Used Index Multi Spindle Machine for sale (164)

Condition: good (used), Year of construction: 2006, INDEX MS52C CNC Multi-Spindle Mfd. 2006 Control: Siemens 840D 6 Spindles 52mm Capacity Hjlhcdst Rkzwowxsfd Equipped as pictured Under power Knoll System Chip Conveyor Riedel Chiller 3.6 meter (12ft) IEMCA SIR Bar Feed SIR MS52/F Type 38 XL Mfd. 2005

Condition: used, Year of construction: 2024, INDEX MS22-8 Mfd. 2024 2 NCU (4) Y-Axis SL Control Cutting hours: 1,000 Turnkey Available Located in Europe 4-Meter IEMCA SIR MS22-8/43/P Rack loader 50 Hz D9-13-19-25 Bar length 4300 mm with drilling unit and minimum quantity lubrication unit additional end-of-bar sensor Bar stock 500mm (D12-D24) Bar stock 340 mm (D5-D11). Additional storage chain for 22 bars with Profinet interface. 1 11007253 (21711) 1 set (8 pieces) bar stock pushers, external clamping for bar stock diameters D7-D10 mm, internal clamping for bar stock diameters D13-D18 mm, consisting of: Hfelhcsxnrtcsdwxod 8 bar stock pushers D12 8 rotating sleeves D12 1 10287026 (21712) 1 set (8 pieces) bar stock pushers, external clamping for bar stock diameters D11-D16 mm, internal clamping for bar stock diameters D19-D24 mm, consisting of: 8 bar stock pushers D18 8 rotating sleeves D18 1 10536056 (21713) 1 set (8 pieces) bar stock pushers for bar diameters D17 mm-D22 mm, consisting of: 8 bar stock pushers D23 8 rotating sleeves D23 1 10414481 (21702) 1 set (8 pcs.) of internal clamping sleeves D12mm for bar diameters D13 mm - D18 mm Drill diameter D8 mm. 1 10472413 (21704) 1 set (8 pcs.) of external stops D12 mm for bar diameters D13 mm - D18 mm pre-machined. 1 10264327 (21703) 1 set (8 pcs.) of internal clamping sleeves D18mm for bar diameters D19 mm - D24 mm Drill diameter D15mm. 1 10058206 (21705) 1 set (8 pcs.) of external stops D18 mm for bar diameter D19 mm - D24 mm pre-machined. 1 12123486 Drill for drilling unit consisting of: 1 indexable insert drill D 15 mm 10 indexable inserts for steel 2 solid carbide drills D 8 mm

Condition: used, Year of construction: 1994, INDEX MS 25E Max. bar diameter round / square: 26 / 18 mm Spindle pitch circle diameter: 230 mm Max. bar feed: 100 mm Longitudinal slide travel (total / working / adjustment): 85 / 50 / 330 mm Holhcdwjymdchjxjfd Cross slide travel (total / working / adjustment): 36 / 16 / 20 mm Spindle speeds (12 / 24 steps with 1.25 / 1.12): 366 – 5,020 rpm Main drive: 15 kW / 1,450 rpm Voltage: 400 V / 50 Hz Operating hours: 62,283 h Working hours: 4,916 h Dimensions (incl. bar guide): approx. L x W x H approx. 7 x 1.5 x 2 m Weight: approx. 6 t Scope of delivery: Machine INDEX MS 25E

Condition: used, Year of construction: 2000, INDEX MS42C Hfolhcdoymc S Ujwxod Max. bar diameter: 42 mm Spindle pitch circle diameter: 320 mm Main spindle: - Power clamping with INDEX spring-loaded hollow clamping cylinder and collet - Max. clamping stroke: 4 mm - Actuation force: 26 kN Main spindle drive: - Rated power: 5 kW - Rated speed: 1,500 rpm - Rated torque: 32 Nm - Max. speed: 5,000 rpm Synchronous spindle and driven tool holder: - Rated power: 5.3 kW - Rated speed: 1,500 rpm - Rated torque: 34 Nm - Max. speed: 5,000 rpm Cross slides: - Max. number: 10 - Travel (X): 70 mm - Travel (Z): 140 mm - Max. feed force +X: 11.4 kN - Max. feed force −X: 7.9 kN - Max. feed force +Z: 11.4 kN - Max. feed force −Z: 7.9 kN - Rapid traverse speed: 15 m/min Longitudinal spindles: - Quantity: 6 - Travel (Z): 240 mm - Max. feed force +Z: 15.1 kN - Max. feed force −Z: 11.6 kN - Rapid traverse speed: 15 m/min Cross slides for longitudinal spindles: - Max. number: 6 - Travel (X): 70 mm - Max. feed force +X: 11.4 kN - Max. feed force −X: 7.9 kN - Rapid traverse speed: 15 m/min Synchronous spindle: - Clamping system: spring-loaded clamping cylinder - Max. clamping diameter: 42 mm - Chuck outer diameter: 112 mm - Jaw stroke: 1 mm - Max. total clamping force: 13 kN Weight: approx. 11,000 kg Scope of delivery: - Hydraulic unit KNOLL KTS 32-48-T - Bar loader CUCCHI PLURIMANDRINO, year 2000 - Workshop cabinet with machine accessories - KNOLL VRF 500 - Chip conveyor KNOLL 400 S-1/250

