Edge banding machine

SCM OLIMPIC K500 T-ER2

Condition: good (used), Code: 0473 Brand: SCM Model: OLIMPIC K 500 T/ER-2 - Norme CE Automatic edge bander with grinding unit for wood, veneer, pvc, melamine, abs edges, for furniture, joinery, custom furnishings, panels, kitchens, bathroom furniture and various - CE Standard Features: Min/max panel height mm 8/60 Panel height with Round group mm 10/45 Edge thickness mm 0,4/8 Roll edge thickness mm 0,4/3 Min panel width mm 55 Feed speed mt/min 11 Presser with motorized vertical adjustment Panel support shoulder Soundproof protection booth Incoming liquids Composition: Lodpfsvkdtwox Ab Isrg Anti-adhesive unit consisting of two nozzles for spray application of the liquid - Two containers with anti-adhesive release liquid Grinding unit with 2 high-frequency motors - Diamond tools H64 MM - Diameter mm 100 F 30 h 65 - Copying kit for grinding unit Gluing unit VC 560 for edge application on panels up to 60 mm - Glue pot capacity kg 1,5 - Interchangeable pot End cutting unit - 2 independent motors each Kw 0,35 at 12000 rpm - Motor inclination from 0° to 15° - N° 2 blades diameter mm 115 - Front copiers Tilting Trimming Bevelling unit - to remove top and bottom excess edge - N° 2 motors Kw 0,55 - 12000 rpm - Inclination from 0° to 25° - Kit 2 pneumatic positions for quick change of processing from thin edges to radius edges Rounding unit with 2 motors sliding on prismatic guides - It performs both rounding and trimming of thin and thick edges - N° 2 motors each 0,55 Kw - 12000 rpm Edge Scraping unit for optimal finishing of Abs/Pvc edge complete with rotating copiers and suction hoods with chip collection box Glue Scraping unit - for removing glue residue from the bottom and top surfaces of panels Brush unit for perfect cleaning and polishing of the plastic material edge - Motor each Kw 0,25 - Brush diameter mm 150 Phon unit for Pvc/Abs edges Compressed air 7 bar Overall dimensions mm 5500 x 1150 x 1550 h Weight kg 1780

Condition: excellent (used), SINGLE SIDE EDGE BANDER (Left) Edges (band in rolls) thickness (Min/Max) mm 0,4 / 3 Edges thickness in strips / lippings (min/max) mm 0,4 / 8 (12)* Panels thickness (min/max) mm 8 / 60 Numerical Control "StarTouch" + "Touch 7" Lredpfx Asxlqntjb Iog Feeding speed m/min 12-18 Top pressure system with rubber belt (C.N.) Spraying unit (Anti-sticking liquid) AAR In-feed fence, adjustable by N.C. "EASY SIZE PLUS" Pre-milling Unit (vertical joint trimmers) 2 x Kw Lamps to heat the workpieces side Glueing Unit (P.U.R. Glue + Quick Melt system) "VC/800" - "VC/6" + "AirFusion AF15" Band Pressure zone (N.C. adjustment) Edge coils supporting unit - 1 Snipping (end-cutting) K/SEL Rough Trimming unit RS/K Fine Trimming unit RI / 800 (3 pos.) Multi Function Unit (Profile contour Trimming Unit) “4 EDGE” KIT Spraying Unit (for sliding liquid) Profile edge scraping unit RAS/1000 Glue scraper RCA / 2C Milling grooving unit K-100 (1 x Kw 1,8) 90° Hot Air Heater (to reactivate the color of plastic tape) Panels Return System "SAG" Mod. SPINNER 47 / 63

Condition: as good as new (ex-display), Year of construction: 2021, functionality: fully functional, overall weight: 915 kg, type of input current: three-phase, input voltage: 400 V, input current: 24 A, input frequency: 50 Hz, Worktable dimensions 3465x710mm, height 875mm Gluing thickness roller edges 0.4 - 3mm Glue-on thickness strip edges up to 5mm, min - max. workpiece thickness 8-50mm min. Workpiece length/width with roller edges 190/110mm min. Length of panel 120mm Lsdsuacqzspfx Ab Isrg Feed speed 9 m/min Feed motor 0.55 kW Working air pressure of pneumatics 6.5 bar Suction hood glue container 80mm 2 suction hoods Flush trimming unit 60mm 2 extraction hoods Pre-milling unit 80mm Working temperature 20-190C° Equipment: Pre-milling unit (jointing) Rounding unit (corner copying) Gluing unit, applying and pressing on the edge (self-lubricating glue pot) Trimming unit, for cutting off 90° of the protruding edge at the front and rear Flush trimming unit (joining) Scraper unit Buffing unit Surface scraper Automatic application of the strip edges with edge magazine Kit for quick change of the glue container Device for heating the panel edge Non-stick agent spraying unit Spraying unit for finishing the edge

