Used Kaltenbach Cold Saw for sale (116)

Condition: used, Year of construction: 1980, machine/vehicle number: 55155, disk of circular saw-Ø: 400 mm cutting area at 90° round: 130 mm cutting area at 90° square: 200 x 80 bzw. 315 x 40 mm Hnsdpoct Nc Iofx Aaier cutting area in mitre at 45° square: flach/hochkant 180x70/100x60 mm cutting speed: 19/28 m/min engine: 380 V, 1,7/2,6 kW space needed: 1100 x 1050 x 1620 mm weight: 850 kg

Condition: good (used), Year of construction: 1984, machine/vehicle number: 102335, Offer 23172 Technical data: - Saw blade diameter up to 400 mm Hjdpormkl Ajfx Aaionr - Cutting range with saw blade diameter 400 mm - at 90° round 130 mm - square 120 mm - flat up to 260 x 60 mm - Mitre adjustment left + right 0 - 90 ° - Cutting speed 1750 / 3500 m/min - Feed speed of the saw blade 0 - 3 m/min - Rapid return 3000 mm/min - Saw drive 400 V / 3.7 / 4.4 kW - Pneum. Material vice with adjustable clamping pressure - Space requirement approx. W 1200 x H 1900 x D 1200 mm - Weight approx. 600 kg - Outfeed roller conveyor 3000 mm - Infeed roller conveyor 3000 mm

Condition: used, Year of construction: 2008, machine/vehicle number: 81266- V 80381, Lg.no. 24394 Hydr. rotary and tilting welding table - Four-axis welding manipulator Technical data: - max. load capacity 15000 kg - Face plate dimensions 2990 x 2990 mm - min. Table height in horizontal position approx. 1070 mm - Face plate can be rotated + swiveled or tilted - Faceplate can be moved horizontally + vertically, travel 1250 mm - Rotation electr. infinitely variable - Right + left rotation Hsdougtiuopfx Aaienr - Welding current transmission approx. 700 A - Drive 400 V - Connected load 33.0 kW - Manual remote control for speed regulation - E. foot switch - Space requirement approx. W 2990 x H 1070 x D 5500 mm - Weight approx. 12500 kg

Condition: used, Year of construction: 1981, machine/vehicle number: 55848, Lg. No. 24029 Technical Specifications: - Saw blade diameter up to 400 mm - Cutting range at 90°: round 130 mm - square 120 mm - rectangular 300 x 40 mm - or 240 x 85 mm - at 45°: round 130 mm Hnsdswk Icbepfx Aaior - square 110 mm - rectangular 245 x 40 mm - Miter adjustable left and right 0 - 90° each - 2 cutting speeds 13 + 26 m/min - Drive 400 V / 1.2 / 1.8 kW - Saw blade feed speed continuously adjustable hydraulically - Coolant system - Automatic material refill system - Space requirement approx. W 2400 x H 1850 x D 1100 mm - Weight approx. 1250 kg

Year of construction: 1986, condition: good (used), machine/vehicle number: 106157, Offer 21035 Technical data: - Saw blade diameter up to 400 mm - Cutting range with a saw blade diameter of 400 mm - at 90° round 130 mm - square 120 mm Hjdpfsg A Rgfex Aaienr - flat up to 260 x 60 mm - Miter adjustment left + right 0 - 90° - Cutting speed 1750 / 3500 m/min - Feed speed of the saw blade 0 - 3 m/min - Rapid return 3000 mm/min - Saw drive 400 V / 3.7 / 4.4 kW - 2 pneumatic material clamping devices with adjustable clamping pressure - Space requirement approx. W 1200 x H 1900 x D 1200 mm - Weight approx. 600 kg