Condition: used, Year of construction: 2007, operating hours: 26,721 h, number of spindles: 6, spindle speed (max.): 10,000 rpm, bar diameter (max.): 22 mm, total width: 1,800 mm, total length: 3,200 mm, total height: 2,850 mm, travel distance X-axis: 62 mm, travel distance Y-axis: 12 mm, travel distance Z-axis: 85 mm, overall weight: 6,500 kg, Working spindles: Quantity: 6 Maximum bar diameter: 22 mm Spindle pitch circle diameter: 230 mm Travel distances X / Z: 62 / 85 mm Rapid traverse speed: 15 m/min Synchronous hollow spindle drives: Quantity: 6 Maximum speed: 10,000 rpm Nominal speed: 8,300 rpm Power: 15 kW at 18 Nm Chuck diameter: 110 mm Swiveling synchronous spindles: Quantity: 2 Z-axis travel: 120 mm Feed force: 2.5 kN Rapid traverse speed: 15 m/min Swiveling angle: 132° Counter spindle: Maximum speed: 10,000 rpm Nominal speed: 8,000 rpm Power: 9.2 / 12 / 14 kW at 11 Nm Tool carriers: Maximum quantity: 11 Travel distances X / Y / Z: 62 / ± 12 / 85 mm CNC control: C 200-4D (Siemens Sinumerik 840D) Dimensions: approx. L x W x H 3.2 x 1.8 x 2.85 m Weight: approx. 6.5 t Operating hours: 61,997 h Working hours: 42,235 h Scope of delivery: - INDEX bar loader - Bar loader IEMCA SIR MS22 P, year 2008 - Coolant unit with belt filter - Chip conveyor KNOLL 400 S-1/290 Hjlhcdjymaw Ijwxsfd - Coolant filter unit KNOLL FKA/1780 RSF 100 - Workshop cabinet with machine accessories

Condition: used, Year of construction: 2015, operating hours: 26,721 h, number of spindles: 6, spindle speed (max.): 10,000 rpm, bar diameter (max.): 22 mm, total width: 1,800 mm, total length: 3,200 mm, total height: 2,850 mm, travel distance X-axis: 62 mm, travel distance Y-axis: 12 mm, travel distance Z-axis: 85 mm, overall weight: 6,500 kg, number of tool stations in tool turret 3: 11, INDEX MS 22C Working spindles: Number: 6 Maximum bar diameter: 22 mm Spindle pitch circle diameter: 230 mm X / Z axis travels: 62 / 85 mm Rapid traverse: 15 m/min Synchronous hollow spindle drives: Number: 6 Maximum speed: 10,000 rpm Nominal speed: 8,300 rpm Power: 15 kW at 18 Nm Chuck diameter: 110 mm Swiveling synchronous spindles: Number: 2 Z axis travel: 120 mm Feed force: 2.5 kN Rapid traverse: 15 m/min Swiveling angle: 132° Counter spindle: Maximum speed: 10,000 rpm Nominal speed: 8,000 rpm Power: 9.2 / 12 / 14 kW at 11 Nm Tool carriers: Maximum number: 11 Travels X / Y / Z: 62 / ±12 / 85 mm Hjlhceyl U Npedwxsfd CNC control: C 200-4D (Siemens Sinumerik 840D) Dimensions (approx.) L x W x H: 3.2 x 1.8 x 2.85 m Weight (approx.): 6.5 t Operating hours: 26,721 h Machine hours: 20,859 h Scope of delivery: INDEX bar loader Coolant unit with belt filter

Condition: good (used), functionality: fully functional, A lot of parts for Index K-16 machine collets, curves, tool holders, shafts, gears, slides, distance rings, end switches, etc. See attached photos. Hfolhcsx Ty Uuodwxed