Condition: used, Year of construction: 2020, total height: 2,500 mm, total length: 5,000 mm, total width: 2,400 mm, Empty weight: 2.500 kg CNC machining centre SCM Morbidelli N100 12 A Lrodpfx Abjwwa Hlo Iog Brand SCM Type Morbidelli N100 12 A Year of construction 2020 Serial number AM00002846 Machining table dimensions 2486x1255 mm (LxW) Groove pattern 40 mm distance Distance between holes vacuum cups 120 mm Equipped with 3 reference gauges Table has 1 vacuum field Table working range X axis 2486 mm Y axis 1255 mm Z-axis 150 mm Stroke of the units X axis 3120 mm Y axis 1685 mm Z axis 250 mm Movement of the axes  Maximum vectorial speed in rapid traverse XY axis 35 m/min Stroke of Z axis 250 mm Panel pass 150 mm Hiteco milling unit Motor power 5.5 kW (7.5 HP) Tool holder HSK-63-F Milling spindle speed 1500-24000 rpm Tool changer 8 positions Central exhaust connection 250 mm Control unit Windows EmbeddedStandard 7 64 bit  21.5 LCD touch screen XILOG-MAESTRO software package  Including vacuum pump Capacity 250 m3/h Power 5.5 kW Max. vacuum 0.9 bar Noise level 81 db (A) Total dimensions 5000x3000x2500 (LxWxH) Total weight 2500 KG - Year: 2020 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Serial number: AM00002846 - Transport dimensions: 5000mm x 2400mm x 2500mm (l x w x h) - Transport weight [kg]: 2500kg Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets

Condition: used, Year of construction: 2020, functionality: fully functional, workpiece height (max.): 45 mm, edge thickness (max.): 3 mm, type of input current: three-phase, Further technical data: Ball-bearing turntable for edge banding rolls, Ø 740 mm Edge thickness: 0.4 – 3 mm Workpiece height: 8 – 45 mm Extendable workpiece support up to 450 mm Manually adjustable workpiece height m-motion and x-motion PLUS control systems (highest setting repeat accuracy, programmable) Robust processing units in new design, solid machine base, precise extraction system Additional equipment: Surface scraper Spraying unit for cleaning agent LED lighting package Tempora 45.03 Spraying unit for release agent Ljdpfx Abexdb U Uj Ijrg Cross-cut saw unit with 45° travel path and radius processing Pneumatic-mechanical infeed lock 75 x-motion PLUS package Tempora 45.03

Condition: used, Year of construction: 2009, Used SCM edgebander model OLIMPIC K1000 Lodpfexrndxsx Ab Ierg Control panel with membrane keyboard Technical data: Min. panel height: 8 mm Max. panel height: 55 mm Min. edge thickness (roll): 0.4 mm Max. edge thickness (roll): 3 mm Max. edge thickness (solid wood): 12 mm Configuration: Strip edge magazine Glue pot capacity 1.5 kg, with independent motor No. 4 pressure rollers with pneumatic feed, first roller with independent motor Edge roll guillotine End trimming unit with 2 independent motors, tiltable 0-15° - each 0.35 KW - 12,000 rpm Overlapping trimming unit with 2 motors, each 0.65 KW - 12,000 rpm - tools with reversible knives Tiltable corner rounding unit for flat/radius finishing; 2 motors each 0.5 KW - 12,000 rpm, electro-pneumatic positioning - tools with reversible knives Electro-pneumatic exclusion of the unit Glue scraper unit Machine length: 4,310 mm Year of manufacture: 2009 CE marked

Condition: used, Lange B90 KFE Edge thickness: 0.4 - 3 / 5 mm Control panel: PLC touch panel Pre-milling unit for workpiece edge preparation before the gluing section Automatic edge magazine for roll materials Teflon-coated quick-change glue pot for hot-melt adhesive granulate Workpiece height: 8 - 50 mm Fine-adjustable glue roller Ledpfx Asxl Aw Teb Isrg Guillotine shears up to 3 mm for pre-cutting roll material Pressure unit End trimming unit Multi-function milling unit for flush trimming, radius milling, and bevel milling Corner copying unit for head edges up to 2 mm, activatable from the control panel Radius scraper blade Flat scraper blade Buffing unit Spraying device at infeed and outfeed Year of manufacture: 2018 Machine is OPERATIONAL and in GOOD CONDITION Ex works price NET €15,000.00

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 2650x640x1400 mm Weight 700 kg Total power requirement 5 kw Lodpfovz E T Hsx Ab Isrg

Condition: used, machine/vehicle number: 008228, Type of edging: Thin edge, Thick edge Gluing System: EVA Hotmelt Max feed speed: 8 m/min Lredpfjxfhvzex Ab Ieg Maximum panel thickness: 40 mm Operating Units: 4 nr
