD (RATED AT 60HZ SUPPLY) BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE 30 KVA TRANSFORMER AND CABLE QUICK TOOL SETTER - MANUAL PROGRAMMABLE TAILSTOCK IN LIEU OF STDMACHINE CONSTRUCTION & FEATURES 12” STANDARD CHUCK SIZE. 30° SLANT BED ONE PIECE HEAVY DUTY CAST IRON CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. HARDENED & GROUND BOX GUIDEWAYS FOR HEAVY DUTY CUTTING. 12 STATION HIGH SPEED RIGID SERVO DRIVEN TOOL TURRET – BMT65P. 2,800 RPM 26.0 / 18.5 [35.0 / 25.0 GEARLESS] KW HIGH POWER MAIN SPINDLE. 24 X 30 M/MIN RAPID TRAVERSE RATES – X & Z AXES. C-AXIS MAIN SPINDLE. ERGONOMIC DESIGN FOR EASY ACCESS TO CHUCK & TURRET.

Condition: new, Year of construction: 2023, functionality: fully functional, HYUNDAI-WIA HD3100YA FANUC 0IT PLUS CNC LATHE WITH Y AXIS MACHINE CONSTRUCTION & FEATURES ▪ ONE PIECE HEAVY DUTY CAST IRON BED CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. ▪ 3,500 RPM MAIN SPINDLE. ▪ 5,000 RPM LIVE TOOLING SPEED. ▪ HEAVY DUTY CUTTING WITH EXCELLENT PERFORMANCE. ▪ WEDGE TYPE Y-AXIS. ▪ 12 STATION HIGH SPEED RIGID SERVO TURRET – BMT55P ▪ HARDENED & GROUND BOX GUIDE WAYS MACHINE CAPACITIES Swing Over the Bed Ø 800 MM Swing Over the Carriage Ø 670 MM Maximum Turning Diameter Ø 420 MM Maximum Turning Length 760 MM Hedsx Thu Nopfx Afcsi Bar Capacity – Main Spindle Ø 81 MM MAIN SPINDLE Chuck Size Ø 10” - 254 MM Spindle Bore Ø 91 MM Spindle Speed (Rpm) 3,500 RPM Motor (Max / Cont.) 26.0 / 18.5 KW Torque (Max / Cont.) 734 / 522 NM Spindle Type BELT Spindle NoseA2-8 FEED Travel X265 MM Travel Y120 (± 60) MM Travel Z830 MM Rapid Speed X24 M / MIN Rapid Speed Y10 M / MIN Rapid Speed Z30 M / MIN Slide Type HARDENED & GROUND BOX GUIDEWAYS TURRET Number of Tools12 Tool Size - OD25 MM² Tool Size - IDØ 20 MM Indexing Time0.2 SEC / STEP Y-Axis Type WEDGE TYPE LIVE TOOL Motor (Max / Cont.) 5.5 / 3.7 KW Milling Tool Speed 5,000 RPM Torque (Max / Cont.) 70/0 / 35.4 NM Collet Size Ø 16 – ER25 Type BMT-65P TAIL STOCK Taper MT 5 Quill Diameter Ø 100 MM Quill Travelb120 MM Travel b830 MM Voltage 415 V / 50 HZ / 3PH Floor Space (L x W) 3,630 X 1,910 MM Height 1,960 MM Weight 6,200 KGS INCLUDED FACTORY FITTED MACHINE OPTIONS CONVEYOR & CHIP BOX HELICAL INTERPOLATION FUNCTION HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD CALL LAMP (3 COLOUR) - IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE TRANSFORMER - 415V 3PH 50HZ QUICK TOOL SETTER - AUTO MAIN SPINDLE - 3,500 RPM, 26.0 / 18.5 KW, 734 NM BELT DRIVEN PROGRAMMABLE TAILSTOCK IN LIEU OF STD QUILL FORWARD / REVERSE CONFIRMATION DEVICE QUILL TYPE TAILSTOCK - MANUAL TYPE MT#5 100 MM DIA QUILL, 120 MM QUILL TRAV STANDARD FEATURES SPINDLE POSITIONING MAIN - 0.001 DEG INDEX (C1-AXIS) CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 10 INCH 3 JAW HYDRAULIC CHUCK CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE HYDRAULIC CHUCK PRESSURE INTERLOCK - MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) PART PROGRAM STORAGE - 2MB SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD COOLANT TANK 180 LITRES FULL SPLASH GUARDING SYSTEM CALL LIGHT TOOLBOX TOOLING PACKAGE QUILL TYPE TAILSTOCK 12 STATION BMT65P SERVO TURRET, LIVE TOOLS 5,000 RPM, 5.5 KW, 47.0 NM

Condition: excellent (used), Year of construction: 2007, operating hours: 11,000 h, functionality: fully functional, turning length: 500 mm, turning diameter: 240 mm, spindle bore: 65 mm, spindle speed (max.): 4,000 rpm, travel distance Y-axis: 40 mm, spindle motor power: 15 W, Working length 500 mm Max. working diameter 240 mm Spindle speeds 4.000 rpm Spindle bore 65 mm Number of tools 12 pcs Y-travel +/- 40 mm Control FANUC 18 i TB Hjdpjycubtofx Afcsi Running hours 5.000 Main motor power 15 Kw

Condition: excellent (used), Year of construction: 2019, turning length: 700 mm, spindle bore: 76 mm, travel distance X-axis: 195 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 720 mm, Twin spindle construction Twin turret configuration with Y Axis (Y-Axis Cutting complex shaped work piece) Build in Spindle motor High Rigidity BMT Turret Full C-Axis 360.000 Slant bed construction 45 Gr Please note Pictures is example not orginal picture ! Max. turning Ø: 290mm X-Axis: 165/195mm Y-Axis: 100mm Z-Axis: 700/720mm B Axis: 668° Spindle bore: 76mm Speedrange: 5000Rpm Spindle power: 22kW Subspindle speeds: 5000Rpm Subspindle bore: 76mm Hsdpfjx I Nikex Afcsi Subspindle power: 22kW ATC / revolver: 12 Speed live tools: 5000Rpm Positions lower revolver:12 Speed live tools: 5000Rpm Power live tools: 6kW Chip conveyor: Yes Tool eye: Yes Length: 3800mm Width: 2000mm Height: 2100mm Weight: 8500kg