Condition: good (used), Year of construction: 2006, Number of working spindles: 6 pieces Bar spindle diameter capacity: 32 mm Working spindle maximum speed: 6000 rpm Hslhcdwjrqzzpsxjfd Spindle chuck diameter: 40 mm Maximum number of tool carriers: 12 pieces Tool carrier travel distances: X = 72 mm, Z = 100 mm Part catcher receiver available in 6.1 position KNOLL chip conveyor In-machine air intake filtration system available (ventilation) Weight: 7,200 kg Magazine: IEMCA 3300 mm capacity bar feeder

Condition: used, Year of construction: 2003, INDEX MS32G Overhauled completely: 2020 Original mfd. 2003 6 Spindles 32mm Capacity Siemens 840D control Equipped as pictured Kraft & Bauer fire extinguishing system All spindles on the machine were overhauled 2 years ago incl. clamping cylinder except for one on the GSP. - GSP is equipped with Hainbuch Spanntop and used Röhm jaw chucks - No tools are included - No FZ tubes / no bar pusher Hjlhow A S H Uscdwxsfd - Last year, spindle encoders on the HSP incl. GSP were completely renewed. Equipped with Lenord & Bauer IEMCA SIR-MS32/33/P See attached specifications.

Condition: excellent (used), Year of construction: 2021, INDEX MS22-8 Mfd. 2021 (Commissioned 2022) Double NCU (2) Synchrons MBL Bar Feed 3.3 Meters Estimated Hours: 10,000 Holewt Unvehcdwxsfd Contact us for full specifications

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, INDEX MS40-6 CNC Multi-Spindle Year of Manufacture: 2011 Commissioned: 2012 Control: Siemens 840D (Dual NCU) Bar Capacity: 40 mm Slide Units Position 1.1: X / Z NC controlled Position 1.2: X / Z NC controlled Position 2.1: X / Z NC controlled Position 2.2: X / Z NC controlled Position 3.1: X / Y / Z NC controlled (Y ± 21 mm) Position 3.2: X / Z NC controlled Position 4.1: X / Z NC controlled Position 4.2: X / Z NC controlled Position 5.1: X / Z NC controlled Position 5.2: X / Z NC controlled Position 6.1: X / Z NC controlled Position 6.2: X / Z NC controlled Position 6.3: X NC controlled, Z fixed Holjxndgzshcdwxefd Bar Feed IEMCA SIR MS40/33/P magazine bar loader Workpiece Handling Parts chute at spindle position 6 Workpiece conveyor at spindle position 6 Synchronization unit at spindle position 6.1 Parts ejector Coolant feed preparation through counter spindle Back-Working Attachment at slide position 6.2 Up to 3 fixed toolholders Auxiliary Drive Preparation Electrical preparation for 2 auxiliary drives with electronic shaft (positions 1–3), synchronous with main and counter spindle Electrical preparation for 2 auxiliary drives with electronic shaft (positions 4–6), synchronous with main and counter spindle Compatible with auxiliary drives with incremental encoder (double module) Chip & Coolant System Hinge-belt chip conveyor (cross type), discharge height 1200 mm, front discharge with lift pump for filter unit Coolant filtration unit (50 Hz): Coolant tank: 800 L Vacuum rotation filter: 650 L capacity Plate heat exchanger for coolant cooling Heat exchanger pump: 80 L/min 7 bar Low-pressure pump: 300 L/min 4 bar High-pressure pump: 55 L/min 40 bar Safety & Environmental Automatic CO₂ fire extinguishing system with optical/thermal detection Preparation for central exhaust system Shut-off flap for central oil mist extraction Control Options & NC Functions 16/16 freely programmable I/O interface Transmit / Tracyl function (milling cylindrical paths on OD and face) Dual transmit function for Y-axis transformation NC option: counter spindle / polygon turning with electronic shaft Process Monitoring Integrated ARTIS monitoring system based on torque, current, or power evaluation Up to 4 channels (max. 8 drives) monitoring 4 tools simultaneously at stations 1–3 Up to 4 channels (max. 8 drives) monitoring 4 tools simultaneously at stations 4–6

Condition: excellent (used), Year of construction: 1991, functionality: fully functional, machine/vehicle number: 080005, • Turning diameter over slide: 1920 mm • Axis height: 1300 mm Hfelhcdjwab Rdewxjd • Center distance: 2000 to 30000 mm • Maximum workpiece weight: 10–40 tons • Bed width: 2119 mm • Spindle speed: 1–500 rpm • Gear ratios: 4 • Spindle end: A2-15 • Spindle motor: 30/37 kW (optionally up to 60/75 kW) • Spindle bore: 230 mm (can be extended up to 610 mm) • Turret type: servo, 4 or 10 positions • Tool cross-section: 50/40 mm • X-axis travel: 1200 mm • Z-axis travel: 2000 to 30000 mm • X-axis ball screw: 63 mm x P10 • Ball screw in Z axis: 63 mm x P10 (over 5 m: 80 mm x P10) • Tailstock quill diameter: 235 mm (possible up to 360 mm) • Tailstock quill extension: 250 mm (possible up to 300 mm) • Tailstock quill taper: MT #7 • Rapid traverse: 7 m/min