Year of construction: 2002, condition: reconditioned (used), Beam cutting, drilling and marking line DISC SAW Brand: KALTENBACH Model: HDM 1431 / T13 / SP-CNC Year 2002 Serial number: 122.400 Weight without accessories: 10,980kh - Disc saw with downward cut. - Geared saw unit, drive system and saw blade on wear-resistant swivel bearing. - Heavy saw gear with pinions in oil bath, with inclined teeth, hardened and sharp. - Hydraulic advancement of the saw blade, adjustable according to the table, very fast recoil. - Hydraulic horizontal clamping device. Rear clamping jaw with long-stroke clamping cylinder and automatic recoil limitation. - Vertical clamping block with self-adjusting push plate. - Oblique cutting device to adjust the angle from 45° to the left to 35° to the right. - Material sensor to automatically switch from rapid advance to work advance. - Hydraulically elevating feed roller for optimum material transport on the saw table. - Economical lubrication by means of a micro-dosing installation, especially suitable for sawing profiles. - Chip collector installed on the machine bench. Specs: - Cutting disc housing: 100x4x30x250mm - Cutting disc diameter: 1,430mm - Cutting width: 9.5mm - Cutting speed: 10 to 20m/min. - Saw advance speed: 0-400mm/min. - Fast reverse speed: 2000mm/min. - Total power: 25KW - Working height: 640mm Cutting capacities: 90º cut - Angle steel: 250mm - Steel in U: 400mm - Double T-beam: 600mm - Wide flanged beam: 1008x302mm - Special wing beams: 1000x450mm Cut to degrees: IPBv beam - 75º: 1008x302mm - 60º: 910x302mm - 45º: 716x304mm - 40º: 716x304mm - 35º: 478X307mm IPBs beam - 75º: 1008x402mm - 45º: 524x357mm IPE beam - 45º: 600x220mm DRILLING UNIT Brand: Kaltenbach Model: KDX1215 Serial number: 122.401 Work capabilities: - Angular steel (minimum - maximum): 80x65x10mm - 250x250x28mm - Steel in U (minimum - maximum): 80x45mm - 400x110mm - Double T beam (minimum - maximum): 80x46mm - 600x220mm - Wide flanged beam (minimum - maximum): 100x100mm - 1,008x302mm - Extra wide wings beam: 1,200x500mm Drilling units: 3 - Vertical (Y axis) 1 pc. - Horizontal (Z and W axes) 2ud. Drilling diameters: 8 - 40mm RPM: 150 - 1100 Fast forward - Fast reverse: 3,850mm/min. - 8,000mm/min. Drilling spindle feed rate: 0-500mm/min. Fast spindle positioning tool: 15,000mm/min. Automatic tool changer: 5 u. in each drilling unit. 3x5 u. = 15 total Total power: 45KW MARKING UNIT FEEDING: 26 METERS OF ENTRY WITH BEAM FEEDER + 6 SIDE ARMS FOR BEAM ENTRY IN PARALLEL TO THE ROLLER TRACKS Hnedpfx Ajhzbipsaior 30 METERS OF ROLLER TRACKS WITH OUTPUT + 6 SIDE ARMS 4 SIDE ARM FOR SMALL PIECES THE GREAT MAJORITY OF ROLLERS ARE MOTORIZED It occupies approximately 60 linear meters between input and output power. *Request machine installation plans.

Condition: used, Max. saw blade diameter: 400 mm Pneumatic material clamp Manual feed Hjdpfx Aaoxn Nwleisnr

Year of construction: 1998, condition: used, Max. saw blade diameter: 350 mm Manual material tensioner Hnedpfx Aexvzdtsaisr

Condition: used, Cold circular saw for light metal Saw blade 350 mm ø Cold circular saw for steel, Spontan Saw blade 225 mm ø, pneumatic saw feed, length stop 1,500 mm Hjdpfx Ajyl Nt Noaijnr Cold circular saw for steel, Spontan Saw blade 225 mm ø, hydraulic feed 300 mm Control unit defective

Condition: good (used), Year of construction: 1987, functionality: fully functional, saw blade diameter: 375 mm, cutting range round steel at 90°: 135 mm, total length: 850 mm, total height: 1,800 mm, total width: 1,100 mm, overall weight: 680 kg, Semi automatic circular saw, blade Ø 375 mm, capacity Ø ca. 135 mm, motor 3,0 / 4,0 kw 2-speed 1420/2880 rpm, hydraulic vertical clamp, 1 horizontal clamp, stops 30°, 45°, 60° 90° double side, coolant device, measuring device 2 meters; dimension 85x110x180 cm, weight ca. 680 kgs Hnsdpfx Aox Dl Dmeaior

Condition: refurbished (used), functionality: fully functional, saw blade diameter: 400 mm, Semi-automatic Mitre Circular Saw KKS 400 E Hnsdpfeyq Sdzex Aaijr Completely overhauled to as-new condition – available from stock WORKING RANGE Round material: 130 mm Square material: 120 mm 2 cutting speeds Your advantage: - Machine directly overhauled by the manufacturer including 6-month parts warranty - All machines are completely dismantled and overhauled - Only original KALTENBACH spare parts are used