Condition: good (used), Year of construction: 2006, Year of manufacture: 1998 to 2006 Available from current location Hfslhsypltgocdwxed

Condition: used, Year of construction: 2015, Technical details: number of spindles: 6 spindle passage: 22 mm ?Bar feeder complete is 4.70 meters - for 3 meters of material Holhcdwexc Idmjxsfd ?The machine is still on ?Materail to be processed on the machine: Steel ?Production with OIL Machine has only Single-NCU without PCU. The complete energy supply of all 6 main spindles was replaced in April 25. *

Year of construction: 1992, condition: ready for operation (used), Number of spindles: 6, max. bar capacity: 42mm, max. machining diameter: 42mm, speed: 5000rpm, machining slides: 4, number of slides front/rear: 4/2. Machine dimensions X/Y/Z: approx. 7200mm/1700mm/2300mm, weight: approx. 10000kg. The machine has an electrical problem as a result of which the control does not start up. Documentation available. On site inspection is possible. Heljx Tum Sohcdwxsfd

Condition: used, Year of construction: 1998, number of spindles 6 spindle passage 27 mm turning length 59 mm hexagon material 24 mm Hfolhcovh Naqjdwxjd square material 18 mm cross slide travel 36 mm longitudinal slide travel 85 mm spindle turning speed range 366 - 5020 U/min max. torque 95 Nm control INDEX total power requirement 20 kW - 6 cross slides - 6 longitudinal slides - polygon device - thread cutting device - hydr. tapping device - workpiece removal belt - bar loading magazine PIETRO CUCCHI, model AN-BN Accessories: various tool holders, various collets, chip conveyor, coolant

Condition: excellent (used), Perfectly preserved six-spindle INDEX MS 25 automatic lathe with six transverse and six longitudinal tool guides. The price is negotiable depending on the selected additional equipment: clamping pods, tools, chip conveyor, etc. Hfelhsqhkukocdwxed The machine is still in production. Viewing possible by arrangement.

Condition: not inspected (used), functionality: unexamined, machine/vehicle number: 8208124, quill stroke: 100 mm, controller model: INDEX S3T B, spindle diameter: 103 mm, tailstock quill diameter: 100 mm, No reserve price – guaranteed sale to the highest bidder! Submitting a bid obligates timely collection between 08.04.26 and 16.04.26! TECHNICAL DETAILS Working spindle diameter: 103 mm Tailstock quill diameter: 100 mm Quill stroke: 100 mm Number of turret stations: 16 Turret head: EFG 250 MACHINE DETAILS Control: INDEX S3T B Operating voltage: 380 V Frequency: 50 Hz Control voltage: 220 V Rated current: 100 A Dimensions & weight L x W x H: 3500 x 2400 x 2600 mm Machine weight: 3 t Helhcsyk E Sxjdwxofd

Condition: excellent (used), Year of construction: 2019, operating hours: 13,000 h, functionality: fully functional, bar diameter (max.): 22 mm, INDEX MS22-8 Mfd. 2019 2 NCU 2 Syncrons 2 Y-Axis Control: Siemens Solution Line Knoll System Bar Feed: IEMCA SIR rack loader (12-ft) Hslhcox H H Nrodwxjfd 22,000 on-hours 10,000-15,000 Hours

Condition: excellent (used), Year of construction: 2000, INDEX ABC CNC Lathe. Mfd. 2000 Control: Siemens 840C Capacity 65mm Ran oil Still in production, running nylon With 12-ft Bar Feed (pictured) Chip Conveyor Comes the a good amount of tooling Control Type: Siemens SINUMERIK 840C Spindle Speed (max.): 6,000 RPM Power Requirements (V/Hz/PH): 400/60/3 Main Spindle Speed (max.): 6,000 RPM Bar Capacity: 65 mm Power: 20 kW (at 100%) Hfolhcdwsw Td U Rexjd Power: 27 kW (at 40%) Synchronous Spindle Speed (max.): 4,500 RPM Power (max.): 4.2 kW Capacity Tool Carrier 1: 8 (7 + synchronous spindle) Tool Carrier 2: 6 Dimensions Bar Feeder: L 150" x W 27" x H 52" Turning Center: L 80" x W 48" x H 65" Power Enclosure: L 52" x W 18" x H 70" Chip Conveyor: L 88" x W 48" x H 35"