Condition: refurbished (used), Year of construction: 2024, Manufacturer Kaltenbach Type RKS 451 NA Overhaul year 2024 Saw blade VHM / HSS 450 mm Drive power saw motor 5,5 KW Speed infinitely variable 10 - 60 min-1 Cutting speed saw blade (450 mm) 15-75 m/min Saw height control infinitely variable fully electronic 5 Working area square 90° max.: 140 x 140 mm Working area flat 90° max.: 240 x 70 mm Working area round 90° max.: 150 mm Feed length 5-9999 mm Hnodpfsuiy Trex Aaier Feed speed AC servo max.: 500 mm/s Weight (saw)approx.: 2100 kg Dimensions LxWxH (saw)approx.: 2500mm x 1300mm x 2100mm Footprint LxW 2500mm x 1300mm Due to its equipment and design, the machine can be used very efficiently for a wide range of applications. The HMI interface for controlling the machine ensures simple and problem-free operation of the system. Due to the design of the sawing system, it is possible to realize a very precise length tolerance. The machine is generally overhauled in our company at the customer's request. Among other things, the following points will be renewed: - Conversion to Siemens S7 PLC control - Conversion to Siemens HMI operating panel - Replacement of the ball screw - Replacement of servo motor and servo inverter - Replacement of the frequency converter for the main saw drive - New electronic components - Maintenance or replacement of all hydraulic cylinders and valve terminals - Optimization and overhaul of the cooling system - Replacement of general wear parts - Overhaul of the machine body The machine also features - Fully automatic feed - Fully automatic height control - Frequency-controlled main saw motor - Hydraulic material clamping Warranty: Unless otherwise agreed, we provide a 6-month guarantee on all parts overhauled or replaced by us. Working time and wearing parts are excluded from the warranty. Optional: - Extra-long material feed device (2000mm) for efficient sawing of large cut-off lengths - Chain magazine for 6m of material - Removal gripper system for sorting the cut-off pieces - Delivery and installation on your premises - Training of your employees

Condition: refurbished (used), Year of construction: 2024, Overhaul year: 2024 Saw blade max. carbide 500/550 mm Drive power saw motor: 6 KW Saw motor speed in 6 stages: 2400- 3200 min-1 Saw blade cutting speed (500-550 mm): 3800 - 5500 m/min Saw blade feed steplessly adjustable 0-40 mm/s Saw height control infinitely adjustable fully electronic Working area square 90° max.: 160 x 160 mm Working area flat 90° max.: 380 x 60 mm Working area round: 90° max.:165 mm Feed length: 10-9999 mm Feed speed AC servo max. 400 mm/s Compressed air connection on site 6 bar Weight(saw)approx.:2850 kg Dimensions LxWxH(saw)approx.:2900mm x 1725mm x 2200mm Footprint LxW 2900mm x 1725mm The machine is in mint condition, both technically and visually, after a completed retrofit. Thanks to its equipment and design, the machine can be used very efficiently for a wide range of applications. The positioning system ensures simple and very profitable operation of the machine. Thanks to the powerful motor, short cycle times can be achieved even when sawing thick-walled profiles or solid materials. The soundproof cabin reduces noise emissions to a minimum. The machine is generally overhauled in our company at the customer's request. Among other things, the following points were renewed: - Conversion to Siemens S7 PLC control - Conversion to Siemens HMI operating panel - Replacement of the ball screw - Replacement of servo motor and servo inverter - Replacement of the frequency converter for the main saw drive (optional) - New electrical components - New pneumatic lines - Maintenance or replacement of all hydraulic cylinders and valve terminals - Overhaul of the extraction system - Overhaul of minimum lubrication system - Replacement of general wear parts - Overhaul of the soundproof cabin The machine also has - Soundproof cabin - Zero point adjustment (manual) Hnjdpfx Asuiy Rqsaijr Warranty: Unless otherwise agreed, we provide a 6-month warranty on all parts overhauled or replaced by us. Working time and wearing parts are excluded from the warranty. Optional: - Chain magazine for 4/6m materials - Splitting extension (for a high-quality cut surface without return marks) - Horizontal clamping saw line - Cut stop in material feed unit - Reinforced motor 11 KW - Roller conveyors - Delivery and installation on your premises - Training of your employees

Condition: like new (used), Year of construction: 2024, Saw blade solid carbide / HSS: max. 425 mm Drive power: - Two-stage with chain: 1.7/2.6 kW, - Two-stage with belt pulley: 3.7/4.5 kW Cutting speed saw blade (400 mm): - two-stage with chain: 10/20 m/min, 13/26 m/min, 15/30 m/min - two-stage with belt pulley: 20/40 m/min, 30/60 m/min Infinitely variable saw speed control fully electronic Working range square 90° max.:120 x 120 mm 45° max: Working range flat: 90° max.:230 x 80 mm 45° max: Working range round: 90° max.: 140 mm 45° max: Feed length single stroke: 5-1000 mm Multiple stroke: 5-9999 mm Feed speed AC servo max: 500 mm/s Weight(saw)approx.:3100 kg Dimensions LxWxH( saw)approx.:2500mm x 1300mm x 2100mm Footprint LxW: 2500mm x 1300mm Due to its equipment and design, the machine can be used very efficiently for a wide range of applications. The HMI interface for controlling the machine ensures simple and problem-free operation of the system. Due to the design of the sawing system, it is possible to realize a very precise length tolerance. The machine is generally overhauled in our company at the customer's request. Among other things, the following points will be renewed: - Conversion to Siemens S7 PLC control - Conversion to Siemens HMI operating panel - Replacement of the ball screw - Replacement of servo motor and servo inverter Hedpfxouiy R Rj Aaijnr - Replacement of the frequency converter for the main saw drive - New electronic components - Maintenance or replacement of all hydraulic cylinders and valve terminals - Optimization and overhaul of the cooling system - Replacement of general wear parts - Overhaul of the machine body The machine also features - Fully automatic feed - Fully automatic miter adjustment +/- 60° Warranty: Unless otherwise agreed, we guarantee our machines for 6 months on all parts overhauled or replaced by us. Working time and wearing parts are excluded from the guarantee. Optional: - Sink scraper - Extended feed unit 2000mm - Chain magazine for 6m of material - Removal gripper system for sorting the cut-off pieces - Removal gripper system for sorting the cut-off pieces and realizing a multiple recut at the end of the workpiece - Delivery and installation on your premises - Training of your employees

Condition: used, diameter of saw band: 350cutting area - round: 350cutting area rectangle: 350 x 350total power requirements: 2,2 Used cold circular saw Kaltenbach SKL 350 Cutting Capacity at 90°: Round: Up to 135 mm Square: Up to 120 mm Flat: Up to 70 x 280 mm Cutting Capacity at 45°: Square: Up to 105 mm Flat: Up to 55 x 210 mm Saw Blade Speeds: 2,250 and 4,500 rpm Motor Power: 5/6 hp (approx. 3.7/4.5 kW) Hnodpsv Ncpbjfx Aaior Weight: Approx. 650 kg Dimensions (L x W x H): Approx. 1,200 x 1,200 x 1,500 mm

Year of construction: 2000, condition: good (used), Weight: 4600 kg Dimensions LBH: 4350 x 1070 x 2690 mm Saw blade dimensions: 8250 x 54 x 1.6 mm Hedpjhkhumefx Aaisnr Fright basis: EXW with disassembling Price: on demand The 2000 Kaltenbach KBS 1001 DG band saw is a semi-automatic, high-performance band saw for cutting and drilling profiles. The Kaltenbach band saw has a two-metal saw blade M42 measuring 8250 mm x 54 mm x 1.6 mm. The motor of the saw is frequency controlled and has a driving power of 7.5 kW. The cutting speed is continuously adjustable between 16 - 100 m / min. -Working height is 450 mm, working width 1000mm. -drill diameter:10- 40 mm -material dimension max: 1000mmx450mm -material dimension min:65mmx65mm -3 drilling axes, one vertical and one horizontal -drill feed rate of 20-200mm/min -5 tool changer position per axis with an iso 40 tool holder The machine can transmit data in different ways: 1. The operator is programmed directly on the control panel. 2. The data is entered into the job preparation via computer and then imported as a CSV file. Data transfer takes place via a floppy disk or network. 3. Data are entered using CAD programs. DSTV data is imported via a floppy disk or network.