Condition: used, spindle passage 25 mm turning speeds 5750 U/min Rest 4 straight turning atchm. - working travel . mm turret head 8 bar loader LNZ Hydrobar parts catcher The tech. Data are manufacturer or operator information and therefore non- Holhoyutvascdwxefd binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, spindle passage 60 mm cross-slide 4 turret head 6 Pos. The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop Hslhceyt R E Ajdwxefd If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: excellent (used), Year of construction: 2009, operating hours: 28,742 h, functionality: fully functional, bar passage: 65 mm, FANUC Series 31i-Model A 3 turrets Hfoljydmbuohcdwxod Parts conveyor Magazine Further details on request

Condition: used, TECHNICAL DETAILS - Number of axes : 10 - Number of spindles : 2 - Number of turrets : 3 MAIN SPINDLE - Spindle nose : A2-5 - Spindle power : 22/29 [kW] - Spindle speeds : 7.000 [rpm] - Max. bar diameter : 42 [mm] - Max. chuck diameter : 110 [mm] - C axis indexing precision : 0,001 [°] COUNTER-SPINDLE - Spindle nose : A2-5 - Spindle power : 16,5/19 [kW] - Spindle speeds : 7.000 [rpm] - Max. bar diameter : 42 [mm] * Max. chuck diameter : 110 [mm] - C axis indexing precision : 0,001 [°] - Travel : 500 [mm] - Rapid traverse rate : 60 [m/min] - Spindle / counter-spindle distance : 515 [mm] UPPER LEFT TURRET Hfjlhcoyfw I Usdwxed - Number of positions : 10 - Number of motorized positions : 10 - X/Z stroke : 70 / 250 [mm] - Y stroke : 70 [mm] - Tool type : VDI 25 - Live tools speed : 8.000 [rpm] - Live tools power : 4,2 [kW] UPPER RIGHT TURRET - Number of positions : 10 - Number of motorized positions : 10 - X stroke : 125 [mm] - Tool type : VDI 25 - Live tools speed : 8.000 [rpm] - Live tools power : 4,2 [kW] LOWER LEFT TURRET - Number of positions : 10 - Number of motorized positions : 10 - X/Z stroke : 70 / 400 [mm] - Y stroke : 70 [mm] - Tool type : VDI 25 - Live tools speed : 8.000 [rpm] - Live tools power : 4,2 [kW] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 37 [kW] WEIGHT & DIMENSIONS - Machine floor space : 5990 x 1710 [mm] - Machine height : 2140 [mm] - Machine weight : 5.500 [kg] MACHINE HOURS - Number of working hours : 16759 [h] EQUIPMENT - CNC : Fanuc Series 31i-B - 3 colors status lamp - Coolant tank * with high-pressure pump : 25 [bars] * with paper filtering unit - Coolant through spindle - Chips conveyor : DROITE - Cooling unit : KLH - Parts catcher - Parts conveying strip - Bar loader : IEMCA BOSS 552 HD/32L

Condition: ready for operation (used), Year of construction: 1998, operating hours: 39,445 h, controller manufacturer: SIEMENS, controller model: SINUMERIK 840C, number of axes: 12, This 12s Index MS42C was manufactured in 1998. It features a maximum bar diameter of 42 mm and operates with a fully automatic system, making it suitable for high-volume precision turned parts. The machine is equipped with a Siemens SINUMERIK 840C control system and AC servo drives, ensuring efficient performance. Consider the opportunity to buy this Index MS42C automation equipment. Contact us for further details. • Maximum bar diameter: 42 mm • Number of spindles: 6 • Spindle pitch circle diameter: approx. 320 mm • Maximum spindle speed: approx. 5,000 rpm • Number of CNC axes: 12 linear axes (6 × X, 6 × Z) • Axis configuration: X/Z per spindle station • Control: Siemens SINUMERIK 840C (INDEX OEM integration) • Drive system: AC servo drives with SERCOS interface • Automation level: Fully automatic • Operating mode: Continuous production (24/7 capable) • Cooling: Central coolant system • Lubrication: Central automatic lubrication • Electrical supply: 3-phase industrial power • Installed power: approx. 70–75 kW (configuration dependent) • Machine construction: Rigid cast iron base • Typical materials: Steel, stainless steel, aluminum, brass • Typical applications: High-volume precision turned parts Hfslhsyhf N Escdwxjd
